Kubernetes at NU.nl (2019-09-05)

Slides of the presentation about Kubernetes practices and learnings at NU.nl.
This presentation was the first of two at the Dutch Kubernetes meetup at the Sanoma Netherlands offices, that took place on Sept. 5th 2019

#kubernetes #aws #devops #cncf #nu.nl #cloud-computing

Transcript

1. @
2. Introduction
3. Me @NU.nl
4. NU.nl About • First dutch digital news platform. • Unique visitors: • 7 mln. / month • 2.1 mln. / day • Page hits: ~12 mln / day • API: ~150k rpm / 2500rps
5. NU.nl Sanoma • Part of Sanoma • NL: NU.nl, Viva, Libelle, Scoopy • FI: Helsingin Sanomat • Reaching ~9.8 mln dutch people / month
6. IT organization Teams • NU.nl teams • Web 1 (application / front-end-ish) • Web 2 (application / back-end-ish / infra) • Feature 1 & 2 (cross-discipline) • iOS • Android • Sanoma teams • DevSupport, Mediatool, Content Aggregation
7. NU.nl Growing number of teams • Increased number of parallel workflows • Testing • Releasing • Roadmaps • Knowing about everything no longer possible • Aligning ‘procedures by agreement’ increasingly hard
8. Why Kubernetes?
9. Current infrastructure AWS accounts & VPCs VPC sanoma RDS Elasticache ALBs EC2 Cloudfront API CMS WWW XYZ VPC nu-test FOO K8S VPC nu-prod BAR K8S
10. Infrastructure provisioning Terrible (Terraform + Ansible) terrible plan terrible apply terrible ansible
11. Development workflow From code to release • Code • Automated tests • Code review • Manually initiated deploy to test • Feature test • Manually initiated deploy to staging • Exploratory test • Manually initiated deploy to production
12. DevOps practices Solid foundation • All infra in code • Terraform • Terrible providing mechanisms: • Authorization • Managing TF state files
13. DevOps practices But… • Setting up additional test environments slow • Slow feedback loop • Terraform plan vs apply (surprise surprise, it didn’t work) • Ansible (~20 minutes) • Vagrant? (but not fully representative of EC2) • Config drift • Hard to nail down every system package version • EC2 instances having different lifecycle
14. DevOps practices But… (part 2) • No scaling infra* • Heavily invested in Ansible • Config & secrets management problematic • GUIs time consuming • No change history • Or highly detached from code history • No context • Not overly secret *Yes, we know it’s 2019
15. DevOps practices But… (part 3) • Current deployment system assumes fixed set of servers • Possible alternatives include: • ASG rolling updates (can get slow) • Pull current application code on start-up (even slower) • Bake AMI • Periodically poll for application version to be deployed • Works quite well • …as long as new code combined with config doesn’t break. • So a certain level of orchestration would be needed.
