How to Test Your Compose UI

While Compose is easy to adopt, not creating legacy code right at the start of such a journey requires extra planning, awareness, and, most importantly, testing. We'll have a look at how we can test pure Compose UIs as well as hybrid ones that have Views and composables too.

In this talk, we'll learn what the semantics tree is, its relation to the composition, how we can manipulate it in composables using the Semantics modifier, how we can implement composables with testability in mind, and how we can test pure Compose, and hybrid UIs.

I gave this talk in the Kotlin devroom of FOSDEM 2023 in Brussels on 2023.02.04.

Transcript

1. stewemetal
   istvanjuhos.dev
   How to Test Your Compose UI
   István Juhos


   View Slide

2. #fosdem23 – @stewemetal istvanjuhos.dev
   Source of examples
   github.com/stewemetal/composehydrationtracker


   View Slide

3. #fosdem23 – @stewemetal istvanjuhos.dev
   Testing Views - Recap ☕
   • View(Group) objects with rendering and behavior
   • Views are inflated from XML descriptors or instantiated in code
   • Views are directly referrable by View IDs


   View Slide

4. #fosdem23 – @stewemetal istvanjuhos.dev
   Testing Compose UI
   🧪


   View Slide

5. #fosdem23 – @stewemetal istvanjuhos.dev
   Testing Compose UI
   • No direct access to the Composition
   • No UI objects to look up directly
   • No UI element IDs
   • Not every Composable emits UI
   ❌
   ❌
   ❌
   ❌
   🧪


   View Slide

6. #fosdem23 – @stewemetal istvanjuhos.dev
   @Composable
   fun EntryList(
   entries: List = emptyList(),
   ) {
   LazyColumn {
   items(entries) { item ->
   HydrationItem(item = item)
   }
   }
   }
   @Composable
   fun HydrationItem(item: HydrationEntry) {
   Row(
   modifier = Modifier
   .wrapContentHeight(
   align = Alignment.CenterVertically,
   Composables to test: EntryList
   #fosdem23 – @stewemetal
   EntryList
   HydrationItem


   View Slide

7. #fosdem23 – @stewemetal istvanjuhos.dev
   HydrationItem(item = item)
   }
   }
   }
   @Composable
   fun HydrationItem(item: HydrationEntry) {
   Row(
   modifier = Modifier
   .wrapContentHeight(
   align = Alignment.CenterVertically,
   )
   .padding(16.dp)
   ) {
   Text(
   "${item.milliliters} ml",
   modifier = Modifier.weight(1f),
   )
   Text("${item.dateTime}")
   }
   }
   Composables to test: HydrationItem
   HydrationItem
   EntryList
   #fosdem23 – @stewemetal


   View Slide

8. #fosdem23 – @stewemetal istvanjuhos.dev
   Setting up Compose UI tests


   View Slide

9. #fosdem23 – @stewemetal istvanjuhos.dev
   "// Test rules and transitive dependencies:
   androidTestImplementation "androidx.compose.ui:ui-test-junit4"
   "// Needed for createComposeRule, but not createAndroidComposeRule:
   debugImplementation "androidx.compose.ui:ui-test-manifest"
   Setting up Compose UI tests
   implementation platform("androidx.compose:compose-bom:$compose_bom_version")


   View Slide

10. #fosdem23 – @stewemetal istvanjuhos.dev
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4!::class)
    class EntryListTest {
    !// !!...
    }
    create ComposeRule ()
    Android
    @get:Rule
    val composeTestRule =


    View Slide

11. #fosdem23 – @stewemetal istvanjuhos.dev
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4!::class)
    class EntryListTest {
    !// !!...
    }
    create ComposeRule ()
    Android
    @get:Rule
    val composeTestRule =


    View Slide

12. #fosdem23 – @stewemetal istvanjuhos.dev
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4!::class)
    class EntryListTest {
    !// !!...
    }
    create ComposeRule ()
    Android
    @get:Rule
    val composeTestRule =


