A tour of Ansible

A guided tour of Ansible's awesome features and capabilities. Learn how a complex tool can simply automate your infrastructure.

Transcript

1. Provisioning, Config, Execution, (more) Fun


   View Slide

2. Steve Pereira
   18 years in IT
   Startups and Enterprise
   Love learning about,
   teaching and talking about:
   • DevOps
   • CI/CD
   • Automation
   • Scale
   WHO AM I?


   View Slide

3. ANSIBLE FEATURES
   • Automation for local and remote system provisioning
   • Automation for local and remote applications deployment
   • No agents to install on remote systems
   • Using existing SSHd on remote systems and native SSH on host
   • Parallel by default - scale to 6000 targets with single master
   • Language that approaches plain english


   View Slide

4. ANSIBLE CONVENTIONS
   Playbooks - contain required tasks to configure systems and deploy
   Tasks - individual actions to perform on remote or local machines
   Roles - modular, single-purpose configurations for systems
   Inventory - files containing address information of target machines
   Handlers - actions triggered by tasks
   Templates - customizable files destined for managed machines


   View Slide

5. MINIMUM VIABLE ANSIBLE
   $ ansible all -i 'localhost,' -c local -m ping
   localhost | success >> {
   "changed": false,
   "ping": "pong"
   }


   View Slide

6. WHAT ELSE?
   • ansible webservers -m setup
   • ansible lb -m copy -a "src=hosts dest=/tmp/hosts”
   • ansible webservers -m yum -a "name=curl state=installed”
   • ansible webservers -m service -a "name=nginx
   state=restarted”
   • ansible-doc -l


   View Slide

7. PLAYBOOKS
   ---
   - hosts: webservers
   vars:
   http_port: 80
   max_clients: 200
   remote_user: root
   tasks:
   - name: ensure apache is at the latest version
   yum: pkg=httpd state=latest
   - name: write the apache config file
   template: src=/srv/httpd.j2 dest=/etc/httpd.conf
   notify:
   - restart apache
   - name: ensure apache is running (and enable it at boot)
   service: name=httpd state=started enabled=yes
   handlers:
   - name: restart apache
   service: name=httpd state=restarted
   example_playbook.yml


   View Slide

8. PLAYBOOKS
   ---
   - hosts: webservers
   vars:
   http_port: 80
   max_clients: 200
   remote_user: root
   tasks:
   - name: ensure apache is at the latest version
   yum: pkg=httpd state=latest
   - name: write the apache config file
   template: src=/srv/httpd.j2 dest=/etc/httpd.conf
   notify:
   - restart apache
   - name: ensure apache is running (and enable it at boot)
   service: name=httpd state=started enabled=yes
   handlers:
   - name: restart apache
   service: name=httpd state=restarted
   example_playbook.yml


   View Slide

9. PLAYBOOKS
   ---
   - hosts: webservers
   vars:
   http_port: 80
   max_clients: 200
   remote_user: root
   tasks:
   - name: ensure apache is at the latest version
   yum: pkg=httpd state=latest
   - name: write the apache config file
   template: src=/srv/httpd.j2 dest=/etc/httpd.conf
   notify:
   - restart apache
   - name: ensure apache is running (and enable it at boot)
   service: name=httpd state=started enabled=yes
   handlers:
   - name: restart apache
   service: name=httpd state=restarted
   example_playbook.yml


   View Slide

10. PLAYBOOKS
    ---
    - hosts: webservers
    vars:
    http_port: 80
    max_clients: 200
    remote_user: root
    tasks:
    - name: ensure apache is at the latest version
    yum: pkg=httpd state=latest
    - name: write the apache config file
    template: src=/srv/httpd.j2 dest=/etc/httpd.conf
    notify:
    - restart apache
    - name: ensure apache is running (and enable it at boot)
    service: name=httpd state=started enabled=yes
    handlers:
    - name: restart apache
    service: name=httpd state=restarted
    example_playbook.yml


    View Slide

11. PLAYBOOKS
    ---
    - hosts: webservers
    vars:
    http_port: 80
    max_clients: 200
    remote_user: root
    tasks:
    - name: ensure apache is at the latest version
    yum: pkg=httpd state=latest
    - name: write the apache config file
    template: src=/srv/httpd.j2 dest=/etc/httpd.conf
    notify:
    - restart apache
    - name: ensure apache is running (and enable it at boot)
    service: name=httpd state=started enabled=yes
    handlers:
    - name: restart apache
    service: name=httpd state=restarted
    example_playbook.yml


    View Slide

12. PLAYBOOKS
    ---
    - hosts: webservers
    vars:
    http_port: 80
    max_clients: 200
    remote_user: root
    tasks:
    - name: ensure apache is at the latest version
    yum: pkg=httpd state=latest
    - name: write the apache config file
    template: src=/srv/httpd.j2 dest=/etc/httpd.conf
    notify:
    - restart apache
    - name: ensure apache is running (and enable it at boot)
    service: name=httpd state=started enabled=yes
    handlers:
    - name: restart apache
    service: name=httpd state=restarted
    example_playbook.yml


