Go Runtime Scheduler

Go Runtime Scheduler

A brief introduction of the basic concepts of Golang's runtime scheduler.

Brandon Gao

June 03, 2016
Tweet

Other Decks in Programming

Transcript

  1. Go scheduler before 1.2 1. Single global mutex (Sched.Lock) and

    centralized state. The mutex protects all goroutine-related operations (creation, completion, rescheduling, etc). 2. Goroutine (G) hand-o (G.nextg). Worker threads (M's) frequently hand-o runnable goroutines between each other, this may lead to increased latencies and additional overheads. Every M must be able to execute any runnable G, in particular the M that just created the G. 3. Per-M memory cache (M.mcache). Memory cache and other caches (stack alloc) are associated with all M's, while they need to be associated only with M's running Go code (an M blocked inside of syscall does not need mcache). A ratio between M's running Go code and all M's can be as high as 1:100. This leads to excessive resource consumption (each MCache can suck up up to 2M) and poor data locality. 4. Aggressive thread blocking/unblocking. In presence of syscalls worker threads are frequently blocked and unblocked. This adds a lot of overhead.
  2. Basic Concepts G -- Goroutine M -- OS thread P

    -- Processor (abstracted concept)
  3. Responsibility M must have an associated P to execute Go

    code, however it can be blocked or in a syscall w/o an associated P. Gs are in P's local queue or global queue G keeps current task status, provides stack
  4. GOMAXPROCS Number of P / / g o / s

    r c / r u n t i m e / p r o c . g o f u n c s c h e d i n i t ( ) { . . . p r o c s : = i n t ( n c p u ) i f n : = a t o i ( g o g e t e n v ( " G O M A X P R O C S " ) ) ; n > 0 { i f n > _ M a x G o m a x p r o c s { n = _ M a x G o m a x p r o c s } p r o c s = n } i f p r o c r e s i z e ( i n t 3 2 ( p r o c s ) ) ! = n i l { t h r o w ( " u n k n o w n r u n n a b l e g o r o u t i n e d u r i n g b o o t s t r a p " ) } . . .
  5. Don't call GOMAXPROCS in runtime (when possible) f u n

    c G O M A X P R O C S ( n i n t ) i n t { i f n > _ M a x G o m a x p r o c s { n = _ M a x G o m a x p r o c s } l o c k ( & s c h e d . l o c k ) r e t : = i n t ( g o m a x p r o c s ) u n l o c k ( & s c h e d . l o c k ) i f n < = 0 | | n = = r e t { r e t u r n r e t } s t o p T h e W o r l d ( " G O M A X P R O C S " ) / / n e w p r o c s w i l l b e p r o c e s s e d b y s t a r t T h e W o r l d n e w p r o c s = i n t 3 2 ( n ) s t a r t T h e W o r l d ( ) r e t u r n r e t }
  6. G -- goroutine Created in user-space Initial 2 KB stack

    space created by f u n c n e w p r o c ( s i z i n t 3 2 , f n * f u n c v a l ) { . . .
  7. goroutine numbers Why Go allows us to create goroutines so

    easily f u n c n e w p r o c 1 ( f n * f u n c v a l , a r g p * u i n t 8 , n a r g i n t 3 2 , n r e t i n t 3 2 , c a l l e r p c u i n t p t r ) * g { _ g _ : = g e t g ( ) / / G E T c u r r e n t G . . . _ p _ : = _ g _ . m . p . p t r ( ) / / G E T i d l e G f r o m c u r r e n t P ' s q u e u e n e w g : = g f g e t ( _ p _ ) i f n e w g = = n i l { n e w g = m a l g ( _ S t a c k M i n ) c a s g s t a t u s ( n e w g , _ G i d l e , _ G d e a d ) a l l g a d d ( n e w g ) / / p u b l i s h e s w i t h a g - > s t a t u s o f G d e a d s o G C s c a n n e r d o e s n ' t l o o k a t u n i n i t i a l i z } Goroutines will be reused
  8. M -- thread Initialization / / g o / s

    r c / r u n t i m e / p r o c . g o / / S e t m a x M n u m b e r t o 1 0 0 0 0 s c h e d . m a x m c o u n t = 1 0 0 0 0 . . . / / I n i t i a l i z e s t a c k s p a c e s t a c k i n i t ( ) . . . / / I n i t i a l i z e c u r r e n t M m c o m m o n i n i t ( _ g _ . m )
  9. P -- processor Max value (?) 1 < < 8

    P will try to put newly created G into its local queue rst, if local queue is full, P will put the new G to global queue (lock)
  10. Work ow + - - - - - - -

    - - - - - - - - - - - - - s y s m o n - - - - - - - - - - - - - - - / / - - - - + | | | | + - - - + + - - - + - - - - - - - + + - - - - - - - - + + - - - + - - - + g o f u n c ( ) - - - > | G | - - - > | P | l o c a l | < = = = b a l a n c e = = = > | g l o b a l | < - - / / - - - | P | M | + - - - + + - - - + - - - - - - - + + - - - - - - - - + + - - - + - - - + | | | | + - - - + | | + - - - - > | M | < - - - f i n d r u n n a b l e - - - + - - - s t e a l < - - / / - - + + - - - + | | + - - - e x e c u t e < - - - - - s c h e d u l e | | | | + - - > G . f n - - > g o e x i t - - + 1 . g o c r e a t e s a n e w g o r o u t i n e 2 . n e w l y c r e a t e d g o r o u t i n e b e i n g p u t i n t o l o c a l o r g l o b a l q u e u e 3 . A M i s b e i n g w a k e n o r c r e a t e d t o e x e c u t e g o r o u t i n e 4 . S c h e d u l e l o o p 5 . T r y i t s b e s t t o g e t a g o r o u t i n e t o e x e c u t e 6 . C l e a r , r e e n t e r s c h e d u l e l o o p
  11. Work sharing Whenever a processor generates new threads, the scheduler

    attempts to migrate some of them to other processors. in hopes of distributing the work to underutilized processors
  12. Compare Intuitively, the migration of threads occurs less frequently with

    work stealing than sharing When all processors have work to do, no threads are migrated by a work-stealing scheduler Threads are always migrated by a work-sharing scheudler
  13. Busy-Leaves Algorithm 0. There is gloabl ready thread pool. 1.