    View Slide

13. #fosdem23 – @stewemetal istvanjuhos.dev
    Setting up Compose UI tests
    @RunWith(AndroidJUnit4!::class)
    class EntryListTest {
    !// !!...
    }
    createComposeRule()
    @get:Rule
    val composeTestRule =


    View Slide

14. #fosdem23 – @stewemetal istvanjuhos.dev
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }
    A simple UI test
    createComposeRule()
    @get:Rule val composeTestRule =


    View Slide

15. #fosdem23 – @stewemetal istvanjuhos.dev
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }


    View Slide

16. #fosdem23 – @stewemetal istvanjuhos.dev
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }


    View Slide

17. #fosdem23 – @stewemetal istvanjuhos.dev
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }


    View Slide

18. #fosdem23 – @stewemetal istvanjuhos.dev
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }


    View Slide

19. #fosdem23 – @stewemetal istvanjuhos.dev
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }
    private val entries = listOf(
    HydrationEntry(…),
    HydrationEntry(…),
    HydrationEntry(…),
    )


    View Slide

20. #fosdem23 – @stewemetal istvanjuhos.dev
    A simple UI test
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }
    So, how can we act or assert on EntryList? 🤔


    View Slide

21. #fosdem23 – @stewemetal istvanjuhos.dev
    The semantics tree 🌳


    View Slide

22. #fosdem23 – @stewemetal istvanjuhos.dev
    The semantics tree 🌳
    • A parallel tree next to the Composition 🌲🌳
    • Used for accessibility and testing
    • Composables (can) contribute to the semantics tree


    View Slide

23. #fosdem23 – @stewemetal istvanjuhos.dev
    The semantics tree 🌳
    composeTestRule.apply {
    setContent {
    Text("100 ml")
    }
    }
    Semantics tree
    root node
    Semantic node with text
    "100 ml"


    View Slide

24. #fosdem23 – @stewemetal istvanjuhos.dev
    The semantics tree 🌳
    composeTestRule.apply {
    setContent {
    Text("100 ml")
    }
    }
    Root
    Text = '[100 ml]'


    View Slide

25. #fosdem23 – @stewemetal istvanjuhos.dev
    The semantics tree 🌳
    composeTestRule.apply {
    setContent {
    Row {
    Text("100 ml")
    }
    }
    }
    Root
    Text = '[100 ml]'


    View Slide

26. #fosdem23 – @stewemetal istvanjuhos.dev
    The semantics tree 🌳
    composeTestRule.apply {
    setContent {
    Row {
    Text("100 ml")
    Text("2023-02-04")
    }
    }
    }
    Text = '[100 ml]' Text = '[2023-02-04]'
    Root


    View Slide

27. #fosdem23 – @stewemetal istvanjuhos.dev
    Visualizing the semantics tree 🌳👀
    Text = '[100 ml]' Text = '[2023-02-04]'
    Root
    Row {
    Text("100 ml")
    Text("2023-02-04")
    }


    View Slide

28. #fosdem23 – @stewemetal istvanjuhos.dev
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts") Text = '[100 ml]' Text = '[2023-02-04]'
    Root


    View Slide

29. #fosdem23 – @stewemetal istvanjuhos.dev
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts")
    D/RowAndTexts: printToLog:
    Printing with useUnmergedTree = 'false'
    Node #1 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    |-Node #2 at (l=0.0, t=66.0, r=136.0, b=125.0)px
    | Text = '[100 ml]'
    | Actions = [GetTextLayoutResult]
    |-Node #3 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    Text = '[2023-02-04]'
    Actions = [GetTextLayoutResult]
    Text = '[100 ml]' Text = '[2023-02-04]'
    Root


    View Slide

30. #fosdem23 – @stewemetal istvanjuhos.dev
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts")
    D/RowAndTexts: printToLog:
    Printing with useUnmergedTree = 'false'
    Node #1 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    |-Node #2 at (l=0.0, t=66.0, r=136.0, b=125.0)px
    | Text = '[100 ml]'
    | Actions = [GetTextLayoutResult]
    |-Node #3 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    Text = '[2023-02-04]'
    Actions = [GetTextLayoutResult]
    Text = '[100 ml]' Text = '[2023-02-04]'
    Root


