Architecture of scalable and resilient apps with GraphQL & event-driven serverless

Architecture of scalable and resilient apps with GraphQL & event-driven serverless

Presents an architecture in which asynchronous serverless functions are triggered from an event system listening to database changes, where the functions execute business logic and update the database back with status and a GraphQL server streaming these changes back to client through subscriptions.

Using:
- [Hasura GraphQL Engine](https://github.com/hasura/graphql-engine)
- PostgreSQL on Amazon RDS
- AWS Lambda

Shahidh K Muhammed

October 06, 2018
Tweet

More Decks by Shahidh K Muhammed

Other Decks in Technology

Transcript

  1. shahidh_k
    AWS Community Day
    Bangalore
    Architecture of scalable and resilient apps with
    GraphQL, Amazon RDS and AWS Lambda
    1

    View Slide

  2. shahidh_k 2
    I’m Shahidh

    View Slide

  3. shahidh_k
    The Problem
    3

    View Slide

  4. shahidh_k
    Traditional architecture
    App
    Database
    API
    Payment microservice Restaurant microservice Delivery microservice
    4
    1. Scalable?
    2. Resilient?

    View Slide

  5. shahidh_k
    Moving towards scale & resilience
    5

    View Slide

  6. shahidh_k
    Async architecture
    App
    Database
    API
    Event system
    Payment processing
    Restaurant approval
    Delivery assignment
    Async microservices
    6

    View Slide

  7. shahidh_k
    Serverless
    7

    View Slide

  8. shahidh_k
    Serverless 
    $ cat index.js
    exports.function = (req, res) => {
    res.json({"message": "Hello World"});
    }
    8
    $ serverless functions deploy hello_world --trigger-http
    https://serverless.functions.net/hello_world
    $ curl https://serverless.functions.net/hello_world
    {"message": "Hello World"}

    View Slide

  9. shahidh_k
    Scalable!
    ● No OPS
    ● No VMs to manage
    ● Don’t need to worry about scaling
    ● Just write the code
    ● Deploy
    ● Scale for “free”
    Graphic Source
    9

    View Slide

  10. shahidh_k
    Resilient?
    ● Serverless functions are ephemeral
    ● No knowledge of state - async
    ● Trigger them on events
    ● Add retries to the mix
    ● We have resiliency
    10

    View Slide

  11. shahidh_k
    Example: Food ordering app
    Column | Value
    -------------------+---------------------------------------
    id | a705a43d-c55b-4a8a-ac16-80679bd02404
    created_at | 2018-09-23 13:24:32.159024+00
    user_id | eca786b6-73ae-44c7-b34f-1757af554464
    is_validated | false
    is_paid | false
    is_approved | false
    is_agent_assigned | false
    11

    View Slide

  12. shahidh_k
    Order state machine with serverless
    is_validated | false
    is_paid | false
    is_approved | false
    is_agent_assigned | false
    is_validated | true
    is_paid | false
    is_approved | false
    is_agent_assigned | false
    is_validated | true
    is_paid | true
    is_approved | false
    is_agent_assigned | false
    is_validated | true
    is_paid | true
    is_approved | true
    is_agent_assigned | false
    is_validated | true
    is_paid | true
    is_approved | true
    is_agent_assigned | true
    Checks
    payment
    New order
    Validate
    order
    Restaurant
    approval
    Agent
    assignment
    Completed
    12

    View Slide

  13. shahidh_k
    Architecture Recap
    ● Microservices became serverless
    functions
    ● Serverless functions are scalable by nature
    ● Database events trigger async serverless
    functions
    ● Resiliency by event source tool instead of
    in the API code
    ● Moved specific failure handling logic to
    generic failure handling
    13

    View Slide

  14. shahidh_k
    The cost
    14
    App
    Database
    API
    Event system
    Payment processing
    Restaurant approval
    Delivery assignment
    Generic Event System
    Event system
    Async Serverless Fns
    Payment processing
    Restaurant approval
    Delivery assignment

    View Slide

  15. shahidh_k
    High level overview
    Database
    Event system
    Payment
    processing
    Restaurant
    approval
    Delivery
    assignment
    Async serverless
    functions
    A
    Database
    API layer
    Payment
    microservice
    Restaurant
    microservice
    Delivery
    microservice
    Synchronous logic Asynchronous logic
    15

    View Slide

  16. shahidh_k
    However, there’s still one
    problem

    View Slide

  17. shahidh_k
    GraphQL
    17

    View Slide

  18. shahidh_k
    REST vs GraphQL
    Product Brand Category
    GET
    PUT
    POST
    PATCH
    DELETE
    GET
    PUT
    POST
    PATCH
    DELETE
    GET
    PUT
    POST
    PATCH
    DELETE
    ProductWithBrand
    18

    View Slide

  19. shahidh_k
    GraphQL changes the way
    we think about UI + API
    ● UI First modelling
    ● Makes API usage more natural
    ● Maps UI components to GraphQL queries
    ● Faster iterations - no back and forth b/n
    frontend-backend
    19

    View Slide

  20. shahidh_k
    GraphQL Subscriptions
    Consume async info from the backend without
    any worries
    It’s as if REST had a WATCH verb
    Datastore
    App
    20

    View Slide

  21. shahidh_k
    Let’s say I want to build...
    21

    View Slide

  22. shahidh_k
    Without GraphQL
    ● Polling from the client
    ● Websockets - custom API
    ● Community fragmentation
    ● Various patterns in different frameworks
    ● More work for the developer
    22

    View Slide

  23. shahidh_k
    With GraphQL
    ● Standardised spec
    ● All GraphQL Clients are compatible with all
    GraphQL Servers
    ● Client implementations available for all
    major platforms and frameworks
    ● Subscriptions: access to async info
    ● Less work for the developer
    23

    View Slide

  24. shahidh_k
    GraphQL Subscriptions
    App Datastore Process
    payment
    Validate
    order
    Agent
    assignme
    nt
    Restauran
    t approval
    New Order
    Complete
    24

    View Slide

  25. shahidh_k
    However, the cost is...
    25
    App
    Database
    API
    Event system
    Payment processing
    Restaurant approval
    Delivery assignment
    Generic Event System
    Event system
    Async Serverless Fns
    Payment processing
    Restaurant approval
    Delivery assignment
    GraphQL Server Subscriptions

    View Slide

  26. shahidh_k
    Traditional
    vs
    GraphQL + Serverless
    Architecture
    26

    View Slide

  27. shahidh_k
    Traditional architecture
    App
    Database
    API layer
    Payment microservice Restaurant microservice Delivery microservice
    27

    View Slide

  28. shahidh_k
    Moving towards scale & resilience
    App
    Database
    API
    Event system
    Payment processing
    Restaurant approval
    Delivery assignment
    Async microservices
    28

    View Slide

  29. shahidh_k
    GraphQL & Serverless architecture
    29
    App
    Database
    Payment processing
    Restaurant approval
    Delivery assignment
    Mutation/Subscriptions Async serverless functions

    View Slide

  30. shahidh_k
    Demo Time!
    30

    View Slide

  31. shahidh_k
    Food ordering app
    31
    https://serverless-demo-aws.hasura.app/order-app

    View Slide

  32. shahidh_k
    Food ordering app - scalable
    32
    https://serverless-demo-aws.hasura.app/analytics-app

    View Slide

  33. shahidh_k
    Food ordering app - resilient
    33
    https://serverless-demo-aws.hasura.app/console

    View Slide

  34. shahidh_k 34
    Thanks
    Questions?
