Compose-View Interop in Practice (mDevCamp 2024)

If you’re working on an already established, large code base, there’s a good chance that your screens still use Views to some extent. However, these screens should still be maintained to keep UI consistency across your app. In this talk, we’ll look at how we can support the maintenance of such screens and custom UI components with Jetpack Compose’s interoperability features while discussing the ups and downs of having hybrid UIs in our apps.

Transcript

1. Compose-View Interop in Practice @stewemetal istvanjuhos.dev István Juhos
2. #mDevCamp – @stewemetal istvanjuhos.dev Compose-View Interop in Practice
3. #mDevCamp – @stewemetal istvanjuhos.dev Compose-View interop features • AndroidView • ComposeView • ComposeViewAdapter • AbstractComposeView • Hybrid (Compose + Espresso) testing
4. #mDevCamp – @stewemetal istvanjuhos.dev Why? • No time to rewrite • Complex custom Views • Whole screens
5. #mDevCamp – @stewemetal istvanjuhos.dev Why? • No time to rewrite • Complex custom Views • Whole screens • A UI library the project uses doesn’t support Compose
6. #mDevCamp – @stewemetal istvanjuhos.dev Why? • No time to rewrite • Complex custom Views • Whole screens • A UI library the project uses doesn’t support Compose • New custom components are easier to implement in Compose
7. #mDevCamp – @stewemetal istvanjuhos.dev Why? RecyclerViewAdapter @BindingAdapter findViewById
8. #mDevCamp – @stewemetal istvanjuhos.dev Why? RecyclerViewAdapter @BindingAdapter findViewById 🗑
9. #mDevCamp – @stewemetal istvanjuhos.dev Using Views in Compose with AndroidView
10. #mDevCamp – @stewemetal istvanjuhos.dev Using Views in Compose with AndroidView
11. #mDevCamp – @stewemetal istvanjuhos.dev AndroidView
12. #mDevCamp – @stewemetal istvanjuhos.dev AndroidView • Including existing View hierarchies in Compose UI • ”We don’t have the resources or a business case to rewrite custom Views”
13. #mDevCamp – @stewemetal istvanjuhos.dev AndroidView • Including existing View hierarchies in Compose UI • ”We don’t have the resources or a business case to rewrite custom Views” • Using UI components not yet available in Compose
14. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View class CustomButtonView @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0, ) : ConstraintLayout(context, attrs, defStyleAttr) { private val button: Button private val progressBar: ProgressBar ... LayoutInflater.from(context).inflate(R.layout.view_custom_button, this, true) ... fun setText(text: String) { button.text = text } override fun setOnClickListener(listener: OnClickListener?) { button.setOnClickListener { listener?.onClick(button) } } }
15. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View class CustomButtonView @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0, ) : ConstraintLayout(context, attrs, defStyleAttr) { private val button: Button private val progressBar: ProgressBar ... LayoutInflater.from(context).inflate(R.layout.view_custom_button, this, true) ... fun setText(text: String) { button.text = text } override fun setOnClickListener(listener: OnClickListener?) { button.setOnClickListener { listener?.onClick(button) } } }
16. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View } ) } @Composable fun AndroidViewDemoScreen(...) { Scaffold( topBar = { ... }, content = { padding -> ...
17. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View AndroidView( modifier = Modifier..., factory = { context -> CustomButtonView(context) }, update = { view -> view.setText("View Button") view.setOnClickListener { ... } }, ) } ) } @Composable fun AndroidViewDemoScreen(...) { Scaffold( topBar = { ... }, content = { padding ->
18. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View AndroidView( modifier = Modifier..., factory = { context -> CustomButtonView(context) }, update = { view -> view.setText("View Button") view.setOnClickListener { ... } }, ) } ) } @Composable fun AndroidViewDemoScreen(...) { Scaffold( topBar = { ... }, content = { padding ->
19. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View AndroidView( modifier = Modifier..., factory = { context -> CustomButtonView(context) }, update = { view -> view.setText("View Button") view.setOnClickListener { ... } }, ) } ) } @Composable fun AndroidViewDemoScreen(...) { Scaffold( topBar = { ... }, content = { padding ->
20. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View AndroidView( modifier = Modifier..., factory = { context -> CustomButtonView(context) }, update = { view -> view.setText("View Button") view.setOnClickListener { ... } }, ) } ) } @Composable fun AndroidViewDemoScreen(...) { Scaffold( topBar = { ... }, content = { padding ->
21. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View AndroidView( modifier = Modifier..., factory = { context -> CustomButtonView(context) }, update = { view -> view.setText(state.buttonText) view.setOnClickListener { ... } }, ) } ) } @Composable fun AndroidViewDemoScreen(...) { Scaffold( topBar = { ... }, content = { padding ->
22. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View
23. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View
24. #mDevCamp – @stewemetal istvanjuhos.dev Existing custom View
25. #mDevCamp – @stewemetal istvanjuhos.dev AndroidView( modifier = Modifier.semantics { testTag = "stats_chart" }, factory = { context -> BarChart(context).apply { layoutParams = LayoutParams( LayoutParams.MATCH_PARENT, LayoutParams.MATCH_PARENT, ) } }, update = { barChart -> // Set up barChart }, ) View from a lib - MPAndroidChart
26. #mDevCamp – @stewemetal istvanjuhos.dev AndroidView( modifier = Modifier.semantics { testTag = "stats_chart" }, factory = { context -> BarChart(context).apply { layoutParams = LayoutParams( LayoutParams.MATCH_PARENT, LayoutParams.MATCH_PARENT, ) } }, update = { barChart -> // Set up barChart }, ) View from a lib - MPAndroidChart
27. #mDevCamp – @stewemetal istvanjuhos.dev Testing AndroidView
28. #mDevCamp – @stewemetal istvanjuhos.dev • Screenshot tests ✅ Testing AndroidView
29. #mDevCamp – @stewemetal istvanjuhos.dev • Screenshot tests ✅ • Testing the layout 🤔 Testing AndroidView
30. #mDevCamp – @stewemetal istvanjuhos.dev Testing AndroidView
31. #mDevCamp – @stewemetal istvanjuhos.dev @Test fun androidViewDemo_buttonClick() { composeTestRule.apply { var buttonClicked = false setContent { AndroidViewDemoScreen() { buttonClicked = true } } Espresso.onView(withText("View Button")).apply { check(matches(isDisplayed())) perform(click()) } assertTrue(buttonClicked) } } Testing AndroidView
32. #mDevCamp – @stewemetal istvanjuhos.dev @Test fun androidViewDemo_buttonClick() { composeTestRule.apply { var buttonClicked = false setContent { AndroidViewDemoScreen() { buttonClicked = true } } Espresso.onView(withText("View Button")).apply { check(matches(isDisplayed())) perform(click()) } assertTrue(buttonClicked) } } Testing AndroidView
33. #mDevCamp – @stewemetal istvanjuhos.dev Testing AndroidView @Test fun androidViewDemo_buttonClick() { composeTestRule.apply { var buttonClicked = false setContent { AndroidViewDemoScreen() { buttonClicked = true } } Espresso.onView(withText("View Button")).apply { check(matches(isDisplayed())) perform(click()) } assertTrue(buttonClicked) } }
34. #mDevCamp – @stewemetal istvanjuhos.dev Testing AndroidView @Test fun androidViewDemo_buttonClick() { composeTestRule.apply { var buttonClicked = false setContent { AndroidViewDemoScreen() { buttonClicked = true } } Espresso.onView(withText("View Button")).apply { check(matches(isDisplayed())) perform(click()) } assertTrue(buttonClicked) } }
35. #mDevCamp – @stewemetal istvanjuhos.dev Testing AndroidView @Test fun androidViewDemo_buttonClick() { composeTestRule.apply { var buttonClicked = false setContent { AndroidViewDemoScreen() { buttonClicked = true } } Espresso.onView(withText("View Button")).apply { check(matches(isDisplayed())) perform(click()) } assertTrue(buttonClicked) } }
36. #mDevCamp – @stewemetal istvanjuhos.dev Testing AndroidView @Test fun androidViewDemo_buttonClick() { composeTestRule.apply { var buttonClicked = false setContent { AndroidViewDemoScreen() { buttonClicked = true } } Espresso.onView(withText("View Button")).apply { check(matches(isDisplayed())) perform(click()) } assertTrue(buttonClicked) } }
37. #mDevCamp – @stewemetal istvanjuhos.dev Testing AndroidView @Test fun androidViewDemo_buttonClick() { composeTestRule.apply { var buttonClicked = false setContent { AndroidViewDemoScreen() { buttonClicked = true } } Espresso.onView(withText("View Button")).apply { check(matches(isDisplayed())) perform(click()) } assertTrue(buttonClicked) } } ✅
38. #mDevCamp – @stewemetal istvanjuhos.dev Adding compositions to Views with ComposeView
39. #mDevCamp – @stewemetal istvanjuhos.dev Adding compositions to Views with ComposeView
40. #mDevCamp – @stewemetal istvanjuhos.dev ComposeView
41. #mDevCamp – @stewemetal istvanjuhos.dev ComposeView • Including Compose UI in View hierarchies • ”We want to create new UI components in Compose…”
42. #mDevCamp – @stewemetal istvanjuhos.dev ComposeView • Including Compose UI in View hierarchies • ”We want to create new UI components in Compose…” • ”…but we’ll have to use them on View-based screens.”
