Azure Developer CLI Deep Dive

Sponsored · Your Podcast. Everywhere. Effortlessly. Share. Educate. Inspire. Entertain. You do you. We'll handle the rest. →
Toru Makabe
August 25, 2023

Azure Developer CLI Deep Dive

※リンクを多用しています。リンク効かせるにはダウンロードしてください。

Toru Makabe

August 25, 2023

Transcript

81 slides
  1. 一行にまとめると “azd provides best practice, developer-friendly commands that map to

    key stages in your workflow” What is the Azure Developer CLI? | Microsoft Learn
  2. azdとは • Microsoftが開発を主導する、OSSのCLIツール(MIT License) • Azureを使うアプリ/インフラ技術者、どちらにも有用 • テンプレートから、アプリとインフラのコードを生成 • 公開テンプレートの利用だけでなく、自ら作ることもできる

    • インフラのプロビジョニング • アプリのパッケージングとデプロイ • 複数の開発/実行環境、言語とIaCプロバイダーに対応 • Azure CLI(az)とは別もの Azure Developer CLIとは | Microsoft Learn Azure/azure-dev (github.com)
  3. テンプレート共有サイト(awesome-azd) Awesome AZD Templates | Awesome Azure Dev CLI 62テンプレート

    (2023/8/22現在) 作者が”Azure Dev”のものは azdチーム謹製
  4. サポートされる開発環境 • ローカル(Windows/Linux/macOS) • Dev Container/VS Code Remote – コンテナー

    • GitHub Codespaces • Azure Cloud Shell サポートされている言語と環境 | Microsoft Learn <メモ> azdを使った開発に限った話ではありませ んが、開発環境のCPUがarmアーキテク チャの場合、アプリの依存する要素(コ ンテナイメージなど)がarm未対応、とい うケースがぼちぼちあります。回避策の ひとつはCodespacesでx86マシンを使う、 です。
  5. サポートされる実行環境 • Azure App Service • Azure Static Web apps

    • Azure Container Apps(ベータ) • Azure Functions • Azure Kubernetes Service(ベータ) • Azure Spring Apps(ベータ) サポートされている言語と環境 | Microsoft Learn <メモ> アルファ版は試験的機能であり、`azd config`で明示的に有効にする必要があり ます。いっぽうベータ版では有効化は不 要です。破壊的変更が行われる可能性は ありますが、頻度低くコントロールされ、 かつ文書化されます。
  6. サポートされるIaCプロバイダー • Bicep • Terraform(アルファ) Azure Developer CLIのコード ツールとして Terraform

    をインフラ ストラクチャとして使用する | Microsoft Learn • 本日はBicepを中心に解説します
  7. 試すだけなら • azdをインストールする • `azd auth login`でAzureにログインする • `azd init`コマンドでテンプレートを選択し、コードを生成する

    • `azd up`する • 以下の操作がまとめて実行される • インフラのプロビジョニング: `azd provision` • アプリのパッケージング: `azd package` • アプリのデプロイ: `azd deploy` • すこぶる楽ちん
  8. 推しポイント • 「今風で気が利いている」リポジトリ構造と生成コード • 部分にとどまらず、全体をカバー(アプリとインフラ、開発と運用) • Azureの手練れたちが作った気の利いたテンプレートから生成されるコード • モノリポのリファレンスとしても有用(アプリとインフラ、複数サービス) •

    ちょっとした面倒な作業の自動化、省力化 • GitHub Actionsパイプラインの認証認可設定や変数登録などもコマンド一発 • 複数の環境を管理、切り替え可能 • azdは環境別(開発、本番など)に構成ファイルを作り、コマンド実行のつど読み込む • いちいち環境変数をセットする必要がない • `azd env select`で対象環境を切り替えられる • 活用の自由度が高い • テンプレートから生成されたコードだけ使う/参考にするもよし • azdのコードを読み、パッケージングやデプロイ自動化の参考にするもよし
  9. なぜazdのコードを読むのか • GAから間もなく、まだ情報が少ない • 公式ドキュメント(Microsoft Learn)が、いずれ拡充すると期待しつつ • 動きを理解するならコードを読むのが確実 • 自己解決能力を高める

