The iOS Developer’s Introduction to Vapor (3)

Server-side Swift has been around for a couple of years and as time goes by the maturity of putting Swift on the server grows. With this talk, I will give an introduction to one of the most popular server-side Swift frameworks called Vapor, which recently released a new major version. I will talk a bit about how I ended up doing server-side Swift development after working with iOS for years and I’ll look at the potential synergy between Vapor and iOS. This talk requires no prior knowledge to server-side Swift.

Transcript

1. Introduction to Vapor
   The Developer’s
   3


   View Slide

2. " Head of Vapor Development at Nodes
   Full time Vapor developer since January 2017
   Background in iOS development
   ~50 customer projects and ~40 packages
   @steffendsommer


   View Slide

3. View Slide

4. “Platform support for all Apple platforms as well as
   Linux”


   View Slide

5. View Slide

6. A web framework built in Swift
   Official support for SQLite, MySQL, PostgreSQL and Redis
   Built on top of SwiftNIO



   View Slide

7. View Slide

8.
   Frontend Backend
   Static websites
   Dynamic websites
   API


   View Slide

9. Backend
   API
   Android application
   iOS application
   Single page application
   Illustration borrowed from Jonas Schwartz


   View Slide

10. 1.0
    Sep, 2016
    2.0
    May, 2017
    3.0
    April, 2018
    0.1
    Jan, 2016
    Timeline borrowed from Tanner Nelson


    View Slide

11. ⚙ Configs
    Codable
    Async


    View Slide

12. import Vapor
    let app = try Application()
    let router = try app.make(Router.self)
    router.get("hello") { req in
    return "Hello, world."
    }
    try app.run()



    View Slide

13. Strong, safe and modern language
    Fast and has a low memory footprint (aka. )
    Tech awesomeness
    ♻ Potential synergy between iOS and Vapor


    View Slide

14. ♻
    Models
    ⚠ Errors
    Frameworks used in both places
    Endpoints & Environments
    Business logic
    Styling
    Test code (e.g. mocks)
    ✅ Validation
    ☂ A framework that wraps the endpoints


    View Slide

15. Modern and Swifty API’s
    Great community
    Growing eco system
    Most popular



    View Slide

16.
    Everything is “new”
    Tooling
    ⚙ Foundation
    Eco system
    Resources


    View Slide

17. ≠


    View Slide

18. Number of users
    1
    ≠
    ∞



    View Slide

19. Performance
    ?
    ≠
    < 2 sec



    View Slide

20. Performance
    Free
    ≠
    Pricy



    View Slide

21. Platforms
    iOS
    tvOS
    macOS
    watchOS
    ≠
    macOS
    Linux



    View Slide

22. Bug fixing
    Next release cycle
    ≠
    Fix it now



    View Slide

23. User Interfaces
    Storyboards
    Auto Layout
    Xib
    ≠
    HTML
    CSS
    JavaScript

    Leaf



    View Slide

24. The Xcode Project File
    Merge madness
    ≠
    What file?



    View Slide

25. State
    Used when needed
    ≠
    It’s all about the request



    View Slide

26. Persistence
    Used
    ≠
    Very central



    View Slide

27. Architecture
    MVC
    MVVM
    MVP
    VIPER
    ≠
    MVC



    View Slide

28. ?


    View Slide

29. https://www.serversideswift.work


    View Slide

30. Create a new post
    Show all published posts, sorted by a publish date
    Show details of a single post


    View Slide

31. brew install vapor/tap/vapor
    1


    View Slide

32. vapor new ServerSideSwiftWork
    2


    View Slide

33. vapor xcode
    3


    View Slide

34. View Slide

35. http://localhost:8080/hello


    View Slide

36. SQLite
    Fluent
    Leaf



    View Slide

37. View Slide

38. // swift-tools-version:4.2
    import PackageDescription
    let package = Package(
    name: "ServerSideSwiftWork",
    dependencies: [
    // A server-side Swift web framework.
    .package(url: "https://github.com/vapor/vapor.git", from: "3.0.0"),
    // Swift ORM (queries, models, relations, etc) built on SQLite 3.
    .package(url: "https://github.com/vapor/fluent-sqlite.git", from: "3.0.0"),
    // Template engine
    .package(url: "https://github.com/vapor/leaf.git", from: "3.0.1"),
    ],
    targets: [
    .target(name: "App", dependencies: ["Leaf", "FluentSQLite", "Vapor"]),
    .target(name: "Run", dependencies: ["App"]),
    .testTarget(name: "AppTests", dependencies: ["App"])
    ]
    )


