1. (Unofficial) Guide to
   App Architecture Guide
   Saryong Kang
   Developer Relations Engineer @ Google
   1


   View Slide

2. Disclaimer
   ● The opinions stated here are my own, not necessarily those of Google.
   2


   View Slide

3. Agenda
   What App Architecture Guide doesn’t tell you
   Domain Layer
   Data Layer
   UI Layer
   01
   02
   03
   04
   3


   View Slide

4. Agenda
   What App Architecture Guide doesn’t tell you
   Domain Layer
   Data Layer
   UI Layer
   01
   02
   03
   04
   4


   View Slide

5. Clean Architecture
   ● There have been long discussion on how to adopt Clean
   Architecture into mobile app design
   ○ SOLID principle
   ○ Layered component architecture
   ● E.g. Blog post in 2015
   5


   View Slide

6. 6
   Source: https://qiita.com/koutalou/items/07a4f9cf51a2d13e4cdc
   注意: Googleの公式な意見と関係ありません


   View Slide

7. So..
   Is Clean Architecture
   a design pattern?
   7


   View Slide

8. Clean Architecture is more like
   a way of thinking
   than
   a design / architectural pattern.
   8


   View Slide

9. ● The important implication from Clean Architecture is that the
   layered structure helps design of mobile application
   ● However,
   ○ there’s no specific definition of components in each layer
   ○ the diagram in previous page just shows one example of best
   practices
   9
   Clean Architecture is not a pattern


   View Slide

10. 10
    Source (left): https://blog.cleancoder.com/uncle-bob/2012/08/13/the-clean-architecture.html
    Source (right): https://blog.cleancoder.com/uncle-bob/2012/08/13/the-clean-architecture.html


    View Slide

11. Yes, Clean Architecture affected Arch. Guide a lot
    ● Layered architecture: UI - Domain - Data Layer
    ● SOLID principle, especially Single Responsibility Principle
    ● However, it's not an implementation of Clean Architecture
    11


    View Slide

12. Why doesn’t the Guide cover these concepts?
    ● MVI (Flux, Redux), MVP, …
    ○ Not because they are not important
    ● The guide doesn’t intend to cover every patterns and architecture
    that make sense in mobile design
    ○ It’s curated collection of best practices and recommendations
    for most common use cases
    12


    View Slide

13. Agenda
    What App Architecture Guide doesn’t tell you
    Domain Layer
    Data Layer
    UI Layer
    01
    02
    03
    04
    13


    View Slide

14. Why is “Domain” so important?
    ● It may solve design problems caused differences between UI and Data
    layer.
    ○ Even when you don’t need to implement domain “layer”, you need to
    consider about the mediator
    ● When you focus UI layer too much,
    ○ Screen-centric design: it makes difficult deal with logics beyond
    screen
    ○ Agile side effect: elements of screen became backlog / features;
    then class
    ● When you focus data layer too much,
    ○ Data schema affects domain / UI layer directly → typical
    antipattern
    14


    View Slide

15. Challenge: as an Android Engineer,
    we may not have enough
    design experiences.
    15


    View Slide

16. Let me prove it.
    16


    View Slide

17. Coffee Maker Case Study
    ● A series of coffee makers (Mark V will come
    out eventually)
    ● Warmer plate keeps the pot warm for
    extended time
    a. Put coffee grounds into the filter and
    slide the filter in
    b. Pour water in the water strainer and
    press Brew button
    c. Water is heated until boiling
    d. The pressure of the steam forces the
    water to be sprayed over the coffee
    grounds
    e. Coffee drips through the filter into the
    pot
    17
    Source: https://cleancoders.com/episode/clean-code-episode-15
    Image source: https://www.cafeappliances.com/


    View Slide

18. Coffee Maker Case Study
    ● Boiler (can be turned on / off)
    ● Warmer plate (can be turned on / off)
    ● Sensor for the warmer plate
    (3 states: warmerEmpty, potEmpty,
    potNotEmpty.
    ● Sensor for the boiler
    (2 states: boilerEmpty, boilerNotEmpty)
    ● Brew button + Light indicator
    ● A pressure-relief valve
    18
    Source: https://cleancoders.com/episode/clean-code-episode-15
    Image source: https://www.cafeappliances.com/