    At the beginning of each step, each processor either is idle or has a thread to work on 2. Those processors that are idle begin the step by attempting to remove any ready thread from the pool. - 2.1 If there are su ciently many ready threads in the pool to satisfy all of the idle processors, then every idle processor gets a ready thread to work on - 2.2 Otherwise, some processors remain idle. 3. Then each processor that has a thread to work on executes the next instruction from that thread until the thread either spawns, stalls or dies.
  14. Randomized work-stealing algorithm 0. The centralized thread pool of Busy-Leaves

    Algorithm is distributed across the processors. 1. Each processor maintains a ready deque data structure of threads. 2. A processor obtains work by removing the thread at the bottom of its ready deque. 3. The Work-Stealing Algorithm begines work stealing when ready deques empty. - 3.1 The processor becomes a thief and attempts to steal work from a victim processor chosen uniformly at random. - 3.2 The thief queries the ready deque of the victim, and if it is nonempty, the thief removes and begins work on the top thread. - 3.3 If the victim's ready deque is empty, however, the thief tries again, picking another victim at random.
  15. Reminder -- Go Runtime Entities M must have an associated

    P to execute Go code, however it can be blocked or in a syscall w/o an associated P. Gs are in P's local queue or global queue G keeps current task status, provides stack Implements both Busy-Leaves & Randomized Work-Stealing
  16. goroutine queues t y p e p s t r

    u c t { / / A v a i l a b l e G ' s ( s t a t u s = = G d e a d ) g f r e e * g g f r e e c n t i n t 3 2 } t y p e s c h e d t s t r u c t { / / G l o b a l c a c h e o f d e a d G ' s . g f l o c k m u t e x g f r e e * g n g f r e e i n t 3 2 }
  17. steal goroutine from global queue / / G e t

    f r o m g f r e e l i s t . / / I f l o c a l l i s t i s e m p t y , g r a b a b a t c h f r o m g l o b a l l i s t . f u n c g f g e t ( _ p _ * p ) * g { r e t r y : g p : = _ p _ . g f r e e i f g p = = n i l & & s c h e d . g f r e e ! = n i l { l o c k ( & s c h e d . g f l o c k ) f o r _ p _ . g f r e e c n t < 3 2 & & s c h e d . g f r e e ! = n i l { _ p _ . g f r e e c n t + + g p = s c h e d . g f r e e s c h e d . g f r e e = g p . s c h e d l i n k . p t r ( ) s c h e d . n g f r e e - - g p . s c h e d l i n k . s e t ( _ p _ . g f r e e ) _ p _ . g f r e e = g p } u n l o c k ( & s c h e d . g f l o c k ) g o t o r e t r y }
  18. steal goroutine from other places / / F i n

    d s a r u n n a b l e g o r o u t i n e t o e x e c u t e . / / T r i e s t o s t e a l f r o m o t h e r P ' s , g e t g f r o m g l o b a l q u e u e , p o l l n e t w o r k . f u n c f i n d r u n n a b l e ( ) ( g p * g , i n h e r i t T i m e b o o l ) { . . . / / r a n d o m s t e a l f r o m o t h e r P ' s f o r i : = 0 ; i < i n t ( 4 * g o m a x p r o c s ) ; i + + { i f s c h e d . g c w a i t i n g ! = 0 { g o t o t o p } _ p _ : = a l l p [ f a s t r a n d 1 ( ) % u i n t 3 2 ( g o m a x p r o c s ) ] v a r g p * g i f _ p _ = = _ g _ . m . p . p t r ( ) { g p , _ = r u n q g e t ( _ p _ ) } e l s e { s t e a l R u n N e x t G : = i > 2 * i n t ( g o m a x p r o c s ) / / f i r s t l o o k f o r r e a d y q u e u e s w i t h m o r e t h a n 1 g g p = r u n q s t e a l ( _ g _ . m . p . p t r ( ) , _ p _ , s t e a l R u n N e x t G ) } i f g p ! = n i l { r e t u r n g p , f a l s e } } . . .
  19. Multi Threading Go programs are naturally multithreading programs All the

    pros and cons of multithreading programs apply
  20. NUMA Aware Go Scheduler Global resources (MHeap, global RunQ and

    pool of M's) are partitioned between NUMA nodes; netpoll and timers become distributed per-P.
  21. References Scalable Go Scheduler Design Doc (https://docs.google.com/document/d/1TTj4T2JO42uD5ID9e89oa0sLKhJYD0Y_kqxDv3I3XMw/edit#) Go Preemptive Scheduler

    Design Doc (https://docs.google.com/document/d/1ETuA2IOmnaQ4j81AtTGT40Y4_Jr6_IDASEKg0t0dBR8/edit) Scheduling Multithreaded Computations by Work Stealing (http://supertech.csail.mit.edu/papers/steal.pdf) What every programmer should know about memory (https://www.akkadia.org/drepper/cpumemory.pdf)
