New groove with docker and orchestration

1 / 105 © 2017 <[email protected]>, @PRossbach, Agile Meetup 03/2017
M��nster Walk-through Docker Orchestration

M��nster The Purpose, Organisation, Technology Transition concept Peter Rossbach - bee42 solutions gmbh @PRossbach [email protected]

M��nster From monolith to µService

M��nster <=> <=> Werner Vogels CTO Amazon 2006, You build it, you run it http://queue.acm.org/detail.cfm?id=1142065

M��nster Build, Ship and Run Any App, Anywhere

M��nster

M��nster Package your software Isolating your application dependencies Creating your application golden image and ship it Creating ready to start applications that are easily distributable Allowing easy and fast scaling of instances of you application Testing out applications and disposing them afterwards Roll forward you service faster

M��nster Separation of concerns Developers focus on creating a system, instead only applications System administrators focus on deployment and delivery Better resource utilization More apps on one host Faster development, testing, integration and delivery Portability Build in one environment, distributed and run on many others Scalability Easy to spin up new containers Fast migrate to more powerful features

M��nster Microservice means developing a single, small, meaningful functional feature as single service. Each service has its own process and communicates with lightweight mechanism, deployed in single or multiple servers. Each service manages its own data exclusively. Microservice Architecture – A Quick Guide

M��nster Split the monolith into smaller pieces Scale app horizontally and vertically Increase developer productivity Increase developer velocity Adpat newer technologies faster Swapout older technologies Faster delivery and value

M��nster The Art of Scalability

M��nster Redundancy Routing Error detection Failover Detect growing latencies Auto scaling up and down Control resource usage Control your dependencies Versioning Isolation Auto delivery

M��nster Netflix OSS MICHAEL NYGARD - Release IT Chaos Monkey

M��nster I. Codebase One codebase tracked in revision control, many deploys II. Dependencies Explicitly declare and isolate dependencies III. Config Store config in the environment IV. Backing Services Treat backing services as attached resources V. Build, release, run Strictly separate build and run stages VI. Processes Execute the app as one or more stateless processes

M��nster VII. Port binding Export services via port binding VIII. Concurrency Scale out via the process model IX. Disposability Maximize robustness with fast startup and graceful shutdown X. Dev/prod parity Keep development, staging, and production as similar as possible XI. Logs Treat logs as event streams XII. Admin processes Run admin/management tasks as one-off processes The Twelve Factors

M��nster From source to production Build and use CI/CD Pipelines Use Jenkins, Gitlab/CI or CI cloud services Docker Hub Travis CI Codeship Circle Ci

M��nster

M��nster Docker machines New docker engine (>1.12) based on docker swarmkit :-) https://github.com/docker/swarmkit https://speakerdeck.com/rossbachp/docker-swarmkit

M��nster Core OS Rancher OS Boot2Docker Project Atomic VMware Photon OS™ Moby OS (Docker for Mac - alpine) Hypriot OS (ARM, AARCH64)

M��nster

M��nster Desired State Reconciliation Service Types Replicated Services Global Services Configurable Updates Parallelism Delay Restart Policies Default Security

M��nster

M��nster Resource Awareness Constraints IDs names labels (e.g. node.labels.foo!=bar1) Strategies spread strategy least loaded nodes respect the constraints respect the resource requirements

M��nster State Store replicated (Raft based) extremely fast (in-memory reads) save snapshots Topology Management managers workers Node Management pause/unpause drain/activate auto failure detection

M��nster Mutual TLS create CA or use a user CA manage certs to all nodes Acceptance Policy auto accept manually accept require a secret to join the cluster Certificate Rotation rotated and reloaded transparently on every node default is 3 months, the minimum is 30 minutes

M��nster Create new machines with digitalocean|scaleway|xyhve Setup network (overlay) Manage a swarm on it :) use Docker > 1.13.x

M��nster http://play-with-docker.com/

M��nster https://github.com/bee42/docker-machine-scaleway-creator https://github.com/bee42/docker-machine-digitalocean-creator

