ActiveStorage

Talks about the new library coming to Rails 5.2

Links:

-
http://edgeguides.rubyonrails.org/active_storage_overview.html

- http://edgeguides.rubyonrails.org/active_storage_overview.html#has-many-attached

- http://edgeguides.rubyonrails.org/active_storage_overview.html#previewing-files

-
http://edgeguides.rubyonrails.org/active_storage_overview.html#direct-uploads

-
http://edgeguides.rubyonrails.org/active_storage_overview.html#direct-uploads

- https://rubygems.org/gems/annotate
-
http://imagemagick.org/script/index.php

- https://www.imagemagick.org/script/command-line-options.php

Transcript

1. ActiveStorage
   Radoslav Stankov 13/03/2018


   View Slide

2. Radoslav Stankov
   @rstankov

   http://rstankov.com

   http://github.com/rstankov


   View Slide

3. View Slide

4.

   http://react-not-a-conf.com

   28th April


   View Slide

5. View Slide

6.

   http://edgeguides.rubyonrails.org/active_storage_overview.html



   View Slide

7. # == Schema Information
   #
   # Table name: speakers
   #
   # id :integer not null, primary
   # name :string(255) not null
   # bio :text
   # created_at :datetime
   # updated_at :datetime
   #
   class Speaker < ApplicationRecord
   validates :name, presence: true
   end


   View Slide

8. # == Schema Information
   #
   # Table name: speakers
   #
   # id :integer not null, primary
   # name :string(255) not null
   # bio :text
   # created_at :datetime
   # updated_at :datetime
   #
   class Speaker < ApplicationRecord
   validates :name, presence: true
   end


   View Slide

9. # == Schema Information
   #
   # Table name: speakers
   #
   # id :integer not null, primary
   # name :string(255) not null
   # bio :text
   # created_at :datetime
   # updated_at :datetime
   #
   class Speaker < ApplicationRecord
   validates :name, presence: true
   end
   !


   View Slide

10. # == Schema Information
    #
    # Table name: speakers
    #
    # id :integer not null, primary
    # name :string(255) not null
    # bio :text
    # created_at :datetime
    # updated_at :datetime
    #
    class Speaker < ApplicationRecord
    validates :name, presence: true
    end
    https://rubygems.org/gems/annotate


    View Slide

11. # == Schema Information
    #
    # Table name: speakers
    #
    # id :integer not null, primary
    # name :string(255) not null
    # bio :text
    # created_at :datetime
    # updated_at :datetime
    #
    class Speaker < ApplicationRecord
    validates :name, presence: true
    end


    View Slide

12. # == Schema Information
    #
    # Table name: speakers
    #
    # id :integer not null, primary
    # name :string(255) not null
    # bio :text
    # created_at :datetime
    # updated_at :datetime
    #
    class Speaker < ApplicationRecord
    validates :name, presence: true
    has_one_attached :photo
    end


    View Slide

13. speaker.photo.attach(params[:photo])


    View Slide

14. speaker.photo.nil?

    speaker.photo.present?
    speaker.photo.attached?


    View Slide

15. speaker.photo.purge
    speaker.photo.purge_later


    View Slide

16. View Slide

17. # == Schema Information
    #
    # Table name: speakers
    #
    # id :integer not null, primary
    # name :string(255) not null
    # bio :text
    # created_at :datetime
    # updated_at :datetime
    #
    class Speaker < ApplicationRecord
    validates :name, presence: true
    has_one_attached :photo
    end


    View Slide

18. run rails active_storage:install
    run rails db:migrate


    View Slide

19. create_table 'active_storage_attachments' do |t|
    t.string 'name', null: false
    t.string 'record_type', null: false
    t.bigint 'record_id', null: false
    t.bigint 'blob_id', null: false
    t.datetime 'created_at', null: false
    end
    create_table 'active_storage_blobs' do |t|
    t.string 'key', null: false
    t.string 'filename', null: false
    t.string 'content_type'
    t.text 'metadata'
    t.bigint 'byte_size', null: false
    t.string 'checksum', null: false
    t.datetime 'created_at', null: false
    end


    View Slide

20. speaker.photo.metadata
    {
    'identified' => true,
    'width' => 80,
    'height' => 80,
    'analyzed' => true
    }


    View Slide

21. speaker.photo.url
    #=> NoMethodError: undefined method `url'
    for #


    View Slide

22. speaker.photo.service_url


    View Slide

23. image_tag speaker.photo
    url_for speaker.photo
    link_to 'download', speaker.photo


