Web Accessibility

Web Accessibility

Debunking the myth, an overview of what it is and how tos

Răzvan Roșu

October 17, 2018
Tweet

More Decks by Răzvan Roșu

Other Decks in Technology

Transcript

  1. What is Web Accessibility? Myth Accessibility is often viewed as

    making your site work on screen readers. What Accessibility really is Accessibility is a subset of UX focused on making your websites usable by the widest range of people possible, including those who have disabilities.
  2. Why should we care about Accessibility? The main reason is

    the concept’s definition itself: we want our application to be usable by as many people as possible. We should also care due to good ethics and laws and regulations.
  3. Statistics: Persons with disabilities in Europe are a significant group:

    • 10% to 15% of the total population • 50 to 75 million people in EU27* • There is a strong correlation between disability and ageing (numbers increase with demographic change) Source: Labour Force Survey (European Commission-Eurostat 2002) http://ec.europa.eu/ipg/standards/accessibility/index_en.htm *EU27 - European Union during 2007 - 2013 when it had 27 countries - European Union after 2016 without UK due to Brexit
  4. Disabilities to account for: 1. Blindness and vision impairment 2.

    Deaf and hard of hearing 3. Physical disabilities 4. Cognitive disabilities
  5. 1. Blindness and Vision impairment A person is legally blind

    if: - his/her visual acuity is less than 20/200 At the distance of 20 feet (~6m), a person doesn’t see a text, which can be seen at 200 feet (~60m) by a person with perfect eyesight. - his/her view angle is less than 20 degrees https://www.allaboutvision.com/lowvision/legally-blind.htm
  6. 1. Blindness and Vision impairment Color blindness is a deficiency

    in distinguishing colors. The ideal contrast ratio between two colors is of 4.5:1 https://webaim.org/resources/contrastchecker/ Chrome extension for live color blindness simulation: https://chrome.google.com/webstore/detail/i-want-to-see-like-the-co/jebeedfnielkcjlcokhiobodkjjpbjia Side by side color blind comparison tool: https://www.toptal.com/designers/colorfilter
  7. 1. Blindness and Vision impairment Accessibility solutions and tools: •

    Braille • Screen readers • Screen magnifiers • Scaling the UI (entirely) • Font size increase (only) • High contrast Themes Humanware Braillant BI 40 Freedom Scientific JAWS
  8. Disabilities to account for: 1. Blindness and vision impairment 2.

    Deaf and hard of hearing 3. Physical disabilities 4. Cognitive disabilities
  9. 2. Deaf and hard of hearing People with a hearing

    disability rely heavily on visual information. We should provide audio and video content with a description and subtitles (closed captions). Do not autoplay media content. An interview with a Deaf academic librarian on web experience: https://developer.paciellogroup.com/blog/2017/02/sounding-out-the-web-accessibility-for-deaf-and-hard-of-hearing-people-part-1/ https://developer.paciellogroup.com/blog/2017/03/sounding-out-the-web-accessibility-for-deaf-and-hard-of-hearing-people-part-2/
  10. Disabilities to account for: 1. Blindness and vision impairment 2.

    Deaf and hard of hearing 3. Physical disabilities 4. Cognitive disabilities
  11. 3. Physical disabilities For physical disabilities, we need to take

    into account users that don’t navigate web pages with the traditional mouse (along a keyboard). Ensuring the possibility to navigate by keyboard exclusively should be good enough for the time being, but have in mind other means such as Eye Controlling. https://www.tobii.com/tech/ https://arstechnica.com/gadgets/2017/08/windows-adding-eye-control-to-boost-accessibility/
  12. Disabilities to account for: 1. Blindness and vision impairment 2.

    Deaf and hard of hearing 3. Physical disabilities 4. Cognitive disabilities
  13. 4. Cognitive disabilities Examples: - Autism - Attention deficit disorder

    (ADD) - Anxiety disorder - Dyslexia: difficulty in reading - Dyscalculia: difficulty in understanding number-related concepts - etc
  14. 4. Cognitive disabilities In regards to dyslexia, sans-serif fonts are

    recommended and fonts that have an unique shape for each letter. e.g.: Arial, Comic Sans*, Verdana, Century Gothic A font created with dyslexia in mind: https://www.dyslexiefont.com/en/typeface/ *Comic Sans is a great font choice for countering dyslexia
  15. 4. Cognitive disabilities Not all disabilities can be overcome purely

    from the UI. We need to understand the difficulties our users are facing and only then, together with the UX, we can probably do something about it. Dark Patterns: tricks used in websites and apps that make you buy or sign up for things you didn’t mean to. Darkpatterns.org About users with social disorders using the web: https://developer.paciellogroup.com/blog/2018/08/a-web-of-anxiety-accessibility-for-people-with-anxiety-and-panic-disorders-part-1/
  16. Disabilities to account for: 1. Blindness and vision impairment 2.

