  1. Elasticsearch 2 Security
    - Beyond Basic
    Authentication
    Hendrik Saly, codecentric AG

    View Slide

  2. Elasticsearch Security
    No security within Elasticsearch by default
    Secure it by
    using proxies/tunnels
    let the application handle security
    using security plugins

    View Slide

  3. Elasticsearch Security - by proxy
    Error prone (complex regex stuff)
    ES API changes must be manually maintained
    HTTP REST only
    No Document or Field level security

    View Slide

  4. Elasticsearch Security - by application
    If user access Elasticsearch not directly but through an application
    Handle security within the application
    Make sure that only the application can access Elasticsearch
    (Firewall)
    No security applied to intra-cluster communication

    View Slide

  5. Elasticsearch Security - by plugin
    thats what this talk is about
    Two plugins available
    Shield 2 (commercial, by elastic)
    Search Guard (open source, by floragunn)
    This talk focus on Shield

    View Slide

  6. Elasticsearch Security - HTTP/REST and
    Transport
    HTTP/REST
    Transport protocol (raw tcp)
    also used for intra-cluster communication
    With basic authentication SSL/TLS is mandatory

    View Slide

  7. Authentication & Authorization
    Authentication: Who am i
    Username/Principal (+ secret for a prove)
    Authorization: What i am allowed to do/see
    Roles/Groups with privileges/permissions assigned

    View Slide

  8. What should be secured?
    Access to nodes
    restrict on TCP/IP Level (ip filtering)
    restrict by authentication
    Intra-cluster communication
    Limit actions (read, write, admin, … )
    Limit access to specific documents (DLS)
    Limit access to specific fields (FLS)

    View Slide

  9. Shield config
    # All cluster rights
    # All operations on all indices
    admin:
    cluster: all
    indices:
    '*':
    privileges: all
    # Only GET read action on index named events_index
    get_user:
    indices:
    'events_index':
    privileges: 'indices:data/read/get'
    https://www.elastic.co/guide/en/shield/current/reference.html#privileges-
    list

    View Slide

  10. Shield Realm
    Combines
    HTTP Authentication method (Basic/SPNEGO/… )
    OR PKI Authentication via SSL/TLS
    Backend Authentication
    (Backend Authorization)

    View Slide

  11. Shield Realm

    View Slide

  12. PKI authentication
    Two-way SSL authentication via X.509 certificates
    Single-Sign On possible
    Root CA recommended
    SSL/TLS required
    Great for Machine-to-Machine communication
    Works in browser too

    View Slide

  13. Generate certificates
    Assume there is a CA
    Server certificate for each node
    //Generate server certificate
    keytool -genkey -keystore keystore.jks \
    -dname "CN=localhost, OU=SSL, O=Test, L=Test, C=DE" \
    -ext san=dns:localhost,ip:127.0.0.1 \
    //san -> Subject Alternative Names
    //https://www.digicert.com/subject-alternative-name.htm
    //Generate CSR
    keytool -certreq ...
    //let CA sign an import signed cert back into keystore
    //along with the root CA chain
    keytool -import ...

    View Slide

  14. Generate certificates
    Client certificates for each client/user
    //Create a client key
    openssl genrsa -out client.key 2048
    //Create a client certificate
    openssl req -key client.key -new -out client.req \
    -subj "/C=DE/ST=TESTU/L=TESTU/O=TESTU/OU=TESTU/CN=Mister Spock"
    openssl x509 -req -in client.req \
    ... \
    -out client.crt
    //optional: create a PCKS12 certificate
    openssl pkcs12 -export -clcerts -in client.crt -inkey client.key -out client.p12 \
    -password pass:p12pass

    View Slide

  15. wget/curl
    Access PKI protected URLs
    wget -qO- \
    --ca-cert=chain-ca.pem \
    --certificate=client.crt \
    --private-key=client.key \
    https://localhost:9200/_logininfo?pretty
    curl -E client.crt \
    --key client.key \
    --cacert chain-ca.pem \
    "https://localhost:9200/_logininfo?pretty"

    View Slide

  16. Firefox

    View Slide

  17. DEMO
    Setup PKI realm
    https://github.com/salyh/elasticsearch-beyond-basicauthentication

    View Slide

  18. Kerberos/SPNEGO authentication
    Fits into Kerberos/AD infrastructure
    Enterprise grade security
    Single-Sign On possible
    No SSL/TLS required
    Works great with browsers

    View Slide

  19. Kerberos Realm
    Supports HTTP/REST
    Supports Transport protocol
    No JAAS login.conf needed (but its used under the hood)
    as well as GSS-API (Generic Security Service Application Program
    Interface)

    View Slide

  20. Kerberos Realm
    Access Kerberos protected URLs
    kinit [email protected]
    curl -k --negotiate -u : \
    "https://localhost:9200/_logininfo?pretty"

    View Slide

  21. Kerberos Realm
    Access Kerberos protected transport protocol
    //KerberizedClient "client wrapper"
    Client client = ...;
    KerberizedClient kc = new KerberizedClient(client,
    "[email protected]",
    "secret",
    "HTTP/[email protected]");
    KerberizedClient kc = new KerberizedClient(client,
    "[email protected]",
    Paths.get("ticket.cc"),
    "HTTP/[email protected]");

    View Slide

  22. DEMO
    Setup Kerberos realm
    https://github.com/salyh/elasticsearch-beyond-basicauthentication

    View Slide

  23. Mapping Users to Roles
    CONF_DIR/shield/users/role_mapping.yml
    monitoring:
    - "cn=admins,dc=example,dc=com"
    user:
    - "cn=John Doe,cn=contractors,dc=example,dc=com"
    - "cn=users,dc=example,dc=com"
    - "cn=admins,dc=example,dc=com"

    View Slide

  24. Document Level Security in Shield 2
    Limit access to particular documents matching a query
    1. role
    2. index
    3. privilege
    4. query
    customer_care: (1)
    indices:
    '*': (2)
    privileges: read (3)
    query: '{"term" : {"department_id" : "12"}}'' (4)

    View Slide

  25. Field Level Security in Shield 2
    Limit access to fields within a document
    my_role:
    indices:
    '*':
    privileges: read
    fields:
    - customer.*

    View Slide

  26. Limitations
    Shield is commercial and closed source
    No real separation between authentication and authorization
    Limited multirealm support
    XFF support unknown (for IP filtering)
    Shield config must be synchronized between nodes
    No nested LDAP roles

    View Slide

  27. Alternatives
    Floragunn Search Guard Plugin
    Open Source (ASL2 License)
    Currently only ES 1.x supported and low activity
    Central configuration approach
    More flexible, more features

    View Slide

  28. Whats probably next?
    SAML (Security Assertion Markup Language)
    OAuth 2
    Waffle (native Windows authentication)

    View Slide

  29. Links
    https://github.com/salyh/elasticsearch-beyond-basicauthentication
    https://github.com/codecentric/elasticsearch-shield-kerberos-realm
    https://www.elastic.co/guide/en/shield/current/pki.html
    https://www.elastic.co/guide/en/shield/current/custom-realms.html
    https://www.elastic.co/guide/en/shield/current/reference.html#ref-
    actions-list
    https://github.com/floragunncom/search-guard
    https://github.com/dblock/waffle

    View Slide

  30. Thank you!
    Follow me on Twitter:
    This work is licensed under a
    [email protected]
    @hendrikdev22
    Creative Commons Attribution 4.0 International License

    View Slide
