Ruby VM Internals: TMI

RubyConf 2015 talk.

Transcript

1. View Slide

2. JavaScript


   View Slide

3. Everything is broken.


   View Slide

4. Ruby VM Internals
   The TMI Edition


   View Slide

5. Aaron Patterson


   View Slide

6. @tenderlove


   View Slide

7. View Slide

8. View Slide

9. View Slide

10. Ruby Core Team
    Rails Core Team


    View Slide

11. I am bad at saying "no"


    View Slide

12. View Slide

13. View Slide

14. ☁


    View Slide

15. https://github.com/ManageIQ/
    manageiq


    View Slide

16. RubyConf 5k


    View Slide

17. TEXAS!!!


    View Slide

18. View Slide

19. Stupid Ruby VM Tricks


    View Slide

20. Stupid Ruby VM Tricks


    View Slide

21. Stupid Ruby VM Tricks


    View Slide

22. Ruby’s Virtual Machine
    and its internals


    View Slide

23. WARNING:
    THIS IS A TECH TALK


    View Slide

24. &&&&&


    View Slide

25. Ruby’s Virtual Machine
    and its internals


    View Slide

26. Actually a talk about Failure.


    View Slide

27. Building an AOT Compiler


    View Slide

28. Rebrand Failure as:
    "Potential For Success"


    View Slide

29. Time Breakdown of "Feeling
    Successful"
    1%
    9%
    11%
    11%
    31%
    37%
    Fail
    Fail
    Fail
    Fail
    Fail
    Success


    View Slide

30. At least I learned something,
    right?


    View Slide

31. NO


    View Slide

32. View Slide

33. ruby myprogram.rb


    View Slide

34. Stuff that happens
    before the program runs
    Running the actual
    program
    eval


    View Slide

35. Stuff that happens
    before the program runs
    Running the actual
    program
    Lexer
    Virtual Machine
    About 2 Slides Each
    Parser
    Compiler
    Most of Our Time


    View Slide

36. Lexer


    View Slide

37. DOT
    name: 'each'
    DO
    END
    array.each do; end name: 'array'
    LEXER


    View Slide

38. Parser


    View Slide

39. Method Call
    array each
    block
    DOT
    name: 'each'
    DO
    END
    name: 'array'
    PARSER
    AST
    (Abstract Syntax Tree)


    View Slide

40. Hsing-Hui Hsu
    @SoManyHs
    3:05


    View Slide

41. Ruby 1.8 and 1.9 Diverge


    View Slide

42. Ruby 1.8: Interprets AST


    View Slide

43. AST Interpreter
    Method Call
    array each
    block


    View Slide

44. Ruby 1.9+: YARV (VM)


    View Slide

45. put self
    send array
    send each
    Compile Phase
    Method Call
    array each
    block
    COMPILER


    View Slide

46. What is a Virtual Machine?


    View Slide

47. It’s like a Real Machine,
    but it’s Virtual.


    View Slide

48. global _start
    section .text
    _start:
    ; write(1, message, 13)
    mov rax, 1 ; system call 1 is write
    mov rdi, 1 ; file handle 1 is stdout
    mov rsi, message ; address of string to
    output
    mov rdx, 13 ; number of bytes
    syscall ; invoke operating system to
    do the write
    ; exit(0)
    mov eax, 60 ; system call 60 is exit
    xor rdi, rdi ; exit code 0
    syscall ; invoke operating system to
    exit
    message:
    db "Hello, World", 10 ; note the newline at the
    end


    View Slide

49. These are defined by the
    capabilities of the processor


    View Slide

50. Virtual Machines
    Give You Freedom


    View Slide

51. What instructions should I
    dream up today?


    View Slide

52. Two Types of VM:
    Stack Based & Register Based


    View Slide

53. Stack Based VMs


    View Slide

54. Like a Calculator


    View Slide

55. HP Calculators are RAD


    View Slide

56. 9 * 18


    View Slide

57. 9㾑 18㾑


    View Slide

58. View Slide

59. *


    View Slide

60. View Slide

61. "That’s so much work, why
    bother?"


