Database Implementation in Microservices

Today, 91%(of Global Companies) are using or have plans to use microservices.
Microservices motivates 82%(of agility) & 78%(of scalability) in digital business impact.
There are many people say that microservices is too hard to be implemented especially related to the database. Is that true? Let the code answer it because The Code never Lies ! You or I? Sometimes, We could Lie.

Transcript

1. Show Me the Code : Database Implementation in Microservices Architecture
2. Contact Rony Setyawan Software Architect Technical Lead Developer rony.setyawan@telkom.co.id ronysetyawan.io medium.com/@rony.setyawan.st
3. Description Today, 91%(of Global Companies) are using or have plans to use microservices. Microservices motivates 82%(of agility) & 78%(of scalability). There are many people say that microservices is too hard to be implemented especially related to the database. Is that true? Let the code answer it because The Code never Lies! You or I ? Sometimes, we could lie.
4. Bibliography Newman, Sam. (2015). Building Microservices. O’Reilly Media. Bas, Len., Clements, Paul., Kazman, Rick. (2013). Software Architecture in Practice. Pearson Education, Inc. Martin, Robert C. (2009). Clean Code : A Handbook of Agile Software Craftsmanship.Pearson Education, Inc. LightStep. (2018). New Research Reveals Record Growth in Microservices Is Disrupting the Operational Landscape. globenewswire.com/news-release/2018/05/02/1494613/0/en/New-Research-Reveals-Record-G rowth-in-Microservices-Is-Disrupting-the-Operational-Landscape.html
5. What is Microservice?
6. What is Microservice ? User experience Physical Computing architectural style that structures an application as a collection of services that are : • Small as Services • Focused on Doing One Thing Well • Autonomous • Support Technology Heterogeneity • Independently Deployable • Loosely Coupled • Decentralized
7. Why Microservice?
8. Monolithic Architecture - Microservices User experience Physical Computing
9. Bringing It All Together ! User experience Physical Computing
10. What is Database ?
11. What is Database ? User experience Physical Computing • Organized collection of data • Electronically from a computer system • Using formal design and modeling techniques • Easy to be Accessed, Managed, Updated, Deleted
13. Want More Detail ? User experience Physical Computing
14. Here We Go!!! Focus, Focus, Focus
15. How the Real World Works User experience Physical Computing
16. Database - 1 CREATE DATABASE BLANJACOM; CREATE TABLE `Customers` ( `id` int PRIMARY KEY AUTO_INCREMENT, `name` varchar(255), `phone_number` varchar(255), `email` varchar(255), `balance` int, `wallet` ENUM ('linkaja', 'tmoney', 'ovo') ); CREATE TABLE `Orders` ( `id` int PRIMARY KEY AUTO_INCREMENT, `customer_id` int, `status` ENUM ('pending', 'refund', 'approved', 'completed'), `created_at` datetime DEFAULT (now()), `updated_at` datetime DEFAULT (now()) ); ALTER TABLE `Orders` ADD FOREIGN KEY (`customer_id`) REFERENCES `Customers` (`id`);
17. Database - 2 INSERT INTO `Customers` (`id` ,`name`,`phone_number`,`email`,`balance`,`wallet`) VALUES (1, "Hepta Yuniarita", "08123456789", "hepta.yuniarita@telkom.co.id", 500000, "linkaja"); INSERT INTO `Customers` (`id` ,`name`,`phone_number`,`email`,`balance`,`wallet`) VALUES (2, "Komang Budi Aryasa", "08198765432", "komang.aryasa@telkom.co.id", 1000000, "linkaja"); INSERT INTO `Customers` (`id` ,`name`,`phone_number`,`email`,`balance`,`wallet`) VALUES (3, "Andri Qiantori", "08123459876", "andri.qiantori@gmail.com", 100000, "ovo"); INSERT INTO `Orders` (`id` ,`customer_id`,`status`) VALUES (1, 1, "pending"); INSERT INTO `Orders` (`id` ,`customer_id`,`status`) VALUES (2, 2, "completed"); INSERT INTO `Orders` (`id` ,`customer_id`,`status`) VALUES (3, 3, "pending");
