1. Python as number crunching glue Jiahao Chen jiahao@mit.edu @mitpostdoc theochem.mit.edu 1 Thursday, September 22, 2011
2. This is not a crash course on scientific computing or numerical linear algebra Recommended texts: 2 nr.com Thursday, September 22, 2011
3. NumPy and SciPy How to say: NumPy: no official pronunciation SciPy: “sigh pie” 3 Thursday, September 22, 2011
4. NumPy and SciPy How to say: NumPy: no official pronunciation SciPy: “sigh pie” 3 Where to get: scipy.org, numpy.scipy.org You might already have it Otherwise, have fun installing it ;) Thursday, September 22, 2011
5. You may already know how to use numpy/ scipy! Similar to Matlab, Octave, Scilab, R. see: http://mathesaurus.sourceforge.net/ In many cases, Matlab/Octave/Scilab code can be translated easily to use numpy +scipy+matplotlib. Other interfaces exist: e.g. mlabwrap lets you wrap Python around Matlab. 4 Thursday, September 22, 2011
6. Approximately continuous arithmetic floating point* - vs - Exact discrete arithmetic booleans, integers, strings, ... *David Goldberg, “What every computer scientist should know about floating-point arithmetic” 5 Thursday, September 22, 2011
7. Using numpy can make code cleaner 6 a = range(10000000) b = range(10000000) c = [] for i in range(len(a)): c.append(a[i] + b[i]) import numpy as np a = np.arange(10000000) b = np.arange(10000000) c = a + b What’s different?? Thursday, September 22, 2011
8. What’s different? 7 a = range(10000000) b = range(10000000) c = [] #a+b is concatenation for i in range(len(a)): c.append(a[i] + b[i]) import numpy as np a = np.arange(10000000) b = np.arange(10000000) c = a + b #vectorized addition Using numpy can save lots of time 0.333s 7.050s (21x) a convenient interface to compiled C/Fortran libraries: BLAS, LAPACK, FFTW, UMFPACK,... creates list of dynamically typed int creates ndarray of statically typed int Thursday, September 22, 2011
9. Numerical sw stack 8 Python BLAS NumPy SciPy FFTW ... linear algebra Fourier transforms External Fortran/C Your code LAPACK ... Thursday, September 22, 2011
10. “One thing that graduate students eventually learn is that you can hide just about anything in a NxN matrix... (for sufficiently large N)” - anonymous string theorist 9 Thursday, September 22, 2011
11. “One thing that graduate students eventually learn is that you can hide just about anything in a NxN matrix... (for sufficiently large N)” - anonymous string theorist 9 If your data can be put into a matrix/vector, numpy/scipy can help you! Thursday, September 22, 2011
12. You may already be working with matrix/vector data... 10 bitmap/video waveform database table text differential equation model graph Thursday, September 22, 2011
13. 11 # Chapter NumPy SciPy 1 Scientific Computing 2 Systems of linear equations X X 3 Linear least squares X 4 Eigenvalue problems X X 5 Nonlinear equations X 6 Optimization X 7 Interpolation X 8 Numerical integration and differntiation X 9 Initial value problems for ODEs X 10 Boundary value problems for ODEs X 11 Partial differential equations X 12 Fast Fourier Transform X 13 Random numbers and stochastic simulation X Table of contents from Michael Heath’s textbook Thursday, September 22, 2011
14. Outline: * NumPy: explicit data typing with dtypes : array manipulation with ndarrays * SciPy: high-level numerical routines : use cases * NumPy/SciPy as code glue: f2py and weave 12 Thursday, September 22, 2011
15. The most fundamental object in NumPy is the ndarray (N-dimensional array) v[:] vector M[:,:] matrix x[:,:,...,:] higher order tensor unlike built-in Python data types, ndarrays are designed for homogeneous, explicitly typed data 13 Thursday, September 22, 2011