    View Slide

19. Looks nice?
    19
    Source: https://cleancoders.com/episode/clean-code-episode-15


    View Slide

20. Think again: is that a screaming architecture?
    20
    ● A series of coffee makers (Mark V will come out
    eventually)
    ● Warmer plate keeps the pot warm for extended time
    a. Put coffee grounds into the filter and slide the filter in
    b. Pour water in the water strainer and press Brew button
    c. Water is heated until boiling
    d. The pressure of the steam forces the water to be
    sprayed over the coffee grounds
    e. Coffee drips through the filter into the pot


    View Slide

21. Design example: Coffee Maker Mark IV
    21
    Source: https://cleancoders.com/episode/clean-code-episode-15


    View Slide

22. Design example: Coffee Maker Mark IV
    22
    Source: https://cleancoders.com/episode/clean-code-episode-15


    View Slide

23. Insight
    ● Data- or entity-centric thinking can give you good design
    ● Instead, abstracting key actions and actors is more important
    ● You can design mediator like the following:
    ○ 1. DDD-ish design
    ○ 1-1. Use Case (Transaction Script, which is anti-pattern in DDD)
    ○ 2. non-domain mediator layer
    eg. Gateway, Mapper, Data Controller, Translator, …
    ○ 3. put them into Data Layer: Repository
    23


    View Slide

24. Agenda
    What App Architecture Guide doesn’t tell you
    Domain Layer
    Data Layer
    UI Layer
    01
    02
    03
    04
    24


    View Slide

25. Repository pattern
    ● Common misconception: Repository in Android is anti-pattern!?
    ○ It violates Single Responsibility Principle?!
    ● Repository provides abstraction to be called from domain (or UI)
    layer
    ○ It hides details of data saving / loading
    25


    View Slide

26. Data Source
    ● Data Source hides implementation of data I/O
    ● Liskov Substitution Principle (LSP)
    ○ When replacing a subclass with another, its behavior
    shouldn’t be changed
    ■ REST ↔ gRPC
    ■ Room ↔ other ORM
    ■ Real impl. ↔ Fake
    26


    View Slide

27. Considerations on Data Layer
    ● If you only have simple operations like CRUD,
    you may not need both of Repository and Data Source
    ● Consider a separated life cycle in Repository
    ● Who should be the Single Source of Truth in your app?
    27


    View Slide

28. Agenda
    What App Architecture Guide doesn’t tell you
    Domain Layer
    Data Layer
    UI Layer
    01
    02
    03
    04
    28


    View Slide

29. What AAC ViewModel does for you
    ● ACC VM provides minimal features to help developers implement
    general VM
    ○ Mechanism to store state safely
    ■ Safe from configuration change (by default)
    ■ Safe from process kill (thru SavedStateHandler)
    ○ Coroutine Scope
    ○ Dependency Injection via Dagger Hilt
    ○ Helper for Jetpack Navigation
    29


    View Slide

30. What AAC ViewModel does for you
    ● However,
    ○ it’s completely your job to make VM VM-like
    ⇒ Adopting AAC VM doesn’t automatically mean you built a
    good MVVM architecture.
    ○ it may not appropriate for some use cases
    ○ sometimes implementation of VM seems too verbose
    30


    View Slide

31. If you don’t like it,
    ● You can build your own!
    ○ And AAC ViewModel source code will inspire you about how
    to implement Saved State Handler, its own Life Cycle,
    Coroutines Scope, Navigation, etc.
    31


    View Slide

32. Another Downside of ViewModel: Verbosity
    ● Circular event flow
    ○ (1) View event occurred
    ○ (2) ViewModel deal with it
    and then modify the state
    ○ (3) View observes
    changed state, then show
    it to the screen
    32
    override fun onViewCreated(...) {
    // (1)
    binding.plusButton.setOnClickListener { _ ->
    viewModel.incrementCounter()
    }
    // (3)
    viewModel.counter.observe(viewLifeCycleOwner) {
    binding.plusButton.text = "Count: $it"
    }
    }
    class CounterViewModel {
    private val _counter = MutableStateFlow(0)
    val counter: StateFlow
    get() = _counter.asStateFlow()
    fun incrementCounter() {
    // (2)
    _counter.value += 1
    // something aync...
    }
    }


