Java Framework for Database-Centric Web Engineering

Java Framework for Database-Centric Web Engineering

Presentation given at WebE 2001, 4th Workshop on Web Engineering (in conjunction with 10th International World Wide Web Conference), Hong Kong.

ABSTRACT: We present a database-centric approach to web site development in which both application and web content data are managed by a database. The development process is based on three main stages of information modelling, document content design and presentation specification. A Java framework based on the OMS object-oriented data management system has been developed to support the development life cycle from rapid prototyping through to operation. We describe how the framework supports access from heterogeneous clients and how it has been extended to include a web content manager.

Research paper: https://beatsigner.com/publications/signer_WebE2001.pdf

Beat Signer
PRO

May 20, 2001
Tweet

More Decks by Beat Signer

Other Decks in Science

Transcript

  1. Java Framework for Database-
    Centric Web Site Engineering
    Beat Signer, Michael Grossniklaus and Moira C. Norrie
    {signer, grossniklaus, norrie}@inf.ethz.ch
    Institute for Information Systems
    ETH Zurich

    View Slide

  2. Outline
    • Motivation
    • OMS Database Development Suite
    • XML Server Component
    • Customised Applications
    • Content Management Server

    View Slide

  3. Motivation
    • Current web interfaces to DB systems are
    ▪ Based on HTML and related technologies
    ▪ Optimised for large displays (> 640x480 pixels)
    • Trend to new types of devices with different
    browser capabilities
    ▪ WebPads, Handhelds (Palm, Handspring,... ), WAP-
    enabled mobile phones, NTT DoCoMo's I-Mode
    phones, Digital TV, ...
    ▪ Not suited for 1:1 rendering of most existing web sites

    View Slide

  4. Motivation...
    • Generic database interface instead of developing
    a new interface from scratch for every device type
    ▪ Use a technology which allows the separation of
    content from its presentation (XML)
    ▪ Rendering (XSL) based on the user agent type
    requesting the data

    View Slide

  5. OMS Database Development Suite
    Application Modelling
    OM
    Semantic Object Data Model
    Database & Application
    Design
    OMS Pro
    Rapid Prototyping System
    and Lightweight DBMS
    Implementation
    OMS Java
    Data Management System
    & Application Framework

    View Slide

  6. DB-Centric Web Site Development
    Information Model
    Document Content
    Document
    DB with
    Generic Browsers
    DB with
    Defaut Templates
    DB with Customised
    Templates

    View Slide

  7. XML Server Component
    OMS Java API
    OMS Java Workspace
    XML Servlet HTML Servlet WML Servlet
    Main Entry Servlet
    XML Server
    XML
    Browser
    HTML
    Browser
    WML
    Browser
    Delegation
    Builds XML
    based on JDOM
    XML + XSLT
    → Response

    View Slide

  8. Example
    XML Response





    Beat



    /images/ETH/beat.jpg






    Attributes
    Types
    Methods
    Links

    View Slide

  9. Application Development
    1. Prototype the OM model in OMS Pro
    2. Export to OMS Java
    • DDL (Data Definition Language), DML (Data
    Modification Language)
    3. Installation of XML Server with default XSL
    stylesheets and servlets
    4. Optional customisation of stylesheets and
    servlets

    View Slide

  10. Community Agenda

    View Slide

  11. Existing Solutions
    • Conventional content
    management systems
    • Document elements are
    stored in a DB
    • Databases brought to the
    web
    • Close relation between
    database type and page
    Document Based Approach Data Based Approach

    View Slide

  12. Content Management Server
    Application
    Objects
    CMComponents
    CMTemplates
    CMWorkflows CMGatekeepers
    CMContents

    View Slide

  13. Content Management Server...

    View Slide

  14. CMPage
    CMContainer
    CMNavigation
    CMContainer
    Content Management Server...
    CMText
    CMPicture
    CMText
    CMText
    GlobisEvent
    CMMixed
    CMMixed
    CMPicture
    CMText
    CMText
    CMLink

    View Slide

  15. Content Management Server...

    View Slide

  16. Conclusion
    • Database-Centric Web Engineering
    ▪ Support entire development process
    ▪ Manage document content and application objects
    • OMS Java Framework
    ▪ High-Level Data Management
    ▪ XML Server
    ▪ Content Management

    View Slide