    • 便利ゆえ、強く依存してしまう可能性がある • ブラックボックスにしない • コマンドの中でやっていることが参考になる • 自動化や効率化のヒントがたくさんある • 自動化に必要な情報とその取得元/取得方法、バリデーション、リソースの操作、エラー/ 例外処理、etc • そこに読めるコードがあるから • コツをつかめば難しくありません
  10. 読む環境 • VS Codeなどコードナビゲーションしてくれる環境がおすすめ • 定義や参照、実装へジャンプできると読みすすめやすい • Dev Containerはさらにおすすめ •

    azdのリポジトリにDev Container定義が入っている (GoツールチェインやVS Code Go拡張入り) • `azd init`でテンプレートからコードを生成しておくとよい • テンプレートは何でもよい (本日はContainerized React Web App with Java API and MongoDB on Azureを使用) • azdが生成し、参照、編集する対象を見ながらコードを読むとピンときやすい • azdコマンドを打ちながら読むとさらに腹落ちする
  11. 読む前に知っておきたいポイント • azdはGoで書かれている • CLIフレームワーク“Cobra”を使っている • お作法を知っていると読みやすい • DIコンテナ”golobby/container”を使っている •

    DI/IoCしているとわかっていれば読みやすい • 採用の経緯 https://github.com/Azure/azure-dev/pull/1253 • 拡張/差し替えしやすい作りにしている
  12. Cobraの基本(1/2) var cmdPrint = &cobra.Command{ Use: "print [string to print]",

    Short: "Print anything to the screen", Long: `print is for printing anything back to the screen. For many years people have printed back to the screen.`, Args: cobra.MinimumNArgs(1), Run: func(cmd *cobra.Command, args []string) { fmt.Println("Print: " + strings.Join(args, " ")) }, } Cobra. Dev • cobra.Command構造体にコマンドの中身を詰める • コマンド名と説明、引数、実行する関数などを定義する
  13. Cobraの基本(2/2) var rootCmd = &cobra.Command{Use: "app"} rootCmd.AddCommand(cmdPrint, cmdEcho) cmdEcho.AddCommand(cmdTimes) rootCmd.Execute()

    Cobra. Dev • ルートコマンドを作る • ルートコマンドにサブコマンドを追加する • サブコマンドにサブコマンドを追加できる • ルートコマンドを実行 • Cobraが入力に応じてコマンド(サブコマンド)を判断し、実行 • この例では`app print hoge`を実行すると、cmdPrintに定義したサブコマンドが引数hoge で呼ばれる
  14. サブサブ…コマンド configActions(root, opts) envActions(root) infraActions(root) pipelineActions(root) telemetryActions(root) templatesActions(root) authActions(root) https://github.com/Azure/azure-

    dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/cmd/root.go#L104 • NewRootComd関数にサブコマンドのサブコマンドまでベタに書くと、読みにくい • サブコマンドにサブコマンドがある場合、関数化している
  15. DIコンテナを意識(1/3) root.Add("show", &actions.ActionDescriptorOptions{ Command: newShowCmd(), FlagsResolver: newShowFlags, ActionResolver: newShowAction, OutputFormats:

    []output.Format{output.JsonFormat}, DefaultFormat: output.NoneFormat, }) https://github.com/Azure/azure-dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/cmd/root.go#L126 • cobra.Command構造体に直接詰めてないところがある • DIコンテナで後から解決するんだな、と意識して読む • 実行時の流れを追いたいときは、ActionResolverの定義に飛ぶ • この例ではnewShowAction • newShowActionはshowAction構造体を作る
  16. DIコンテナを意識(2/3) func (s *showAction) Run(ctx context.Context) (*actions.ActionResult, error) { res

    := contracts.ShowResult{ Name: s.projectConfig.Name, Services: make(map[string]contracts.ShowService, len(s.projectConfig.Services)), } [snip] https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/cmd/show.go#L87C1-L91C3 • 各コマンドには、その構造体をレシーバとするRunメソッドがある • 各コマンドが何をやっているかを知りたいときは、主にここを読む
  17. DIコンテナを意識(3/3) registerCommonDependencies(ioc.Global) cobraBuilder := NewCobraBuilder(ioc.Global) // Compose the hierarchy of

    action descriptions into cobra commands cmd, err := cobraBuilder.BuildCommand(root) https://github.com/Azure/azure-dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/cmd/root.go#L310 • DIまわりの処理は、この辺の関数を読むとわかる • コマンドの組み立てだけでなく、必要なリソースの準備もしている • 例: プロジェクト構成ファイルを読み込み、ProjectConfig構造体を作る • 「この構造体、どこで作ってるの…」なんて時は、この辺の関数を読んでみる
  18. Azureにログインする azd auth login [flags] --check-status --client-certificate string --client-id string