43. #mDevCamp – @stewemetal istvanjuhos.dev Adding ComposeView to a Layout <LinearLayout> <com.google.android.material.appbar.MaterialToolbar android:id="@+id/toolbar" android:layout_height="wrap_content" android:layout_width="match_parent" app:title="View Screen"/> </LinearLayout>
44. #mDevCamp – @stewemetal istvanjuhos.dev Adding ComposeView to a Layout <LinearLayout> <com.google.android.material.appbar.MaterialToolbar android:id="@+id/toolbar" android:layout_height="wrap_content" android:layout_width="match_parent" app:title=”View Screen"/> <androidx.compose.ui.platform.ComposeView android:id="@+id/composeView" android:layout_height="wrap_content" android:layout_width="match_parent" android:paddingTop="8dp"/> </LinearLayout>
45. #mDevCamp – @stewemetal istvanjuhos.dev A hybrid Activity with ComposeView
46. #mDevCamp – @stewemetal istvanjuhos.dev A hybrid Activity with ComposeView class ComposeViewDemoActivity : AppCompatActivity() { private lateinit var binding: ActivityComposeViewDemoBinding ... } override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) binding = ActivityComposeViewDemoBinding.inflate(layoutInflater) setContentView(binding.root) }
47. #mDevCamp – @stewemetal istvanjuhos.dev A hybrid Activity with ComposeView binding.toolbar.title = "View Screen" binding.composeView.apply { setViewCompositionStrategy(DisposeOnDetachedFromWindow) setContent { CustomButton( text = "Compose Button", modifier = Modifier..., ) { ... } } } override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) binding = ActivityComposeViewDemoBinding.inflate(layoutInflater) setContentView(binding.root) }
48. #mDevCamp – @stewemetal istvanjuhos.dev A hybrid Activity with ComposeView binding.toolbar.title = "View Screen" binding.composeView.apply { setViewCompositionStrategy(DisposeOnDetachedFromWindow) setContent { CustomButton( text = "Compose Button", modifier = Modifier..., ) { ... } } } override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) binding = ActivityComposeViewDemoBinding.inflate(layoutInflater) setContentView(binding.root) }
49. #mDevCamp – @stewemetal istvanjuhos.dev A hybrid Activity with ComposeView binding.toolbar.title = "View Screen" binding.composeView.apply { setViewCompositionStrategy(DisposeOnDetachedFromWindow) setContent { CustomButton( text = "Compose Button", modifier = Modifier..., ) { ... } } } override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) binding = ActivityComposeViewDemoBinding.inflate(layoutInflater) setContentView(binding.root) }
50. #mDevCamp – @stewemetal istvanjuhos.dev A hybrid Activity with ComposeView binding.toolbar.title = "View Screen" binding.composeView.apply { setViewCompositionStrategy(DisposeOnDetachedFromWindow) setContent { CustomButton( text = "Compose Button", modifier = Modifier..., ) { ... } } } override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) binding = ActivityComposeViewDemoBinding.inflate(layoutInflater) setContentView(binding.root) } ❗ ❗ ❗ ❗
51. #mDevCamp – @stewemetal istvanjuhos.dev Testing ComposeView @RunWith(AndroidJUnit4::class) class DemoComposeViewTest { @get:Rule val androidComposeTestRule = createAndroidComposeRule<ComposeViewDemoActivity>() @Test fun composeView_Button_isVisible() { androidComposeTestRule.apply { Espresso.onView(withText("View Screen")) .check(matches(isDisplayed())) onNodeWithText("Compose Button").assertIsDisplayed() } } }
52. #mDevCamp – @stewemetal istvanjuhos.dev Testing ComposeView @RunWith(AndroidJUnit4::class) class DemoComposeViewTest { @get:Rule val androidComposeTestRule = createAndroidComposeRule<ComposeViewDemoActivity>() @Test fun composeView_Button_isVisible() { androidComposeTestRule.apply { Espresso.onView(withText("View Screen")) .check(matches(isDisplayed())) onNodeWithText("Compose Button").assertIsDisplayed() } } }
53. #mDevCamp – @stewemetal istvanjuhos.dev Testing ComposeView @RunWith(AndroidJUnit4::class) class DemoComposeViewTest { @get:Rule val androidComposeTestRule = createAndroidComposeRule<ComposeViewDemoActivity>() @Test fun composeView_Button_isVisible() { androidComposeTestRule.apply { Espresso.onView(withText("View Screen")) .check(matches(isDisplayed())) onNodeWithText("Compose Button").assertIsDisplayed() } } }
