What's NNNNNNNNew in Android Security? - Oct 2016

Android N brings a plethora of security enhancements to the platform and the SDK. Including Network Layer Security, Hardware-backed Keystore, APK Signing v2, Scoped Directory Access and Direct Boot.

Links in more clickable form on https://scottyab.com/2016/10/whats-new-in-android-security-oct-2016/

Transcript

1. What’s NNNNew in Android Security?
   Scott Alexander-Bown
   droidcon
   London 2016 @ScottyAB


   View Slide

2. View Slide

3. At a glance
   Direct boot
   Keystore
   ‘Securer’ networking
   Misc system and app differences
   Permissions in M
   @ScottyAB


   View Slide

4. Terms
   6.0 - M - API 23 - Marshmallow
   7.0 - N - API 24 - Nougat
   @ScottyAB


   View Slide

5. Direct Boot


   View Slide

6. Booting encrypted device
   pre-7.0
   Boot halted for pin/password
   Device encrypted with same key
   Android used block-level
   encryption
   @ScottyAB


   View Slide

7. Direct Boot mode
   Boot direct to lock screen
   Calls, SMS & Alarms work
   And your app too!
   @ScottyAB


   View Slide

8. File based encryption
   Default
   @ScottyAB


   View Slide

9. View Slide

10. Direct Boot aware
    android:name=".directboot.MyDirectBootAwareReceiver"

    android:directBootAware="true">








    @ScottyAB


    View Slide

11. Direct Boot aware
    android:name=".directboot.MyDirectBootAwareReceiver"

    android:directBootAware="true">








    @ScottyAB


    View Slide

12. Accessing device encrypted storage
    @Override

    public void onReceive(Context context, Intent intent) {



    Context directBootContext =
    ContextCompat.createDeviceProtectedStorageContext(context);



    if (directBootContext != null) {

    SharedPreferences sharedPreferences =
    PreferenceManager.getDefaultSharedPreferences(directBootContext);



    String token = sharedPreferences.getString(READ_ONLY_OAUTH_TOKEN, null);



    //do read only API lookup

    ///...

    }

    }
    @ScottyAB


    View Slide

13. Accessing device encrypted storage
    @Override

    public void onReceive(Context context, Intent intent) {



    Context directBootContext =
    ContextCompat.createDeviceProtectedStorageContext(context);



    if (directBootContext != null) {

    SharedPreferences sharedPreferences =
    PreferenceManager.getDefaultSharedPreferences(directBootContext);



    String token = sharedPreferences.getString(READ_ONLY_OAUTH_TOKEN, null);



    //do read only API lookup

    ///...

    }

    }
    @ScottyAB


    View Slide

14. Accessing device encrypted storage
    @Override

    public void onReceive(Context context, Intent intent) {



    Context directBootContext =
    ContextCompat.createDeviceProtectedStorageContext(context);



    if (directBootContext != null) {

    SharedPreferences sharedPreferences =
    PreferenceManager.getDefaultSharedPreferences(directBootContext);



    String token = sharedPreferences.getString(READ_ONLY_OAUTH_TOKEN, null);



    //do read only API lookup

    ///...

    }

    }
    @ScottyAB


    View Slide

15. Direct Boot, so what is it good for?
    Messaging apps, important user notifications.
    Already using a BootCompleted listener?
    Recommended limited scope i.e Readonly API tokens
    @ScottyAB


    View Slide

16. Android Keystore
    @ScottyAB
    Android 4.3


    View Slide

17. What is the KeyStore?
    Originally for unlocking DRM content
    App’s can securely create and store
    their crypto keys.
    Requires device pin or password (or
    fingerprint)
    Ideally secure element / Trust zone
    (hardware-based)
    @ScottyAB


    View Slide

18. What’s new?
    Android M introduced broader
    range of capabilities.
    N+ must be hardware backed
    (new devices)
    Time sensitive (Android M)
    @ScottyAB


    View Slide

19. Attestation
    Key is baked into the firmware
    Create a Key
    Remotely validate its cert chain
    N+ (New hardware)
    @ScottyAB


    View Slide

20. By @doriancussen


    View Slide

21.
    @ScottyAB


    View Slide

22. Securer Networking
    Custom trust store / anchors
    Debug only Overrides CA
    Block non https traffic
    Limit the certs you trust
    @ScottyAB


    View Slide

23. minSdkVersion=24?