    --client-secret string --docs --federated-credential-provider string -h, --help --redirect-port int --tenant-id string --use-device-code[=true] • `azd login`はdeprecated Azure Developer CLI リファレンス | Microsoft Learn
  19. 認証情報の永続化場所 func GetUserConfigDir() (string, error) { configDirPath := os.Getenv("AZD_CONFIG_DIR") if

    configDirPath == "" { homeDir, err := os.UserHomeDir() if err != nil { return "", fmt.Errorf("could not determine current home directory: %w", err) } configDirPath = filepath.Join(homeDir, cConfigDir) [snip] https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/config/manager.go#L83 • Azure CLI(az)とは別なので注意 “.azd”
  20. azdプロジェクトを初期化する azd init [flags] -b, --branch string --docs -e, --environment

    string -h, --help -l, --location string --subscription string -t, --template string Azure Developer CLI リファレンス | Microsoft Learn
  21. テンプレート指定形式 switch strings.Count(path, "/") { case 0: return fmt.Sprintf("https://github.com/Azure-Samples/%s", path),

    nil case 1: return fmt.Sprintf("https://github.com/%s", path), nil default: return "", fmt.Errorf( [snip] https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/templates/path.go#L18 • -tオプションで、GitHubリポジトリからテンプレートの取得を試みる • オーナー名抜きでリポジトリ名のみが指定された場合は、Azure-Samplesの下を見に行く
  22. `azd init`で作成されるファイルとディレクトリ構造 ├── .azdo [ For Azure DevOps ] │

    └── azure-dev.yaml [ Azure Pipelines workflow to deploy to Azure using azd ] ├── .azure [ For storing Azure configurations] │ └── <your environment> [ For storing all environment-related configurations] │ ├── .env [ Contains environment variables ] │ └── config.json [ Contains environment configuration ] ├── .devcontainer [ For DevContainer ] │ ├── devcontainer.json [ For setting up the containerized development environment ] │ └── Dockerfile [ For building the container image ] ├── .github [ For GitHub workflow ] │ └── azure-dev.yaml [ GitHub Actions workflow to deploy to Azure using azd ] ├── infra [ For creating and configuring Azure resources ] │ ├── abbreviations.json [ Recommended abbreviations for Azure resources ] │ ├── main.bicep [ Main infrastructure file ] │ └── main.parameters.json [ Parameters file ] └── azure.yaml [ Describes the app and type of Azure resources] プロジェクトをAzure Developer CLIと互換性のあるものにする | Microsoft Learn
  23. 超重要! azure.yaml (1/2) name: todo-java-mongo-aca metadata: template: [email protected] services: web:

    project: ./src/web language: js host: containerapp api: project: ./src/api language: java host: containerapp • アプリのソースの場所や言語、実行環境などを指定する • このファイルの指定で、ビルドやパッケージング、デプロイで使うツールと動きが変わる
  24. 超重要! azure.yaml (2/2) services: api: project: ./src/api language: js host:

    appservice hooks: prerestore: shell: sh run: echo 'Restoring API service...' prepackage: run: ./hooks/prepackage.sh • コマンドの実行前後にフックを入れてカスタマイズできる コマンドフックとイベントフックを使用してAzure Developer CLIワークフローをカスタマイズする | Microsoft Learn
  25. 新しい環境を作り、既定値として設定する azd env new <environment> [flags] --docs -h, --help -l,