54. #mDevCamp – @stewemetal istvanjuhos.dev Testing ComposeView @RunWith(AndroidJUnit4::class) class DemoComposeViewTest { @get:Rule val androidComposeTestRule = createAndroidComposeRule<ComposeViewDemoActivity>() @Test fun composeView_Button_isVisible() { androidComposeTestRule.apply { Espresso.onView(withText("View Screen")) .check(matches(isDisplayed())) onNodeWithText("Compose Button").assertIsDisplayed() } } }
55. #mDevCamp – @stewemetal istvanjuhos.dev Testing ComposeView @RunWith(AndroidJUnit4::class) class DemoComposeViewTest { @get:Rule val androidComposeTestRule = createAndroidComposeRule<ComposeViewDemoActivity>() @Test fun composeView_Button_isVisible() { androidComposeTestRule.apply { Espresso.onView(withText("View Screen")) .check(matches(isDisplayed())) onNodeWithText("Compose Button").assertIsDisplayed() } } } ✅
56. #mDevCamp – @stewemetal istvanjuhos.dev Tweaking the XML preview with ComposeViewAdapter
57. #mDevCamp – @stewemetal istvanjuhos.dev ComposeViewAdapter • Wraps a ComposeView to render an XML preview • Supports parameterized previews
58. #mDevCamp – @stewemetal istvanjuhos.dev Banners, a Composable to include in an XML layout
59. #mDevCamp – @stewemetal istvanjuhos.dev class BannersPreviewDataProvider : PreviewParameterProvider<List<BannerData>> { ... } @Preview @Composable private fun BannersPreview( @PreviewParameter(BannersPreviewParameterProvider::class) banners: List<BannerData>, ) { ... } @Composable fun Banners( banners: List<BannerData>, ) { ... } Banners, a Composable to include in an XML layout
60. #mDevCamp – @stewemetal istvanjuhos.dev @Composable fun Banners( banners: List<BannerData>, ) { ... } class BannersPreviewDataProvider : PreviewParameterProvider<List<BannerData>> { ... } @Preview @Composable private fun BannersPreview( @PreviewParameter(BannersPreviewParameterProvider::class) banners: List<BannerData>, ) { ... } Banners, a Composable to include in an XML layout
61. #mDevCamp – @stewemetal istvanjuhos.dev @Composable fun Banners( banners: List<BannerData>, ) { ... } class BannersPreviewDataProvider : PreviewParameterProvider<List<BannerData>> { ... } @Preview @Composable private fun BannersPreview( @PreviewParameter(BannersPreviewParameterProvider::class) banners: List<BannerData>, ) { ... } Banners, a Composable to include in an XML layout
62. #mDevCamp – @stewemetal istvanjuhos.dev class BannersPreviewDataProvider : PreviewParameterProvider<List<BannerData>> { ... } @Preview @Composable private fun BannersPreview( @PreviewParameter(BannersPreviewParameterProvider::class) banners: List<BannerData>, ) { ... } @Composable fun Banners( banners: List<BannerData>, ) { ... } Banners, a Composable to include in an XML layout
63. #mDevCamp – @stewemetal istvanjuhos.dev class BannersPreviewDataProvider : PreviewParameterProvider<List<BannerData>> { ... } @Preview @Composable private fun SingleBannerPreview() { ... } @Composable fun Banners( banners: List<BannerData>, ) { ... } Banners, a Composable to include in an XML layout
64. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1" .../> <View android:id="@+id/viewContent2"/> </LinearLayout>
65. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1" .../> <View android:id="@+id/viewContent2"/> </LinearLayout> <ComposeView android:id="@+id/banners"/>
66. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1" .../> <View android:id="@+id/viewContent2"/> </LinearLayout> <ComposeView android:id="@+id/banners"/>
67. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1" .../> <View android:id="@+id/viewContent2"/> </LinearLayout> <ComposeView android:id="@+id/banners"/>
68. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.SingleBannerPreview" > <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
69. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.SingleBannerPreview" > <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
70. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.SingleBannerPreview" > <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
71. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.SingleBannerPreview" > <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
72. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.SingleBannerPreview" > <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
73. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.BannersPreview" tools:parameterProviderClass= "hu.stewemetal.demo.BannersKt. BannersPreviewDataProvider" > <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
74. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.BannersPreview" tools:parameterProviderClass= "hu.stewemetal.demo.BannersKt. BannersPreviewDataProvider" > <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
75. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.BannersPreview" tools:parameterProviderClass= "hu.stewemetal.demo.BannersKt. BannersPreviewDataProvider" tools:parameterProviderIndex="0"> <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
76. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.BannersPreview" tools:parameterProviderClass= "hu.stewemetal.demo.BannersKt. BannersPreviewDataProvider" tools:parameterProviderIndex="0"> <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
77. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.BannersPreview" tools:parameterProviderClass= "hu.stewemetal.demo.BannersKt. BannersPreviewDataProvider" tools:parameterProviderIndex="1"> <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout>
78. #mDevCamp – @stewemetal istvanjuhos.dev The Layout and the Preview <LinearLayout> <MaterialToolbar .../> <View android:id="@+id/viewContent1"/> <ComposeViewAdapter android:id="@+id/bannersPreview" tools:composableName= "hu.stewemetal.demo.BannersKt.BannersPreview" tools:parameterProviderClass= "hu.stewemetal.demo.BannersKt. BannersPreviewDataProvider" tools:parameterProviderIndex="1"> <ComposeView android:id="@+id/banners"/> </ComposeViewAdapter> <View android:id="@+id/viewContent2"/> </LinearLayout> ❗ ❗ ❗ ❗
79. #mDevCamp – @stewemetal istvanjuhos.dev Using Compose to render Views with AbstractComposeView
80. #mDevCamp – @stewemetal istvanjuhos.dev AbstractComposeView • Use Compose UI components to render Views 💡
81. #mDevCamp – @stewemetal istvanjuhos.dev AbstractComposeView <androidx.compose.ui.platform.ComposeView android:id="@+id/composeView" android:layout_width="match_parent" android:layout_height="wrap_content" />
82. #mDevCamp – @stewemetal istvanjuhos.dev AbstractComposeView <androidx.compose.ui.platform.ComposeView android:id="@+id/composeView" android:layout_width="match_parent" android:layout_height="wrap_content" /> binding.composeView .setContent { YourAppTheme { ... } }
83. #mDevCamp – @stewemetal istvanjuhos.dev AbstractComposeView class ComposeView @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0 ) : AbstractComposeView(...) { private val content = mutableStateOf<(@Composable () -> Unit)?>(null) @Composable override fun Content() { content.value?.invoke() } }
84. #mDevCamp – @stewemetal istvanjuhos.dev AbstractComposeView class ComposeView @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0 ) : AbstractComposeView(...) { private val content = mutableStateOf<(@Composable () -> Unit)?>(null) @Composable override fun Content() { content.value?.invoke() } }
85. #mDevCamp – @stewemetal istvanjuhos.dev AbstractComposeView class ComposeView @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0 ) : AbstractComposeView(...) { private val content = mutableStateOf<(@Composable () -> Unit)?>(null) @Composable override fun Content() { content.value?.invoke() } }
86. #mDevCamp – @stewemetal istvanjuhos.dev AbstractComposeView class ComposeView @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0 ) : AbstractComposeView(...) { private val content = mutableStateOf<(@Composable () -> Unit)?>(null) @Composable override fun Content() { content.value?.invoke() } }
87. #mDevCamp – @stewemetal istvanjuhos.dev AbstractComposeView developer.android.com/reference/kotlin/androidx/compose/ui/platform/AbstractComposeView
88. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables class CustomButton
89. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables class CustomButton @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0, ) : FrameLayout(context, attrs, defStyleAttr) { !!... }
90. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables class CustomButton @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0, ) : ConstraintLayout(context, attrs, defStyleAttr) { !!... }
91. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables class CustomButton @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0, ) : AppCompatButton(context, attrs, defStyleAttr) { !!... }
92. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables class CustomButton @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0, ) : AbstractComposeView(context, attrs, defStyleAttr) { !!... }