    View Slide

24. CWAC-NetSecurity
    https://github.com/commonsguy/cwac-netsecurity
    @ScottyAB


    View Slide

25. Configuring CAs for Debugging
    Self signed certs in development
    Only enabled when android:debuggable=true
    Safer that conditional code
    @ScottyAB


    View Slide

26. Configuring CAs for Debugging













    @ScottyAB


    View Slide

27. Manifest
    android:icon="@mipmap/ic_launcher"

    android:label="@string/app_name"

    android:networkSecurityConfig=“@xml/
    network_security_config_debug_ca" />
    @ScottyAB


    View Slide

28. User certs no longer trusted by default
    @ScottyAB


    View Slide

29. Trusting user installed certs













    @ScottyAB


    View Slide

30. Pinning Certificates
    SSL pinning lets apps limit the set of certificates they
    accept
    Pin a hash of the SubjectPublicKeyInfo of the X.509
    certificate.
    @ScottyAB


    View Slide

31. SSL Pinning




    scottyab.com



    7HIpactkIAq2Y49…Y=



    fwza0LRMXouZHR…E=








    @ScottyAB


    View Slide

32. How to get the Pin?


    View Slide

33. How to get the Pin?
    $ openssl s_client -servername scottyab.com
    -connect scottyab.com:443 | openssl x509 -
    pubkey -noout | openssl rsa -pubin -outform
    der | openssl dgst -sha256 -binary | openssl
    enc -base64
    Thanks to John Kozyrakis @ikoz
    @ScottyAB


    View Slide

34. Misc
    Misc
    @ScottyAB


    View Slide

35. Under the hood
    The media stack and
    platform hardening
    Kernel hardening (with error
    correction)
    @ScottyAB


    View Slide

36. Seamless OTA updates
    @ScottyAB


    View Slide

37. App data directory
    App data directory now user
    only 700 permissions
    Sharing files is explicitly opt-in
    Use FileProvider (support-lib)
    Training article “Sharing Files”
    @ScottyAB


    View Slide

38. APK signing schema v1
    Problems
    Deleting files
    adding files to meta-inf
    DOS app
    @ScottyAB


    View Slide

39. APK signing schema v2
    Faster
    More Secure
    You’re already using both?
    zipalign before (not after)
    @ScottyAB


    View Slide

40. Scoped directory access
    Access common external storage
    directories
    Storage Access Framework
    Environment.DIRECTORY_MOVIES
    Remember to call
    takePersistableUriPermission()
    @ScottyAB


    View Slide

41. Misc differences
    No more access to MAC
    addresses
    Overlays can no longer be
    displayed on top of
    permissions dialogs
    Reduced the power of
    device admin applications
    @ScottyAB


    View Slide

42. @ScottyAB


    View Slide

43. Runtime Permissions
    •Permissions that users “get”
    •Control on specific permissions
    •Easy for users
    •Updates don’t require approval
    @ScottyAB


    View Slide

44. Tips of Working with Android Permissions
    Only use the permissions
    necessary for your app to work
    Be transparent
    Make system accesses
    explicit
    Context, Context, Context!
    @ScottyAB


    View Slide

45. Permissions required by libraries.
    @ScottyAB


    View Slide

46. Checking Device health - SafetyNet API
    Read device?
    Vulnerable?
    Rooted?
    @ScottyAB


    View Slide

47. https://github.com/scottyab/safetynethelper


    View Slide

48. play.google.com/store/apps/details?id=com.scottyab.safetynet.sample


    View Slide

49. SafetyNetApi - SafeBrowsing
    Social Engineering
    Potentially Harmful Apps
    @ScottyAB


    View Slide

50. Recap
    Direct boot
    Keystore
    Securer networking
    Misc system and app differences
    Permissions in M
    @ScottyAB


    View Slide

51. Thanks!
    Questions?
    Scott Alexander-Bown
    @ScottyAB
    hello@scottyab.com
    Shout outs:
    @commonsguy
    @ikoz
    +AdrianLudwig
    @doriancussen
    @niallscott
    @trionkidnapper
    @subsymbolics


    View Slide

52. Resources
    https://www.blackhat.com/ldn-15/summit.html#what-can-you-do-to-an-apk-without-its-private-key-except-
    repacking
    https://doridori.github.io/android-security-the-forgetful-keystore/#sthash.hFHQpV3A.5WcUVfYk.dpbs
    http://android-developers.blogspot.co.uk/2016/09/security-enhancements-in-nougat.html
    https://developer.android.com/about/versions/nougat/android-7.0.html#apk_signature_v2
    https://blog.stylingandroid.com/nougat-direct-boot/
    SafetyNet Helper library https://github.com/scottyab/safetynethelper
    Security patch date util - https://gist.github.com/scottyab/77bac6600986eb6a619e07a3d0abae3f
    *Adrian Ludwig’s Google IO talk - What’s new in Android Security (M &N) - https://www.youtube.com/watch?
    v=XZzLjllizYs
    @ScottyAB


    View Slide

53. Training / Developer Docs
    https://developer.android.com/training/articles/security-key-
    attestation.html
    https://developer.android.com/training/articles/scoped-
    directory-access.html#accessing
    https://developer.android.com/training/articles/user-data-
    permissions.html#tenets_of_working_with_android_permissions
    https://developer.android.com/training/articles/direct-boot.html
    @ScottyAB


    View Slide