M��nster

M��nster $ CONTROL_API_VERSION="$(docker version --format '{{.Server.APIVersion}}')" $ tar -C $DOCKER_CERT_PATH -cf- ca.pem cert.pem key.pem | docker run --name dockercontrol -i \ -v /docker busybox \ sh -c "tar -C /docker -xf- echo export DOCKER_API_VERSION=$CONTROL_API_VERSION echo export DOCKER_TLS_VERIFY=1 >>/docker/env echo export DOCKER_CERT_PATH=/docker >>/docker/env" echo export DOCKER_HOST=$DOCKER_HOST >>/docker/env $ docker run --rm \ --volumes-from dockercontrol docker \ sh -c "source /docker/env; docker ps" $ sudo curl -L https://raw.githubusercontent.com/jpetazzo/dctrl/master/dctrl \ >/usr/local/bin/dctrl $ sudo chmod +x /usr/local/bin/dctrl http://jpetazzo.github.io/2016/04/03/one-container-to-rule-them-all/ https://github.com/jpetazzo/dctrl

M��nster Use a whoami service Service Options Docker service update uuid rolling update Visualizer of docker swarming Monitor docker and services with Prometheus ELK Stack Simple DIND Swarming Loadbalancing with Traefik Docker Meetup Bochum 1.12:)

M��nster https://github.com/emilevauge/whoamI $ docker run -d -P --name iamfoo emilevauge/whoami $ docker inspect --format '{{ .NetworkSettings.Ports }}' iamfoo map[80/tcp:[{0.0.0.0 32769}]] $ curl "http://0.0.0.0:32769" Hostname : 6e0030e67d6a IP : 127.0.0.1 IP : ::1 IP : 172.17.0.27 IP : fe80::42:acff:fe11:1b GET / HTTP/1.1 Host: 0.0.0.0:32769 User-Agent: curl/7.35.0 Accept: */*

M��nster $ REGION=asm2 $ SIZE=1gb $ DOT=<token> $ docker-machine create \ --driver digitalocean \ --digitalocean-region $REGION \ --digitalocean-size $SIZE\ --digitalocean-access-token $DOT \ --digitalocean-private-networking \ --engine-label "cluster=moby2017" \ --engine-label "role=master" \ --engine-label "region=$REGION" \ swarm-master $ docker $(docker-machine config swarm-master) swarm init \ --advertise-addr $(docker-machine ip swarm-master):2377 $ SWARM_TOKEN=`docker $(docker-machine config swarm-master) \ swarm join-token worker -q`

M��nster $ docker-machine ssh <SWARM-MACHINE> $ SWARM_TOKEN=`docker $(docker-machine config swarm-master) \ swarm join-token worker -q` $ docker $(docker-machine config $MACHINE) swarm join \ --token $SWARM_TOKEN \ $(docker-machine ip swarm-master):2377 Second terminal $ docker-machine ssh swarm-master $ docker node ls

M��nster $ docker service create --name whoami emilevauge/whoami $ docker service update --replicas 2 whoami $ docker service inspect whoami [ { "ID": "ch1cizq1k61qigbswzdd0sryj", "Version": { "Index": 717 }, "CreatedAt": "2016-06-19T11:01:39.630354919Z", "UpdatedAt": "2016-06-19T11:02:20.137102719Z", "Spec": { "Name": "whoami", ... ] $ docker service inspect whoami |jq "{ name: .[].Spec.Name , replicas: .[].Spec.Mode.Replica { "name": "whoami", "replicas": 2 }

