How music works, using Ruby

How music works, using Ruby

That strange phenomenon where air molecules bounce against each other in a way that somehow comforts you, makes you cry, or makes you dance all night: music. Since the advent of recorded audio, a musician doesn't even need to be present anymore for this to happen (which makes putting "I will always love you" on repeat a little less awkward).

Sound engineers have found many ways of making music sound good when played from a record. Some of their methods have become industry staples used on every recording released today.

Let's look at what they do and reproduce some of their methods in Ruby!

See https://github.com/thijsc/how_music_works for all code examples.

4a1379eb0f10e1dd0e1466bfbf0f8245?s=128

Thijs Cadier

May 18, 2022
Tweet

More Decks by Thijs Cadier

Other Decks in Programming

Transcript

  1. How Music Works Thijs Cadier / / How music works

    RailsConf 2022 RailsConf 2022
  2. •Get interested, don’t understand it •Write Code •Understand it a

    whole lot better •Show the outcome of this to you all! My process 00 Thijs Cadier / / How music works RailsConf 2022
  3. Thijs Cadier / / How music works RailsConf 2022 What

    we are covering today: 01 What is music made of? 02 A very brief history of recorded music 03 Digital audio 04 Ampli fi cation 05 Making sounds 06 Mixing 07 Compression 01 What is music made of? 02 A very brief history of recorded music 03 Digital audio 04 Ampli fi cation 05 Making sounds 06 Mixing 07 Compression Thijs Cadier / / How music works
  4. A waveform that we perceive as having pitch, timbre and

    a tempo. What is music made of? 01 Thijs Cadier / / How music works RailsConf 2022
  5. A waveform Thijs Cadier / / How music works RailsConf

    2022
  6. None
  7. From a sound source to your ear Thijs Cadier /

    / How music works RailsConf 2022
  8. Your ear resonates with the waveform

  9. From follicles to your brain

  10. How does the brain map a waveform? Thijs Cadier /

    / How music works RailsConf 2022
  11. Pitch 0s 2s Thijs Cadier / / How music works

    RailsConf 2022
  12. Timbre Thijs Cadier / / How music works RailsConf 2022

  13. Tempo Thijs Cadier / / How music works RailsConf 2022

  14. 0s 2s

  15. Back in the day music was always live. Thijs Cadier

    / / How music works RailsConf 2022
  16. Recorded music But then came Thijs Cadier / / How

    music works RailsConf 2022
  17. 02 A very brief history of recorded music Thijs Cadier

    / / How music works RailsConf 2022
  18. None
  19. None
  20. None
  21. None
  22. None
  23. None
  24. None
  25. None
  26. None
  27. None
  28. None
  29. Digital audio 03 Thijs Cadier / / How music works

    RailsConf 2022
  30. None
  31. None
  32. Digital audio A lot of numbers in a sequence Thijs

    Cadier / / How music works RailsConf 2022
  33. None
  34. 3 def read_wave(path) 4 # Open the input wave 5

    reader = WaveFile::Reader.new(path) 6 # Prepare a buffer for all samples 7 samples = [] 8 # Loop through all buffers in the file 9 loop do 10 begin 11 # Read part of the file 12 buffer = reader.read(8198) 13 # Add it to the samples buffer 14 samples.concat(buffer.samples) 15 rescue EOFError 16 # We're at the end, return the samples buffer 17 return samples 18 end 19 end 20 end
  35. None
  36. 22 def write_wave(path, samples) 23 WaveFile::Writer.new(path, wave_format) do |writer| 24

    writer.write(WaveFile::Buffer.new(samples, wave_format)) 25 end 26 end
  37. None
  38. None
  39. None
  40. None
  41. 14 def write_points_image(path, samples) 15 image = ChunkyPNG::Image.new(WIDTH, HEIGHT, BLACK)

    16 17 samples.each_with_index do |sample, i| 20 position = if sample > 0 21 HALFWAY - offset_from_halfway(sample) 22 else 23 HALFWAY + offset_from_halfway(sample) 24 end 25 26 image.rect(i, position, i + 8, position + 8, YELLOW, YELLOW) 27 end 28 29 separator_line(image) 30 31 image.save(path) 32 end
  42. None
  43. 41 slices = samples.each_slice(samples_per_pixel).map do |samples| 42 positive_average = samples.select

    do |sample| 43 sample.positive? 44 end.sum / samples_per_pixel 45 46 negative_average = samples.select do |sample| 47 sample.negative? 48 end.map do |sample| 49 sample.abs 50 end.sum / samples_per_pixel 51 52 # Return both 53 [positive_average, negative_average] 54 end
  44. 04 Amplification Thijs Cadier / / How music works RailsConf

    2022
  45. None
  46. None
  47. None
  48. 1 drum = read_wave("input/drum.wav") 2 3 def amplify(track, ratio) 4

    track.map do |sample| 5 sample * ratio 6 end 7 end 8 9 louder = amplify(drum, 2.0) 10 write_wave("output/louder.wav", louder)
  49. 1 drum = read_wave("input/drum.wav") 2 3 def amplify(track, ratio) 4

    track.map do |sample| 5 sample * ratio 6 end 7 end 8 9 clipping = amplify(drum, 4.0) 10 write_wave("output/clipping.wav", clipping)
  50. Clipping