    --location string --subscription string Azure Developer CLI リファレンス | Microsoft Learn
  26. 環境関連ファイルのありか ├── .azdo [ For Azure DevOps ] │ └──

    azure-dev.yaml [ Azure Pipelines workflow to deploy to Azure using azd ] ├── .azure [ For storing Azure configurations] │ └── <your environment> [ For storing all environment-related configurations] │ ├── .env [ Contains environment variables ] │ └── config.json [ Contains environment configuration ] ├── .devcontainer [ For DevContainer ] │ ├── devcontainer.json [ For setting up the containerized development environment ] │ └── Dockerfile [ For building the container image ] ├── .github [ For GitHub workflow ] │ └── azure-dev.yaml [ GitHub Actions workflow to deploy to Azure using azd ] ├── infra [ For creating and configuring Azure resources ] │ ├── abbreviations.json [ Recommended abbreviations for Azure resources ] │ ├── main.bicep [ Main infrastructure file ] │ └── main.parameters.json [ Parameters file ] └── azure.yaml [ Describes the app and type of Azure resources]
  27. 既定の環境名 suggest := environment.CleanName(filepath.Base(wd) + "-dev") if len(suggest) > environment.EnvironmentNameMaxLength

    { suggest = suggest[len(suggest)- environment.EnvironmentNameMaxLength:] } • `azd init`時に新たな環境が作られるが、既定の環境名は実行ディレクトリ名 + “-dev” https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/cmd/init.go#L182
  28. .envファイルの例 AZURE_ENV_NAME="azd-demo-todo-java-aca-dev" AZURE_SUBSCRIPTION_ID="df671090-66cd-42d6-a023-164643e521fc" SERVICE_API_IMAGE_NAME="crmz36ye4xiqojo.azurecr.io/todo-java-mongo- aca/api-azd-demo-todo-java-aca-dev:azd-deploy-1691653114" SERVICE_API_RESOURCE_EXISTS="true" SERVICE_WEB_IMAGE_NAME="crmz36ye4xiqojo.azurecr.io/todo-java-mongo- aca/web-azd-demo-todo-java-aca-dev:azd-deploy-1691653230" SERVICE_WEB_RESOURCE_EXISTS="true" •

    azdの各コマンドが.envレコードを作成、参照する • 重要: `azd provision`の結果(出力)が保存される(後述) • .envファイルは.gitignoreでgitの対象から除外されている • azd利用者は後述の`azd env refresh`で.envを再現できる • .envにシークレットなど秘匿情報を置かないようにしましょう • テンプレートの多くが、秘匿情報はKey Vaultを使うようにしています
  29. azd env list 実行例 $ azd env list NAME DEFAULT

    azd-demo-todo-java-aca-dev false azd-demo-todo-java-aca-prod true
  30. 環境設定を更新する azd env refresh <environment> [flags] --docs -e, --environment string

    -h, --help --hint string • Azureのリソース(デプロイ結果)を取得し、.envに反映する • インフラをazdで管理しないプロジェクト、インフラを管理しない開発者にとって特に重要 • たとえばアプリのテストやデバッグだけのために.envを作りたい、というケース Azure Developer CLI リファレンス | Microsoft Learn
  31. 環境設定の取得先 (1/2) stateOptions := provisioning.NewStateOptions(ef.flags.hint) getStateResult, err := ef.provisionManager.State(ctx, stateOptions)

    if err != nil { return nil, fmt.Errorf("getting deployment: %w", err) } if err := provisioning.UpdateEnvironment(ef.env, getStateResult.State.Outputs); err != nil { return nil, err } • IaCプロバイダーから状態を取得し、.envを更新する https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/cmd/env.go#L423
  32. 環境設定の取得先 (2/2) deployments, err := p.findCompletedDeployments(ctx, p.env.GetEnvName(), scope, options.Hint()) [snip]

    state := State{} state.Resources = make([]Resource, len(deployment.Properties.OutputResources)) • Bicepの場合、完了したデプロイメント情報を取得し、outputResourcesを状態として扱う • よって.envに入れたい情報は、Bicepのoutputで定義しておく https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/infra/provisioning/bicep /bicep_provider.go#L209
  33. アプリで.envを読みたい "configurations": [ { "name": "Debug API", "type": "java", [snip]

    "envFile": "${input:dotEnvFilePath}" }, "inputs": [ { "id": "dotEnvFilePath", "type": "command", "command": "azure-dev.commands.getDotEnvFilePath" } ] • テスト/デバッグでアプリから.envを読みたいときがある • VS Code azd拡張のgetDotEnvFilePathコマンドで、その時点のdefault環境の.envパスを取得 • これはlaunch.jsonでの定義例
  34. Azure リソースをプロビジョニングする azd provision [flags] --docs -e, --environment string -h,