M��nster Usage: docker service create [OPTIONS] IMAGE [COMMAND] [ARG...] Create a new service Options: --constraint list Placement constraints (default []) --container-label list Container labels (default []) --dns list Set custom DNS servers (default []) --dns-option list Set DNS options (default []) --dns-search list Set custom DNS search domains (default []) --endpoint-mode string Endpoint mode (vip or dnsrr) -e, --env list Set environment variables (default []) --env-file list Read in a file of environment variables (default []) --group list Set one or more supplementary user groups for the container (default []) --health-cmd string Command to run to check health --health-interval duration Time between running the check (ns|us|ms|s|m|h) (default none) --health-retries int Consecutive failures needed to report unhealthy --health-timeout duration Maximum time to allow one check to run (ns|us|ms|s|m|h) (default none) --help Print usage --host list Set one or more custom host-to-IP mappings (host:ip) (default []) --hostname string Container hostname -l, --label list Service labels (default []) --limit-cpu decimal Limit CPUs (default 0.000) --limit-memory bytes Limit Memory (default 0 B) --log-driver string Logging driver for service --log-opt list Logging driver options (default []) --mode string Service mode (replicated or global) (default "replicated") --mount mount Attach a filesystem mount to the service ...

M��nster ... --name string Service name --network list Network attachments (default []) --no-healthcheck Disable any container-specified HEALTHCHECK --port port Publish a port --replicas uint Number of tasks (default none) --reserve-cpu decimal Reserve CPUs (default 0.000) --reserve-memory bytes Reserve Memory (default 0 B) --restart-condition string Restart when condition is met (none, on-failure, or any) --restart-delay duration Delay between restart attempts (ns|us|ms|s|m|h) (default --restart-max-attempts uint Maximum number of restarts before giving up (default none) --restart-window duration Window used to evaluate the restart policy (ns|us|ms|s|m|h) --secret secret Specify secrets to expose to the service --stop-grace-period duration Time to wait before force killing a container (ns|us|ms|s|m|h) -t, --tty Allocate a pseudo-TTY --update-delay duration Delay between updates (ns|us|ms|s|m|h) (default 0s) --update-failure-action string Action on update failure (pause|continue) (default "pause") --update-max-failure-ratio float Failure rate to tolerate during an update --update-monitor duration Duration after each task update to monitor for failure (ns|us| --update-parallelism uint Maximum number of tasks updated simultaneously (0 to update -u, --user string Username or UID (format: <name|uid>[:<group|gid>]) --with-registry-auth Send registry authentication details to swarm agents -w, --workdir string Working directory inside the container

M��nster $ eval $(docker-machine env swarm_master) $ docker service create --name cadvisor --mode global \ --mount type=bind,source=/,target=/rootfs/,writable=false \ --mount type=bind,source=/var/run/,target=/var/run/ \ --mount type=bind,source=/sys/,target=/sys/,writable=false \ --mount type=bind,source=/var/lib/docker/,target=/var/lib/docker/,writable= --publish 8080:8080 \ google/cadvisor:latest Add a new node, and service is started...

M��nster $ docker node update --label-add foo worker1 $ docker node update --label-add foo --label-add bar worker1 Usage: docker node update [OPTIONS] NODE Update a node Options: --availability string Availability of the node (active/pause/drain) --help Print usage --label-add value Add or update a node label (key=value) (defaul --label-rm value Remove a node label if exists (default []) --role string Role of the node (worker/manager)

M��nster node attribute matches example node.id node ID node.id == 2ivku8v2gvtg4 node.hostname node hostname node.hostname != node-2 node.role node role: manager node.role == manager node.labels user defined node labels node.labels.security == high engine.labels Docker Engine’s labels engine.labels.operatingsystem == ubuntu 14.04

M��nster $ docker service create \ --name redis_2 \ --constraint 'node.labels.type == queue' \ redis:3.0.6

M��nster $ docker service update \ --constraint-add 'node.labels.storage == ssd' \ redis_2 option description --constraint-add value Add or update placement constraints (default []) --constraint-rm value Remove a constraint (default []) --container- label-add value Add or update container labels (default []) --container- label-rm value Remove a container label by its key (default [])

M��nster $ docker service create \ --name redis_2 \ --label com.example.foo="bar" --label bar=baz \ redis:3.0.6

M��nster id label name $ docker service ls -f "id=0bcjw" $ docker service ls --filter label=project $ docker service ls --filter label=project=project-a $ docker service ls --filter name=redis