16. Where to start? Everything’s connected
17. Timing What direction to move? • DevOps challenges • Desire to improve delivery process, having true artifacts • Early 2018 • Containers are a well-established way of ‘packaging’ an application • Kubernetes getting out of early-adopters phase • NU.nl (re-)launching a new product: NUjij
18. Improvement layers A journey or a destination? 1: Containers as artifacts • Versatile • Forces us to do certain things right • 12factor • Centralized logging • Easily moved through a pipeline • Lots of tooling
19. Improvement layers A journey or a destination? 2: A flexible platform to deploy and run containerized applications on • Tackling challenges at platform level instead of per-application: • Scaling • Security updates • Observability • Deployment & configuration process
20. Improvement layers A journey or a destination? 2: A flexible platform to deploy and run containerized applications on • Kubernetes • Rapidly increasing adoption • Short feedback loop • Ability to run locally (unlike, say, ECS) • Easily stamp out deployments for: • feature testing/demo-ing • e2e tests
21. Narrowing the scope Lets not get carried away The goal is not: • To chop up change all of our applications into nano- micro-services • They’re not that monolithic anyway • To put everything in Kubernetes • Managed AWS services where possible • Redis, RDS Focus on agility and efficiency of what we change most frequently: Code
22. Initial cluster setup The journey begins
23. Multiple clusters By criticality 3 AWS accounts, 3 clusters: • osc-nu-prod • production • osc-nu-test • test • staging • osc-nu-dev • proofing infra changes
24. Kops Why Kops? • Manages cluster upgrades • Rolling upgrade • Draining nodes • EKS not yet available • Let alone in eu-west-1
25. Kops Glueing together cluster setup and kube-system setup
26. Kops Upgrading a cluster
27. Kops Upgrading a cluster
28. Kops Templating Terraform and custom vars
29. Components kube-system • Networking • Calico • EFS • previousnext/k8s-aws-efs • No AZ-restrictions when re-scheduling pods • Creates new EFS filesystem for each PersistentVolumeClaim • Security & reliability (isolated IOPs budgets) • Slow on initial deploy
30. Components kube-system • AWS IAM Authenticator • The ‘Zalando suite’ • Skipper • Skipper Daemonset • kube-ingress-aws-controller Deployment • ExternalDNS • Configures PowerDNS (& others) based on ingress host
31. Components Zalando skipper • Skipper Daemonset • Feature rich (metrics, shadow traffic, blue/green) • kube-ingress-aws-controller Deployment • https://github.com/zalando-incubator/kube- ingress-aws-controller • Sets up & manages ALB • Finds appropriate ACM certificate • Supports multiple ACM certificates per ALB
32. Components Autoscaling • Horizontal Pod Autoscaler • Scales number of pods based on (CPU) utilization • Cluster autoscaler • Running on master nodes • Scales asg out when pods pending • Scales asg in when nodes underutilized
33. Components Logging & metrics • ELK • Prometheus / Grafana
34. Jenkins Build & Deploy pipeline
35. Jenkins Temporary deployment for running tests • Deploy to temp. namespace • Jenkins-SU • Run tests in deployment • Deploy to test/staging/production • By bumping image version • Production: Jenkins-SU • Clean up temp. namespace • Jenkins-SU
36. Jenkins Jenkins-SU • Sets up namespace • Adding RBAC for Jenkins • Only if ns name matches pattern ‘Jenkins-*’ • Deletes namespace • Only if ns name matches pattern ‘Jenkins-*’ • Avoids need for Jenkins to be able to delete every namespace curl -X POST --user ${JENKINS_SU_AUTH} --data '{\"name\": \"${K8S_BUILD_NS}\"}' http://su.jenkins-su/ns/ curl -X DELETE --user ${JENKINS_SU_AUTH} --data '{\"name\": \"${K8S_BUILD_NS}\"}' http://su.jenkins-su/ns/
37. Kubernetes in action
38. Kubernetes in action Questions • Will it be stable? • Will we be able to operate? • Should we wait for EKS? • Do we actually want EKS? What will EKS be like?
