1. Using Splunk Uses and User Stories
2. What is Splunk? • Hugs and Unicorns • For those that wish to play the Splunk home game: • https://github.com/tfhartmann/ splunk101
3. What Is Splunk? • An engine that indexes time series ASCII events, providing strong searching, reporting, and analytical tools. • A Sonic Screwdriver • What Splunk *isn’t* - a database
4. User Searches Network Devices: Routers Switches Firewalls Network Appliances: TACACS VPN SourceFire StealthWatch Splunk Forwarders: Linux Solaris Windows Servers Phase 4, version 2 splunkcollector1 splunkcollector1 Various destinations: • Qradar • LCE • Nessus Pages Emails Filtered Selective unfiltered Unfiltered Opsware TCP UDP splunkindex1 splunksearch1 splunksearch2 splunksearch1 splunksearch2 splunkindex2 splunkindex3 splunkindex4 splunkindex1 splunkindex2 splunkindex3 splunkindex4 What is Splunk? • Events are sent into indexers via agents, files, or by listening on open ports • Users interface with Splunk through the GUI, CLI, or API on “Search Heads”
5. Reporting / Dashboards
6. Track -A- MAC • As a SysAdmin I want to automate tracking and notification of stolen hardware so that I can notify alert the Police if it it shows up on campus. • When a laptop is stolen it will either stay on the campus network, or join a managed network somewhere in town, when this happens we want to notify the campus PD so that they can respond. • Originally this process was manual, or a cron job that polled network devices grep’ing for a match. This then started a chain of manual procedures to notify the appropriate officer.
7. Track -A- MAC v2.0 • Search was critical to how this was done in automating the process. • Notifications: • Splunk allows for built in notifications through emails and custom scripts • Sub Searches which allowed us to push a csv from another app (Essential) • Lookups allowed us to integrate multiple tools within a single search query • Campus Map API • Custom “Who Is” app which looked up switch information
8. Track -A- MAC - Impact • By Automating the process we were able to: • Quickly alert the appropriate authorities and recover stolen hardware. • Provide a self service portal for the PD and Security and streamline the process of adding stolen hardware to the watch list.
9. Spammers!   • As an email admin I want to locate compromised accounts so that the mail performance doesn’t suffer when spammers compromise a user account to send spam. • Our UNIX Team ran into an issue where they were alerted that mail performance was suffering. Most often caused by a compromised user account being used to relay spam from the mail servers.
10. Spammers!   • Using standard deviation of login events was essential to catching spammers early. • The UNIX pipeline style of the search language allowed administrators without a statistics background to use existing tools and data. • The ability to trigger an external account lockout event through a script was essential
11. Spammers!  -­‐  Impact • By analyzing users actual usage patterns and acting when that pattern changed erratically we were able to address a problem before it became service impacting. • We used role based access controls to ensure that sensitive data was only accessible to the appropriate teams. • Our SysAdmin were happier; hugs and Unicorns for all!
12. DMCA Policy Violations • As a IT security officer I want to respond to DMCA (Digital Millennium Copyright Act ) violation notices so that I can comply with the organizations legal obligations • receiving and responding to DMCA notifications was a long and arduous process. Emails were parsed by the mail servers and forwarded to the Cyber Security team, who had to track back the offending IP address to a particular person. • A string of IT Security people, a dedicated lawyer, and multiple operations people were required to track back the relevant information • Parts of the process were automated but fragile and prone to breaking
13. DMCA Policy Violations v2.0 • To address this we used Splunk to map back, *who* had *what* IP address when. • Searching across multiple data sources, DNS, DHCP, PAT/NAT logs, wireless access point, and routers and switches was critical • Lookup were critical in mapping MAC, IP Address, and ports back to a registered user. • macros were essential and allowed us to create custom functions that we could present through the API to security team. • REST API was essential in providing a constant interface for external tools to integrate with
14. DMCA Policy Violations Impact • By completely automating the process we were able to speed the process up, freeing up staff time. • Increase the the hit rate to 100% • Remove false positives • Provide self services interfaces to our Security team though the API and RBAC
15. Visualizing Network Data • As a Network Manager I want to know who is using eduRoam so that I can plan for the future.
16. VPN Usage • As the NOC I want to dashboards on the status of our VPN service so that I can publish our service status to the IT community.
17. NetFlow / Binary Data • As a Network/Security Engineer I want to perform analysis on NetFlow Data so that I can determine patterns in network traffic and the effects • NetFlow is a Cisco binary protocol used to analyze network flows: a sequence of packets from a source computer to a destination • Although NetFlow can be translated into text output in much the same way as syslog, Splunk can not natively ingest NetFlow streams.
18. NetFlow / Binary Data • The volume of data produced by most networks is large enough to require larger Splunk infrastructures and more storage. • Splunk is licensed by volume of data ingested per day, which makes NetFlow data often prohibitively expensive. • Although we wanted to use Splunk the obstacles of ingesting a binary source data and license cost pushed us towards other products like flow analyzers like Stealthwatch
19. Summary (Pro’s) • Splunk is a great tool for discovering and making use of chaotic time based event streams • Case 1: Track -A- MAC we are able to correlate disparate data sources, preform external lookups to enrich the data and then trigger actions in an automated way to help recover stolen property. • Case 2: Compromised Email accounts. Splunks presentation of common statistical tools allowed nonspecialists to preform more in depth analysis of the event stream in order to increase service availability. • Easy to Install and configure - a Single RPM and configuration is done through INI Files. • UNIX style pipeline, the ease in which data is ingested, and the ability to enrich the data allowed for a lot flexibility. • Role Based Access Control allowed us to comply with policies and secure our data.
20. Wait… what about.. • When we initially started using Splunk, we were also considering the ArcSite logger. • ArcSite proved difficult to configure even with professional services • The logger application was Slooooow • Connectors proved fragile and unless events were standardized in a particular way didn’t match • Initially in our environment the was a strongly configured syslog-ng server that Arcsite was never able to consume • We weren’t easily able to answer many ‘open ended’ questions
21. Summary (Con’s) • Splunk is not a great tool for consuming binary data. • Splunk licensing is a large deterrent to adoption, especially when the data volumes are high and the user case are open ended, for example DNS query logs or NetFlow data • Splunk is not a great tool when data sets aren’t marked with a time stamp. • While flat text files can be indexed and searched, Splunk treats the event like a time based event.
