It seeeeeez! - Computer Vision with OpenCV

A (more scientific) little workshop on computer vision with C++/OpenCV.

Transcript

1. It seeeeeez!
   Computer Vision with OpenCV
   Marcel Neidinger
   Department of Mathematics and Computer Science,
   University of Basel
   April 27, 2017


   View Slide

2. Derivation of Gradient Form for Images
   Introduce transformation V : R3 → R2
   (
   3
   x
   )
   yt →
   (
   2
   x − v1t
   )
   y − v2t (1)
   Rewrite I(x, y, t) = ˜
   I(V(x, y, t)) and use chain-rule for
   derivative
   gradI(x, y, t) = grad˜
   I(x − v1t, y − v2t) ·
   (
   1 0 −v1
   0 1 −v2
   )
   (2)
   We search for ∂I
   ∂t
   → third component
   ∂I
   ∂t
   = −
   (
   v1
   ·
   ∂I
   ∂x
   + v2
   ∂I
   ∂y
   )
   = −(grad˜
   I ·⃗
   v) (3)
   It seeeeeez! Computer Vision with OpenCV 2 / 1


   View Slide

3. Derivation of Gradient Form for Images
   Introduce transformation V : R3 → R2
   (
   3
   x
   )
   yt →
   (
   2
   x − v1t
   )
   y − v2t (1)
   Rewrite I(x, y, t) = ˜
   I(V(x, y, t)) and use chain-rule for
   derivative
   gradI(x, y, t) = grad˜
   I(x − v1t, y − v2t) ·
   (
   1 0 −v1
   0 1 −v2
   )
   (2)
   We search for ∂I
   ∂t
   → third component
   ∂I
   ∂t
   = −
   (
   v1
   ·
   ∂I
   ∂x
   + v2
   ∂I
   ∂y
   )
   = −(grad˜
   I ·⃗
   v) (3)
   It seeeeeez! Computer Vision with OpenCV 2 / 1


   View Slide

4. OpenCV is practical
   It seeeeeez! Computer Vision with OpenCV 3 / 1


   View Slide

5. OpenCV: History
   Started at Intel Research
   Cross-plattform library for CV
   Today: More then a CV Library (machine learning)
   It seeeeeez! Computer Vision with OpenCV 4 / 1


   View Slide

6. Programming OpenCV
   + =
   It seeeeeez! Computer Vision with OpenCV 5 / 1


   View Slide

7. Programming OpenCV
   + =
   It seeeeeez! Computer Vision with OpenCV 5 / 1


   View Slide

8. Programming OpenCV
   + =
   It seeeeeez! Computer Vision with OpenCV 5 / 1


   View Slide

9. Programming OpenCV
   + =
   It seeeeeez! Computer Vision with OpenCV 5 / 1


   View Slide

10. Programming OpenCV
    OpenCV is polygamous.
    - Florian Spiess
    It seeeeeez! Computer Vision with OpenCV 6 / 1


    View Slide

11. Programming OpenCV
    OpenCV is polygamous.
    - Florian Spiess
    We will still use C++ in this workshop.
    Why?
    It’s the root language of OpenCV(fastest)
    Most examples are in C++(followed by python)
    It seeeeeez! Computer Vision with OpenCV 6 / 1


    View Slide

12. Programming OpenCV
    OpenCV is polygamous.
    - Florian Spiess
    We will still use C++ in this workshop.
    Why?
    It’s the root language of OpenCV(fastest)
    Most examples are in C++(followed by python)
    I’m a c++ fanboy and this is my workshop
    It seeeeeez! Computer Vision with OpenCV 6 / 1


    View Slide

13. Loading an image
    #include
    int main(int argc, char** argv)
    {
    cv::Mat img;
    img = cv::imread(argv[1]);
    }
    It seeeeeez! Computer Vision with OpenCV 7 / 1


    View Slide

14. Displaying the image
    [...]
    cv::namedWindow(”debug”, cv::CV_WINDOW_AUTOSIZE);
    imshow(”debug”, img);
    while( true )
    {
    if( cv::waitKey(0) != −1 )
    {
    break;
    }
    }
    It seeeeeez! Computer Vision with OpenCV 8 / 1


    View Slide

15. Theory: Segmenting images
    It seeeeeez! Computer Vision with OpenCV 9 / 1


    View Slide

16. Segementation in OpenCV
    // Create new image to store greyscale
    cv::Mat imgGray, imgThresh;
    cv::cvtColor( img, imgGray, cv::CV_BGR2GRAY );
    // Threshold
    int value = 20;
    int maxval = 255;
    cv::threshold( imgGray, imgThresh, value, maxval,
    cv::THRESH_BINARY);
    dst(x, y) =
    {
    maxval, if src(x, y) > value
    0, else
    (4)
    It seeeeeez! Computer Vision with OpenCV 10 / 1


    View Slide

17. OpenCV: Finding contours
    std::vector > contours;
    std::vector hierarchy;
    cv::findContours( imgThresh, contours, hierarchy,
    CV_RETR_TREE, CV_CHAIN_APPROX_SIMPLE, cv::
    Point(0,0) );
    It seeeeeez! Computer Vision with OpenCV 11 / 1


    View Slide

18. OpenCV: Practical example
    Enough examples.
    Let’s write a tennis ball
    tracker
    It seeeeeez! Computer Vision with OpenCV 12 / 1


    View Slide

19. OpenCV: And moving images?
    VideoCapture cap(0);
    if( !cap.isOpened() )
    {
    return −1;
    }
    for(;;)
    {
    Mat frame;
    cap >> frame;
    // Treat like normal picture
    }
    It seeeeeez! Computer Vision with OpenCV 13 / 1


    View Slide

20. Beyond the scope
    This barely scratched the surface of what OpenCV can do
    Advanced object detection
    Advanced feature selection
    Advanced tracking and object recognition methods
    Video analysis capabilities
    Machine Learning Capabilities(Boosting, Cascaders, k-nearest
    Neighbor …)
    Support for OpenCL and CUDA
    Integration into e.g. TensorFlow
    It seeeeeez! Computer Vision with OpenCV 14 / 1


    View Slide

21. Beyond the scope
    This barely scratched the surface of what OpenCV can do
    Advanced object detection
    Advanced feature selection
    Advanced tracking and object recognition methods
    Video analysis capabilities
    Machine Learning Capabilities(Boosting, Cascaders, k-nearest
    Neighbor …)
    Support for OpenCL and CUDA
    Integration into e.g. TensorFlow
    Theorem
    Rule of Thumb: If there is an algorithm in computer vision,
    OpenCV has a highly optimized implementation readily available.
    It seeeeeez! Computer Vision with OpenCV 14 / 1


    View Slide

22. Questions?


    View Slide