16. numpy primitive dtypes 14 Bits Boolean Signed integer Unsigned integer Float Complex 8 bool int8 uint8 16 int16 uint16 32 int32 uint32 float32 64 int intp uint float float64 complex64 64 int64 uint64 float float64 complex64 128 float128 complex128 256 complex256 dtypes bring explicit typing to Python Thursday, September 22, 2011
17. >>> mol = np.array(mol, dtype={'atomicnum':('uint8',0), 'coords':('3float64',1)}) >>> mol['atomicnum'] array([8, 1, 1], dtype=uint8) Recarray: ndarray of data structure with named fields (record) 15 Structured array: ndarray of data structure >>> mol = np.zeros(3, dtype=('uint8, 3float64')) >>> mol[0] = 8, (-0.464, 0.177, 0.0) >>> mol[1] = 1, (-0.464, 1.137, 0.0) >>> mol[2] = 1, (0.441, -0.143, 0.0) >>> mol array([(8, [-0.46400000000000002, 0.17699999999999999, 0.0]), (1, [-0.46400000000000002, 1.137, 0.0]), (1, [0.441, -0.14299999999999999, 0.0])], dtype=[('f0', '|u1'), ('f1', '<f8', (3,))]) Thursday, September 22, 2011
18. The most fundamental object in NumPy is the ndarray (N-dimensional array) In 2D, the matrix class is also useful, especially when porting Matlab/Octave code. * For matrices, a*b is matrix multiply. For ndarrays, a*b is elementwise multiply. * Matrices have convenient attributes: M.T transpose of M M.H Hermitian conjugate of M M.I matrix inverse of M * Matrices are always 2D, no matter how you manipulate them. ****** This can lead to some very severe, insidious bugs. ****** using asarray() and asmatrix() views allows the best of both worlds. see: http://docs.scipy.org/doc/numpy/reference/ arrays.classes.html#matrix-objects 16 Thursday, September 22, 2011
19. Memory layout of matrices column major: first dimension is contiguous in memory Fortran, Matlab, R,... row major: last dimension is contiguous in memory C, Java, numpy,... Why you should care: • Cache coherence • Transposing a matrix is very expensive 17 Thursday, September 22, 2011
20. • from Python iterable: lists, tuples,... e.g. array([1, 2, 3]) == asarray((1, 2, 3)) • from intrinsic functions empty() allocates memory only zeros() initializes to 0 ones() initializes to 1 arange() creates a uniform range rand() initializes to uniform random randn() initializes to standard normal random ... • from binary representation in string/buffer • from file on disk 18 Creating ndarrays Thursday, September 22, 2011
21. fromfunction() creates an ndarray whose entries are functions of its indices e.g. the Hilbert matrix >>> np.fromfunction(lambda i,j: 1./(i+j+1), (4,4)) array([[ 1. , 0.5 , 0.33333333, 0.25 ], [ 0.5 , 0.33333333, 0.25 , 0.2 ], [ 0.33333333, 0.25 , 0.2 , 0.16666667], [ 0.25 , 0.2 , 0.16666667, 0.14285714]]) 19 1..n Generating ndarrays Thursday, September 22, 2011
22. arange(): like range() but accepts floats >>> import numpy as np >>> np.arange(2, 2.5, 0.1) array([ 2. , 2.1, 2.2, 2.3, 2.4]) linspace(): creates array with specified number of elements, spaced equally between the specified beginning and ending. >>> np.linspace(2.0, 2.4, 5) array([ 2. , 2.1, 2.2, 2.3, 2.4]) 20 Generating ndarrays Thursday, September 22, 2011
23. 21 ndarray native I/O Format Reader Writer pickle pickle.loads() dumps() pickle np.load() dumps() NPY np.load() np.save() NPZ np.load() np.savez() Memory map np.memmap np.memmap NPY is numpy’s native binary format NPZ is a zip file of NPYs Memory map: a class useful for handling huge matrices won’t load entire matrix into memory Thursday, September 22, 2011
24. 22 ndarray text I/O Format Reader Writer String eval() np.array_repr() String or below with StringIO or below with StringIO Text file np.loadtxt() np.genfromtxt() np.recfromtxt() savetxt() CSV np.recfromcsv() Matrix Market scipy.io.mmread() mmwrite() Thursday, September 22, 2011