    View Slide

24. <% Speaker.all do |speaker| %>
    <%= image_tag speaker.photo %>
    <% end %>


    View Slide

25. ArgumentError in Admin::Speakers#index
    Showing /Users/rstankov/Projects/ConferenceBox/app/views/admin/speakers/index.html.slim where
    line #18 raised:


    View Slide

26. ArgumentError in Admin::Speakers#index
    Showing /Users/rstankov/Projects/ConferenceBox/app/views/admin/speakers/index.html.slim where
    line #18 raised:
    "


    View Slide

27. <% Speaker.all do |speaker| %>
    <%= image_tag speaker.photo if speaker.photo.attached? %>
    <% end %>


    View Slide

28. ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.8ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 35], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.4ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 30], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.6ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 40], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Blob Load (1.3ms) SELECT "active_storage_blobs".* FROM "active_storage_blobs" WHERE "active_storage_blobs"."id" = $1 LIMIT $2 [["id",
    16], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.0ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 23], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.1ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 18], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (2.0ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 49], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (2.0ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 7], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.1ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 21], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.1ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 11], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.1ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 10], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.4ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 50], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.0ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 52], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.2ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 17], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]
    ↳ app/views/admin/speakers/index.html.slim:17
    ActiveStorage::Attachment Load (1.8ms) SELECT "active_storage_attachments".* FROM "active_storage_attachments" WHERE
    "active_storage_attachments"."record_id" = $1 AND "active_storage_attachments"."record_type" = $2 AND "active_storage_attachments"."name" = $3 LIMIT $4
    [["record_id", 38], ["record_type", "Speaker"], ["name", "photo"], ["LIMIT", 1]]


    View Slide

29. View Slide

30. <% Speaker.with_attached_photo.all do |speaker| %>
    <%= image_tag speaker.photo if speaker.photo.attached? %>
    <% end %>


    View Slide

31. View Slide

32. View Slide

33. View Slide

34. image_tag image.variant(resize: '100x100')


    View Slide

35. ActiveStorage
    BlobsController
    ActiveStorage
    DiskController


    View Slide

36. ActiveStorage
    BlobsController
    AWS


    View Slide

37. image_tag image.variant(resize: '100x100')


    View Slide

38. image_tag image.variant(resize: '100x100').service_url


    View Slide

39. View Slide

40. speaker.photo.variant(resize:'100x100').processed.service_url


    View Slide

41. View Slide

42.

    http://imagemagick.org/script/index.php



    View Slide

43.

    https://www.imagemagick.org/script/command-line-options.php



    View Slide

44. def speaker_photo(speaker, size:)
    speaker.photo.variant(
    resize: "#{size}x#{size}^",
    gravity: 'center',
    crop: "#{size}x#{size}+0+0"
    )
    end


    View Slide

45. module HasVariants
    def has_one_attached_with_variants(attribute_name, variants = {})
    has_one_attached attribute_name
    define_method "#{attribute_name}_variant" do |variant_name|
    attachment = public_send(attribute_name)
    return unless attachment.attached?
    variant_options = variants.fetch(variant_name) do
    raise "UnknownVariant '#{variant_name}', not in #{variants.keys.join})"
    end
    attachment.variant(*variant_options)
    end
    end
    end
    #


    View Slide

46. class Speaker < ApplicationRecord
    extend HasVariants
    has_one_attached_with_variants :photo, {
    small: { resize: '100x100' },
    medium: { resize: '200x200' }
    # ...
    }
    end
    speaker.photo_vartiant(:small)
    #


    View Slide

47. View Slide

48. View Slide

49. $ Disk Service
    % AWS Service
    & Azure Service
    ' Google Cloud Service
    ( Mirror Service
    Services


    View Slide

50. <%= form.file_field :photos, multiple: true %>


    http://edgeguides.rubyonrails.org/active_storage_overview.html#has-many-attached



    View Slide

51. image_tag talk.video.preview(resize: '100x100')
    image_tag talk.slides.preview(resize: '100x100')


    http://edgeguides.rubyonrails.org/active_storage_overview.html#previewing-files



    View Slide

52.

    http://edgeguides.rubyonrails.org/active_storage_overview.html#direct-uploads

    Form Rails AWS
    <%= form.file_field :photos %>


    View Slide

53.

    http://edgeguides.rubyonrails.org/active_storage_overview.html#direct-uploads

    Form AWS
    <%= form.file_field :photos, direct_upload: true %>


    View Slide

54. View Slide

55. View Slide

56. Thanks )


    View Slide

57. https://speakerdeck.com/rstankov/activestorage


    View Slide