  51. None
  52. 05 Making Sounds Thijs Cadier / / How music works

    RailsConf 2022
  53. None
  54. None
  55. 3 # Create output array 4 output = [] 5

    6 0..SAMPLE_RATE.times do 7 output << Random.rand(-30_000..30_000) 8 end 9 10 write_wave("output/noise.wav", output)
  56. None
  57. 1 class Square 2 include Enumerable 3 4 def next_sample

    5 sample = if @position < @length / 2 6 20_000 7 else 8 -20_000 9 end 10 @position += 1 11 if @position > @length 12 @position = 0 13 end 14 sample 15 end 16 17 def each 18 loop { yield next_sample } 19 end 20 end
  58. 3 # Create a new oscillator 4 oscillator = Square.new(440,

    SAMPLE_RATE) 5 6 # Create output array 7 output = [] 8 9 oscillator.each_with_index do |sample, i| 10 break if i > SAMPLE_RATE 11 output << sample 12 end 13 14 write_wave("output/square.wav", output)
  59. None
  60. 1 def next_sample 2 sample = Math.sin(@position * Math::PI /

    2) * 25_000 3 4 # Increment position 5 @position += @increment_by 6 7 # Reset position if over max 8 if @position >= frequency 9 @position = 0.0 10 end 11 12 # Return the sample 13 sample 14 end
  61. None
  62. None
  63. 3 SAMPLE_RATE = 44_100 4 5 # Create multiple oscillators

    6 a_note = Sine.new(440, SAMPLE_RATE) 7 c_sharp_note = Sine.new(554.37, SAMPLE_RATE) 8 e_note = Sine.new(659.25, SAMPLE_RATE)
  64. 10 # Create output array 11 output = [] 12

    13 0..SAMPLE_RATE.times do |i| 14 # Get the samples for all three notes 15 sample_one = a_note.next_sample / 3 16 sample_two = c_sharp_note.next_sample / 3 17 sample_three = e_note.next_sample / 3 18 19 output << sample_one + sample_two + sample_three 20 end 21 22 write_wave("output/chord.wav", output)
  65. None
  66. None
  67. 4 one = Sine.new(220, SAMPLE_RATE) 5 two = Square.new(220, SAMPLE_RATE)

    6 7 # Create output array 8 output = [] 9 10 0..SAMPLE_RATE.times do |i| 11 # Get the samples for all three notes 12 sample_one = one.next_sample / 3 13 sample_two = two.next_sample / 3 14 15 output << sample_one + sample_two 16 end
  68. 06 Mixing Thijs Cadier / / How music works RailsConf

    2022
  69. None
  70. Mixing multiple channels Thijs Cadier / / How music works

    RailsConf 2022
  71. Results in a complicated waveform Thijs Cadier / / How

    music works RailsConf 2022
  72. None
  73. 1 require_relative "../helpers" 2 3 bass = read_wave("input/bass.wav") 4 drum

    = read_wave("input/drum.wav") 5 piano = read_wave("input/piano.wav")
  74. 9 def sum_tracks(*tracks) 10 [].tap do |out| 11 for i

    in 0..tracks.first.length do 12 # Start with zero 13 summed = 0 14 15 # Loop through all the tracks and increment 16 # the summed sample with its value 17 tracks.each do |track| 18 next unless track[i] 19 # Increment the summed sample, but first 20 # make it a bit less loud so we don't clip 21 summed += track[i] / 1.5 22 end 23 24 # Append the summed sample to the output 25 out << summed 26 end 27 end 28 end
  75. None
  76. Compression 07 Thijs Cadier / / How music works RailsConf

    2022
  77. None
  78. Thijs Cadier / / How music works RailsConf 2022 0

    1 2 3 4 5 6 7 8 9 10 4 8 12 16
  79. Treshold Thijs Cadier / / How music works RailsConf 2022

    0 1 2 3 4 5 6 7 8 9 10 4 8 12 16
  80. Apply compression with a ratio Thijs Cadier / / How

    music works RailsConf 2022 0 1 2 3 4 5 6 7 8 9 10 4 8 12 16
  81. Apply compression with a ratio Thijs Cadier / / How

    music works RailsConf 2022 0 1 2 3 4 5 6 7 8 9 10 4 8 12 16
  82. Apply make up gain Thijs Cadier / / How music

    works RailsConf 2022 0 1 2 3 4 5 6 7 8 9 10 4 8 12 16
  83. None
  84. 5 def reduce_peaks(track, treshold, ratio) 6 [].tap do |out| 7

    track.each do |sample| 8 if sample > treshold or sample < -treshold 9 out << sample / ratio 10 else 11 out << sample 12 end 13 end 14 end 15 end
  85. 17 def apply_makeup_gain(track, makeup) 18 track.map do |sample| 19 sample

    * makeup 20 end 21 end
  86. 23 peaks_reduced = reduce_peaks(input, 1000, 8) 24 makeup_gain_applied = apply_makeup_gain(peaks_reduced,

    12.0) 25 26 # Write it to disk 27 write_wave("output/final.wav", makeup_gain_applied)
  87. None
  88. None
  89. ALMOST LUNCH TIME! Thijs Cadier / / How music works

    RailsConf 2022
  90. None
  91. LUNCH TIME! Thijs Cadier / / How music works RailsConf

    2022