25. 23 ndarray binary I/O Format Reader Writer List np.array() ndarray.tolist() String np.fromstring() tostring() String or below with StringIO or below with StringIO Raw binary file scipy.io.numpyio.fread() ndarray.fromfile() fwrite() .tofile() MATLAB scipy.io.loadmat() savemat() netCDF scipy.io.netcdf.netcdf_file scipy.io.netcdf.netcdf_file WAV audio scipy.io.wavfile.read() write() Image (via PIL) scipy.misc.imread() scipy.misc.fromimage() imsave() toimage() Also video (OpenCV), HDF5 (PyTables), FITS (PyFITS)... Thursday, September 22, 2011
26. Indexing >>> x = np.arange(12).reshape(3,4); x array([[ 0, 1, 2, 3], [ 4, 5, 6, 7], [ 8, 9, 10, 11]]) >>> x[1,2] 6 >>> x[2,-1] 11 >>> x[0][2] 2 >>> x[(2,2)] 10 >>> x[:1] array([[0, 1, 2, 3]]) >>> x[::2,1:4:2] array([[ 1, 3], [ 9, 11]]) 24 #slices return views, not copies #tuple row, then column Thursday, September 22, 2011
27. Fancy indexing >>> x = np.arange(12).reshape(3,4); x array([[ 0, 1, 2, 3], [ 4, 5, 6, 7], [ 8, 9, 10, 11]]) >>> x[(2,2)] 10 >>> x[np.array([2,2])] #same as x[[2,2]] array([[ 8, 9, 10, 11], [ 8, 9, 10, 11]]) >>> x[np.array([1,0]), np.array([2,1])] array([6, 1]) >>> x[x>8] array([ 9, 10, 11]) >>> x>8 array([[False, False, False, False], [False, False, False, False], [False, True, True, True]], dtype=bool) 25 array index Boolean mask Thursday, September 22, 2011
28. Fancy indexing II >>> y = np.arange(1*2*3*4).reshape(1,2,3,4); y array([[[[ 0, 1, 2, 3], [ 4, 5, 6, 7], [ 8, 9, 10, 11]], [[12, 13, 14, 15], [16, 17, 18, 19], [20, 21, 22, 23]]]]) >>> y[0, Ellipsis, 0] # == y[0, ..., 0] == [0,:,:,0] array([[ 0, 4, 8], [12, 16, 20]]) >>> y[0, 0, 0, slice(2,4)] # == y[(0, 0, 0, 2:4)] array([2, 3]) 26 Thursday, September 22, 2011
29. Broadcasting >>> x #.shape = (3,4) array([[ 0, 1, 2, 3], [ 4, 5, 6, 7], [ 8, 9, 10, 11]]) >>> y #.shape = (1,2,3,4) array([[[[ 0, 1, 2, 3], [ 4, 5, 6, 7], [ 8, 9, 10, 11]], [[12, 13, 14, 15], [16, 17, 18, 19], [20, 21, 22, 23]]]]) 27 >>> y * x array([[[[ 0, 1, 4, 9], [ 16, 25, 36, 49], [ 64, 81, 100, 121]], [[ 0, 13, 28, 45], [ 64, 85, 108, 133], [160, 189, 220, 253]]]]) What happens when you multiply ndarrays of different dimensions? Case I: trailing dimensions match Thursday, September 22, 2011
30. Broadcasting >>> a = np.arange(4); a array([0, 1, 2, 3]) >>> b = np.arange(4)[::-1]; b array([3, 2, 1, 0]) >>> a + b array([3, 3, 3, 3]) 28 What happens when you multiply ndarrays of different dimensions? Case II: trailing dimension is 1 >>> b.shape = 4,1 >>> a + b array([[3, 4, 5, 6], [2, 3, 4, 5], [1, 2, 3, 4], [0, 1, 2, 3]]) >>> b.shape = 1,4 >>> a + b array([[3, 3, 3, 3]]) Thursday, September 22, 2011
31. In 2D, the matrix class is often more useful than ndarrays, especially when porting Matlab/Octave code. * For matrices, a*b is matrix multiply. For ndarrays, a*b is elementwise multiply. * Matrices have convenient attributes: M.T transpose of M M.H Hermitian conjugate of M M.I matrix inverse of M * Matrices are always 2D, no matter how you manipulate them. ****** This can lead to some very severe, insidious bugs. ****** using asarray() and asmatrix() views allows the best of both worlds. see: http://docs.scipy.org/doc/numpy/reference/ arrays.classes.html#matrix-objects 29 Matrix operations Thursday, September 22, 2011
32. Matrix functions You can apply a function elementwise to a matrix... >>> from numpy import array, exp >>> X = array([[1, 1], [1, 0]]) >>> exp(X) array([[ 2.71828183, 2.71828183], [ 2.71828183, 1.]]) ...or a matrix version of that function >>> from scipy.linalg import expm >>> expm(X) array([[ 2.71828183, 7.3890561 ], [ 1. , 2.71828183]]) other functions in scipy.linalg.matfuncs 30 Thursday, September 22, 2011
