Scheduling Applications at Scale

Tools like Docker and rkt make it easier than ever to package and distribute applications. Unfortunately, not all organizations have the luxury of being able to package their applications in a container runtime.

Many organizations have virtualized workloads that cannot be easily containerized, such as applications that require full hardware isolation or virtual appliances. On the opposite end of the spectrum, some organizations deploy workloads that are already static binaries such as Go applications or Java applications that only rely on the JVM. These types of applications do not benefit from containerization as they are already self-contained. To address the growing heterogeneity of workloads, HashiCorp created Nomad – a globally aware, distributed scheduler and cluster manager.

Nomad is designed to handle many types of workloads, on a variety of operating systems, at massive scale. Nomad empowers developers to specify jobs and tasks using a high-level specification in a plain-text file. Nomad accepts the job specification, parses the information, determines which compatible hosts have available resources, and then automatically manages the placement, healing, and scaling of the application. By placing multiple applications per host, Nomad maximizes resource utilization and dramatically reduces infrastructure costs.

The flexibility of Nomad’s design brings the benefits of a scheduled application workflow to organizations with heterogeneous workloads and operating systems. This talk will discuss the pros and cons of running in a scheduled environment and includes a series of live demos to supplement the learning experience.

Transcript

1. http://1stchoicesportsrehab.com/wp-content/uploads/2012/05/calendar.jpg Scheduling Applications at Scale Meeting Tomorrow's Application Needs, Today
2. SETH VARGO @sethvargo
5. Nomad Globally Distributed Optimistically Concurrent Scheduler
6. Nomad Globally Distributed Optimistically Concurrent Scheduler
7. sched·ul·er COMPUTING (n.) a program that arranges jobs or a computer's operations into an appropriate sequence.
8. NORMAL sched·ul·er (n.) a person or machine that organizes or maintains schedules.
9. Schedulers map a set of work to a set of resources
10. https://cdn.shopify.com/s/files/1/0167/3936/files/04-MS-Excel-4-0-Office-4-0_large.gif
11.   Operator Datacenter
12.   Operator Datacenter Skywalker Vader Leia Solo
13.   Operator Datacenter PYTHON PYTHON GOLANG GOLANG GOLANG Skywalker Vader Leia Solo
14.   Operator Datacenter RUBY PYTHON PYTHON PYTHON GOLANG GOLANG GOLANG GOLANG NODE Skywalker Vader Leia Solo
15.   Operator Datacenter RUBY PYTHON PYTHON PYTHON GOLANG GOLANG GOLANG GOLANG NODE Skywalker Vader Leia Solo RUBY VADER LEIA SOLO 192.168.1.4 192.168.1.5 192.168.1.7 192.168.1.253 88:45:13:B6:87:C4 94:CE:4F:C8:54:C3 CA:9A:3D:7F:8B:CB 72:30:9C:0D:1E:74 Randomly kills applications
16.   Operator Datacenter RUBY PYTHON PYTHON PYTHON GOLANG GOLANG GOLANG GOLANG NODE Skywalker Leia Solo RUBY VADER LEIA SOLO 192.168.1.4 192.168.1.5 192.168.1.7 192.168.1.253 88:45:13:B6:87:C4 94:CE:4F:C8:54:C3 CA:9A:3D:7F:8B:CB 72:30:9C:0D:1E:74 Randomly kills applications F F Vader
17.   Operator Datacenter RUBY PYTHON PYTHON PYTHON GOLANG GOLANG GOLANG GOLANG NODE Skywalker Leia Solo RUBY VADER LEIA SOLO 192.168.1.4 192.168.1.5 192.168.1.7 192.168.1.253 88:45:13:B6:87:C4 94:CE:4F:C8:54:C3 CA:9A:3D:7F:8B:CB 72:30:9C:0D:1E:74 Randomly kills applications F F Vader PYTHON PYTHON PYTHON
18.   Operator Datacenter RUBY GOLANG GOLANG GOLANG GOLANG NODE Skywalker Leia Solo RUBY VADER LEIA SOLO 192.168.1.4 192.168.1.5 192.168.1.7 192.168.1.253 88:45:13:B6:87:C4 94:CE:4F:C8:54:C3 CA:9A:3D:7F:8B:CB 72:30:9C:0D:1E:74 Randomly kills applications Vader PYTHON PYTHON PYTHON
19.   Operator Datacenter RUBY GOLANG GOLANG GOLANG GOLANG NODE Skywalker Leia Solo RUBY VADER LEIA SOLO 192.168.1.4 192.168.1.9 192.168.1.7 192.168.1.253 88:45:13:B6:87:C4 94:CE:4F:C8:54:C3 CA:9A:3D:7F:8B:CB 72:30:9C:0D:1E:74 Rebuilt on 04/20/2016 Vader PYTHON PYTHON PYTHON
20.   Operator Datacenter RUBY GOLANG GOLANG GOLANG GOLANG NODE Skywalker Leia Solo RUBY VADER LEIA SOLO 192.168.1.4 192.168.1.9 192.168.1.7 192.168.1.253 88:45:13:B6:87:C4 94:CE:4F:C8:54:C3 CA:9A:3D:7F:8B:CB 72:30:9C:0D:1E:74 Rebuilt on 04/20/2016 Vader PYTHON PYTHON PYTHON
21. This does not scale
22. CPU Scheduler CORE CORE CORE CORE CPU SCHEDULER KERNEL APACHE REDIS BASH
23. CPU Scheduler CORE CORE CPU SCHEDULER KERNEL APACHE REDIS BASH
24. Schedulers in the Wild Type Work Resources CPU Scheduler Threads Physical Cores EC2 / Nova Virtual Machines Hypervisors Hadoop YARN MapReduce Jobs Client Nodes Cluster Scheduler Applications Machines
