Customizing Envoy Proxy with WebAssembly

Envoy Proxy is the go-to proxy for cloud-native environments for its speed and extensibility which has made it a popular choice as a proxy at the edge and as sidecars for service mesh.

Envoy proxy’s extensibility comes in the form of filters which are written in CPP and compiled directly into an instance of Envoy. This limits the accessibility to developers who know CPP and requires maintaining and shipping different versions of the Envoy Proxy code. WebAssembly support is working to make this process easier and accessible to more people by allowing filters to be built in your favorite language (CPP, Rust, TinyGo and more), precompiled into WASM, and then run in a WASM vm inside of Envoy.

This presentation covers:
* Overview of WebAssembly, use cases and benefits
* How to build, share and use Envoy filters with WASM
* Overview of WebAssembly Hub

Watch the video https://youtu.be/8W23jt6741I
Try the Hub https://webassemblyhub.io
Join the community https://slack.solo.io
Learn more https://www.solo.io

Transcript

1. WebAssembly and Envoy Proxy Feb 06, 2020 Christian Posta Global Field CTO @christianposta Scott Weiss Principal Engineer @ilackarms
2. 2 | Copyright © 2020 01 02 03 04 Service Mesh Data Plane and Control Plane Traffic Patterns North/South vs. East/West Extending the Data Plane WebAssembly Agenda
3. 3 | Copyright © 2020 SERVICE MESH JOURNEY INNOVATION MODERNIZE TO MICROSERVICES SERVICE MESH MANAGEMENT ANY MESH - ANYWHERE ADAPTIVE SERVICE MESH
4. 4 | Copyright © 2020 What is a proxy? • A proxy applies policy to network traffic by acting as a middle-man between a client and server • Common proxies contain features for TCP and HTTP traffic, including: − TLS termination / Authorization / Security − Traffic Monitoring and Telemetry − Load Balancing, Health checks, Locality-aware routing & more • The popular Envoy Proxy exposes its features through TCP and HTTP filters Traditional Proxy Architecture
5. 5 | Copyright © 2020 Service Mesh - Service Proxies • The Service Mesh Architecture introduces a service proxy (Envoy Proxy) into every Kubernetes Pod • All TCP/HTTP traffic between pods is routed via the service proxies − Pods only ever connect directly to each other via to their “sidecar” proxy • Each service proxy acts as a personal firewall/gateway into and out of each individual pod • Together, the service proxies are known as the service-mesh data plane
6. 6 | Copyright © 2020 Service Mesh - Control Plane • Proxies retrieve their configuration from a centralized discovery service known as the control plane • The control plane combines information about the environment with user configuration to configure the proxies (data plane) • The control plane and data plane together constitute the service mesh • Service mesh manages the service-to-service communication (east-west traffic) 1 https://blog.envoyproxy.io/service-mesh-data-plane-vs-control-plane-2774e720f7fc
7. 7 | Copyright © 2020 API Gateway - Edge Proxy • While a service mesh manages traffic between services • API gateways manage the traffic between the service mesh (cluster) and the outside world, aka “the edge” • Acts as the “Gateway” for accessing heterogenous backends, e.g. in a microservices environment
8. 8 | Copyright © 2020 API Gateway vs Service Mesh EAST-WEST TRAFFIC NORTH-SOUTH TRAFFIC SERVICE I SERVICE II SERVICE III SERVICE IV SERVICE V
9. 9 | Copyright © 2020 API Gateway vs Service Mesh EAST-WEST TRAFFIC NORTH-SOUTH TRAFFIC SERVICE I SERVICE II SERVICE III SERVICE IV SERVICE V Everything is running Envoy
10. 10 | Copyright © 2020 Extending the Envoy Proxy Data Plane • Envoy processes traffic via pluggable modules called “filters” • These filters are chained together to process the request • Envoy ships with OOTB filters • Envoy supports extension with custom filters
11. 11 | Copyright © 2020 Extending Envoy Proxy - Adding Custom Filters CURRENTLY: − Write filter in C++ − Statically link it to Envoy (requires compiling Envoy) − Ship and deploy new version of Envoy
12. 12 | Copyright © 2020 Extending Envoy Proxy - Adding Custom Filters THE OLD WAY: − Write filter in C++ − Statically link it to Envoy (requires compiling Envoy) − Ship and deploy new version of Envoy
13. 13 | Copyright © 2020 Web Assembly? THE NEW WAY: WebAssembly WebAssembly (abbreviated Wasm) is a binary instruction format for a stack-based virtual machine Portable compilation of high-level languages like C/C++/Rust, enabling deployment on the web for client and server applications Envoy Proxy starting to introduce support for WebAssembly
14. 14 | Copyright © 2020 Extending Envoy Proxy - Adding Custom Filters THE NEW WAY: WebAssembly − Write filter in any language − Compile to .wasm module − Dynamically load in Envoy Proxy during runtime
15. 15 | Copyright © 2020 Extending Envoy Proxy - Adding Custom Filters THE NEW WAY: WebAssembly Benefits Include − Accessible to more developers beyond C++ − Eliminate need to customize, distribute and maintain a distro of Envoy Proxy − Reliability as Envoy and Module are isolated from each other − Solutions that use Envoy Proxy can also leverage WebAssembly − NOTE: Not recommended for production use (yet!)
16. 16 | Copyright © 2020 Introducing WebAssembly Hub and wasme Build, Deploy, and Publish • Write filter in any language • Compile to .wasm module • Dynamically load in Envoy Proxy during runtime • Publish and share filters
17. 17 | Copyright © 2020 https://webassemblyhub.io
18. 18 | Copyright © 2020 WebAssembly Hub • wasme CLI tool for interacting with the hub ◦ wasme build
19. 19 | Copyright © 2020 WebAssembly Hub • wasme CLI tool for interacting with the hub ◦ wasme build ◦ wasme deploy ◦ wasme push
20. 20 | Copyright © 2020 20 | Copyright © 2020 Demo
21. 21 | Copyright © 2020 TRY THE HUB webassemblyhub.io GITHUB github.com/solo-io/wasme DOCS docs.solo.io/web-assembly-hub/latest COMMUNITY slack.solo.io Links to View More