33. SciPy by example * Data fitting * Signal matching * Disease outbreak modeling (epidemiology) 31 http://scipy-central.org/ Thursday, September 22, 2011
34. Least-squares curve fitting from scipy import * from scipy.optimize import leastsq from matplotlib.pyplot import plot #Make up data x(t) with Gaussian noise num_points = 150 t = linspace(5, 8, num_points) x = 11.86*cos(2*pi/0.81*t-1.32) + 0.64*t\ +4*((0.5-rand(num_points))*\ exp(2*rand(num_points)**2)) # Target function model = lambda p, x: \ p[0]*cos(2*pi/p[1]*x+p[2]) + p[3]*x # Distance to the target function error = lambda p, x, y: model(p, x) - y # Initial guess for the parameters p0 = [-15., 0.8, 0., -1.] p1, _ = leastsq(error, p0, args=(t, x)) t2 = linspace(t.min(), t.max(), 100) plot(t, x, "ro", t2, model(p1, t2), "b-") raw_input() 32 fit data to model Thursday, September 22, 2011
35. Matching signals Suppose I have a short audio clip that I know to be part of a larger file How can I figure out its offset? Problem: naïve matching scales as O(N2) 33 Thursday, September 22, 2011
36. An O(N lg N) solution Naïve matching scales as O(N2) How can we do faster? phase correlation Exploit Fourier transforms: they encode relative offsets in complex phase 34 60o 1/6 Thursday, September 22, 2011
37. From math to code 35 Thursday, September 22, 2011
38. From math to code 35 import numpy #Make up some data N = 30000 idx = 24700 size = 300 data = numpy.random.rand(N) frag_pad = numpy.zeros(N) frag = data[idx:idx+size] frag_pad[:size] = frag #Compute phase correlation data_ft = numpy.fft.rfft(data) frag_ft = numpy.fft.rfft(frag_pad) phase = data_ft * numpy.conj(frag_ft) phase /= abs(phase) cross_correlation = numpy.fft.irfft(phase) offset = numpy.argmax(cross_correlation) print 'Input offset: %d, computed: %d' % (idx, offset) from matplotlib.pyplot import plot plot(cross_correlation) raw_input() #Pause Thursday, September 22, 2011
39. From math to code 35 import numpy #Make up some data N = 30000 idx = 24700 size = 300 data = numpy.random.rand(N) frag_pad = numpy.zeros(N) frag = data[idx:idx+size] frag_pad[:size] = frag #Compute phase correlation data_ft = numpy.fft.rfft(data) frag_ft = numpy.fft.rfft(frag_pad) phase = data_ft * numpy.conj(frag_ft) phase /= abs(phase) cross_correlation = numpy.fft.irfft(phase) offset = numpy.argmax(cross_correlation) print 'Input offset: %d, computed: %d' % (idx, offset) from matplotlib.pyplot import plot plot(cross_correlation) raw_input() #Pause Thursday, September 22, 2011
40. Modeling a zombie apocalypse 36 http://blogs.cdc.gov/publichealthmatters/2011/05/preparedness-101- zombie-apocalypse/ Thursday, September 22, 2011
41. Modeling a zombie apocalypse 37 http://www.scipy.org/Cookbook/Zombie_Apocalypse_ODEINT Normal (S) Zombie Dead (R) Each person can be in one of three states Thursday, September 22, 2011
42. Modeling a zombie apocalypse 38 http://www.scipy.org/Cookbook/Zombie_Apocalypse_ODEINT Normal (S) Zombie Dead (R) Various processes connect these states birth (P) normal death + resurrection (G) transmission (B) destruction (A) Thursday, September 22, 2011
43. from numpy import linspace from scipy.integrate import odeint P = 0 # birth rate d = 0.0001 # natural death rate B = 0.0095 # transmission rate G = 0.0001 # resurrection rate A = 0.0001 # destruction rate def f(y, t): Si, Zi, Ri = y return [P - B*Si*Zi - d*Si, B*Si*Zi + G*Ri - A*Si*Zi, d*Si + A*Si*Zi - G*Ri] y0 = [500, 0, 0] # initial conditions t = linspace(0, 5., 1000) # time grid soln = odeint(f, y0, t) # solve ODE S, Z, R = soln[:, :].T From math to code 39 http://www.scipy.org/Cookbook/Zombie_Apocalypse_ODEINT S Z R r d + G B A Thursday, September 22, 2011
