Automatic Code Generation for SPA

Automatic Code Generation for SPA

tanakaworld

July 03, 2019
Tweet

More Decks by tanakaworld

Other Decks in Technology

Transcript

  1. Automatic Code Generation
    for SPA
    Mercari x Merpay Frontend Tech Talk vol.2
    2019/07/03
    @_tanakaworld

    View Slide

  2. About Me
    ● Twitter: @_tanakaworld
    ● GitHub: tanakaworld
    ● Merpay
    ○ Software Engineer (Frontend)
    ○ CSTool / MSTool

    View Slide

  3. 1. What is Code Generation?
    2. Tell about the Real World Rearchtecture project
    3. Tips of Generator
    Agenda

    View Slide

  4. What is
    Code Generation?

    View Slide

  5. Automatically generate SDK from schema
    Spec
    Source Code
    SDK
    Schema
    Source Code
    SDK
    Generator

    View Slide

  6. Schema Driven Development
    ● Make Development flow more efficiently
    ● Automatic
    ○ Source Code Generation
    ○ Document Generation
    ○ Testing

    View Slide

  7. Microservices in Merpay
    Protocol Buffers
    ● gRPC
    ● Write Schema by Protocol Buffers
    ● Generate Client and Server

    View Slide

  8. Protocol Buffers
    service SampleAPI {
    rpc GetUser(GetUsersRequest) returns (GetUsersResponse) {
    option (google.api.http) = {
    get : "/users"
    body: "*"
    };
    }
    }
    message GetUsersRequest {}
    message GetUsersResponse {
    repeated User user = 1;
    } .proto

    View Slide

  9. Code Generation in Merpay Frontend
    Proxy
    HTTP gRPC

    View Slide

  10. .proto to TypeScript
    export namespace SampleAPI {
    export class GetUser
    implements APIRequest {
    _response?: GetUsersResponse;
    path = "/users";
    method: HTTPMethod = "get";
    constructor(public parameter: GetUsersRequest) {}
    }
    }
    export interface GetUsersRequest {}
    export interface GetUsersResponse {
    user?: User[];
    }

    View Slide

  11. REAL WORLD
    Rearchitecture
    Project

    View Slide

  12. REAL WORLD Rearchitecture Project
    1. Overview
    2. Backend Implementation
    3. API schema
    4. Generator
    5. Frontend Implementation

    View Slide

  13. 1. Overview

    View Slide

  14. https://proff.io/

    View Slide

  15. Traditional Rails App
    ● Render every time in Server
    ● Bad UX

    View Slide

  16. Rearchitecture
    ● Re-implement 70% features
    ● Backend RESTful API
    56 Endpoints
    ● Frontend SPA
    24 pages

    View Slide

  17. 2. Backend
    Implementation

    View Slide

  18. Well known JSON serializers
    ● jbuilder
    ● active_model_serializers
    ● •••
    ● fast_jsonapi

    View Slide

  19. fast_jsonapi
    https://medium.com/netflix-techblog/fast-json-api-serialization-with-ruby-on-rails-7c06578ad17f
    ● A lightning fast JSON:API
    serializer for Ruby Objects
    ● Around 25 times faster than AMS
    ● is used in several APIs at Netflix

    View Slide

  20. JSON:API
    ● https://jsonapi.org

    View Slide

  21. Why fast_jsonapi was developed?
    ● Netflix
    ○ always use JSON:API
    ● AMS is too flexible
    ○ AMS is designed to serialize JSON in several different
    formats, not just JSON:API

    View Slide

  22. Serializer
    class BookSerializer
    include FastJsonapi::ObjectSerializer
    attributes :id,
    :title,
    :description,
    :created_at,
    :updated_at
    end

    View Slide

  23. {
    "data":[
    {
    "id":"1",
    "type":"book",
    "attributes":{
    "id":1,
    "title":"AAA",
    "description":"Test",
    "created_at":"2019-06-23T13:28:32.550Z",
    "updated_at":"2019-06-23T13:28:32.573Z"
    }
    }
    ]
    }

    View Slide

  24. 3. API schema

    View Slide

  25. View Slide

  26. OpenAPI Specification
    ● https://swagger.io/specification/v2/
    ● fka “Swagger”
    ● help you design, build, document and consume REST APIs

    View Slide

  27. TL;DR;
    API
    ● Resource
    ● Request
    ● Response
    ● Method
    ● URL
    ● Params
    RSpec
    Schema
    /app/books

    View Slide

  28. ● https://github.com/fotinakis/swagger-blocks
    ● Works with all Ruby web frameworks
    ● 100% support for all features of the Swagger 2.0 spec
    ● Can use Ruby DSL to write OpenAPI schema
    swagger-blocks