    Deaf and hard of hearing 3. Physical disabilities 4. Cognitive disabilities
  17. Laws and Regulations Starting with January 2010, all new EUROPA

    websites must be compliant with the Web Content Accessibility Guidelines 2.0, level AA. http://ec.europa.eu/ipg/standards/accessibility/index_en.htm In 2017, WCAG 2.0 AA compliance has been imposed in the U.S. as well. https://siteimprove.com/en-us/blog/no-more-excuses-there-is-now-a-us-deadline-for-beco ming-accessible/ WCAG 2.0 standard: https://www.w3.org/TR/WCAG20/
  18. Laws and Regulations Here’s a glimpse of WCAG 2.0 AA

    rules: • Links Links must have a context. The text within the link must be discernible. • Media Captions are provided for all live audio content in synchronized media. • etc
  19. Tools and Technologies for Accessibility 1. Semantic markup 2. WAI-ARIA

    3. Accessibility DOM Tree 4. Screen Readers 5. The A11Y project
  20. Semantic Markup Each HTML tag has been created with a

    purpose. Developers have enough flexibility to use every tag as any tag, filling the behavior with CSS and JS. By using the markup as intended, it gives the document meaning (or semantics).
  21. HTML 4 tags <a> <abbr> <acronym> <address> <applet> <area> <b>

    <base> <basefont> <bdo> <big> <blockquote> <body> <br> <button> <caption> <center> <cite> <code> <col> <colgroup> <dd> <del> <dfn> <dir> <div> <dl> <dt> <em> <fieldset> <font> <form> <frame> <frameset> <h1> <h2> <h3> <h4> <h5> <h6> <head> <hr> <html> <i> <iframe> <img> <input> <ins> <isindex> <kbd> <label> <legend> <li> <link> <map> <menu> <meta> <noframes> <noscript> <object> <ol> <optgroup> <option> <p> <param> <pre> <q> <s> <samp> <script> <select> <small> <span> <strike> <strong> <style> <sub> <sup> <table> <tbody> <td> <textarea> <tfoot> <th> <thead> <title> <tr> <tt> <u> <ul> <var>
  22. HTML 4 tags without obsolete tags <a> <abbr> <acronym> <address>

    <applet> <area> <b> <base> <basefont> <bdo> <big> <blockquote> <body> <br> <button> <caption> <center> <cite> <code> <col> <colgroup> <dd> <del> <dfn> <dir> <div> <dl> <dt> <em> <fieldset> <font> <form> <frame> <frameset> <h1> <h2> <h3> <h4> <h5> <h6> <head> <hr> <html> <i> <iframe> <img> <input> <ins> <isindex> <kbd> <label> <legend> <li> <link> <map> <menu> <meta> <noframes> <noscript> <object> <ol> <optgroup> <option> <p> <param> <pre> <q> <s> <samp> <script> <select> <small> <span> <strike> <strong> <style> <sub> <sup> <table> <tbody> <td> <textarea> <tfoot> <th> <thead> <title> <tr> <tt> <u> <ul> <var>
  23. HTML 4 tags without obsolete and meta tags <a> <abbr>

    <acronym> <address> <applet> <area> <b> <base> <basefont> <bdo> <big> <blockquote> <body> <br> <button> <caption> <center> <cite> <code> <col> <colgroup> <dd> <del> <dfn> <dir> <div> <dl> <dt> <em> <fieldset> <font> <form> <frame> <frameset> <h1> <h2> <h3> <h4> <h5> <h6> <head> <hr> <html> <i> <iframe> <img> <input> <ins> <isindex> <kbd> <label> <legend> <li> <link> <map> <menu> <meta> <noframes> <noscript> <object> <ol> <optgroup> <option> <p> <param> <pre> <q> <s> <samp> <script> <select> <small> <span> <strike> <strong> <style> <sub> <sup> <table> <tbody> <td> <textarea> <tfoot> <th> <thead> <title> <tr> <tt> <u> <ul> <var>
  24. Most common HTML 4 tags <a> <abbr> <acronym> <address> <applet>

    <area> <b> <base> <basefont> <bdo> <big> <blockquote> <body> <br> <button> <caption> <center> <cite> <code> <col> <colgroup> <dd> <del> <dfn> <dir> <div> <dl> <dt> <em> <fieldset> <font> <form> <frame> <frameset> <h1> <h2> <h3> <h4> <h5> <h6> <head> <hr> <html> <i> <iframe> <img> <input> <ins> <isindex> <kbd> <label> <legend> <li> <link> <map> <menu> <meta> <noframes> <noscript> <object> <ol> <optgroup> <option> <p> <param> <pre> <q> <s> <samp> <script> <select> <small> <span> <strike> <strong> <style> <sub> <sup> <table> <tbody> <td> <textarea> <tfoot> <th> <thead> <title> <tr> <tt> <u> <ul> <var>
  25. HTML 5 tags <article> <aside> <audio> <bdi> <canvas> <data> <datalist>