39. Learning from failure
40. 1 No memory limits
41. Incident 1 Accidentally trying to load a ElasticSearch index of 90Gb • Misconfigured elast-alert (trying to read entire index) • No memory limit configured
42. Incident 1 Accidentally trying to load a ElasticSearch index of 90Gb • Required manual intervention: Yes • Stopping the bleeding: • Remove elast-alert • Permanent fixes: • Don’t load entire index • Apply limits
43. 2 No CPU limits
44. Incident 2 Rapid traffic increase affecting core components • 2019-03-18 Utrecht shooting • 11:11 First article published • 11:56 breaking push • CPU burstable pods causing node 100% CPU • Core components (kubelet, ingress) suffering
45. Incident 2 Rapid traffic increase affecting core components
46. Incident 2 Rapid traffic increase affecting core components
47. Incident 2 Rapid traffic increase affecting core components
48. Incident 2 Rapid traffic increase affecting core components
49. Incident 2 Rapid traffic increase affecting core components pod pod kubelet skipper node Pods: 0.4 CPU req. 0.8 CPU limit 80% CPU utilization pod kubelet skipper node pod Pods: 0.4 CPU req. 0.8 CPU limit 120% CPU utilization problems
50. Incident 2 Rapid traffic increase affecting core components • Required manual intervention: No • Fixes: • Reduce CPU burstable amount of pods • Increase resource requests of skipper • Mind QoS: Guaranteed, Burstable, Best effort • Reserve cpu & memory for kubelet • --kube-reserved • --system-reserved
51. 3 Memory limits
52. OOMkiller
53. Incident 3 Application update increasing memory footprint • Upgrade including moving from MongoDB 3 to MongoDB 4 • HorizontalPodAutoscaler based on CPU • Scaling based on CPU not kicking in • New increased memory footprint causing OOMkilled
54. Incident 3 Application update increasing memory footprint
55. Incident 3 Application update increasing memory footprint • Required manual intervention: Yes • Stopping the bleeding: • Increase memory limit of Talk pods • Permanent fixes: • Adjust CPU request/limit & HPA thresholds • Scale on both CPU and memory • Note: Not all applications ‘give back’ memory • Set memory limit higher than request to prevent ‘snowball effect’
56. Incident 3 OOMKilled snowball effect pod pod pod pod pod pod pod pod pod pod starting … 1 2 3 4
57. 3 Memory limits !? (obligatory this-is-fine meme)
58. That’s not fine Is it? • On the positive side: • All are result of (lack of) resource limit configuration • This can be learned • On the negative side: • This needs to be learned • Note: ‘Availability bias’
59. Improving
60. Automation Improving the pipeline • Automating setting the image version is not enough • Rolling out Kubernetes manifests still manual task • Updating configuration & secrets still manual task • Duplication in manifests between stages • Not easily seen what parts are different • Differences intentional or accidental? • This actually slows us down • Does git represent the current state? kubectl -n talk get secrets env -o json |jq -r '.data | map_values(@base64d) | to_entries | .[] | .key + "=\"" + .value +"\""'
61. Helm The package manager for Kubernetes • Charts • Configured via values • It’s like Terraform modules • Or Ansible group_vars • Leveraging community knowledge and efforts • E.g. prometheus-operator • No need to copy charts, able to reference. • Helm v3
62. SOPS: Secrets OPerationS Secrets management stinks, use some sops! • By Mozilla • Manage AWS API access, not keys • Versatile • YAML, JSON, ENV, INI, binary (plain text) • Not limited to Kubernetes • Meaningful diffs • Alternatives considered: • Kamus • Bitnami SealedSecrets
63. Helmfile Wiring it together • Charts • Referenced from online chart sources or local • Environments • Test, staging, production • Referencing values and secrets • Releases • Release name • Reference to chart • Values (can be a templated file, using vars and secrets from environment)
64. Helmfile Wiring it together environment values secrets (SOPS) release X release Y release Z ENV values values values Helmfile
65. Helmfile Wiring it together • Advantages: • Meaningful git diffs • Easily manage multiple releases in single pipeline, e.g.: • Everything related to monitoring and logging • Kube-system • Declarative definition • Of what would otherwise be numerous helm args and steps in CI/CD pipeline
66. Helmfile Wiring it together • Advantages (continued): • Ability to pass in ENV vars • E.g. build result image tags • Ability to reference complex charts created by community • Charts as a building block allows re-use. Example: • Instead of plain yaml you write a chart • If fitting workflow, the chart can be a published artifact • Chart can be re-used e.g. in e2e tests
67. Helmfile Wiring it together • Disadvantages: • 2 levels of templating • Chart itself • Only if writing own charts • Environment & release values into Helm values • Template error message not overly clear • Or even misleading • At least it breaks
68. Helmfile Example
69. Helmfile Example
70. Helmfile Example
71. Helmfile Jenkins
73. Helmfile Final words But tiller? • Helm as a templating engine • Option: Using Helm 2 ‘Tillerless’ • Tiller outside of cluster, not by-passing RBAC • Start using Helm as package manager when Helm 3 settles down • Easy removal of temp. per-feature deploys • Diffs
74. Challenge Auto-scaling
75. scale fast… scale far…
76. Auto-scaling Breaking news push
77. Auto-scaling Types of scaling • Reactive • Breaking news • K8S cluster-autoscaler • Can’t schedule pod? Add nodes. • Predictive • Ticket sale start • Black Friday
78. Auto-scaling Types of scaling • From within cluster • K8S cluster-autoscaler • From outside of cluster • ASG scaling policies