18. Database - 3 var es = require('eventstore')({ type: 'mongodb', host: 'localhost', port: 27017, dbName: 'eventstore', eventsCollectionName: 'events', snapshotsCollectionName: 'snapshots', transactionsCollectionName: 'transactions', timeout: 10000 maxSnapshotsCount: 3 authSource: 'authedicationDatabase', username: 'blanjacom', password: 'secret' url: 'mongodb://user:pass@host:port/db?opts positionsCollectionName: 'positions' }); es.useEventPublisher(function(evt) { // bus.emit('event', evt); });
19. Database - 4 es.getFromSnapshot({ aggregateId: 'myAggregateId', aggregate: 'person', // optional context: 'hr' // optional }, function(err, snapshot, stream) { var snap = snapshot.data; var history = stream.events; // events history from given snapshot // myAggregate.loadSnapshot(snap); // myAggregate.loadFromHistory(history); }); es.useEventPublisher(function(evt, callback) { bus.sendAndWaitForAck('event', evt, callback); }); es.defineEventMappings({ id: 'id', commitId: 'commitId', commitSequence: 'commitSequence', commitStamp: 'commitStamp', streamRevision: 'streamRevision' });
20. Database - 5 es.getEventStream('streamId', function(err, stream) { stream.addEvent({ my: 'event' }); stream.addEvents([{ my: 'event2' }]); stream.commit(); stream.commit(function(err, stream) { console.log(stream.eventsToDispatch); // this is an array containing all added events in this commit. }); }); es.store.getLastEvent({ aggregateId: txs[0].aggregateId, aggregate: txs[0].aggregate, // optional context: txs[0].context // optional }, function (err, lastEvent) { if(err) { console.log('ohhh :-('); return; } es.store.repairFailedTransaction(lastEvent, function (err) { if(err) { console.log('ohhh :-('); return; } console.log('event proceed'); }); }); });
21. Shared Database BLANJA ORDER API BLANJA ORDER mSERVICE BLANJA CUSTOMER API BLANJA CUSTOMER mSERVICE BLANJA SINGLE LARGE DATABASE BLANJA LEGACY SYSTEM BLANJA LEGACY API
22. Database Per Service User experience Physical Computin g BLANJA ORDER API BLANJA ORDER microSERVICE User experience BLANJA CUSTOME R API BLANJA CUSTOMER microSERVICE BLANJA ORDER DATABASE BLANJA CUSTOMER DATABASE
23. SAGA - Choreography User experience Physical Computing BLANJA ORDER API BLANJA ORDER mSERVICE User experience BLANJA CUSTOMER API BLANJA CUSTOMER mSERVICE BLANJA ORDER DATABASE BLANJA CUSTOMER DATABASE Order Channel Customer Channel Publish order event Subscribe order event Publish customer event Subscribe customer event
24. CQRS User experience Physical Computin g BLANJA ORDER API BLANJA ORDER mSERVICE User experience BLANJA CUSTOMER API BLANJA CUSTOMER mSERVICE BLANJA ORDER DATABASE BLANJA CUSTOMER VIEW DATABASE Order Channel Customer Channel BLANJA ORDER VIEW DATABASE BLANJA CUSTOMER DATABASE Publish order event Subscribe customer event Subscribe order event Publish customer event
25. EVENT SOURCING User experienc e Physica l Computi ng BLANJA ORDER API BLANJA ORDER microSERVICE User experienc e BLANJA CUSTOMER API BLANJA CUSTOMER microSERVICE BLANJA ORDER VIEW DATABASE BLANJA CUSTOMER VIEW DATABASE Order Channel Customer Channel BLANJA ORDER SNAPSHOT DATABASE BLANJA CUSTOMER DATABASE BLANJA ORDER EVENT DATABASE BLANJA ORDER DATABASE BLANJA CUSTOMER SNAPSHOT DATABASE BLANJA CUSTOMER EVENT DATABASE Publish order event Subscribe order event Publish customer event Subscribe customer event
