Spring Framework 5.0 Themes and Trends

Spring Framework 5.0
Themes and Trends
Sébastien Deleuze @sdeleuze
Brian Clozel @bclozel

View Slide

Unless otherwise indicated, these slides are © 2013-2015 Pivotal Software, Inc. and licensed under a 
Creative Commons Attribution-NonCommercial license: http://creativecommons.org/licenses/by-nc/3.0/
Spring Framework 5
‣ Reactive foundations
‣ Spring WebFlux
‣ Kotlin builtin support
‣ Functional bean registration
‣ Baseline upgrade & cleanup
‣ Java 9 support
‣ Performance improvements
2

View Slide

Reactive foundations

View Slide

Why going Reactive?
4
More for scalability and 
stability than for speed

View Slide

What issue are we trying to solve?
5
1 request = 1 thread

View Slide

From blocking to event-based
6
Neutral to latency

View Slide

Reactive Streams
7
Publisher Subscriber
Backpressure
request(n) data
0..N data then
0..1 (Error | Complete)

View Slide

8

View Slide

9

View Slide

10

View Slide

Reactive Streams is 4 interfaces (and a TCK)
11
public interface Publisher {
void subscribe(Subscriber super T> s);
}
public interface Subscriber {
void onSubscribe(Subscription s);
void onNext(T t);
void onError(Throwable t);
void onComplete();
}
public interface Subscription {
void request(long n);
void cancel();
}
public interface Processor extends Subscriber, Publisher {
}

View Slide

Spring Framework 5 uses Reactor
for its Reactive foundations
Reactor, RxJava, Akka Streams, etc.
12
Reactive libraries
Your web application can use

View Slide

Flux
• Implements Reactive Streams Publisher
• 0 to n elements
• Operators: flux.map(…).zip(…).flatMap(…)
13

View Slide

Mono
• Implements Reactive Streams Publisher
• 0 to 1 element
• Operators: mono.then(…).otherwise(…)
14

View Slide

StepVeriﬁer
15
StepVerifier.create(flux) 
.expectNext("foo", "bar") 
.verifyComplete();
‣ Designed to test easily Reactive Streams Publishers
‣ Carefully designed after writing thousands of
Reactor and Spring WebFlux tests

View Slide

Blocking versus Reactive API
16
interface ReactiveUserRepository {
Mono findOne(String id);
Flux findAll();
Mono save(Mono user);
}
interface UserRepository {
User findOne(String id);
List findAll();
void save(User user);
}
Blocking API Reactive API
‣ Method returns when all the data has 
been received
‣ Exceptions thrown when an error occurs
‣ Method returns immediately
‣ Error event instead of throwing exception
‣ Complete event instead of method return
‣ Mono = error or success, no data
‣ Data comes as events too the 
Mono or Flux return value

View Slide

Upcoming high-level features
17

View Slide

Spring WebFlux

View Slide

spring-webmvc
@Controller, @RequestMapping
Servlet API
Servlet Container
spring-webflux
HTTP / Reactive Streams
Servlet 3.1, Netty, Undertow
Router Functions

View Slide

Spring MVC
20
@RestController
public class UserController {
private final UserRepository repo;
public UserController(UserRepository repo) { this.repo = repo; }
@GetMapping("/user/{id}")
public User findOne(@PathVariable String id) { return repo.findOne(id); }
@GetMapping("/user")
public List findAll() { return repo.findAll(); }
@PostMapping("/user")
public void save(@RequestBody User user) { repo.save(user); }
}
User findOne(String id);
List findAll();
void save(User user);
}

View Slide

WebFlux annotation-based server
21
@RestController
public class ReactiveUserController {
private final ReactiveUserRepository repo;
public ReactiveUserController(ReactiveUserRepository repo) { this.repo = repo; }
public Mono findOne(@PathVariable String id) { return repo.findOne(id); }
public Flux findAll() { return repo.findAll(); }
public Mono save(@RequestBody Mono user) { repo.save(user); }
}
Mono findOne(String id);
Flux findAll();
Mono save(Mono user);
}

View Slide

Flux: array versus stream
22
JSON
application/json
JSON Streaming
application/stream+json
Server-Sent Events
text/event-stream
[
{"a": "foo", "b": "bar"},
{"a": "baz", "b": "boo"}
]
‣ Single Jackson invocation
‣ Doesn’t support infinite streams
{"a": "foo", "b": "bar"}
{"a": "baz", "b": "boo"}
…
‣ Jackson invocation per element
‣ Supports infinite streams
data: {"a": "foo", "b": "bar"}
data: {"a": "baz", "b": "boo"}
…
public Flux findAll()