    View Slide

31. #fosdem23 – @stewemetal istvanjuhos.dev
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts")
    D/RowAndTexts: printToLog:
    Printing with useUnmergedTree = 'false'
    Node #1 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    |-Node #2 at (l=0.0, t=66.0, r=136.0, b=125.0)px
    | Text = '[100 ml]'
    | Actions = [GetTextLayoutResult]
    |-Node #3 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    Text = '[2023-02-04]'
    Actions = [GetTextLayoutResult]
    Text = '[100 ml]' Text = '[2023-02-04]'
    Root


    View Slide

32. #fosdem23 – @stewemetal istvanjuhos.dev
    Visualizing the semantics tree 🌳👀
    • In Compose tests
    onRoot()
    .printToLog("RowAndTexts")
    D/RowAndTexts: printToLog:
    Printing with useUnmergedTree = 'false'
    Node #1 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    |-Node #2 at (l=0.0, t=66.0, r=136.0, b=125.0)px
    | Text = '[100 ml]'
    | Actions = [GetTextLayoutResult]
    |-Node #3 at (l=0.0, t=66.0, r=224.0, b=125.0)px
    Text = '[2023-02-04]'
    Actions = [GetTextLayoutResult]
    Text = '[100 ml]' Text = '[2023-02-04]'
    Root


    View Slide

33. #fosdem23 – @stewemetal istvanjuhos.dev
    Visualizing the semantics tree 🌳👀
    • In Android Studio
    • Layout Inspector


    View Slide

34. #fosdem23 – @stewemetal istvanjuhos.dev
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    !// !!...
    }
    ) {
    Text("100 ml")
    Text("2023-02-04")
    }


    View Slide

35. #fosdem23 – @stewemetal istvanjuhos.dev
    Root
    Text = '[100 ml]' Text = '[2023-02-04]'
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    !// !!...
    }
    ) {
    Text("100 ml")
    Text("2023-02-04")
    }


    View Slide

36. #fosdem23 – @stewemetal istvanjuhos.dev
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    contentDescription = "List item"
    }
    ) {
    Text("100 ml")
    Text("2023-02-04")
    }
    Root
    Text = '[100 ml]' Text = '[2023-02-04]'
    ContentDescription =
    '[List item]'


    View Slide

37. #fosdem23 – @stewemetal istvanjuhos.dev
    Modifying the semantics tree 🌳
    Row(
    modifier = Modifier
    .semantics {
    testTag = "List item"
    }
    ) {
    Text("100 ml")
    Text("2023-02-04")
    }
    Root
    Text = '[100 ml]' Text = '[2023-02-04]'
    Tag =
    '[List item]'


    View Slide

38. #fosdem23 – @stewemetal istvanjuhos.dev
    Using the semantics tree...
    @get:Rule val composeTestRule = createComposeRule()
    @Test
    fun entriesExist_entriesDisplayed() {
    composeTestRule.apply {
    setContent {
    HydrationTrackerTheme {
    EntryList(
    entries = entries
    )
    }
    }
    "// ""...
    }
    }
    !!...we can test Compose UI 🤩


    View Slide

39. #fosdem23 – @stewemetal istvanjuhos.dev
    Compose testing API


    View Slide

40. #fosdem23 – @stewemetal istvanjuhos.dev
    Select nodes - Finders
    • onRoot
    onRoot()
    .printToLog(”TAG") Root
    Text = '[100 ml, 2023-02-04]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2023-02-04]'


    View Slide

41. #fosdem23 – @stewemetal istvanjuhos.dev
    Select nodes - Finders
    • onNodeWithTag
    onNodeWithTag("List item")
    Root
    Text = '[100 ml, 2023-02-04]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2023-02-04]'


    View Slide

42. #fosdem23 – @stewemetal istvanjuhos.dev
    Select nodes - Finders
    • onNodeWithContentDescription
    onNodeWithContentDescription(
    "100 ml on 2023-02-04",
    )
    Root
    Text = '[100 ml, 2023-02-04]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2023-02-04]'