    <details> <dialog> <dl> <dt> <dd> <embed> <figcaption> <figure> <footer> <header> <hgroup> <keygen> <main> <mark> <menu> <menuitem> <meter> <nav> <output> <progress> <rb> <rp> <rt> <rtc> <ruby> <section> <source> <summary> <template> <time> <track> <video> <wbr>
  26. Tools and Technologies for Accessibility 1. Semantic markup 2. WAI-ARIA

    3. Accessibility DOM Tree 4. Screen Readers 5. The A11Y project
  27. WAI-ARIA Web Accessibility Initiative - Accessible Rich Internet Applications It

    is a technical specification created by the World Web Consortium (W3C) on increasing accessibility of the web. https://w3c.github.io/aria/ With HTML, CSS and JS we can recreate the behaviour of any existing tag. With WAI-ARIA, we can fill the accessibility gaps.
  28. WAI-ARIA Roles: defines what an element is or does e.g.:

    role=”navigation” The HTML5 tag <nav> is a Landmark with the ARIA role of navigation built-in. We can manually add the ARIA landmark role=”navigation” to any html tag. Properties: used for adding extra meaning or semantics to elements e.g.: aria-required=”true” States: special properties that define the current condition of elements e.g.: aria-disabled=”true”
  29. WAI-ARIA Start building an UI with native HTML elements (they

    have built in semantics and behavior). Continue with adding ARIA roles, states and properties to the elements lacking the desired accessibility. List of all ARIA landmark roles: https://www.w3.org/TR/wai-aria-practices/examples/landmarks/HTML5.html
  30. Tools and Technologies for Accessibility 1. Semantic markup 2. WAI-ARIA

    3. Accessibility DOM Tree 4. Screen Readers 5. The A11Y project
  31. Tools: Accessibility DOM Tree We can think of the Accessibility

    Tree as an API describing the basic page structure with less information and fewer nodes. e.g.: example of an Accessibility DOM Tree for a basic form
  32. Tools and Technologies for Accessibility 1. Semantic markup 2. WAI-ARIA

    3. Accessibility DOM Tree 4. Screen Readers 5. The A11Y project
  33. Screen Readers A screen reader is a form of assistive

    technology. It facilitates user interaction with content. It relies on a user agent to retrieve and render content.
  34. Screen Readers Available solutions: ◦ VoX (browser extension) ◦ Voice

    Over (MacOS, iOS) ◦ NVDA (Windows) ◦ ORCA (Linux) ◦ Dragon (3rd party) ◦ JAWS (3rd party) ◦ TalkBack Android
  35. Screen Readers Screen Readers react to ALL CAPS and CSS

    text-transform: uppercase. There are two specs that we can use to customize the way the screen reader reads: 1. CSS Speech Module (limited browser support) https://www.w3.org/TR/2018/NOTE-css3-speech-20180605/ The Speech Module is the successor of Aural Style Sheets (deprecated). https://developer.mozilla.org/en-US/docs/Web/CSS/Aural 2. Web Speech API This specification defined a JavaScript API that enables integrating speech recognition and synthesis into web pages. https://w3c.github.io/speech-api/speechapi.html
  36. Screen Readers Both CSS Speech Module and Web Speech API

    use Text To Speech (TTS). A Text To Speech system converts normal language text into speech. TTS engines are built in most platforms. Voice assistants like Alexa or Google Assistant use the platform’s TTS most of the times. But they can also use a bundled TTS alternative (for better language support or a wider choice of voices). https://tink.uk/using-the-web-speech-api-to-simulate-css-speech-support/
  37. Tools and Technologies for Accessibility 1. Semantic markup 2. WAI-ARIA

    3. Accessibility DOM Tree 4. Screen Readers 5. The A11Y project
  38. The A11Y Project The A11Y project’s main goal is to

    facilitate accessibility implementation on the web. It is an open-source initiative, with the objective of promoting accessibility. It provides an up-to-date collection of resources and how-to examples and it also tracks events on the topic. The term ‘A11Y’ stands for AccessibilitY as a numeronym. 11 https://a11yproject.com/
  39. Tools and Technologies for Accessibility 1. Semantic markup 2. WAI-ARIA

    3. Accessibility DOM Tree 4. Screen Readers 5. The A11Y project
  40. References • Demo: https://github.com/razvan-rosu/demo-we b-accessibility • WCAG 2.0: https://www.w3.org/TR/WCAG20/ •

    Semantic markup: https://html.com/semantic-markup/ • WAI-ARIA: https://w3c.github.io/aria/ • The A11Y Project: https://a11yproject.com/
