Introduction to Kubernetes - FOSSMeet'21

Kubernetes builds upon 15 years of experience of running production workloads at Google, combined with best-of-breed ideas and practices from the community. It is an open-source system for automating deployment, scaling, and management of containerized applications. This talk will give an overview of kubernetes architecture and how to deploy the containerized application in the kubernetes cluster.

https://foss.coep.org.in/fossmeet/Fossmeet21/

Transcript

1. Introduction to Kubernetes Rahul Krishnan R A FOSSMeet’21
2. https://uk.linkedin.com/in/rahulkrishnanra @rahulkrishnanra About Me > Consultant @ Capgemini > Gopher > OpenEBS and Debian Contributor
3. What we cover? - What are containers? - Microservices in containers - Need of container Orchestrator - Stepping into Kubernetes - Kubernetes Architecture - K8s Pod, Deployment, service, Ingress - Demo
4. What are containers? versus Hypervisor Infrastructure Guest Os Guest Os App A App B App A App B App C App D Docker Host Operating System Infrastructure Virtual Machine The hardware is virtualized so multiple operating system can be isolated on the machine Containers Virtualized operating system - libraries and applications are isolated
5. Front End Account Services Payment Services Shipping Services User Front End Account Services Payment Services Shipping Services User Microservices in containers Microservices Application Monolithic Application
6. Need of container Orchestrator - Container orchestartion automated the deployment, management, Scaling, and networking of containers - Framework for managing containers and microservices architecture at scale
7. Stepping into Kubernetes - Open source container orchestartion tool - Orginally developed and designed by Google - Google donated the kubernetes project to CNCF - Builds upon 15 years of running production workloads at Google - Eliminates many of the manual process involved in deploying and Scaling containerized applications
8. Pod 1 Pod 2 Pod 3 Pod 1 Pod 2 Pod 3 Container Runtime Container Runtime kubelet kube-proxy kubelet kube-proxy API Server Scheduler Controller-Manager etcd Worker Node 1 Worker Node 2 CLI K8s Master Kubernetes Architecture UI container1 container2 container2 container2 container2 container2 container2 container1 container1 container1 container1 container2
9. POD in k8s - Smallest deployable units - Unit of replication in Kubernetes - Pod is a group of one or more containers - Pods are ephemeral - Primary primitive for running containerized workload - May contain one or more containers
10. Deployment Replica Set Replica Set Replica Set Pod Pod Pod Pod Pod Pod NODE NODE NODE K8s Deployment - Pods are usually managed by one more layer of abstraction - Declare how many replicas of a pod should be running at a time - Declare the desired state of the system
11. Service A app=A app=A app=A - Service routes traffic across a set of Pods - Discovery and routing among dependent Pods - Services match a set of Pods using Labels and Selectors - An abstraction which defines a logical set of Pods and a policy by which to access them Service in k8s
12. Cluster Ingress Service Service Pod Pod Pod Pod - Ingress exposes HTTP and HTTPS routes from Outside the cluster to services within the cluster - Ingress Controller is responsible for fulfilling the ingress Ingress
13. { Demo }