    --help --preview • --previewオプションを使うと、ドライランできる • BicepであればWhat-If Azure Developer CLI リファレンス | Microsoft Learn
  35. プロビジョニングに使われるコード ├── .azdo [ For Azure DevOps ] │ └──

    azure-dev.yaml [ Azure Pipelines workflow to deploy to Azure using azd ] ├── .azure [ For storing Azure configurations] │ └── <your environment> [ For storing all environment-related configurations] │ ├── .env [ Contains environment variables ] │ └── config.json [ Contains environment configuration ] ├── .devcontainer [ For DevContainer ] │ ├── devcontainer.json [ For setting up the containerized development environment ] │ └── Dockerfile [ For building the container image ] ├── .github [ For GitHub workflow ] │ └── azure-dev.yaml [ GitHub Actions workflow to deploy to Azure using azd ] ├── infra [ For creating and configuring Azure resources ] │ ├── abbreviations.json [ Recommended abbreviations for Azure resources ] │ ├── main.bicep [ Main infrastructure file ] │ └── main.parameters.json [ Parameters file ] └── azure.yaml [ Describes the app and type of Azure resources]
  36. 注: main.parameters.json { "$schema": "https://schema.management.azure.com/schemas/2019-04- 01/deploymentParameters.json#", "contentVersion": "1.0.0.0", "parameters": {

    "apiAppExists": { "value": "${SERVICE_API_RESOURCE_EXISTS=false}" }, "webAppExists": { "value": "${SERVICE_WEB_RESOURCE_EXISTS=false}" }, [snip] } } • `azd provision`を使わず、Bicepで直接プロビジョニングしたい場合は注意が必要 • `azd provision`は環境設定を元にmain.parameters.jsonの ${変数} を置き換えている • Bicepで直接プロビジョニングしたいときは、別途 ${変数} の部分をセットすること 環境変数を管理する | Microsoft Learn
  37. パラメータ置き換えの実装 "github.com/drone/envsubst“ [snip] replaced, err := envsubst.Eval(string(parametersBytes), func(name string) string

    { if name == environment.PrincipalIdEnvVarName { return principalId } return p.env.Getenv(name) }) • drone/envsubstを使ってパラメータを環境設定で置き換えている • drone/envsubstを使うと ${var=default} のような多様な表現が可能 • 例: "${SERVICE_WEB_RESOURCE_EXISTS=false}" https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/infra/provisioning/bicep/bicep_provider.g o#L40
  38. main.bicepのポイント var abbrs = loadJsonContent('./abbreviations.json') var resourceToken = toLower(uniqueString(subscription().id, environmentName,

    location)) var tags = { 'azd-env-name': environmentName } var apiContainerAppNameOrDefault = '${abbrs.appContainerApps}web-${resourceToken}' var corsAcaUrl = 'https://${apiContainerAppNameOrDefault}.${containerApps.outputs.defaultDomain}' • 複数環境でリソース名が衝突させないのは、azdではなくBibepの仕事 • ユニークになるような resourceTokenを作ってリソース名に追加している • 自らインフラのコードを書くときは意識する プロジェクトをAzure Developer CLIと互換性のあるものにする | Microsoft Learn
  39. アプリケーションのコードをパッケージングする azd package <service> [flags] --all --docs -e, --environment string

    -h, --help Azure Developer CLI リファレンス | Microsoft Learn • 例: Javaでは、ビルド(`mvn compile`)とパッケージング(`mvn package`)が実行される
  40. 複数フレームワーク対応 frameworkService, err := sm.GetFrameworkService(ctx, serviceConfig) [snip] buildResult, err :=

    runCommand( ctx, task, ServiceEventBuild, serviceConfig, func() *async.TaskWithProgress[*ServiceBuildResult, ServiceProgress] { return frameworkService.Build(ctx, serviceConfig, restoreOutput) }, ) • Mavenや.NETなど、複数のビルド/パッケージングフレームワークに対応する • FrameworkServiceインターフェイスを満たす構造体のBuildやPackageメソッドを呼ぶ https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/project/service_manager.go#L226
  41. 複数実行環境対応 serviceTarget, err := sm.GetServiceTarget(ctx, serviceConfig) [snip] err = serviceConfig.Invoke(ctx,