M��nster Mount Named Volume Mount Anonymous Volume Bind Mount Volume

M��nster $ docker service create \ --name my-service \ --replicas 3 \ --mount type=volume,source=my-volume,destination=/path/in/container,volume nginx:alpine

M��nster $ docker service create \ --name my-service \ --replicas 3 \ --mount type=volume,destination=/path/in/container \ nginx:alpine

M��nster $ docker service create \ --name my-service \ --mount type=bind,source=/path/on/host,destination=/path/in/container \ nginx:alpine

M��nster https://github.com/bee42/docker-on-rpi-lab

M��nster UUID swarming # login to swarm manager $ docker build --build-arg UUID_VERSION=0.0.1 \ -t bee42/rpi-uuid:0.0.1 -f Dockerfile.uuid . $ docker tag bee42/rpi-uuid:0.0.1 queenshive:5000/bee42/rpi-uuid:0.0.1 $ docker push queenshive:5000/bee42/rpi-uuid:0.0.1 $ docker service create --name uuid queenshive:5000/bee42/rpi-uuid:0.0.1 $ docker service update --publish-add 9080:8080 uuid $ docker service update --replicas 2 uuid UUID next version $ docker build --build-arg UUID_VERSION=0.0.2 \ -t bee42/rpi-uuid:0.0.2 -f Dockerfile.uuid . $ docker tag bee42/rpi-uuid:0.0.2 queenshive:5000/bee42/rpi-uuid:0.0.2 $ docker push queenshive:5000/bee42/rpi-uuid:0.0.2 $ docker service update \ --replicas 4 \ --update-delay 10s \ --image queenshive:5000/bee42/rpi-uuid:0.0.2 uuid

M��nster $ curl 192.168.5.1:9080/uuid/index.jsp { "Container": "9e1daabe3fb2", "UUID": "37a971b7-1467-47de-90e2-20cd2d9de4df", "Date": "2016/10/25 14:30:25", "Timestamp": "1477405825", "Version": "0.0.2" }

M��nster $ docker run -it -d -p 5000:5000 \ -e HOST=192.168.5.1 \ -e PORT=5000 \ -v /var/run/docker.sock:/var/run/docker.sock \ queenshive:5000/bee42/swarm-visualizer https://github.com/ManoMarks/docker-swarm-visualizer

M��nster

M��nster $ docker service create --name node --mode global --network prom \ --mount type=bind,source=/proc,target=/host/proc \ --mount type=bind,source=/sys,target=/host/sys \ --mount type=bind,source=/,target=/rootfs \ prom/node-exporter \ -collector.procfs /host/proc \ -collector.sysfs /host/proc \ -collector.filesystem.ignored-mount-points "^/(sys|proc|dev|host|etc)($|/) $ docker service create --name cadvisor --network prom --mode global \ --mount type=bind,source=/,target=/rootfs \ --mount type=bind,source=/var/run,target=/var/run \ --mount type=bind,source=/sys,target=/sys \ --mount type=bind,source=/var/lib/docker,target=/var/lib/docker \ google/cadvisor:latest

M��nster $ cat >prometheus.conf <<EOFglobal: scrape_interval: 1s scrape_configs: - job_name: 'prometheus' static_configs: - targets: ['localhost:9090'] - job_name: 'node' dns_sd_configs: - names: ['tasks.node'] type: 'A' port: 9100 - job_name: 'cadvisor' dns_sd_configs: - names: ['tasks.cadvisor'] type: 'A' port: 8080 EOF $ cat >Dockerfile <<EOF FROM prom/prometheus COPY prometheus.yml /etc/prometheus/prometheus.yml EOF $ docker build -t localhost:5000/prometheus . $ docker push localhost:5000/prometheus $ docker service create --network prom --name prom \ --publish 9090:9090 localhost:5000/prometheus