44. Using external code “NumPy can get you most of the way to compiled speeds through vectorization. In situations where you still need the last ounce of speed in a critical section, or when it either requires a PhD in NumPy-ology to vectorize the solution or it results in too much memory overhead, you can reach for Cython or Weave. If you already know C/C++, then weave is a simple and speedy solution. If, however, you are not already familiar with C then you may find Cython to be exactly what you are looking for to get the speed you need out of Python.” - Travis Oliphant, 2011-06-20 see: http://www.scipy.org/PerformancePython http://technicaldiscovery.blogspot.com/ 2011/06/speeding-up-python-numpy-cython- and.html 40 Thursday, September 22, 2011
45. Python as code glue - numpy.f2py: wraps * C, Fortran 77/90/95 functions * Fortran 90/95 module data * Fortran 77 COMMON blocks - scipy.weave * .inline: compiles & runs C/C++ code manipulating Python scalars/ndarrays * .blitz: interfaces with Blitz++ Other wrapper libraries and programs: see http://scipy.org/Topical_Software 41 Thursday, September 22, 2011
46. numpy.f2py: Fortran/C $ cat>invsqrt.f real*8 function invsqrt (a) real*8 a invsqrt = 1.0/sqrt(a) end $ f2py -c -m invsqrt invsqrt.f $ python -c 'import invsqrt; print invsqrt.invsqrt(4)' 0.5 see: http://www.scipy.org/F2py 42 $ cat>invsqrt.c #include <math.h> double invsqrt(a) { return 1.0/sqrt(a); } $ cat>invsqrt.m python module invsqrt interface real*8 function invsqrt(x) intent(c) :: invsqrt real*8 intent(in) :: x end function invsqrt end interface end python module invsqrt $ f2py invsqrt.m invsqrt.c -c $ python -c 'import invsqrt; print invsqrt.invsqrt(4)' 0.5 Thursday, September 22, 2011
47. scipy.weave.inline >>> from scipy.weave import inline >>> x = 4.0 >>> inline('return_val = 1./sqrt(x));', ['x']) 0.5 see: https://github.com/scipy/scipy/blob/ master/scipy/weave/doc/tutorial.txt 43 inline Extension python scipy weave distutils core on-the-fly compiled C/C++ program Thursday, September 22, 2011
48. scipy.weave.blitz Uses the Blitz++ numerical library for C++ Converts between ndarrays and Blitz arrays >>> # Computes five-point average using numpy and weave.blitz >>> import numpy import empty >>> from scipy.weave import blitz >>> a = numpy.zeros((4096,4096)); c = numpy.zeros((4096, 4096)) >>> b = numpy.random.randn(4096,4096) >>> c[1:-1,1:-1] = (b[1:-1,1:-1] + b[2:,1:-1] + b[:-2,1:-1] + b [1:-1,2:] + b[1:-1,:-2]) / 5.0 >>> blitz("a[1:-1,1:-1] = (b[1:-1,1:-1] + b[2:,1:-1] + b [:-2,1:-1] + b[1:-1,2:] + b[1:-1,:-2]) / 5.") >>> (a == c).all() True see: https://github.com/scipy/scipy/blob/master/scipy/weave/doc/ tutorial.txt 44 Thursday, September 22, 2011
49. Parallelization The easy way: numpy/scipy’s primitives automatically use vectorization compiled into external BLAS/LAPACK/... libraries The usual way: - MPI interfaces (mpi4py,...) - Python threads/multiprocessing/... - OpenMP/pthreads... in external C/Fortran see: http://www.scipy.org/ParallelProgramming 45 Thursday, September 22, 2011
50. How I use NumPy/Scipy 46 Text input Matrices Test model Visualize Text output scipy.optimize Quasi-Newton optimizers External binary Binary output ndarray. fromfile() Thursday, September 22, 2011
51. Beyond NumPy/SciPy 47 Python NumPy SciPy External Fortran/C My script CVXOpt many more examples at http://www.scipy.org/Topical_Software PyTables VTK matplotlib My interactive session Pylab HDF5 file I/O numerical optimization visualization PyMol molecule viz. plots Thursday, September 22, 2011