79. Auto-scaling Scaling speed node spin-up duration node count 70% utilization
80. Auto-scaling Times 5 within 5 minutes?
81. Cluster auto-scaler Bag of tricks • Mix predictive and reactive • Add asg instances without telling cluster-autoscaler • Traffic expected to arrive by the time cluster-autoscaler starts to scale in, leaving plenty of resources as needed. • Pause pods • Lower priority pods that can safely be evicted • Effectively ‘creating headroom’ in cluster
82. Considerations When engaging ‘ludicrous mode’™ Can control-plane handle scale? • KOPS • Size master nodes for max. cluster size • Overhead cost • EKS • What’s behind the abstraction? • ELB 503s exist after all • Plan: Proof of concepts
83. Pending Not the pods…
84. Consider EKS Managed control plane EKS Kops Managed control plane Total control over setup Easier: EKS IAM roles for pods • Launched 2019-09-04 (yesterday)* Smooth rolling upgrade process Probably cheaper (2/3 of 3x m4.large) No VPC CNI Pod density limitations * https://aws.amazon.com/blogs/opensource/introducing-fine-grained-iam-roles-service-accounts/
85. EKS IAM roles for pods Also possible on DIY clusters, officially launched yesterday • OIDC federation access (OpenID Connect identity provider) • Assume role via Secure Token Service (STS) • Projected service account tokens (JWT) in pod • STS can validate JWT tokens against OIDC provider • Boils down to: • Enable/set-up prerequisites in cluster • Add ServiceAccount having IAM role annotation to pod • Use recent AWS SDK
86. Multiple clusters per AWS account Don’t lock ourselves in a corner. api.<aws-account-name>.<k8s-sanoma-domain> api.<cluster-name>.<aws-account-name>.<k8s-sanoma-domain> Route53 zone 1 Route53 zone 1 Route53 zone 2 NS records
87. CI/CD to separate cluster Similar flows • No more taints and tolerations • Similar authorization mechanism to all deploy targets • Possibly IAM • No need for Jenkins-SU • Clusters should be cattle anyway
88. Pipelines GitOps • Manage namespaces via pipeline: • kube-system • monitor • Creation of application namespaces including RBAC • Helmfile
89. System applications Small improvements • Prometheus-operator • PrometheusRule resource type • Default dashboards • EFS • https://github.com/previousnext/k8s-aws-efs • Current. Works well but not a lot of active development. • 2 contributors. 46 stars. • https://github.com/kubernetes-incubator/external-storage • De facto EFS provisioner. 146 contributors. 1630 stars. • Bonus: No more time-consuming initial volume set-up
90. Expand Increase Return on Investment • Add more applications • Facilitate parallel testing & development workflows • Feature testing • Mobile app development • E2e tests
91. Links Further reading Scaling & spot instances: • https://itnext.io/the-definitive-guide-to-running-ec2-spot-instances-as-kubernetes-worker-nodes-68ef2095e767 EKS: • https://medium.com/glia-tech/productionproofing-eks-ed52951ffd6c QoS: • https://www.replex.io/blog/everything-you-need-to-know-about-kubernetes-quality-of-service-qos-classes Failure stories: • https://k8s.af/
92. Summary
93. Know your limits Automate all the things Everything code Kubernetes is a journey, not a destination All should be cattle. No pets allowed!
94. ?