View Slide

WebFlux functional API
23
‣ Reactive
‣ Client and server
‣ Lightweight
‣ Flexible
‣ Can be use with or without dependency injection!
‣ Simple functional building blocks

View Slide

WebFlux functional server API
24
‣ RouterFunction
Mono>
route(ServerRequest request)
‣ RequestPredicate
boolean test(ServerRequest request)
‣ HandlerFunction
Mono handle(ServerRequest request)
‣ HandlerFilterFunction
Mono filter(ServerRequest request,
HandlerFunction next)

View Slide

WebFlux functional server API
25
@Controller
public class UserController {
public RouterFunction route() {
return RouterFunctions
.route(GET("/users"), this::listUsers)
.andRoute(POST("/users"), this::createUser);
}
Mono listUsers(ServerRequest request) { ... }
Mono createUser(ServerRequest request) { ... }
}

View Slide

RequestPredicates
26
‣ HTTP method
‣ Path
‣ Path prefix
‣ Path extension
‣ Headers
‣ Content type
‣ Accept
‣ Query param

View Slide

New WebClient API
27
WebClient client = WebClient.create();
Mono githubUser = client
.get()
.uri("https://api.github.com/users/{username}", username)
.exchange()
.then(response -> response.bodyToMono(GithubUser.class));
Mono twitterUser = client
.get()
.uri("https://api.twitter.com/1.1/users/show.json?screen_name={username}", username)
.exchange()
.then(response -> response.bodyToMono(TwitterUser.class));
return githubUser.and(twitterUser, (github, twitter)-> new AppUser(github, twitter));

View Slide

WebFlux demo

View Slide

WebFlux Streaming Showcase
29
https://github.com/bclozel/webflux-streaming-showcase
quote-stream
streaming-service
GET /quotes 
"application/stream+json"
GET /quotes/feed 
"text/event-stream"
MongoDB

View Slide

Kotlin Support

View Slide

Kotlin
‣ Overcome Java limitations
‣ Elegant and pragmatic language
‣ Concise code
‣ Simple and easy to learn
‣ Very good Java interoperability
‣ Embrace both functional and object
oriented programming
31

View Slide

How does it compare with …
32
Same conciseness and expressive code, 
but Kotlin default static typing and null-safety 
make a big diﬀerence.
"Kotlin is a software engineering language in contrast
to Scala which is a computing science language." 
Eric Kolotyluk, Electronic Arts, Scala developer
Swift Swift and Kotlin share similar syntax. Swift is coming
from native world while Kotlin is coming from JVM
world.

View Slide

Domain model classes
33
public class User {
private String userName;
private String firstName;
private String lastName;
private Point location;
public User(String userName, String firstName, String lastName) {
this(userName,firstName, lastName, null);
}
public User(String userName, String firstName, String lastName, Point location) {
Assert.notNull(userName);
Assert.notNull(firstName);
Assert.notNull(lastName);
this.userName = userName;
this.firstName = firstName;
this.lastName = lastName;
this.location = location;
}
public String getUserName() {
return userName;
}
public void setUserName(String userName) {
this.userName = userName;
}
public String getFirstName() {
return firstName;
}
public void setFirstName(String firstName) {
this.firstName = firstName;
}
public String getLastName() {
return lastName;
}
public void setLastName(String lastName) {
this.lastName = lastName;
}
public Point getLocation() {
return location;
}
public void setLocation(Point location) {
this.location = location;
}
@Override
public boolean equals(Object o) {
if (this == o) {
return true;
}
if (o == null || getClass() != o.getClass()) {
return false;
}
UserJ j = (UserJ) o;
if (!userName.equals(j.userName)) {
return false;
}
if (!firstName.equals(j.firstName)) {
return false;
}
if (!lastName.equals(j.lastName)) {
return false;
}
return location != null ? location.equals(j.location) : j.location == null;
}
@Override
public int hashCode() {
int result = userName.hashCode();
result = 31 * result + firstName.hashCode();
result = 31 * result + lastName.hashCode();
result = 31 * result + (location != null ? location.hashCode() : 0);
return result;
}
@Override
public String toString() {
return "User{" +
"userName='" + userName + '\'' +
", firstName='" + firstName + '\'' +
", lastName='" + lastName + '\'' +
", location=" + location +
'}';
}
}
data class User( 
val userName: String, 
val firstName: String?, 
val lastName: String?, 
val location: Point = Point(0, 0) 
)
Generates equals()
and hashcode()
val = immutable
var = mutable
String? = nullable
String = non-nullable
Optional parameter
with default value
Constructor +
properties declaration