    ServiceEventPackage, eventArgs, func() error { [snip] serviceTargetPackageTask := serviceTarget.Package(ctx, serviceConfig, frameworkPackageResult) [snip] • App ServiceやContainer Appsなど、複数の実行環境(サービスターゲット)に対応する • ServiceTargetインターフェイスを満たす構造体のPackageメソッドを呼ぶ https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/project/service_manager.go#L280
  42. アプリケーションをAzureにデプロイする azd deploy <service> [flags] --all --docs -e, --environment string

    --from-package string -h, --help Azure Developer CLI リファレンス | Microsoft Learn
  43. azd upでやっていること packageOptions := &middleware.Options{CommandPath: "package"} _, err = u.runner.RunChildAction(ctx,

    packageOptions, packageAction) [snip] provision.flags = &u.flags.provisionFlags provisionOptions := &middleware.Options{CommandPath: "provision"} provisionResult, err := u.runner.RunChildAction(ctx, provisionOptions, provision) [snip] deployOptions := &middleware.Options{CommandPath: "deploy"} _, err = u.runner.RunChildAction(ctx, deployOptions, deploy) • package、provision、deployサブコマンドを呼び出している https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/cmd/up.go#L125
  44. デプロイ パイプラインを構成する azd pipeline config [flags] --auth-type string --docs -e,

    --environment string -h, --help --principal-id string --principal-name string --principal-role stringArray --provider string --remote-name string Azure Developer CLI リファレンス | Microsoft Learn • GitHub Actions/Azure DevOpsを構成する • 認証認可設定や変数登録ができる
  45. 認証認可設定 clientId, credentials, err := pm.adService.CreateOrUpdateServicePrincipal( ctx, pm.env.GetSubscriptionId(), appIdOrName, pm.args.PipelineRoleNames)

    [snip] err = pm.ciProvider.configureConnection( ctx, gitRepoInfo, prj.Infra, credentials, PipelineAuthType(pm.args.PipelineAuthTypeName)) • サービスプリンシパルを作り • パイプラインに対する認証認可設定を行う https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/pipeline/pipeline_manager.go#L219
  46. GitHub Actions認証認可 switch authType { case AuthTypeClientCredentials: authErr = p.configureClientCredentialsAuth(ctx,

    infraOptions, repoSlug, credentials) default: authErr = p.configureFederatedAuth(ctx, infraOptions, repoSlug, branches, credentials) } https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/pipeline/github_provider.go#L418 • 既定ではフェデレーション資格情報(OIDC)を使うように構成される
  47. GitHub Actions変数登録 for name, value := range map[string]string{ environment.EnvNameEnvVarName: p.env.GetEnvName(),

    environment.LocationEnvVarName: p.env.GetLocation(), environment.SubscriptionIdEnvVarName: p.env.GetSubscriptionId(), } { if err := p.ghCli.SetVariable(ctx, repoSlug, name, value); err != nil { return fmt.Errorf("failed setting %s variable: %w", name, err) } p.console.MessageUxItem(ctx, &ux.CreatedRepoValue{ Name: name, Kind: ux.GitHubVariable, }) } https://github.com/Azure/azure- dev/blob/99ea7577f0df0df2ba34b677da189fafba18c0f7/cli/azd/pkg/pipeline/github_provider.go#L453 • 環境名、ロケーション、サブスクリプションIDがGitHub Actionsの変数に登録される • そのほか、認証認可構成やIaCプロバイダーなどに応じて追加の変数が登録される
  48. 現状の考慮点  全環境が同じIaC(のコード)を使う  「開発環境はリソースを少なく」「開発中のIaCコードは別ディレクトリで」などができない  前述のとおり議論、開発中  ワークアラウンドはブランチの活用(アンチパターンという意見もあり) 

    環境間の差異が大きい場合はazdでインフラを管理せず、BYOI(Bring Your Own Infra.)も検討  `azd enf refresh`でインフラの情報を取得する  全コマンドを使うには広く強い権限が必要  チーム全員がフルスタックエンジニアであることは稀  インフラを管理する人と、そうでない人を分けて考えたほうがよい  環境によって操作したいリソースも異なる  環境ごとに適切なRBAC設定を行い、操作可能なリソースを限定する
