Data Hard with a Vengeance

© Microsoft Corporation

View Slide

“On the fountain, there should be 2 jugs, do you see
them? A 5 gallon and a 3 gallon. Fill one of the jug
with exactly 4 gallons of water and place it on the
scale and the timer will stop. It must be precise, one
ounce of more or less will result in detonation.
If you're still alive in 5 minutes, we'll speak.”

View Slide


View Slide

Action movies Software development
Heroes save the world Engineers build software
Tight deadlines
Yes Yes
Wrong information can be disastrous
Exploding bombs
World domination
Cancelled/delayed projects
Low quality software
Lost data
The ending
Usually happy end. Sometimes happy end.

View Slide

The personal health assistant Baymax
from the Disney picture
“Big Hero 6”

View Slide

Empower people involved with software
to make sound data-driven decisions
about software.
Bug tracking
Software analytics
Games analytics
Software quality
Process improvement
(branches, build)
Productivity

View Slide

ESE Group in
Summer 2014
ESE Group in
Summer 2013

View Slide


View Slide

CodeMine

View Slide

Six years ago…

View Slide

Windows
Brendan Murphy Nachi Nagappan

View Slide

Build
Organization
Source Code
Work Item
Code Review
Test
calls
resolves
opens
resolves
submits
belongs to
implements
requests
comments on
submits
as
belongs to
tests
uses
edits
submitted
into
moves
defines
defines
works
with
Process Information
ships
from
ships
created on
built on
Schedule
Product
Test Job
Executable
Integration
Branch
Change
Source
File
Procedure /
Method
Class / Type
Review
Feature /
Defect
Person
Jacek Czerwonka, Nachiappan Nagappan, Wolfram Schulte, Brendan Murphy:
CODEMINE: Building a Software Development Data Analytics Platform at Microsoft.
IEEE Software 30(4): 64-71 (2013)

View Slide

Risk Prediction

View Slide


View Slide

main
networking
multimedia
Branches at Microsoft
Changes are isolated
=> Less build and test breaks
Process overhead
Time delay (velocity)
integration
integration

View Slide

Blue nodes are
edits to the file
Orange nodes are
move operations

View Slide

Visualizing code velocity
Mostly edits
Mostly integrations
Avg. time for CL to reach next branch:
<= 1 week
>= 3 weeks

View Slide

Assessing branches
Delay
(Cost)
Provided Isolation
(Benefit)
Green dots
are branches
with high benefit
and low cost
Red dots
are branches
with high cost
but low benefit
Each dot
is a branch
Christian Bird, Thomas Zimmermann:
Assessing the value of branches with what-if analysis. SIGSOFT FSE 2012

View Slide

Assessing branches
Delay
(Cost)
Provided Isolation
(Benefit)
Green dots
are branches
with high benefit
and low cost
Red dots
are branches
with high cost
but low benefit
Each dot
is a branch
Christian Bird, Thomas Zimmermann:
Assessing the value of branches with what-if analysis. SIGSOFT FSE 2012
If high-cost-low-benefit had been removed,
changes would each have saved 8.9 days of delay
and only introduced 0.04 additional conflicts.

View Slide

Simplified branch trees
Branching Taxonomy. B. Murphy, J. Czerwonka, and L. Williams. Microsoft Research
Technical Report. MSR-TR-2014-23. http://research.microsoft.com/apps/pubs/?id=209683

View Slide

Field Studies

View Slide


View Slide

Cowboys, ankle sprains, and keepers of quality: How is
video game development different from
software development? Emerson R. Murphy-Hill,
Thomas Zimmermann, Nachiappan Nagappan. ICSE 2014
Understanding and improving software
build teams.
Shaun Phillips, Thomas Zimmermann, Christian Bird.
ICSE 2014
A field study of
refactoring challenges and benefits.
Miryung Kim, Thomas Zimmermann, Nachiappan Nagappan.
SIGSOFT FSE 2012.
Refactoring

View Slide

http://aka.ms/145Questions
Andrew Begel, Thomas Zimmermann.
Analyze This! 145 Questions for Data Scientists in Software Engineering. ICSE 2014

