1. Hadoop and Containers Dinesh Subhraveti Altiscale Inc.
2. Brief History of Containers 2001 2002 2003 2005 Enterprise Linux Container solution — Meiosys 2004 First research paper on Linux Containers — OSDI’02 IBM acquires Meiosys — Focus shifted to AIX First container-based distributed checkpointing — HP Labs First implementation of containers based on syscall interposition — Columbia Most core kernel changes finally made into Linux mainline
3. Container Renaissance “Datacenter is the Computer”
4. Mesos Kubernetes YARN OS Layer Resource Layer Then Now “The new computer needs an OS!”
5. Containers: Enabler of the Datacenter OS Mesos Kubernetes YARN Process Layer OS Layer Resource Layer Then Now
6. Containers ❏ Three dimensions of isolation • Software dependencies and configuration! • Resource consumption (CPU, RAM, disk, network)! • Information integrity and confidentiality (aka, security)! ❏ Why containers as process abstractions of DC-OS? • Provide mechanism for software isolation (via file system namespace)! • Provide defense-in-depth for security! • Better suited for distributed apps! • Containers contain (possibly multiple) restartable processes! • Support for checkpoint/restore, live migration, live OS upgrades, record/replay
7. Why not Virtual Machines? Application — Hardware misalignment Virtual Machine Container Application Applications have round edges — system call interface Hypervisors have square holes — hardware interface Application
8. Why not Virtual Machines? Application — Hardware misalignment Virtual Machine Container Application Applications have round edges — system call interface Hypervisors have square holes — hardware interface Guest OS Application
9. Host iSCSI, NFS Image Format Interpreter Virtual Device VM Exit (Context Switch) Guest Driver Guest File System Host Application Why not Virtual Machines? Layers of Intermediate Software VMs Containers Application High IO overhead due to many intermediate layers
10. Why not Virtual Machines? The Unwelcome Guest! Slow startup time Guest OS licensing and maintenance burden Poor scalability High resource consumption due to duplication Obfuscated network / storage / compute topologies Application semantic information is lost
11. ! Hadoop Resource Manager Map Reduce ! YARN Map Reduce Spark Hbase ... Evolution of Hadoop from Map Reduce to YARN Isolation is an immediate challenge
12. ! Hadoop Resource Manager Map Reduce ! YARN Map Reduce Spark Hbase ... Container Containers on YARN Containers provide a simple and elegant solution Container Virtualization
13. ! Node Manager Job A Task 1 Job B Task 1 Container Containers on YARN Node Manager Spawned Tasks as Containers Container Virtualization Tasks representing the same job share the same container Job A Task 2 Job C Task 1
14. Containers on YARN Advantages Secure multitenancy Performance Isolation Utilization via coscheduling IO and CPU tasks Consistent cluster environment Isolation of software dependencies / configuration Reproducible way to define app environment Rapid provisioning
15. Privilege Isolation through UID namespaces Host Container Container root UID 0 Regular user UID 100 UID Virtualization U Host root UID 0 • UID namespaces are a recent addition to Kernel (DATE) • UIDs in containers can be mapped to different UIDs in host! • Tricky, because you need to translate UIDs of files and other resources! • Provides privilege isolation • Map superuser in container to regular user in host! • Great for YARN, and Docker in general! • Docker predates UID namespaces • Docker support for UID is forthcoming
16. References ! ❏ Blog post describing UID virtualization support in Docker ❏ https://www.altiscale.com/making-docker-work-yarn/ ❏ Apache wiki page tracking work status across Docker and YARN projects ❏ https://wiki.apache.org/hadoop/dineshs/IsolatingYarnAppsInDockerContainers ❏ JIRA tracking Docker integration into YARN ❏ https://issues.apache.org/jira/browse/YARN-1964 ❏ Related Docker tickets ❏ Several tickets linked from: https://github.com/dotcloud/docker/pull/4572

 dineshs@altiscale.com Thank You
17. Backup Containers on Hadoop or Hadoop on Containers?
18. Hadoop on Separate Physical Clusters Awesomely Secure ! Everybody gets private hardware running private services Customer 1 Customer 2 Customer 3
19. Hadoop on Separate Physical Clusters Customer 1 Customer 2 Customer 3 Cannot scale the business this way! Poor utilization Host platform is a huge maintenance burden ❖ Customer A needs R ❖ Customer B needs Matlab ❖ xyz needs ß∂ø… Utilization: 6 Spare: 0 Unused: 3 Utilization: 1 Spare: 6 Unused: 2 Utilization: 4 Spare: 3 Unused: 2
20. Container Clusters to Decouple Host from Customer Each customer gets a container image ❖ Encapsulates customer specific software and configuration ❖ Host platform remains lean and simple Utilization: 6 Spare: 0 Unused: 3 Utilization: 1 Spare: 6 Unused: 2 Utilization: 4 Spare: 3 Unused: 2 Poor utilization Customer 1 Customer 2 Customer 3
21. Global Pool of Resources Global Utilization: 11 Spare: 16 Unused: 0 Container Clusters to Drive Utilization Each customer gets a container image ❖ Encapsulates customer specific software and configuration ❖ Host platform remains lean and simple Densely pack containers together
22. Global Pool of Resources Containers with Fine-grain Resources ❖ Container resource levels adjusted dynamically per customer ➢ As dictated by business policy ❖ Fractional resource allocation
23. Global Pool of Resources Disaggregated Compute and Storage DN NM ❖ Add more storage to Customer 1 cluster from a storage rich node ➢ While a compute intensive job from Customer 2 utilizes the available compute capacity on the same node Independently scale compute and storage