    View Slide

62. GO BACK TO YOUR
    TI-83 Plus


    View Slide

63. Instructions
    9㾑
    18㾑
    *
    Stack
    1: 9
    2: 9
    1: 18
    1: 162


    View Slide

64. HP 49g+
    9㾑
    18㾑
    *
    YARV
    putobject 9
    putobject 18
    opt_mult


    View Slide

65. Virtual Machines
    Should Not Intimidate You


    View Slide

66. C Code Should


    View Slide

67. YARV Code
    putobject 9
    putobject 18
    opt_mult
    Program
    Just an Array Instruction
    Parameters


    View Slide

68. So how do we get this
    "machine code"?


    View Slide

69. Compiler


    View Slide

70. Mult-Pass Compiler


    View Slide

71. AST
    Linked List
    Optimizations
    Byte Code


    View Slide

72. RubyVM::InstructionSequence


    View Slide

73. RubyVM::InstructionSequence
    ins = RubyVM::InstructionSequence.new <def foo
    "hello "
    end
    puts foo + "world"
    eoruby
    puts ins.disasm


    View Slide

74. RubyVM::InstructionSequence
    == disasm: #@>================================
    0000 trace 1 ( 1)
    0002 putspecialobject 1
    0004 putspecialobject 2
    0006 putobject :foo
    0008 putiseq foo
    0010 opt_send_without_block ,
    0013 pop
    0014 trace 1 ( 5)
    0016 putself
    0017 putself
    0018 opt_send_without_block ,
    0021 putstring "world"
    0023 opt_plus ,
    0026 opt_send_without_block ,
    0029 leave
    == disasm: #>=======================================
    0000 trace 8 ( 1)
    0002 trace 1 ( 2)
    0004 putstring "hello "
    0006 trace 16 ( 3)
    0008 leave ( 2)


    View Slide

75. AST


    View Slide

76. What is an AST?


    View Slide

77. "Abstract Syntax Tree"


    View Slide

78. Get the AST
    NODE*
    rb_compile_string(const char *f, VALUE s, int line)


    View Slide

79. NODE is an AST Node
    Method Call
    array each
    block


    View Slide

80. Linked List


    View Slide

81. What is a Linked List (LL)?


    View Slide

82. Invented in 1836


    View Slide

83. Battle of the à la Mode


    View Slide

84. Alexander Graham Link


    View Slide

85. Item 1
    Item 2
    Item 3


    View Slide

86. Linked List Generation
    VALUE
    rb_iseq_compile_node(rb_iseq_t *iseq, NODE *node)
    Our Node
    Final Product


    View Slide

87. AST
    Linked List
    Optimizations
    Byte Code


    View Slide

88. Which Branch To Follow?
    VALUE
    rb_iseq_compile_node(rb_iseq_t *iseq, NODE *node)
    {
    DECL_ANCHOR(ret);
    INIT_ANCHOR(ret);
    if (node == 0) {
    COMPILE(ret, "nil", node);
    iseq_set_local_table(iseq, 0);
    }
    else if (nd_type(node) == NODE_SCOPE) {


    View Slide

89. Which Branch To Follow?
    #define nd_type(n) ((int) (((RNODE(n))->flags &
    NODE_TYPEMASK)>>NODE_TYPESHIFT))


    View Slide

90. LETS DO SOMETHING
    DANGEROUS


    View Slide

91. Reach Inside
    require 'fiddle'
    include Fiddle
    func = Function.new Handle::DEFAULT['rb_compile_string'],
    [TYPE_VOIDP, TYPE_VOIDP, TYPE_INT], TYPE_VOIDP
    node = func.call "", Fiddle.dlwrap("def foo; end"), 0
    p Fiddle.dlunwrap node


    View Slide

92. MUWAHAHAHA
    $ ruby test2.rb
    test2.rb:9:in `p': method `inspect' called on unexpected
    T_NODE object (0x007facab8e6570 flags=0x1)
    (NotImplementedError)
    from test2.rb:9:in `'


    View Slide

93. Which Branch To Follow?
    VALUE
    rb_iseq_compile_node(rb_iseq_t *iseq, NODE *node)
    {
    DECL_ANCHOR(ret);
    INIT_ANCHOR(ret);
    if (node == 0) {
    COMPILE(ret, "nil", node);
    iseq_set_local_table(iseq, 0);
    }
    else if (nd_type(node) == NODE_SCOPE) {