93. #mDevCamp – @stewemetal istvanjuhos.dev class CustomButton @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0, ) : AbstractComposeView(context, attrs, defStyleAttr) { !!... } Views wrapping Composables @Composable fun CustomButtonComposable( text: String, enabled: Boolean, loading: Boolean, ) { !!... }
94. #mDevCamp – @stewemetal istvanjuhos.dev class CustomButton @JvmOverloads constructor( context: Context, attrs: AttributeSet? = null, defStyleAttr: Int = 0, ) : AbstractComposeView(context, attrs, defStyleAttr) { !!... } Views wrapping Composables @Composable fun CustomButtonComposable( text: String, enabled: Boolean, loading: Boolean, ) { !!... } 🧑🎨
95. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables init { context.theme .obtainStyledAttributes( attrs, R.styleable.CustomButton, 0, 0, ).apply { try { (this) } finally { recycle() } } } ... } initAttributes class CustomButton(...) : AbstractComposeView(...) {
96. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables ... } class CustomButton(...) : AbstractComposeView(...) { fun (typedArray: TypedArray) { with(typedArray) { text.value = getString(R.styleable.CustomButton_text).orEmpty() isEnabled.value = getBoolean(R.styleable.CustomButton_enabled, true isLoading.value = getBoolean(R.styleable.CustomButton_loading, fals } } initAttributes
97. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables ... } class CustomButton(...) : AbstractComposeView(...) { fun (typedArray: TypedArray) { with(typedArray) { text.value = getString(R.styleable.CustomButton_text).orEmpty() isEnabled.value = getBoolean(R.styleable.CustomButton_enabled, true isLoading.value = getBoolean(R.styleable.CustomButton_loading, fals } } initAttributes
98. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables class CustomButton(...) : AbstractComposeView(...) { ... } class CustomButton(...) : AbstractComposeView(...) { private val text = mutableStateOf("") private val isEnabled = mutableStateOf(true) private val isLoading = mutableStateOf(false) fun (typedArray: TypedArray) { with(typedArray) { text.value = getString(R.styleable.CustomButton_text).orEmpty() isEnabled.value = getBoolean(R.styleable.CustomButton_enabled, true isLoading.value = getBoolean(R.styleable.CustomButton_loading, fals } } initAttributes
99. #mDevCamp – @stewemetal istvanjuhos.dev Views wrapping Composables ... } class CustomButton(...) : AbstractComposeView(...) { @Composable override fun Content() { YourAppTheme { CustomButtonCompose( text = text.value, enabled = isEnabled.value, loading = isLoading.value, ) } }
100. #mDevCamp – @stewemetal istvanjuhos.dev XML preview <CustomButton ... app:text="Custom Button" /> <CustomButton ... app:text="Custom Button" app:enabled="false" /> <CustomButton ... app:text="Custom Button" app:loading="true" /> ⚠
101. #mDevCamp – @stewemetal istvanjuhos.dev XML preview <CustomButton ... app:text="Custom Button" /> <CustomButton ... app:text="Custom Button" app:enabled="false" /> <CustomButton ... app:text="Custom Button" app:loading="true" /> ⚠ Works out of the box after Android Studio Giraffe Canary 8 https://issuetracker.google.com/issues/187339385 ⚠
102. #mDevCamp – @stewemetal istvanjuhos.dev
103. #mDevCamp – @stewemetal istvanjuhos.dev
104. #mDevCamp – @stewemetal Wrapping up 📦 istvanjuhos.dev
105. #mDevCamp – @stewemetal Resources • developer.android.com/jetpack/compose/migrate/interoperability-apis • developer.android.com/reference/kotlin/androidx/compose/ui/platform/AbstractCompose View • developer.android.com/jetpack/compose/tooling/previews • developer.android.com/jetpack/compose/testing • istvanjuhos.dev/talks/2022/20221005-how-to-test-your-compose-ui/ • istvanjuhos.dev/talks/2023/20230530-composing-a-design-system/ • flaticon.com/free-icons/prague istvanjuhos.dev
106. Compose-View Interop in Practice Photo by Dan Dennis on Unsplash @stewemetal istvanjuhos.dev István Juhos • Consider using the interop features when you introduce Compose in your apps • Hybrid UI previews and testing are supported • Keep the impact on performance and maintenance in mind • Use the right tools for the right job, don’t rush migrations
107. Compose-View Interop in Practice Photo by Dan Dennis on Unsplash @stewemetal istvanjuhos.dev István Juhos Děkuji