View Slide

Microsoft’s Top 10 Questions Essential
Essential +
Worthwhile
How do users typically use my application? 80.0% 99.2%
What parts of a software product are most used and/or loved by
customers?
72.0% 98.5%
How effective are the quality gates we run at checkin? 62.4% 96.6%
How can we improve collaboration and sharing between teams? 54.5% 96.4%
What are the best key performance indicators (KPIs) for
monitoring services?
53.2% 93.6%
What is the impact of a code change or requirements change to
the project and its tests?
52.1% 94.0%
What is the impact of tools on productivity? 50.5% 97.2%
How do I avoid reinventing the wheel by sharing and/or searching
for code?
50.0% 90.9%
What are the common patterns of execution in my application? 48.7% 96.6%
How well does test coverage correspond to actual code usage by
our customers?
48.7% 92.0%
More at http://aka.ms/145Questions

View Slide

Games

View Slide

Thanks to our collaborators in Xbox, Microsoft Games Studios, and Turn 10.
Thanks to interns Ken Hullett, Sauvik Das, Jeff Huang, Gifford Cheung, Thomas Debeauvais,
Erik Harpstead and visiting researchers Tim Menzies and Emerson Murphy-Hill.
Xbox Live Influence of games and achievements on (paid) Xbox live memberships
Influence of friends on titles played
Characterizing players with Xbox Live data
Gameplay Impact of social behavior on retention (Beta of a AAA title)
Influence of gameplay on skill (Halo Reach) => CHI 2013
Assists in a car racing game (Forza 4) => FDG 2014
How to create a successful initial session in games => CHI Play 2014
Engineering Differences between game and traditional software development => ICSE 2014
Lessons learned from game development (ongoing)
Mining software repositories from games (ongoing)
Exploratory Personalization with Avatars in Xbox
Geographic influence, temporal influence, and structural influence

View Slide

Driving skill in Forza Motorsports 4
5% of player base,
sampled randomly
200k players who
played 25M races
Assist usage
Assist transitions
Thomas Debeauvais, Thomas Zimmermann, Nachiappan Nagappan, Kevin Carter, Ryan Cooper,
Dan Greenawalt, Tyson Solberg: An Empirical Study of Driving Skill in Forza Motorsports 4.
FDG 2014

View Slide


View Slide

Approaching a turn in Forza 4
– in EASY mode –

View Slide

Approaching a turn in Forza 4
– in HARD mode –

View Slide

The assist bundles in Forza 4
Easy Medium Hard Advanced Expert
Stability
prevents the car from spinning
when cornering too fast
ON OFF
Traction
prevents the car from spinning
when accelerating
ON OFF
Braking
supports the player when he/she
brakes or should brake
Assisted
w/ ABS
ABS OFF
Shifting helps the player in passing gears
Automatic
w/o clutch
Manual
w/o clutch
Manual
w/ clutch
Line
overlays the optimal trajectory to
follow on the track
Full Brake OFF
Damage
determines how much the
performance of the car can
change during the race
Cosmetic Limited Simulation

View Slide

number of races
Assist usage over number of races
career mode
online multiplayer
number of races

View Slide

Assist transitions
enabled
disabled
race before
race after
yoyo
failure
success
time
time
The player disables
the assist

View Slide

0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
success failure yoyo never disabled
Assist transitions

View Slide

Factors that contribute to the success
of disabling an assist
Factor More likely to keep the assist disabled … Significant for …
Number of races Players who disable an assist early All assists
Races per day Players who race fewer games a day All assists
Rear-wheel drive
(race before)
Players who drove a car with rear-wheel
drive
All assists
Car Performance Index
(race before)
Players who drove a car with lower PI All assists
Position
(race before)
Players who finished first All assists but
Traction and Clutch
Career mode
(race before)
Players who did not play career mode Autobrake, ABS,
Autoshift, Full line,
Brake line

View Slide

“Your work has been incredibly helpful to my
team. Just this week, we’ve had 8 hours of
meeting to design our core gameplay loops
based directly on your data. Quite literally,
we project your data and the player profiles
on the wall while we design. Its awesome.”
About our work on a different game title.

View Slide

How to measure insight?
Amount of discussion the
insight generates?
Number of times the users
invite you back?
Number of issues visited and
retired in a meeting?
Number of
hypotheses rejected?
Tim Menzies

View Slide

Questions you
want to ask
Questions
data
supports
Questions
user cares
about
Inductive Engineering
Tim Menzies, Christian Bird, Thomas Zimmermann, Wolfram Schulte, Ekrem Kocaganeli.
The Inductive Software Engineering Manifesto: Principles for Industrial Data Mining.
MALETS 2011

View Slide

Inductive Engineering
1. Users before algorithms
2. Plan for scale
3. Early feedback
4. Be open-minded
5. Do smart learning
6. Live with the data you have
7. Broad skill set, big toolkit

View Slide