View Slide

Kotlin is much more than a 
"super Java" or than Lombok
34

View Slide

My favorite Kotlin features
‣ Awesome type inference with static typing
‣ Extensions
‣ Reified type parameters
‣ Null safety
‣ Type aliases
‣ Allows to write nice DSL
‣ Smart casts
35

View Slide

Spring Initializr
36
https://start.spring.io/#!language=kotlin

View Slide

Introducing Kotlin support in Spring Framework 5
37
https://goo.gl/gMnhxN

View Slide

Gradle build ﬁles written in Kotlin
38

View Slide

kotlin-spring Gradle and Maven plugin
39
@SpringBootApplication
open class Application {
@Bean
open fun foo() = ...
@Bean
open fun bar() = ...
}
Without kotlin-spring
@SpringBootApplication
class Application {
@Bean
fun foo() = ...
@Bean
fun bar() = ...
}
With kotlin-spring
Also available as a kotlin-allopen generic plugin

View Slide

kotlin-noarg Gradle and Maven plugin
40
configure { 
annotation("org.springframework.data.mongodb.core.mapping.Document") 
}
Also available preconfigured for JPA as kotlin-jpa
@Document
data class User(
@Id val login: String,
val firstname: String,
val lastname: String,
val email: String,
val company: String? = null,
val description: Map = emptyMap(),
val logoUrl: String? = null,
val role: Role = Role.ATTENDEE)

View Slide

Persistence
41
class EventRepository(val template: ReactiveMongoTemplate) {
fun findAll() = template.find(Query().with(Sort("year")))
fun findOne(id: String) = template.findById(id)
fun deleteAll() = template.remove(Query())
fun save(event: Event) = template.save(event)
}

View Slide

Extensions
42
// Spring Boot extensions
fun run(type: KClass<*>, vararg args: String) = SpringApplication.run(type.java, *args)
// Spring Data extensions
inline fun ReactiveMongoOperations.findById(id: Any): Mono =
findById(id, T::class.java)
inline fun ReactiveMongoOperations.find(query: Query): Flux =
find(query, T::class.java)
inline fun ReactiveMongoOperations.findAll(): Flux =
findAll(T::class.java)
inline fun ReactiveMongoOperations.findOne(query: Query): Mono =
find(query, T::class.java).next()
inline fun ReactiveMongoOperations.remove(query: Query): Mono =
remove(query, T::class.java)
// Other extensions
fun ServerRequest.language() =
Language.findByTag(this.headers().header(HttpHeaders.ACCEPT_LANGUAGE).first())

View Slide

Spring MVC
43
@RestController
class UserController(val repo: UserRepository) {
fun findOne(@PathVariable id: String) = repo.findOne(id)
fun findAll() = repo.findAll()
fun save(@RequestBody user: User) = repo.save(user)
}
fun findOne(id: String): User
fun findAll(): List
fun save(user: User)
}
Classes and functions are public by default
Static typing + type inference
Constructor injection
without @Autowired if
single constructor

View Slide

Spring WebFlux annotation-based
44
@RestController
class ReactiveUserController(val repository: ReactiveUserRepository) {
fun findOne(@PathVariable id: String) = repository.findOne(id)
fun findAll() = repository.findAll()
fun save(@RequestBody user: Mono) = repository.save(user)
}
fun findOne(id: String): Mono
fun findAll(): Flux
fun save(user: Mono): Mono
}

View Slide

Spring WebFlux functional Kotlin DSL
45
router {
"/blog" { findAllView(it) }
"/blog/{slug}" { findOneView(it) }
"/api/blog" { findAll(it) }
"/api/blog/{id}" { findOne(it) }
}
Simple path request predicate

View Slide

46
router {
GET("/blog") { findAllView(it) }
GET("/blog/{slug}") { findOneView(it) }
GET("/api/blog") { findAll(it) }
GET("/api/blog/{id}") { findOne(it) }
POST("/api/blog") { create(it) }
}
HTTP method + path predicate

View Slide

47
router {
GET("/blog", blogController::findAllView)
GET("/blog/{slug}", blogController::findOneView)
GET("/api/blog", blogController::findAll)
GET("/api/blog/{id}", blogController::findOne)
POST("/api/blog", blogController::create)
}
Method references

View Slide

48
router {
"/blog".nest {
GET("/", blogController::findAllView)
GET("/{slug}", blogController::findOneView)
}
"/api/blog".nest {
GET("/", blogController::findAll)
GET("/{id}", blogController::findOne)
POST("/", blogController::create)
}
}
Nested routing