    View Slide

43. #fosdem23 – @stewemetal istvanjuhos.dev
    Select nodes - Finders
    • onNodeWithText
    onNodeWithText(
    "100 ml",
    )
    Root
    Text = '[100 ml, 2023-02-04]'
    Tag = '[List item]'
    ContentDescription =
    '[100 ml on 2023-02-04]'


    View Slide

44. #fosdem23 – @stewemetal istvanjuhos.dev
    Select nodes - Finders
    • onAllNodesWith...
    Tag = '[entries_list]'
    onAllNodesNodeWithTag("List item")
    Tag = '[List item]'
    Text = '[100 ml, 2023-02-04]'
    Tag = '[List item]'
    Text = '[500 ml, 2022-07-04]'
    !!...


    View Slide

45. #fosdem23 – @stewemetal istvanjuhos.dev
    Actions
    • performClick
    • performScrollTo...
    • performTextInput
    • performGesture
    • performKeyPress
    • ...
    onNodeWithText("100 ml")
    .performClick()


    View Slide

46. #fosdem23 – @stewemetal istvanjuhos.dev
    Actions
    • performClick
    • performScrollTo...
    • performTextInput
    • performGesture
    • performKeyPress
    • ...
    Role = 'Button'
    Focused = 'false'
    Text = '[100 ml]'
    Actions = [OnClick, GetTextLayoutResult]
    MergeDescendants = 'true'
    onNodeWithText("100 ml")
    .performClick()


    View Slide

47. #fosdem23 – @stewemetal istvanjuhos.dev
    Compose testing cheatseet
    developer.android.com/jetpack/compose/testing-cheatsheet


    View Slide

48. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing


    View Slide

49. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing
    • Adding Compose content to existing View-based layouts
    • Adding existing Views to the composition
    • Compose & Espresso in the same tests
    🪟
    🪟
    ☕
    &


    View Slide

50. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView


    View Slide

51. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView

    android:id="@+id/toolbar”
    style="@style/Widget.MaterialComponents.Toolbar.Primary"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    app:layout_constraintTop_toTopOf="parent” "/>
    android:id="@+id/compose_view"
    android:layout_width="match_parent"
    android:layout_height= "wrap_content"
    app:paddingTop=”8dp"
    app:layout_constraintTop_toBottomOf="@id/toolbar” "/>
    "


    View Slide

52. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView

    android:id="@+id/toolbar”
    style="@style/Widget.MaterialComponents.Toolbar.Primary"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    app:layout_constraintTop_toTopOf="parent” "/>
    android:id="@+id/compose_view"
    android:layout_width="match_parent"
    android:layout_height= "wrap_content"
    app:paddingTop=”8dp"
    app:layout_constraintTop_toBottomOf="@id/toolbar” "/>
    "


    View Slide

53. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView

    android:id="@+id/toolbar”
    style="@style/Widget.MaterialComponents.Toolbar.Primary"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    app:layout_constraintTop_toTopOf="parent” "/>
    android:id="@+id/compose_view"
    android:layout_width="match_parent"
    android:layout_height= "wrap_content"
    app:paddingTop=”8dp"
    app:layout_constraintTop_toBottomOf="@id/toolbar” "/>
    "


    View Slide

54. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView
    class ComposeViewDemoActivity : AppCompatActivity() {
    private lateinit var binding: ActivityComposeViewDemoBinding
    "// ""...
    }
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding = ActivityComposeViewDemoBinding.inflate(layoutInflater)
    setContentView(binding.root)
    }


    View Slide

55. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView
    binding.toolbar.title = "ComposeView Demo Title"
    binding.composeView.apply {
    setViewCompositionStrategy(DisposeOnDetachedFromWindow)
    setContent {
    CustomButton(
    text = "Demo Button",
    modifier = Modifier
    .padding(horizontal = 8.dp)
    .testTag("demo_custom_button"),
    ) {}
    }
    }
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding = ActivityComposeViewDemoBinding.inflate(layoutInflater)
    setContentView(binding.root)
    }


