Unleash the secret power of Kotlin Metadata

Unleash the secret power of Kotlin Metadata

When compiling Kotlin code for the JVM, the resulting bytecode doesn't understand the advanced features of the language – like the difference between `List` and `MutableList`. These "metadata" are hidden, but not lost, and they're a gold mine when trying to create tools designed from the ground up with Kotlin in mind. Join us to learn where to find them, how they're structured and how we can make the most out of them.

Video: https://youtu.be/dAQaZFyZ_hQ

Slides in Keynote (animated): https://goo.gl/5Z7kBc

Links:
+ https://goo.gl/INLPDl -> The Future of Kotlin
+ https://goo.gl/UiT6yh -> descriptors.proto

Eugenio Marletti

July 06, 2017
Tweet

More Decks by Eugenio Marletti

Other Decks in Technology

Transcript

  1. View Slide

  2. View Slide

  3. View Slide

  4. View Slide

  5. List
    List
    MutableList
    MyTypeAlias
    ->
    ->
    ->
    ->
    List
    List
    List
    List

    View Slide

  6. class
    object
    data class
    sealed class
    ->
    ->
    ->
    ->
    class
    class
    class
    abstract class

    View Slide

  7. data class Sample(val counter: Int)

    View Slide

  8. View Slide

  9. View Slide

  10. View Slide

  11. public final class Sample {
    private final int counter;
    public final int getCounter() {
    return this.counter;
    }
    public Sample(int counter) {
    this.counter = counter;
    }
    public final int component1() {
    return this.counter;
    }
    @NotNull
    public final Sample copy(int counter) {
    return new Sample(counter);
    }
    // $FF: synthetic method
    // $FF: bridge method
    @NotNull
    public static Sample copy$default(Sample var0, int var1, int var2, Object var3) {
    if((var2 & 1) != 0) {
    var1 = var0.counter;
    }
    return var0.copy(var1);
    }
    public String toString() {
    return "Sample(counter=" + this.counter + ")";
    }
    public int hashCode() {
    return this.counter;
    }
    public boolean equals(Object var1) {
    if(this != var1) {
    if(var1 instanceof Sample) {
    Sample var2 = (Sample)var1;
    if(this.counter == var2.counter) {
    return true;
    }
    }
    return false;
    } else {
    return true;
    }
    }
    }
    @Metadata(
    k = 1,
    mv = {1, 1, 6},
    bv = {1, 0, 1},
    d1 = {"\u0000 \n\u0002\u0018\u0002\n\u0002\u0010\u0000\n\u0000\n\u0002\u0010\b\n\u0002\b\u0006\n\u0002\u0010\u000b\n\u0002\b\u0003\n\u0002\u0010\u000e\n\u0000\b\u0086\b\u0018\u00002\u00020\u0001B\r\u0012\u0006\u0010\u0002\u001a\u0010\
    d2 = {"LSample;", "", "counter", "", "(I)V", "getCounter", "()I", "component1", "copy", "equals", "", "other", "hashCode", "toString", "", "production sources for module app"}
    ))

    View Slide

  12. @Metadata(
    k = 1,
    mv = {1, 1, 6},
    bv = {1, 0, 1},
    d1 = {"\u0000 \n\u0002\u0018\u0002\n\u0002\u0010\u0000\n\u0000\n\u0002\u0
    d2 = {"LSample;", "", "counter", "", "(I)V", "getCounter", "()I", "compon
    ))

    View Slide

  13. @Metadata
    k
    mv
    bv
    d1
    d2
    xs
    xi

    View Slide

  14. @Metadata
    1. kind
    2. metadata version
    3. bytecode version
    4. data1
    5. data2
    6. extra string
    7. extra int

    View Slide

  15. 7. extra int
    0 -> multi-file class facade or part
    1 -> compiled by a pre-release version
    2 -> Kotlin script source file (.kts)

    View Slide

  16. View Slide

  17. “it depends”
    4. data1
    5. data2
    6. extra string

    View Slide

  18. “it depends” mostly Protocol Buffers
    4. data1
    5. data2
    6. extra string

    View Slide

  19. 1. kind
    1 -> Class
    2 -> File
    3 -> Synthetic class
    4 -> Multi-file class facade
    5 -> Multi-file class part

    View Slide

  20. * nullability (also nested)
    * secondary constructors
    * companion object name
    * properties list
    * delegated types
    * internal visibility
    * sealed class hierarchy
    * type aliases (declaration and usage)
    * generic types (also in/out /*, reified)
    * classes (data/sealed/object/companion)
    * property (var/getter/setter/const/lateinit)
    * value parameter (default/crossinline/noinline)
    * function (operator/infix/inline/tailrec/external)

    View Slide

  21. warning: PLEASE TRY THIS AT HOME

    View Slide

  22. goo.gl/INLPDl -> The Future of Kotlin
    goo.gl/8oFRaU -> kotlin-metadata-samples (Coming Soon™)
    goo.gl/UiT6yh -> descriptors.proto

    View Slide

  23. bit.ly/unleash-kotlin-metadata
    Eugenio
    Marletti
    @workingkills

    View Slide