    View Slide

33. Solution
    ● Allow boiler plate
    ● Data Binding! - can solve this in elegant way
    33


    View Slide

34. Consideration on Jetpack Compose
    ● MVP doesn't make sense in many cases
    ○ Interaction between View and Presenter is done by method
    call
    ○ Declarative View can’t change the screen by one method call
    (without help from additional mediator)
    ● ViewModel seems to make more sense, but.. does it?
    34


    View Slide

35. Consideration on Jetpack Compose
    ● Is ViewModel really necessary to me?
    ○ rememberSavable: the safe state storage provided by AAC
    ViewModel is now possible in Composable function
    ○ If repository in Data layer has independent life cycle from
    View,
    ■ Is it necessary to yield state store to ViewModel?
    ■ Some cases it works well without VM
    (if domain or data layer containes sufficient business
    logic)
    35


    View Slide

36. Consideration on Jetpack Compose
    ● Be cautious about construction
    ○ What is wrong with the code in the next slide?
    36


    View Slide

37. 37
    @Composable
    fun MyComposable(
    viewModel: MyViewModel = hiltViewModel()
    ) {
    Text(text = viewModel.myState)
    }
    class MyViewModel : ViewModel() {
    private val _myState = mutableStateOf("A")
    val myState: State = _myState
    init {
    viewModelScope.launch(Dispatchers.IO) {
    myState = "B"
    }
    }
    }


    View Slide

38. Consideration on Jetpack Compose
    ● Be cautious about construction
    ○ 1. It changes snapshot state in background scheduler
    → Crash!
    ○ 2. Async task in constructor:
    The async block in coroutineScope.launch could be
    finished after the construction was completed
    → hard to debug when error occurred
    → make it hard to write test code
    ○ 3. Violating Single Responsibility Principle:
    The main responsibility of constructor is a short and
    simple instantiation of fields.
    38


    View Slide

39. Consideration on Jetpack Compose
    ● Be cautious about construction
    ○ Suggestions
    ■ Implement separated init() method
    ■ Or, run initial job when view starts collection /
    subscription
    39


    View Slide

40. 40
    private val _myState = MutableStateFlow("A")
    val myState: StateFlow = _myState.asStateFlow()
    .onSubscription {
    // initial loading from local db...
    }
    .map { state ->
    // when _myState updated..
    }
    .stateIn(viewModelScope, SharingStarted.WhileSubscribed(5_000), "")


    View Slide

41. Consideration on Jetpack Compose
    ● Be cautious about the scope
    ○ Don’t add anything that may affect the snapshot
    ○ Don’t store UI state (eg. animation) to VM
    41


    View Slide

42. Consideration on Jetpack Compose
    ● Be cautious about the scope
    ○ ViewModelScope uses Dispatchers.Main.immediate
    ■ instead, you can now use custom CoroutineScope
    https://developer.android.com/jetpack/androidx/release
    s/lifecycle#2.5.0 (addClosable(), new constructor of VM)
    42


    View Slide

43. 43
    class CloseableCoroutineScope(
    context: CoroutineContext = SupervisorJob() + Dispatchers.Main
    ) : Closeable, CoroutineScope {
    override val coroutineContext: CoroutineContext = context
    override fun close() {
    coroutineContext.cancel()
    }
    }
    class MyViewModel(
    val customScope: CloseableCoroutineScope = CloseableCoroutineScope()
    ) : ViewModel(customScope) {
    // You can now use customScope in the same way as viewModelScope
    }


    View Slide

44. Guide to App Architecture Guide Vol. 2
    ● Dependency Injection
    ○ Upside and downside of Dagger Hilt
    ○ Alternatives
    ● Multimodule
    ○ Large scale modular architecture
    ○ When is the best timing to separate modules?
    ○ Why does my multi module project build so slowly?
    44


    View Slide

45. Thanks a lot!
    45


    View Slide