    View Slide

94. Which Branch To Follow?
    enum node_type {
    NODE_SCOPE,


    View Slide

95. THIS IS IT!!!
    default: {
    COMPILE(ret, "scoped node", node->nd_body);
    break;
    }


    View Slide

96. iseq_compile_each


    View Slide

97. iseq_compile_each
    /**
    compile each node
    self: InstructionSequence
    node: Ruby compiled node
    poped: This node will be poped
    */
    static int
    iseq_compile_each(rb_iseq_t *iseq, LINK_ANCHOR *ret, NODE * node, int poped)


    View Slide

98. > 2300 lines


    View Slide

99. `true`
    case NODE_TRUE:{
    if (!poped) {
    ADD_INSN1(ret, line, putobject, Qtrue);
    }
    break;
    }
    AST Node Type
    Add New LL
    Item
    Instruction
    Name
    Instruction
    Arg


    View Slide

100. `p true`
     $ ruby -e'puts RubyVM::InstructionSequence.new("p true").disasm'
     == disasm:
     #@>================================
     0000 trace 1
     ( 1)
     0002 putself
     0003 putobject true
     0005 opt_send_without_block ARGS_SIMPLE>,
     0008 leave
     `putobject`
     Instruction
     `true`
     Parameter


     View Slide

101. If Statements
     then_label = NEW_LABEL(line);
     else_label = NEW_LABEL(line);
     end_label = NEW_LABEL(line);
     compile_branch_condition(iseq, cond_seq, node->nd_cond,
     then_label, else_label);
     COMPILE_(then_seq, "then", node->nd_body, poped);
     COMPILE_(else_seq, "else", node->nd_else, poped);
     ADD_SEQ(ret, cond_seq);
     ADD_LABEL(ret, then_label);
     ADD_SEQ(ret, then_seq);
     ADD_INSNL(ret, line, jump, end_label);
     ADD_LABEL(ret, else_label);
     ADD_SEQ(ret, else_seq);
     ADD_LABEL(ret, end_label);


     View Slide

102. COMPILE recurses,
     ADD_* adds a new LL Item


     View Slide

103. Node
     insn: putself
     Node
     insn: putobject
     arg: true
     Node
     insn: opt_send_without_block
     arg: "p"


     View Slide

104. Why a Linked List?


     View Slide

105. Optimizations


     View Slide

106. rb_iseq_compile_node


     View Slide

107. iseq_setup


     View Slide

108. AST
     Linked List
     Optimizations
     Byte Code


     View Slide

109. iseq_optimize
     Compile time optimizations


     View Slide

110. Optimization Settings
     $ ruby -e'p RubyVM::InstructionSequence.compile_option'
     {:inline_const_cache=>true, :peephole_optimization=>true
     , :tailcall_optimization=>false, :specialized_instructio
     n=>true, :operands_unification=>true, :instructions_unif
     ication=>false, :stack_caching=>false, :trace_instructio
     n=>true, :frozen_string_literal=>false, :frozen_string_l
     iteral_debug=>false, :debug_level=>0}


     View Slide

111. Optimization Settings
     $ ruby -e'p RubyVM::InstructionSequence.compile_option'
     {:inline_const_cache=>true, :peephole_optimization=>true
     , :tailcall_optimization=>false, :specialized_instructio
     n=>true, :operands_unification=>true, :instructions_unif
     ication=>false, :stack_caching=>false, :trace_instructio
     n=>true, :frozen_string_literal=>false, :frozen_string_l
     iteral_debug=>false, :debug_level=>0}


     View Slide

112. Peephole Optimizations:
     Eliminating Dead Code


     View Slide

113. Dead Code == Useless
     Instructions


     View Slide

114. Remove Useless Instructions
     /*
     * useless jump elimination:
     * jump LABEL1
     * ...
     * LABEL1:
     * jump LABEL2
     *
     * => in this case, first jump instruction should jump to
     * LABEL2 directly
     */


