Performance Monitoring Options for WebRTC Deployments

Varun Singh, callstats.io
Presented remotely at WebRTC Meetup IsraelL www.meetup.com/WebRTC-IL/events/146894392/

Transcript

1. Performance Monitoring options for WebRTC deployments WebRTC Meetup, Israel 06 January, 2014 varun@callstats.io @vr000m
2. Varun Singh
3. Multimedia Congestion Control http://www.netlab.tkk.fi/~varun/publication.html http://arkko.com/tools/allstats/varunsingh.html
5. 5 Netradar: Active measurement platform http://www.netradar.org/en
6. 6 http://geek-and-poke.com/
7. Gameplan •  Do nothing à It is someone else’s problem – Insufficient Capacity – Misbehaving Browser – Or… NATs/Firewall – Other customer’s ISP 7
8. Do Nothing •  Use chrome://webrtc-internals •  User monitors their session 8
9. Berlin-Helsinki 0 500 1000 1500 2000 2500 3000 0 50 100 150 200 250 300 Delay Variation [ms] time [s] audio video 9
10. …but on a bad day 0 500 1000 1500 2000 2500 3000 3500 4000 0 50 100 150 200 250 300 350 400 450 500 Delay Variation [ms] time [s] … and this is just audio 10
11. So you’re going to 11 do performance monitoring …
12. Gameplan •  Do Nothing •  Endpoint Monitoring –  Detect à Fix •  Middlebox Monitoring –  Detect à Notify à Fix •  Silver bullet? 12 Ephemeral Fixes
13. Stats API •  Web app queries underlying RTP stack –  Per stream statistics (e.g., Audio and Video) –  In-bound and out-bound statistics •  Identifiers –  RTCP RR –  ICE candidates, … •  Query at application defined intervals –  Typically, 1s http://tools.ietf.org/html/draft-alvestrand-rtcweb-stats-registry http://tools.ietf.org/html/draft-singh-xrblock-webrtc-additional-stats 13
14. StatsAPI: Example var statCollector = setInterval(function () { if (pc && pc.getRemoteStreams() && active == true) { if (pc.getStats) { pc.getStats(onStatsSuccess); } else { log('No stats function. Use Chrome >24.0.1285'); } } }, 1000); onStatsSuccess = function (stats) { // parse the stats.result() // Audio and Video stats // Local and Remote stats } http://dev.w3.org/2011/webrtc/editor/webrtc.html#example 14
15. Middlebox •  TURN server, Conference Server, Gateway, Media Resource Function… •  Detecting WebRTC flows – observe 2 or more categories of packets – STUN messages – DTLS packets – RTP packets •  Audio frames (ptime between 10-30ms) •  Video packets (at least 7 frames per second) 15
16. Silver Bullet? 16
17. RTCP Monitoring •  Send metrics to a performance monitoring server •  Needs support in the WebRTC Stack – Implement RTCP Extension Reports http://tools.ietf.org/html/rfc6792 17
18. Performance Monitoring •  Annoyances – Call setup time, call failures, NAT traversal •  Transport quality – Relayed or not – Session throughput, delay and loss •  Per-stream media quality – MoS, User feedback 18
19. Silver Bullet? •  Correlate performance – Across sessions for the same user – Users in the same network location … à[Aggregate and Summarize]à …! 19
21. PeerConnection Browser Internals (WebRTC Stack) WebRTC API APP Browser Internals (WebRTC Stack) WebRTC API APP •  TURN •  Gateway WebRTC Server Monitoring Architecture Monitoring Server HTTP or WebSockets RTCP XR Client Monitoring STATS API HTTP, IPFIX, or NetFlow 21
22. JS SDK •  callstats.initializeSDK()! –  Authenticate with our backend •  callstats.AddNewFabric()! –  For each peer-connection, setup monitoring •  callstats.sendFabricEvent()! –  fabricSetup à start monitoring –  fabricFailed! –  fabricTerminated à stop monitoring –  … 22
23. 23 Gather Report Analyze FIX Deploy? webrtc-internal? via email? Has this been reported before? Did it solve the issue? Until next report? Integrate Deploy Diagnose FIX
25. Additional Features •  Coupling getUserMedia() constraints and StatsAPI •  better initial application settings – reorder optional and mandatory constraints. 25
26. Finally, •  Do Nothing – chrome://webrtc-internals •  Endpoint and Middlebox Monitoring •  RTCP XR monitoring 26
27. Call to Action •  Signup today at: – Twitter: @vr000m, @callstatsio – Facebook: www.facebook.com/callstats.io 27