    View Slide

13. PLAYBOOKS
    ---
    - hosts: webservers
    vars:
    http_port: 80
    max_clients: 200
    remote_user: root
    tasks:
    - name: ensure apache is at the latest version
    yum: pkg=httpd state=latest
    - name: write the apache config file
    template: src=/srv/httpd.j2 dest=/etc/httpd.conf
    notify:
    - restart apache
    - name: ensure apache is running (and enable it at boot)
    service: name=httpd state=started enabled=yes
    handlers:
    - name: restart apache
    service: name=httpd state=restarted
    example_playbook.yml


    View Slide

14. ROLES
    my_role/
    README.md (readme)
    defaults/ (default values)
    meta/ (role metadata)
    files/ (binaries)
    templates/ (file templates)
    handlers/ (operation handlers)
    tasks/ (playbook files)
    vars/ (custom variables)
    • Easily packaged and shared
    • Download community roles
    • Mix and match


    View Slide

15. INVENTORY
    • Define how ansible will interact with remote hosts
    • Define logical groups of managed nodes
    • One file for each environment
    • Default location : /etc/ansible/hosts
    • INI format, variable overrides
    sample_inventory.ini [loadbalancers]
    10.20.30.41
    10.20.30.42
    [webservers]
    10.20.30.51 hostname=artemis
    10.20.30.52 hostname=apollo


    View Slide

16. TEMPLATES
    • Use Jinja2 templating and variables to customize
    • Defaults available when variables not provided (dev default with prod override)
    etc_logrotate.d.j2 {{ logfile }} {
    rotate {{ 7 | rotate_max }}
    {{ daily | frequency }}
    compress
    missingok
    notifempty
    }


    View Slide

17. IT CAN GET FANCY
    tasks:
    - name: install packages in a users virtualenv
    shell: su - c {{ item[0] }} '(. ./bin/activate && pip install {{ item[1] }})'
    with_nested:
    - [ 'jim', 'joe', 'jack' ]
    - [ package1==1.1,
    package2==1.2,
    package3==1.3 ]
    There are several types of loops:
    Hashes, Fileglobs, Sequence, Subelements, First match, Command results, Random and
    more
    but there’s a builtin pip module, anyways.


    View Slide

18. CONDITIONALS
    tasks:
    - command: /bin/false
    register: result
    ignore_errors: True
    - command: /bin/something
    when: result|failed
    - command: /bin/something_else
    when: result|success
    - command: /bin/still/something_else
    when: result|skipped
    The result of a play can depend on
    the value of a variable, fact
    (something learned about the
    remote system), or previous task
    result.


    View Slide

19. MORE CONDITIONALS!
    tasks:
    - shell: echo "I've got '{{ foo }}'"
    when: foo is defined
    - fail: msg="This play requires 'bar'"
    when: bar is not defined
    - command: echo {{ item }}
    with_items: [ 0, 2, 4, 6, 8, 10 ]
    when: item > 5
    If a required variable has not been
    set, you can skip or fail using
    Jinja2’s defined test. For example:


    View Slide

20. SIMPLE, POWERFUL BUILTINS
    • 261 built-in modules
    • Many cloud providers, packages and tools are integrated
    • Easily add your own in any language
    examples: • ec2 - Create, terminate, start/stop an instance
    • docker - Manage docker containers
    • hipchat Send a message to hipchat
    • s3 - manage objects in S3
    • twilio - Sends a text message to a phone
    • win_service - Manages Windows services
    • zfs - Manage zfs


    View Slide

21. SMOOTH OPERATION
    • Get and set variables easily
    • Simple variable precedence
    • Ordered, predictable execution
    • Tagged, resumable execution
    • ansible doc [foo]


    View Slide

22. SECURITY
    •Can be centralized and locked down via Ansible Tower
    •Can be run from a centralized bastion server
    •Vault encrypts sensitive data
    •Uses ordinary SSH, paramiko or custom transport plugins
    •No extra open ports, use your own user account, sudo!
    •No agents to update or risk vulnerabilities


    View Slide

23. ENTERPRISE GRADE
    •Tower integration with LDAP and AD for RBAC
    •Manage any number of servers across many Tower instances
    •Portal and dashboard views, pushbutton interaction
    •Job scheduling
    •Audit trail
    •High availability


    View Slide

24. ENTERPRISE USE


    View Slide

25. ADVANCED CAPABILITIES
    •Rolling updates/deployment/orchestration (1, 5, n at a time)
    •Canary testing (check for page content or response code)
    •Custom execution paths based on response/error/environment
    •Variable timeouts and parellelism
    •Ansible-pull to invert execution - nodes check in to a master


    View Slide

26. MORE INFORMATION
    https://docs.ansible.com
    http://www.ansible.com/tower
    https://docs.ansible.com/playbooks_best_practices.html
    https://galaxy.ansible.com
    https://github.com/ansible/ansible-examples


    View Slide

27. QUESTIONS?
    @steveElsewhere
    steve@stevepereira.ca
    http://linkedin.com/in/devopsto


    View Slide

28. THANK YOU!
    http://devopsdays.org/events/2015-toronto
    (shameless plug)


    View Slide