M��nster $ docker network create --driver overlay logging $ docker service create --network logging \ --name elasticsearch elasticsearch:2.4 $ docker service create --network logging \ --name kibana --publish 5601:5601 \ -e ELASTICSEARCH_URL=http://elasticsearch:9200 kibana:4.6

M��nster $ cat >logstash.conf <<EOF input { # Listens on 514/udp and 514/tcp by default; change that to non-privileged port syslog { port => 51415 } # Default port is 12201/udp gelf { } heartbeat { } } filter { ruby { code => " event.to_hash.keys.each { |k| event[ k.gsub('.','_') ] = event.remove(k) if k.include?'.' } " } } output { elasticsearch { hosts => ["elasticsearch:9200"] } stdout { codec => rubydebug } } EOF

M��nster $ docker service create --network logging \ --name logstash -p 12201:12201/udp \ logstash:2.4 -e "$(cat ./logstash.conf)" $ docker service ps logstash $ CID=$(docker ps -q --filter label=com.docker.swarm.service.name=logstash) $ docker logs --follow $CID $ docker run --log-driver gelf \ --log-opt gelf-address=udp://127.0.0.1:12201 \ --rm alpine echo hello $ open http://$(docker-machine ip worker1):5601/ $ for SERVICE in app1 app2 ; do docker service update $SERVICE \ --log-driver gelf --log-opt gelf-address=udp://127.0.0.1:12201 done

M��nster Auto update to next software release A/B Testing Canary Deployment Multi-Network Handling Control the liveness with Healthcheck Swarming with prometheus - no scraper at this moment! Create a Visualizer for complex setups Volume Management and Docker Plugin's Check the API DAB Format and docker-compose

M��nster

M��nster $ docker swarm init $ SWARM_TOKEN=$(docker swarm join-token -q worker) $ SWARM_MASTER=$(docker info | grep -w 'Node Address' | awk '{print $3}') $ NUM_WORKERS=3 $ for WORKER_NUMBER in $(seq ${NUM_WORKERS}); do docker run -d --privileged --name worker-${WORKER_NUMBER} \ --hostname=worker-${WORKER_NUMBER} \ -p ${WORKER_NUMBER}2375:2375 docker:1.13.0-rc2-dind docker --host=localhost:${WORKER_NUMBER}2375 swarm join \ --token ${SWARM_TOKEN} \ ${SWARM_MASTER}:2377 done $ docker run -it -d -p 5080:8080 --name visualizer \ -v /var/run/docker.sock:/var/run/docker.sock \ manomarks/visualizer https://medium.com/@alexeiled/docker-swarm-cluster-with-docker-in- docker-on-macos-bdbb97d6bb07#.yry5s0jiv http://blog.terranillius.com/post/swarm_dind/ https://github.com/ManoMarks/docker-swarm-visualizer

M��nster https://traefik.io/ https://github.com/bee42/traefik-with-docker

M��nster

M��nster traefik: image: traefik command: --web --docker --docker.domain=docker.localhost --logLevel=DEBUG ports: - "80:80" - "8080:8080" volumes: - /var/run/docker.sock:/var/run/docker.sock - /dev/null:/traefik.toml whoami: image: emilevauge/whoami labels: - "traefik.backend=whoami" - "traefik.frontend.rule=Host:whoami.docker.localhost"

M��nster $ docker-machine ssh swarm-master \ "docker network create --driver=overlay traefik-net" $ docker-machine ssh swarm-master "docker service create \ --name traefik \ --constraint=node.role==manager \ --publish 80:80 \ --publish 8080:8080 \ --mount type=bind,source=/var/run/docker.sock,target=/var/run/docker.sock \ --network traefik-net \ traefik:v1.2.0-rc2 \ --docker \ --docker.swarmmode \ --docker.exposedbydefault=false \ --docker.domain=traefik \ --docker.watch \ --web" https://github.com/containous/traefik/blob/master/docs/user- guide/swarm-mode.md