View Slide

49
router {
("/blog" and accept(TEXT_HTML)).nest {
GET("/", blogController::findAllView)
GET("/{slug}", blogController::findOneView)
}
("/api/blog" and accept(APPLICATION_JSON)).nest {
GET("/", blogController::findAll)
GET("/{id}", blogController::findOne)
POST("/", blogController::create)
}
}
Rich set of RequestPredicate

View Slide

Leveraging Kotlin nullable information
50
// "GET /foo" and "GET /foo?bar=baz" are allowed
@GetMapping("/foo")
fun foo(@RequestParam bar: String?) = ...
// "GET /foo?bar=baz" is allowed and "GET /foo" will return an error
@GetMapping("/foo")
fun foo(@RequestParam bar: String) = ...

View Slide

Spring Kotlin extensions
51
Mono findAll(ServerRequest request) {
return ServerResponse.ok().body(repository.findAll(), User.class);
}
fun findAll(req: ServerRequest) = ok().body(repository.findAll())
No need to specify explicitly types
thanks to Kotlin reified type parameters
inline fun ServerResponse.BodyBuilder.body(publisher: Publisher) =
body(publisher, T::class.java)
ServerResponseExtensions provided in spring-webflux.jar

View Slide

Spring Framework extensions
52
‣ ApplicationContext
‣ Spring WebFlux
• Client
• Server
‣ Spring MVC
‣ RestTemplate
‣ JDBC
‣ Reactor (via reactor-kotlin)

View Slide

Kotlin type-safe templates
53
import io.spring.demo.*
"""
${include("header")}
${i18n("title")}

${users.joinToLine{ "${i18n("user")} ${it.firstname} ${it.lastname}" }}

${include("footer")}
"""
See https://github.com/sdeleuze/kotlin-script-templating for more details
‣ Regular Kotlin code, no new dialect to learn
‣ Extensible, refactoring and auto-complete support
‣ Need to cache compiled scripts for good performances

View Slide

Tests with JUnit
54
class UserIntegrationTests : AbstractIntegrationTests() {
@Test
fun `Find Dan North`() {
val speaker = client.get()
.uri("/api/speaker/tastapod")
.accept(APPLICATION_JSON)
.exchange().then { r -> r.bodyToMono() }
StepVerifier.create(speaker)
.consumeNextWith {
assertEquals("North", it.lastname)
assertTrue(it.role == Role.SPEAKER)
}
.verifyComplete()
}
}

View Slide

JUnit 5 will improve Kotlin support
55

View Slide

MiXiT reference web application
56
https://github.com/mixitconf/mixit

View Slide

Functional bean registration

View Slide

Functional bean registration API
‣ After XML and JavaConfig, a third major way to register your beans
‣ Lambda with Supplier act as a FactoryBean
‣ Very efficient, no reflection, no CGLIB proxies involved
‣ Usable with pure Spring Framework apps, not yet with Spring Boot
58

View Slide

API example
59
GenericApplicationContext context = new GenericApplicationContext();
context.registerBean(A.class);
context.registerBean(B.class, () -> new B(context.getBean(A.class)));
GenericApplicationContext {
registerBean()
registerBean { B(it.getBean()) }}

View Slide

Choose the ﬂavour you prefer!
60
Boot + WebFlux
WebFlux +
functional bean registration
‣ Automatic server configuration
‣ All Spring Boot goodness!
‣ Bean registration
• Annotation-based
• Optimized Classpath scanning
‣ Reference webapp startup:
• 3 seconds
• 20 Mbytes heap size after GC
‣ Manual server configuration
‣ Bean registration
• Lambda-based
• No Cglib proxy
• No need for kotlin-spring plugin
‣ Reference webapp startup:
• 1.2 seconds
• 10 Mbytes heap size after GC

View Slide

See functional-bean-registration MiXiT branch
61
https://goo.gl/iGwzw3
AnnotationConfigApplicationContext {
registerBean { ReactiveMongoTemplate(SimpleReactiveMongoDatabaseFactory(
ConnectionString(it.environment.getProperty("mongo.uri"))))
}
registerBean()
registerBean()
registerBean()
registerBean()
registerBean()
// ...
}

View Slide

Spring Framework 5.0 Themes and Trends

Spring Framework 5.0 Themes and Trends

Sébastien Deleuze

More Decks by Sébastien Deleuze

Other Decks in Programming

Featured

Transcript
