COM/DCOM: Forgotten Knowledge

Presentation from the phd12 conference report

Transcript

1. COM/DCOM:
   Forgotten Knowledge
   Vladislav Burtsev


   View Slide

2. 2
   COM/DCOM basics
   Advanced capabilities
   Tools & API
   Attacks: Direct COM/DCOM usage
   Attacks: COM Hijacking
   Detection
   Agenda
   2


   View Slide

3. History
   3
   Aimed to solve compatibility and
   sharing problems
   Introduced in 1990s
   and related with OLE, ActiveX,
   DCOM, COM+, MTS, etc
   COM/DCOM Basics


   View Slide

4. 4
   COM/DCOM Basics - Terms
   COM Interface
   A set of methods with defined binary layout
   COM Object
   An instance of a COM Class
   COM Component (COM Server)
   PE file with one or more COM Classes
   DLL
   Class
   Class Instance
   COM Class
   Implements one or more COM Interfaces


   View Slide

5. 5
   COM/DCOM Basics – IN- and OUT-of-process
   COM Server
   IN-process OUT-OF-process
   DLL
   Class
   Instance 1
   Instance 2
   Client Process Server Process
   Proxy to
   Instance 1
   Instance 1
   Stub
   marshal
   unmarshal


   View Slide

6. 6
   COM/DCOM Basics – IUnknown interface
   IUnknown
   COM Object
   HRESULT QueryInterface(const IID& riid, void** ppv);
   ULONG AddRef();
   ULONG Release();


   View Slide

7. 7
   COM/DCOM Basics – Invocation same host
   Client Application SCM
   1. Request with CLSID
   Registry
   2. Lookup in registry
   COM Object
   Server process
   3. Instantiates COM Object
   4. Passes pointer to Object
   5. Call COM Method
   (default) %SystemRoot%\System32\RtCOM64.dll


   View Slide

8. 8
   COM/DCOM Advanced capabilities – Invocation another host
   Registry
   Client
   SCM
   Proxy
   RPC
   SCM
   COM
   Object
   RPC
   Stub
   Application


   View Slide

9. 9
   COM/DCOM Advanced capabilities – Invocation another host
   PowerShell Empire
   ShellBrowserWindow
   ShellWindows
   MMC20.Application
   Excel.Application
   GetTypeFromCLSID
   GetTypeFromProgID
   DCOM
   ServiceStart
   ShellExecute
   ExecuteShellCommand
   RegisterXLL
   DDEInitiate


   View Slide

10. 10
    COM/DCOM Advanced capabilities – Multiple Languages
    C#
    C/C++
    PowerShell
    VBA
    Server XML HTTP 6.0
    open()
    send()
    …
    New-Object -ComObject Msxml2.ServerXMLHTTP.6.0
    [activator]::CreateInstance([type]::GetTypeFromCLSID(…))
    Dim myObj As Object
    Set myObj = CreateObject(“MSXML2.ServerXMLHTTP”)
    MSXML2.ServerXMLHTTP myObj = new ServerXMLHTTP();
    hr = CoCreateInstance(CLSID, NULL, CLSCTX_ALL,
    IID_Interface, reinterpret_cat(&iface))


    View Slide

11. 11
    COM/DCOM Tools & API – Instance Creation
    CoInitializeEx()
    CoCreateInstance()
    Initialize COM for the thread (put it into the
    apartment of given type)
    Create an instance of a given class and return
    a requested interface pointer to the new
    object.
    CoGetClassObject()
    CLSCTX_INPROC_SERVER
    CLSCTX_LOCAL_SERVER
    CLSCTX_REMOTE_SERVER
    Context
    Trying to get a pointer to IClassFactory
    interface
    ClassFactoryObject -> CreateInstance()


    View Slide

12. 12
    COM/DCOM Tools & API – Instance Creation
    CoGetClassObject(rclsid, dwClsContext, pServerInfo, riid, ppv)
    DLL EXE Service
    1. Locate CLSID in HKEY_CLASSES_ROOT
    2. Load DLL from InprocServer32 key
    CoLoadLibrary()
    3. Call GetProcAddress() for DllGetClassObject()
    4. Call DllGetClassObject()
    5. Return Class Factory to caller
    1. Locate CLSID in a global table that maps CLSID to its
    associated Class Factory. This map is managed by
    DCOMLaunch (hosted in svchost.exe)
    2. If not found, locate CLSID in HKEY_CLASSES_ROOT
    3. Launch executable from LocalServer32 key
    where Command Line is stored.
    DCOMLaunch uses CreateProcess()
    4. Created process registers itself in the DCOMLaunch
    table by calling CoRegisterClassObject()
    5. Once registered, client receives a proxy object to the
    class factory
    1. Locate CLSID in a global table that maps CLSID to
    its associated Class Factory. This map is managed
    by DCOMLaunch (hosted in svchost.exe)
    2. If not found, locate CLSID in HKEY_CLASSES_ROOT
    3. Launch executable from AppID key
    where Launch permissions and service name is
    stored.
    DCOMLaunch contacts SCM
    4. Created process registers itself in the
    DCOMLaunch table by calling
    CoRegisterClassObject()
    5. Once registered, client receives a proxy object to
    the class factory