M��nster $ docker-machine ssh swarm-master "docker service create \ --name whoami0 \ --label traefik.port=80 \ --label traefik.enable=true \ --label traefik.backend.loadbalancer=drr \ --network traefik-net \ emilevauge/whoami" $ docker-machine ssh swarm-master "docker service create \ --name whoami1 \ --label traefik.port=80 \ --label traefik.enable=true \ --label traefik.backend.loadbalancer=drr \ --network traefik-net \ emilevauge/whoami" $ curl -H Host:whoami0.traefik http://$(docker-machine ip manager) $ docker-machine ssh swarm-master "docker service update replicas=6 whoami0" $ watch curl -H Host:whoami0.traefik http://$(docker-machine ip manager)

M��nster

M��nster Use old docker swarm Use consul, etcd with registrator New docker swarm 1.12 is available >1.1.0! https://hub.docker.com/r/library/traefik/

M��nster Kubernetes Google App Engine Open Shift Deis Mesos (DC/OS) AWS ECS Rancher OS

M��nster

M��nster declarative management toolkit for orchestrating infrastructure describe infrastructur encapsulation and composition active control monitor infrastucture status detect state divergence take action continuous monitoring and reconciliation rolling update https://github.com/docker/infrakit http://de.slideshare.net/chanezon/whats-new-in-docker- infrakit-docker-meetup-berlin-2016

M��nster

M��nster rule description ONE PURPOSE The container has only one purpose LABELING Add many metadata to your container WORKING The container is up and running FIX DEPENDENCIES The container has controlled dependencies MINIMAL The container has only minimal content, nothing more WHITEBOX The container source must be available SECURE The container must be periodically updated LIMITED The container can only consume limited resources

M��nster TRUST The creator of the containers is trustworthy and the content can be validated rule description

M��nster Nice concept and easy to use Simple and powerful orchestration solution Play around with fun ToDo: Better support of storage handling Serverless and Job scheduling support More options to service create (security and resource handling) Integration of Infrakit Check your networking skills!

M��nster

M��nster reduce you coupling add metrics design for failure setup machines and network automatically handling your persistence states on classic infrastructure your developer need a prod like environment safe your persistence data

M��nster

M��nster Start this presentation with docker run -d -ti -p 4221:80 bee42/docker- orchestration-swarming open http://<dockerhost>:4221/docker- orchestration-swarming Peter Rossbach follow the us at bee42.com @PRossbach More Training: https://bee42.com/#scroll-top-trainings

M��nster 16.3 Docker Meetup Bochum - Docker Birthday Party Zalando 23-25.3 DevOpsGathering Konferenz - Bochum https://devops-gathering.io

M��nster 9-11.5 Docker DevOps Camp - Berlin 27-29.6 Docker DevOps Camp - Berlin https://bee42.com/#scroll-top-trainings

M��nster We offer TOP-IT jobs... https://bee42.com

M��nster Living an Agile culture Influence us to DevOps-Journey Enable people to use modern technologies Build applications that living at the clouds Design services with clever API's Think infrastructure first send your offering to [email protected]

M��nster Create beautiful human responsive services Find new ways to create creative web service Find good solutions with HTML/CSS/Javascript to create simple services Think mobile first send your offering to [email protected]

M��nster We offer jobs... Administrator Experiences with Maintain a cluster of linux machines Setup Docker infrastructure Config management with ansible Release java applications Linux and mysql skills Developer Experiences with Create java based microservices Spring Boot and Netflix Stack Docker knowledge send your offering to [email protected]

M��nster http://www.dpunkt.de/docker

M��nster

M��nster This slides shows shell commands executed in different places. The line prefix shows where to run them: $ ... – local machine > ... – remote machine # ... – docker container

M��nster https://bee42.com https://devops-gathering.io http://www.infrabricks.de https://github.com/bee42/traefik-with-docker https://github.com/bee42/docker-on-rpi-lab https://www.docker.com https://github.com/docker/docker https://github.com/docker/machine https://github.com/docker/swarm https://github.com/docker/compose https://github.com/docker/swarmkit https://github.com/docker/infrakit