     View Slide

115. Specialized Instructions


     View Slide

116. For All Your Special Occasions


     View Slide

117. `foo.bar` vs `foo + bar`


     View Slide

118. Regular Method Dispatch (foo.bar)
     $ ruby -e"puts RubyVM::InstructionSequence.new(\"foo.bar\", nil, nil,
     0, :specialized_instruction => false).disasm"
     == disasm: #@>================================
     0000 putself
     0001 send , , nil
     0005 send , , nil
     0009 leave
     send


     View Slide

119. Regular Method Dispatch (foo + bar)
     $ ruby -e"puts RubyVM::InstructionSequence.new(\"foo + bar\", nil, nil,
     0, :specialized_instruction => false).disasm"
     == disasm: #@>================================
     0000 putself
     0001 send , , nil
     0005 putself
     0006 send , , nil
     0010 send , , nil
     0014 leave
     send


     View Slide

120. Specialized Instructions
     $ ruby -e"puts RubyVM::InstructionSequence.new(\"foo + bar\", nil, nil,
     0, :specialized_instruction => true).disasm"
     == disasm: #@>================================
     0000 putself
     0001 opt_send_without_block ,
     0004 putself
     0005 opt_send_without_block ,
     0008 opt_plus ,
     0011 leave
     send


     View Slide

121. Specialized Instructions
     do less work


     View Slide

122. Reminder: We haven’t even run
     any Ruby code yet.


     View Slide

123. Linked Lists:


     View Slide

124. Byte Code


     View Slide

125. iseq_setup


     View Slide

126. iseq_set_sequence


     View Slide

127. Byte Code:
     A list of integers*.
     *The integers are addresses


     View Slide

128. This fact will come back to
     "byte" us.


     View Slide

129. Raw Instructions
     /**
     ruby insn object list -> raw instruction sequence
     */
     static int
     iseq_set_sequence(rb_iseq_t *iseq, LINK_ANCHOR *anchor)
     {
     LABEL *lobj;
     INSN *iobj;
     struct iseq_line_info_entry *line_info_table;
     unsigned int last_line = 0;
     LINK_ELEMENT *list;
     VALUE *generated_iseq;
     List of actual instructions
     and parameters


     View Slide

130. Adds instruction to the list
     generated_iseq[code_index] = insn;
     …
     case TS_VALUE: /* VALUE */
     {
     VALUE v = operands[j];
     generated_iseq[code_index + 1 + j] = v;
     /* to mark ruby object */
     iseq_add_mark_object(iseq, v);
     break;
     }
     Put the instruction in
     Add Parameter


     View Slide

131. puts 'foo'
     $ ruby -e"puts RubyVM::InstructionSequence.new(\"puts 'foo'\").disasm"
     == disasm: #@>================================
     0000 trace 1
     ( 1)
     0002 putself
     0003 putstring "foo"
     0005 opt_send_without_block ,

     0008 leave
     insn
     "foo"


     View Slide

132. We finally have
     our byte code!


     View Slide

133. Virtual Machine


     View Slide

134. insns.def


     View Slide

135. Instruction Format
     @c: category
     @e: english description
     @j: japanese description
     instruction form:
     DEFINE_INSN
     instruction_name
     (instruction_operands, ..)
     (pop_values, ..)
     (return value)
     {
     .. // insn body
     }
     Byte Code
     Stack


     View Slide

136. putstring Instruction
     /**
     @c put
     @e put string val. string will be copied.
     @j จࣈྻΛίϐʔͯ͠ελοΫʹϓογϡ͢Δɻ
     */
     DEFINE_INSN
     putstring
     (VALUE str)
     ()
     (VALUE val)
     {
     val = rb_str_resurrect(str);
     }


     View Slide

137. VM Optimizations


     View Slide

138. VM Optimization List
     $ ruby -e'p RubyVM::OPTS'
     ["direct threaded code", "operands unification", "inline method cache"]