    View Slide

  29. # app/models/concerns/swagger/book_schema.rb
    module Swagger::BookSchema
    extend ActiveSupport::Concern
    include Swagger::Blocks
    included do
    swagger_schema :Book,
    required: [:title, :description, :image_url] do
    property :id, type: :integer
    property :title, type: :string
    property :description, type: :string
    property :created_at, type: :string
    property :updated_at, type: :string
    end
    end
    end

    View Slide

  30. Wrote Extension for JSON:API
    ● https://github.com/tanakaworld/swagger-blocks-fastjson-api/blob/master/config
    /initializers/swagger_blocks.rb

    View Slide

  31. 4. Generator

    View Slide

  32. Generate API Client
    API Client
    Schema

    View Slide

  33. openapi-generator
    ● https://github.com/OpenAPITools/openapi-generator
    ● It allows generation from OpenAPI Spec
    ○ API client libraries
    ○ Server stubs
    ○ Documentation
    ○ Configuration

    View Slide

  34. View Slide

  35. Install
    npm i -D @openapitools/openapi-generator-cli

    View Slide

  36. Generate
    openapi-generator generate \
    -i ./tmp/swagger.json \
    -g typescript-axios \
    -o ./app/javascript/src/gen/
    --additional-properties="modelPropertyNaming=snake_
    case"
    https://github.com/OpenAPITools/openapi-generator/blob/master/docs/generators/typescript-axios.md

    View Slide

  37. export interface Book {
    id?: number;
    title: string;
    description: string;
    image_url: string;
    created_at?: string;
    updated_at?: string;
    }
    export interface BookResponse {
    id: string;
    type: string;
    attributes: Book;
    }
    export interface CreateBookRequest {
    title?: string;
    description?: string;
    image?: object;
    }

    View Slide

  38. export class SampleAppApi extends BaseAPI {
    public createBook(title?: string, description?: string, image?:
    object, options?: any) {
    •••
    }
    public deleteBook(id: number, options?: any) {
    •••
    }
    public getBook(id: number, options?: any) {
    •••
    }
    public getBooks(options?: any) {
    •••
    }
    public updateBook(id: number, title?: string, description?: string,
    image?: object, options?: any) {
    •••
    }
    }

    View Slide

  39. $ npm run api:gen

    View Slide

  40. 5. Frontend
    Implementation

    View Slide

  41. Overview
    ● Render SPA
    bundle via Rails
    View
    ● with Turbolinks
    ● SPA
    ○ CSR
    ○ Vue
    ○ Vue Router
    ○ Vuex
    API Client
    /app/books
    SPA

    View Slide

  42. Rails Routing
    Rails.application.routes.draw do
    // path for SPA
    // app/books
    // app/books/new
    // app/books/1
    // app/books/1/edit
    // •••
    match 'app/(*spa_path)' => 'spa_app#index', via:
    :get
    end

    View Slide

  43. Response Empty DOM with ‘data-vue’
    // app/views/spa_app/index.html.erb



    View Slide

  44. How it works with Turbolinks
    ● Make Vue instance on 'turbolinks:load'
    ● Destroy Vue instance on 'turbolinks:visit'
    ● ref: https://qiita.com/midnightSuyama/items/efc5441a577f3d3abe74

    View Slide

  45. Make/Destroy Vue instances
    document.addEventListener('turbolinks:load', () => {
    const templates = document.querySelectorAll('[data-vue]');
    templates.forEach((el: HTMLElement) => {
    const option = options[el.dataset.vue]
    const vm = new Vue(Object.assign(option, { el }));
    vms.push(vm);
    });
    });
    document.addEventListener('turbolinks:visit', () => {
    for (let vm of vms) {
    vm.$destroy();
    }
    vms = [];
    });

    View Slide

  46. Use require.context of webpack
    // app/javascript/packs/vue-turbolinks.ts
    const options = {};
    const requireContext = require.context('../options', false,
    /\.ts$/);
    requireContext.keys().forEach(key => {
    const name = key
    .split('/')
    .pop()
    .split('.')
    .shift();
    options[name] = requireContext(key).default;
    });

    View Slide

  47. Option
    // app/javascript/options/spa-app.ts
    import router from '@spa-app/router';
    import store from '@spa-app/store';
    export default {
    router,
    store
    };

    View Slide

  48. Vuex Store Implementation
    ● Use generated API Client in Store
    ● FSA = Flux Standard Action
    ○ https://github.com/redux-utilities/flux-standard-action
    ○ https://github.com/sue71/vuex-typescript-fsa

    View Slide

  49. Vuex + FSA
    store.dispatch('increment')
    // or
    store.dispatch({
    type: 'increment',
    meta: null,
    error: null,
    payload: { ••• }
    })
    https://vuex.vuejs.org/guide/actions.html#dispatching-actions