    View Slide

56. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView
    binding.toolbar.title = "ComposeView Demo Title"
    binding.composeView.apply {
    setViewCompositionStrategy(DisposeOnDetachedFromWindow)
    setContent {
    CustomButton(
    text = "Demo Button",
    modifier = Modifier
    .padding(horizontal = 8.dp)
    .testTag("demo_custom_button"),
    ) {}
    }
    }
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding = ActivityComposeViewDemoBinding.inflate(layoutInflater)
    setContentView(binding.root)
    }


    View Slide

57. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView
    @RunWith(AndroidJUnit4"::class)
    class DemoComposeViewTest {
    @get:Rule
    val androidComposeTestRule =
    createAndroidComposeRule()
    @Test
    fun hybrid_ui_customComposeButton_isVisible() {
    androidComposeTestRule.apply {
    Espresso.onView(withText("ComposeView Demo Title"))
    .check(matches(isDisplayed()))
    onNodeWithText("Demo Button").assertIsDisplayed()
    }
    }
    }


    View Slide

58. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView
    @RunWith(AndroidJUnit4"::class)
    class DemoComposeViewTest {
    @get:Rule
    val androidComposeTestRule =
    createAndroidComposeRule()
    @Test
    fun hybrid_ui_customComposeButton_isVisible() {
    androidComposeTestRule.apply {
    Espresso.onView(withText("ComposeView Demo Title"))
    .check(matches(isDisplayed()))
    onNodeWithText("Demo Button").assertIsDisplayed()
    }
    }
    }


    View Slide

59. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView
    @RunWith(AndroidJUnit4"::class)
    class DemoComposeViewTest {
    @get:Rule
    val androidComposeTestRule =
    createAndroidComposeRule()
    @Test
    fun hybrid_ui_customComposeButton_isVisible() {
    androidComposeTestRule.apply {
    Espresso.onView(withText("ComposeView Demo Title"))
    .check(matches(isDisplayed()))
    onNodeWithText("Demo Button").assertIsDisplayed()
    }
    }
    }
    ✅


    View Slide

60. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing – ComposeView
    @RunWith(AndroidJUnit4"::class)
    class DemoComposeViewTest {
    @get:Rule
    val androidComposeTestRule =
    createAndroidComposeRule()
    @Test
    fun hybrid_ui_customComposeButton_isVisible() {
    androidComposeTestRule.apply {
    Espresso.onView(withText("ComposeView Demo Title"))
    .check(matches(isDisplayed()))
    onNodeWithText("Demo Button").assertIsDisplayed()
    }
    }
    }
    ✅
    ✅


    View Slide

61. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView


    View Slide

62. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    class CustomButtonView @JvmOverloads constructor(
    context: Context,
    attrs: AttributeSet? = null,
    defStyleAttr: Int = 0,
    ) : ConstraintLayout(context, attrs, defStyleAttr) {
    "// ""...
    LayoutInflater.from(context).inflate(R.layout.view_custom_button, this, true)
    "// ""...
    fun setText(text: String) { button.text = text }
    override fun setOnClickListener(listener: OnClickListener?) {
    button.setOnClickListener { listener"?.onClick(button) }
    }
    }


    View Slide

63. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    @Composable
    fun AndroidViewDemo(
    onButtonClick: () -> Unit,
    ) {
    Scaffold(
    topBar = { TopAppBar(title = { Text("AndroidView Demo Title") }) },
    content = { padding ->
    AndroidView(
    modifier = Modifier.padding(padding).wrapContentHeight(),
    factory = { context ->
    CustomButtonView(context).apply {
    setText("Demo Button")
    setOnClickListener { onButtonClick() }
    }
    },
    )
    }
    )
    }