    View Slide

13. 13
    COM/DCOM Advanced capabilities – regsvr32.exe
    LoadLibrary()
    GetProcAddress()
    DllRegisterServer()


    View Slide

14. 14
    COM/DCOM – AMSI
    PowerShell
    Windows Script Host
    JavaScript
    VBScript
    Office VBA
    source: https://learn.microsoft.com/en-us/windows/win32/amsi/how-amsi-helps


    View Slide

15. 15
    COM/DCOM – Attacks: Direct COM/DCOM Usage
    impacket : : dcomexec.py
    PowerShell Empire


    View Slide

16. 16
    COM/DCOM – Attacks: Direct COM/DCOM Usage


    View Slide

17. 17
    COM/DCOM – Attacks: Direct COM/DCOM Usage
    process_creation
    BitsDownload.exe
    file_event
    C:\Users\script.ps1
    Svchost.exe
    process_creation
    cmd.exe
    process_creation
    whoami.exe
    file_event
    C:\Users\info.txt


    View Slide

18. 18
    COM/DCOM – Attacks: COM Hijacking
    HKEY_CLASSES_ROOT
    File extension
    associations
    COM class
    registrations
    Virtualized
    registry root for
    UAC


    View Slide

19. The per-user class registration data in
    HKCU\SOFTWARE\Classes
    mapped to
    %SYSTEMROOT%\AppData\Local\Microsoft\Windows\Usrclass.dat
    19
    COM/DCOM – Attacks: COM Hijacking
    HKEY_CLASSES_ROOT
    Systemwide class registration data in
    HKLM\SOFTWARE\Classes
    = +


    View Slide

20. 20
    COM/DCOM – Abandoned COM keys


    View Slide

21. 21
    COM/DCOM – Attacks: COM Hijacking - ThreatAs


    View Slide

22. 22
    COM/DCOM – Attacks: COM Hijacking - ScriptletURL
    rundll32.exe –sta {GUID}


    View Slide

23. 23
    COM/DCOM – Attacks: COM Hijacking - ScriptletURL
    source: https://github.com/enigma0x3/windows-operating-system-archaeology/blob/master/Evasion/slmgr_COM_hijack.reg


    View Slide

24. 24
    COM/DCOM – Attacks: COM Hijacking - EoP
    source: https://github.com/hfiref0x/UACME


    View Slide

25. 25
    COM/DCOM – Detection
    GetTypeFromCLSID
    GetTypeFromProgID
    +
    ServiceStart
    ShellExecute
    ExecuteShellCommand
    RegisterXLL
    DDEInitiate
    EventID 4104/AMSI


    View Slide

26. 26
    COM/DCOM – Detection
    title: Component Object Model Hijacking via TreatAs
    description: Detects component object model hijacking via treatas
    author: Kaspersky
    status: stable
    tags:
    - attack.persistence
    - attack.privilege_escalation
    - attack.t1546.015
    - attack.defense_evasion
    - attack.t1112
    logsource:
    category: registry_set
    product: windows
    detection:
    selection:
    EventType: SetValue
    TargetObject|endswith:
    - 'Classes\CLSID\*\TreatAs'
    - 'Classes\CLSID\*\ScriptletURL'
    filter:
    Image|endswith:
    - 'program files\common files\microsoft shared\clicktorun\updates\*\officeclicktorun.exe'
    - 'windows\winsxs\amd64_microsoft-windows-servicingstack_*\tiworker.exe'
    condition: selection and not filter
    falsepositives: -
    level: high


    View Slide

27. 27
    COM/DCOM – Detection
    title: Component Object Model Hijacking via rundll32.exe
    description: Detects COM server start via rundll32. It's likely a hijacked COM component.
    author: Kaspersky
    status: stable
    tags:
    - attack.persistence
    - attack.privilege_escalation
    - attack.t1546.015
    - attack.t1548.002
    - attack.defense_evasion
    - attack.t1218.011
    logsource:
    category: process_creation
    product: windows
    detection:
    selection1:
    Image|endswith: '\rundll32.exe'
    selection2:
    CommandLine|contains:
    - '-sta '
    - '/sta '
    CommandLine|contains|all:
    - '{'
    - '}'
    selection3:
    CommandLine|contains: '-localserver '
    condition: selection1 and (selection2 or selection3)
    falsepositives: Legitimate soft (rare)
    level: high


    View Slide

28. Thank you!
    Vladislav Burtsev Threat Intelligence analyst @vladburch
    www.linkedin.com/in/vladislav-burtsev


    View Slide