     View Slide

139. Check vm_core.h


     View Slide

140. Native Execution


     View Slide

141. Code


     View Slide

142. Decode and Dispatch


     View Slide

143. Code
     Loop
     Routine
     Routine


     View Slide

144. Threaded Interpretation


     View Slide

145. Code
     Loop
     Routine
     Routine


     View Slide

146. Code
     Dispatch
     Routine
     Routine
     Dispatch


     View Slide

147. 1. Our VM is Generated
     2. Eliminates the Loop


     View Slide

148. Code
     Dispatch
     Routine
     Routine
     Dispatch


     View Slide

149. We can do better!


     View Slide

150. What if:
     The instruction
     was a function address?


     View Slide

151. Direct Threaded Interpretation


     View Slide

152. Code
     Dispatch
     Routine
     Routine
     Dispatch


     View Slide

153. Failing at AOT Compiling


     View Slide

154. Byte Code:
     A list of integers*.
     *The integers are addresses


     View Slide

155. AHA! If it’s just a list
     of integers, we should be
     able to save that list to a
     file, then load it again.


     View Slide

156. Past Aaron was not too bright.


     View Slide

157. Adds instruction to the list
     generated_iseq[code_index] = insn;
     …
     case TS_VALUE: /* VALUE */
     {
     VALUE v = operands[j];
     generated_iseq[code_index + 1 + j] = v;
     /* to mark ruby object */
     iseq_add_mark_object(iseq, v);
     break;
     }
     Add Parameter


     View Slide

158. VALUE is a heap allocated
     Ruby object.


     View Slide

159. The Pointer Always Changes


     View Slide

160. The Object must be written to
     disk.


     View Slide

161. END STUFF


     View Slide

162. Practical Applications


     View Slide

163. Tweak Optimizations


     View Slide

164. Understand what your Ruby
     code is *really* doing.


     View Slide

165. Interpolation vs String#+
     # "#{foo}#{bar}" vs foo + bar
     z = RubyVM::InstructionSequence.new <x = "\#{foo}\#{bar}"
     eoruby
     puts z.disasm
     z = RubyVM::InstructionSequence.new <x = foo + bar
     eoruby
     puts z.disasm


     View Slide

166. Browse `iseq_compile_each`


     View Slide

167. Which is faster?
     TABLE = {
     'foo' => 'bar'.freeze,
     'bar' => 'baz'.freeze
     }
     def table_lookup x
     TABLE[x]
     end
     def case_lookup x
     case x
     when 'foo' then 'bar'.freeze
     when 'bar' then 'baz'.freeze
     end
     end


     View Slide

168. Now which is faster?
     TABLE = {
     'foo' => 'bar'.freeze,
     'bar' => 'baz'.freeze
     }
     def table_lookup x
     TABLE[x] || 'omg'.freeze
     end
     def case_lookup x
     case x
     when 'foo' then 'bar'.freeze
     when 'bar' then 'baz'.freeze
     when nil then 'omg'.freeze
     end
     end


     View Slide

169. Why?


     View Slide

170. REMEMBER THESE:


     View Slide

171. insns.def
     iseq_compile_each
     rb_iseq_compile_node


     View Slide

172. Where to learn more


     View Slide

173. yarvarch.ja
     #title YARVΞʔΩςΫνϟ
     #set author ೔ຊ Ruby ͷձ ͩ͜͞͞͏͍ͪ
     - 2005-03-03(Thu) 00:31:12 +0900 ͍Ζ͍Ζͱॻ͖௚͠
     ----
     * ͜Ε͸ʁ
     [[YARV: Yet Another RubyVM|http://www.atdot.net/yarv]] ͷ ઃܭϝϞͰ͢ɻ
     YARV ͸ɺRuby ϓϩάϥϜͷͨΊͷ࣍ͷػೳΛఏڙ͠·͢ɻ
     - Compiler
     - VM Generator
     - VM (Virtual Machine)
     - Assembler
     - Dis-Assembler
     - (experimental) JIT Compiler
     - (experimental) AOT Compiler
     ݱࡏͷ YARV ͸ Ruby ΠϯλϓϦλͷ֦ுϥΠϒϥϦͱ࣮ͯ͠૷͍ͯ͠·͢ɻ͜


     View Slide

174. yarvarch.en
     #title YARV: Yet another RubyVM - Software Architecture
     maybe writing.
     * YARV instruction set



     View Slide

175. View Slide

176. Thank You!!!


     View Slide