    View Slide

  50. import { actionCreatorFactory } from
    'vuex-typescript-fsa/lib';
    import { UpdateBookRequest } from '@gen';
    export const namespace = 'books';
    const actionCreator = actionCreatorFactory(namespace);
    export const GetBook = actionCreator<{ id: number; }>(
    'GET_BOOK'
    );
    Define FSAs

    View Slide

  51. Dispatch
    import * as BooksModule from '@spa-app/store/modules/books';
    BooksModule.GetBook.namespaced({ id: 1 });

    View Slide

  52. Actions / Mutations / Getters
    export const module: Module = {
    namespaced: true,
    actions: combineAction(
    action(GetBook, async function(context, action) {
    const { data } = await this.sampleAppAPI
    .getBook(action.payload.id);
    context.commit(BookReceived(data.data));
    })
    )
    };

    View Slide

  53. Tips of
    OpenAPI Generator

    View Slide

  54. Error:
    URLSearchParams
    is not defined

    View Slide

  55. Error: URLSearchParams is not defined
    import * as url from 'url';
    // Error
    const params = url.URLSearchParams(•••);

    View Slide

  56. Workaround
    ● https://github.com/swagger-api/swagger-codegen/issues/6403
    ● I don’t want to change generated code

    View Slide

  57. Override ‘url’ package (Monkey patch)
    // webpacker config
    resolve: {
    alias: {
    '@': path.resolve(__dirname, '../../app/javascript/src'),
    urlOriginal: path.resolve(__dirname, '../../node_modules/url'),
    url: path.resolve(__dirname, './extensions/url')
    }
    }
    // config/webpack/extensions/url.js
    import { parse, resolve, resolveObject, format, Url } from 'urlOriginal';
    import URLSearchParams from '@ungap/url-search-params';
    export { parse, resolve, resolveObject, format, Url, URLSearchParams };

    View Slide

  58. multipart/form-data

    View Slide

  59. was fixed
    ● https://github.com/OpenAPITools/op
    enapi-generator/commit/550774a6e2
    e597d5f4460ec6f8a80951f3ada37e

    View Slide

  60. Heavy Base64 Image
    ● Easy to upload image as Base64 String in Rails
    ○ https://github.com/y9v/carrierwave-base64
    ○ Able to send image via ‘application/json’
    ○ size tooooooo big
    ● Use multipart/form-data instead

    View Slide

  61. Attribute
    Overlapping

    View Slide

  62. e.g. ‘url’
    // ‍♂ This overlaps with import * url from 'url'
    if (url !== undefined) {
    localVarFormParams.append('url', url as any);
    }
    // ‍♂ rename to '_url'
    if (_url !== undefined) {
    localVarFormParams.append('_url', _url as any);
    }
    // convert in Rails
    params.tap {|p| p[:url] = p[:_url]}.permit(
    :title,
    :description,
    :url,
    :image
    )

    View Slide

  63. fixed now
    ● [TS][Axios] To fix conflict params name 'url'
    ○ https://github.com/OpenAPITools/openapi-generator/pull/2921

    View Slide

  64. Try BETA Version

    View Slide

  65. Put .jar into node_modules/
    // @openapitools/openapi-generator-cli/bin/openapi-generator
    const binPath = resolve(__dirname, 'openapi-generator.jar');
    const JAVA_OPTS = process.env['JAVA_OPTS'] || '';
    let command = `java ${JAVA_OPTS} -jar "${binPath}"`;

    View Slide

  66. Generator is changed every day.
    ● You can download and use snapshot
    ● https://oss.sonatype.org/content/repositories/
    snapshots/org/openapitools

    View Slide

  67. Summary

    View Slide

  68. Overview
    Schema
    OpenAPI
    Spec
    API Client SPA

    View Slide

  69. Pro/Con
    ● Pro
    ○ Able to detect unexpected changes
    ○ Reduce change by hand
    ○ Able to reuse API Client for another platform
    ○ Automatically detect diff
    ● Con
    ○ Took time to setup
    ○ Too many things to do
    ○ Too much for single person project

    View Slide

  70. Sample
    ● https://github.com/tanakaworld/swagger-blocks-fastjson-api

    View Slide

  71. Thanks

    View Slide

  72. Appendix

    View Slide

  73. OpenAPI + JSON:API is Bad approach?
    ● https://apisyouwonthate.com/blog/json-api-openapi-and-json-schema-working-i
    n-harmony
    ● “At WeWork, we use JSON Schema to describe the data models, OpenAPI to
    describe everything else, then the message being described is usually JSON API.”

    View Slide

  74. ※ Fast JSON API is not a replacement for AMS
    ● AMS does many things and is very flexible
    ○ This is why fast_jsonapi is more faster
    ● Netflix still use AMS for non JSON:API serialization and deserialization
    ● ref: Performance methodology

    View Slide