    View Slide

64. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    @Composable
    fun AndroidViewDemo(
    onButtonClick: () -> Unit,
    ) {
    Scaffold(
    topBar = { TopAppBar(title = { Text("AndroidView Demo Title") }) },
    content = { padding ->
    AndroidView(
    modifier = Modifier.padding(padding).wrapContentHeight(),
    factory = { context ->
    CustomButtonView(context).apply {
    setText("Demo Button")
    setOnClickListener { onButtonClick() }
    }
    },
    )
    }
    )
    }


    View Slide

65. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    @get:Rule
    val composeTestRule = createComposeRule()
    @Test
    fun composable_withAndroidView() {
    composeTestRule.apply {
    "// ""...
    }
    }
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }


    View Slide

66. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    Espresso.onView(withText("Demo Button")).perform(click())
    assertEquals(true, buttonClicked)
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }


    View Slide

67. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    Espresso.onView(withText("Demo Button")).perform(click())
    assertEquals(true, buttonClicked)
    ✅
    ✅


    View Slide

68. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    assertEquals(true, buttonClicked)
    ✅
    ✅
    ✅❓
    Espresso.onView(withText("Demo Button")).perform(click())


    View Slide

69. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    assertEquals(true, buttonClicked)
    ✅
    ✅
    ✅❓
    ❌
    Espresso.onView(withText("Demo Button")).perform(click())


    View Slide

70. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    Doesn’t work as of Jetpack Compose BOM 2023.01.00 🙁
    https:!//issuetracker.google.com/issues/215231631
    Espresso.onView(withText("Demo Button")).perform(click())


    View Slide

71. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    Espresso.onView(withText("Demo Button")).check { view, _ ->
    view.performClick()
    }
    Unstable workaround
    https:!//issuetracker.google.com/issues/215231631


    View Slide

72. #fosdem23 – @stewemetal istvanjuhos.dev
    Hybrid UI testing - AndroidView
    var buttonClicked = false
    setContent {
    HydrationTrackerTheme {
    AndroidViewDemo { buttonClicked = true }
    }
    }
    onNodeWithText("AndroidView Demo Title").assertIsDisplayed()
    Espresso.onView(withText("Demo Button")).check(matches(isDisplayed()))
    assertEquals(true, buttonClicked)
    Espresso.onView(withText("Demo Button")).check { view, _ ->
    view.performClick()
    }
    ✅
    ✅
    ✅
    ✅❓


    View Slide

73. #fosdem23 – @stewemetal istvanjuhos.dev
    Topics to check out
    • Testing animations in Compose 👀
    • Synchronization and IdlingResources 🕞
    • Screenshot testing with Paparazzi, Showkase, etc. 📸


    View Slide

74. #fosdem23 – @stewemetal istvanjuhos.dev
    Resources
    • developer.android.com/jetpack/compose/testing
    • developer.android.com/jetpack/compose/testing-cheatsheet
    • developer.android.com/jetpack/compose/accessibility
    • developer.android.com/jetpack/compose/semantics
    • youtu.be/kdwofTaEHrs
    • adbackstage.libsyn.com/episode-171-compose-testing
    • github.com/android/compose-samples
    • adavis.info/2021/09/testing-hybrid-jetpack-compose-apps.html
    • github.com/stewemetal/composehydrationtracker


    View Slide

75. #fosdem23 – @stewemetal istvanjuhos.dev
    Resources
    • developer.android.com/jetpack/compose/testing
    • developer.android.com/jetpack/compose/testing-cheatsheet
    • developer.android.com/jetpack/compose/accessibility
    • developer.android.com/jetpack/compose/semantics
    • youtu.be/kdwofTaEHrs
    • adbackstage.libsyn.com/episode-171-compose-testing
    • github.com/android/compose-samples
    • adavis.info/2021/09/testing-hybrid-jetpack-compose-apps.html
    • github.com/stewemetal/composehydrationtracker
    istvanjuhos.dev


    View Slide

76. stewemetal
    istvanjuhos.dev
    How to Test Your Compose UI István Juhos
    • Testing based on the semantics tree
    • Planned accessibility = good testability
    • Hybrid UI testing is supported out of the box
    (although there are issues currently)
    Cover photo by Rob Mulally on Unsplash


    View Slide
