Business Intelligence в микросервисной архитектуре

SECR 2018
Евгений Виноградов
Яндекс.Деньги

В докладе пойдет речь о том, как поменялся подход к разработке BI с переходом компании к микросервисной архитектуре. Я затрону некоторые аспекты разработки хранилища и витрин данных, а также текущие тренды в этой области, которые оказались актуальны для нас.

Transcript

1. Business Intelligence in microservice architecture Evgenii Vinogradov Yandex.Money Software Engineering Conference Russia 2018 October 12-13 Moscow
4. From Greece to Moscow › Boat to Athens › Feet to Taxi › Athens Taxi to Airport › Flight › Moscow Taxi to Digital October › Profit! 5 11
5. How we built realtime BI › High load › Time to Show › Request time › Support architecture
6. We start with ETL 7 Data Warehouse ETL Cubes Source Source Source Reports
7. We start with ETL › Not so much sources › Data is highly aggregated › Gaps are rare and noticable 8
8. We start with ETL 9 Data Warehouse ETL Cubes/Data Marts Source Source Source Reports API
9. Then we add Backoffice interface › More frequent ETL runs › Source should be prepared 10
10. And SLA › Data Update time › Interface Update time › Monitoring 11 Time To Show
11. Testing › Load testing – sources › Load testing – ETL/API › Load Testing – Together › ETL – just pause › And it is not so hard to create › (You can test ETL with just pause) 12
12. Then we start microservicing 13
13. Then we start microservicing 14 Data Warehouse ETL Cubes/Data Marts Source Source Source Reports API
14. Then we start microservicing 15 Data Warehouse ETL Cubes/Data Marts Reports API Source Source Source Source Source Source
15. Then we start microservicing 16 Data Warehouse ETL Cubes/Data Marts Reports API ETL ETL Source Source Source Source Source Source
16. We start with ETL 17 Data Warehouse ETL Cubes/ Data Marts Source Reports Source Source Source Source Source API ETL ETL Aggreg ation
17. Then we start microservicing › A lot of sources give less aggregated and integrated data › One (or more) aggregtation layer › Data Update Time = [delay] * [sources per aggregation] 18
18. Then we start microservicing › Unique Identifier Issue › Aggregation rules sync › ETL still is pretty good 19
19. Update strategies: trade request time for process time and load › Load -> Store -> Show › Load -> Aggregate -> Store -> Show › Load -> Store -> Aggregate -> Show › Load -> Aggregate -> Store - > Update -> Show › Load -> Aggregate -> Store - > Update -> Show 20
20. Update strategies: trade request time for process time and load › Load -> Store -> Show › Load -> Aggregate -> Store -> Show › Load -> Store -> Aggregate -> Show › Load -> Aggregate -> Store - > Update -> Show › Load -> Aggregate -> Store - > Update -> Show 21
21. Drawbacks › Sources still have to store a cache of data › Sources have to preserve timelime (replication point) › Request portion can be huge 22
22. Then we go to events 23 Data Warehouse ETL Cubes/ Data Marts Reports API ETL ETL Aggreg ation Source Source Source Source Source Source
23. Then we go to events 24 Data Warehouse Events Cubes/ Data Marts Reports API ETL ETL Aggreg ation Source Source Source Source Source Source
24. Then we go to events 25 Data Warehouse Events Cubes/ Data Marts Reports API ETL ETL Aggreg ation Aggre gation Source Source Source Source Source Source
25. Update strategies: trade request time for process time and load › Load -> Store -> Show › Load -> Aggregate -> Store -> Show › Load -> Store -> Aggregate -> Show › Load -> Aggregate -> Store - > Update -> Show › Load -> Aggregate -> Store - > Update -> Show › Load -> Construct -> Aggregate -> Store -> Show 26 11
26. Now › We still have ETL for aggregations › Time To Show: 10 sec / source › Source type count: close to 100 27
27. Starring › Data Warehouse: MS SQL Server › ETL: SSIS › Events queue: Kafka › Events reader: С# › Other Sources: API/Java/etc › Out of scope: sharding, downtime, processing, etc 28
28. Key takeaways › ETL works fine with Events › Find sufficient unique identifier among data sources › Metrics: Time to Show and others 29
29. dm_jonny jonny@yamoney.ru Questions? Evgenii VInogradov Head of BI development 30