    View Slide

39. View Slide

40. final class Work: Codable {
    public var id: Int?
    public var company: String
    public var location: String
    public var title: String
    public var description: String
    public var externalUrl: String
    public var publishedAt: Date?
    public init(
    company: String,
    location: String,
    title: String,
    description: String,
    externalUrl: String,
    publishedAt: Date? = nil
    ) {
    self.company = company
    self.location = location
    self.title = title
    self.description = description
    self.externalUrl = externalUrl
    self.publishedAt = publishedAt
    }
    }


    View Slide

41. extension Work: SQLiteModel {}
    extension Work: Migration {}
    extension Work: Content {}
    extension Work: Parameter {}


    View Slide

42. View Slide

43. func create(_ req: Request) throws -> Future {
    return try req
    .content
    .decode(Work.self)
    .save(on: req)
    }


    View Slide

44. func index(_ req: Request) throws -> Future {
    return Work
    .query(on: req)
    .filter(\.publishedAt != nil)
    .sort(\.publishedAt, .descending)
    .all()
    }


    View Slide

45. struct ViewData: Codable {
    let work: [Work]
    }
    func renderIndex(_ req: Request) throws -> Future {
    return Work
    .query(on: req)
    .filter(\.publishedAt != nil)
    .sort(\.publishedAt, .descending)
    .all()
    .flatMap { items in
    try req.view().render("index", ViewData(work: items))
    }
    }


    View Slide

46. func show(_ req: Request) throws -> Future {
    return try req
    .parameters
    .next(Work.self)
    }


    View Slide

47. View Slide

48. Work

    #for(item in work) {

    #(item.title) at #(item.company)

    #(item.description)

    }



    View Slide

49. View Slide

50. public func routes(_ router: Router) throws {
    let workController = WorkController()
    router.get("api/work", use: workController.index)
    router.get("api/work", Work.parameter, use: workController.show)
    router.post("api/work", use: workController.create)
    router.get("work", use: workController.renderIndex)
    }


    View Slide

51. ⚙


    View Slide

52. public func configure(_ config: inout Config, _ env: inout Environment, _ services: inout Services) throws {
    /// Register providers first
    try services.register(FluentSQLiteProvider())
    try services.register(LeafProvider())
    config.prefer(LeafRenderer.self, for: ViewRenderer.self)
    /// Register routes to the router
    let router = EngineRouter.default()
    try routes(router)
    services.register(router, as: Router.self)
    /// Register middleware
    var middlewares = MiddlewareConfig()
    middlewares.use(ErrorMiddleware.self)
    services.register(middlewares)
    // Configure a SQLite database
    let sqlite = try SQLiteDatabase(storage: .memory)
    /// Register the configured SQLite database to the database config.
    var databases = DatabasesConfig()
    databases.add(database: sqlite, as: .sqlite)
    services.register(databases)
    /// Configure migrations
    var migrations = MigrationConfig()
    migrations.add(model: Work.self, database: .sqlite)
    services.register(migrations)
    }


    View Slide

53. View Slide

54. try services.register(FluentSQLiteProvider())
    try services.register(LeafProvider())
    config.prefer(LeafRenderer.self, for: ViewRenderer.self)


    View Slide

55. let router = EngineRouter.default()
    try routes(router)
    services.register(router, as: Router.self)


    View Slide

56. let sqlite = try SQLiteDatabase(storage: .memory)
    var databases = DatabasesConfig()
    databases.add(database: sqlite, as: .sqlite)
    services.register(databases)


    View Slide

57. var migrations = MigrationConfig()
    migrations.add(model: Work.self, database: .sqlite)
    services.register(migrations)


    View Slide

58. View Slide

59. View Slide

60. View Slide

61. View Slide

62. GET http://localhost:8080/work


    View Slide

63.
    Yes, async is hard at first
    RxSwift/ReactiveSwift can be a plus
    Async/await would be great


    View Slide

64. ☁


    View Slide

65. View Slide

66. vapor cloud deploy


    View Slide

67. https://vapor.cloud


    View Slide

68. Multiple regions and cloud providers
    Custom docker templates
    ♻ Internal DNS setup
    Build pipeline
    ✏ Releases and rollback
    Public API
    Database IP
    Built-in Git server
    Commands in separate replicas
    ⚙ Loadbalancer configuration
    More statistics
    All features in the dashboard
    Config updates without redeployment
    And much more…
    Version 2


    View Slide

69. Public alpha
    Now-ish
    Week 40-41


    View Slide

70. https://docs.vapor.codes
    https://discord.gg/vapor
    Tim Condon - Getting Started with Server Side Swift and
    Vapor (Codemobile 2018)
    ? https://www.serversideswift.work
    https://www.serversideswift.info


    View Slide

71. View Slide

72. View Slide

73.
    @steffendsommer


    View Slide