25. Scheduler Advantages Higher Resource Utilization Decouple Work from Resources Better Quality of Service
26. Scheduler Advantages Bin Packing Over-Subscription Job Queueing Higher Resource Utilization Decouple Work from Resources Better Quality of Service
27. Scheduler Advantages Abstraction API Contracts Standardization Higher Resource Utilization Decouple Work from Resources Better Quality of Service
28. Scheduler Advantages Priorities Resource Isolation Pre-emption Higher Resource Utilization Decouple Work from Resources Better Quality of Service
29. Not a New Concept
30. Not Alone
31. Nomad
32. Nomad Cluster Scheduler Deployments Job Specification
33. job "redis" { datacenters = ["us-east-1"] task "redis" { driver = "docker" config { image = "redis:latest" } resources { cpu = 500 # Mhz memory = 256 # MB network { mbits = 10 dynamic_ports = ["redis"] } } } } example.nomad
34. Job specification declares what to run
35. Nomad determines how and where to run
36. Nomad abstracts work from resources
37. Nomad Higher Resource Utilization Decouple Work from Resources Better Quality of Service
38. Designing Nomad
39. Nomad Multi-Datacenter Multi-Region Flexible Workloads Job Priorities Bin Packing Large Scale Operationally Simple
40. Scaling Requirements Thousands of regions Tens of thousands of clients per region Thousands of jobs per region
41. Built on Experience GOSSIP CONSENSUS
42. Serf Cluster Management Gossip Based (P2P) Membership Failure Detection Event System
43. Serf Gossip Protocol Large Scale Production Hardened Operationally Simple
44. Consul Service Discovery Configuration Coordination (Locking) Central Servers + Distributed Clients
45. Consul Multi-Datacenter Raft Consensus Large Scale Production Hardened
46. Built on Experience GOSSIP CONSENSUS Mature Libraries Proven Design Patterns
47. Built on Experience GOSSIP CONSENSUS Mature Libraries Proven Design Patterns Lacking Scheduling Logic
48. Built on Research GOSSIP CONSENSUS
50. Optimistic vs Pessimistic Internal vs External State Single vs Multi Level Fixed vs Pluggable Service vs Batch Oriented
51. Nomad Inspired by Google Omega Optimistic Concurrency State Coordination Service & Batch workloads Pluggable Architecture
52. Consul Architecture CLIENT CLIENT CLIENT CLIENT CLIENT CLIENT SERVER SERVER SERVER REPLICATION REPLICATION RPC RPC LAN GOSSIP SERVER SERVER SERVER REPLICATION REPLICATION WAN GOSSIP
53. Consul Multi-Datacenter Servers per DC Failure Isolation Domain is the Datacenter
54. Single-Region Architecture SERVER SERVER SERVER CLIENT CLIENT CLIENT DC1 DC2 DC3 FOLLOWER LEADER FOLLOWER REPLICATION FORWARDING REPLICATION FORWARDING RPC RPC RPC
55. Multi-Region Architecture SERVER SERVER SERVER FOLLOWER LEADER FOLLOWER REPLICATION FORWARDING REPLICATION REGION B  GOSSIP REPLICATION REPLICATION FORWARDING REGION FORWARDING  REGION A SERVER FOLLOWER SERVER SERVER LEADER FOLLOWER
56. Nomad Region is Isolation Domain 1-N Datacenters Per Region Flexibility to do 1:1 (Consul) Scheduling Boundary
57. Data Model ALLOCATION JOB EVALUATION NODE
58. Evaluation ~= State Change
59. Evaluations Create / Update / Delete Job Node Up / Node Down Allocation Failed
60. Evaluations SCHEDULER func(Evaluation) => []AllocationUpdates
61. Evaluations SCHEDULER func(Evaluation) => []AllocationUpdates Service, Batch, System
62. Server Architecture Omega Class Scheduler Pluggable Logic Internal Coordination and State Multi-Region / Multi-Datacenter
63. Client Architecture Broad OS Support Host Fingerprinting Pluggable Drivers
64. Fingerprinting Type Examples Operating System Kernel, OS, Version Hardware CPU, Memory, Disk Apps (Capabilities) Docker, Java, Consul Environment AWS, GCE
65. Constrain Placement and Bin Pack
66. “Task Requires Linux, Docker, and PCI- Compliant Hardware” expressed as constraints in job file
67. “Task needs 512MB RAM and 1 Core” expressed as resource in job file
68. Execute Tasks Provide Resource Isolation Drivers
69. Containerized Virtualized Standalone Docker Qemu / KVM Java Jar Static Binaries rkt
70. Containerized Virtualized Standalone Docker Qemu / KVM Java Jar rkt Windows Server Containers Hyper-V Xen C# Static Binaries
71. Nomad Schedulers Fingerprints Drivers Job Specification
72. Nomad Single Binary No Dependencies Highly Available
73. Nomad Million Container Challenge 1,000 Jobs 1,000 Tasks per Job 5,000 Hosts on GCE 1,000,000 Containers
75. “ – Negative Nancy No one would ever need to schedule a million containers.
79. Nomad Globally Distributed Optimistically Concurrent Scheduler
80. Nomad Higher Resource Utilization Decouple Work from Resources Better Quality of Service
81. SETH VARGO @sethvargo QUESTIONS?
