diagramize it
Search
Taras Kalapun
February 07, 2014
Programming
1
1.6k
diagramize it
Presentation about free & open source tools to produce diagrams from textural description
Taras Kalapun
February 07, 2014
Tweet
Share
Other Decks in Programming
See All in Programming
私はどうやって技術力を上げたのか
yusukebe
43
19k
Leading Effective Engineering Teams in the AI Era
addyosmani
6
440
NixOS + Kubernetesで構築する自宅サーバーのすべて
ichi_h3
0
910
Introducing ReActionView: A new ActionView-Compatible ERB Engine @ Kaigi on Rails 2025, Tokyo, Japan
marcoroth
3
1k
uniqueパッケージの内部実装を支えるweak pointerの話
magavel
0
1k
iOSエンジニア向けの英語学習アプリを作る!
yukawashouhei
0
200
The Past, Present, and Future of Enterprise Java
ivargrimstad
0
390
Claude Agent SDK を使ってみよう
hyshu
0
800
エンジニアインターン「Treasure」とHonoの2年、そして未来へ / Our Journey with Hono Two Years at Treasure and Beyond
carta_engineering
0
200
The Past, Present, and Future of Enterprise Java
ivargrimstad
0
370
はじめてのDSPy - 言語モデルを『プロンプト』ではなく『プログラミング』するための仕組み
masahiro_nishimi
2
500
技術的負債の正体を知って向き合う / Facing Technical Debt
irof
0
180
Featured
See All Featured
Code Review Best Practice
trishagee
72
19k
Building Flexible Design Systems
yeseniaperezcruz
329
39k
The Art of Programming - Codeland 2020
erikaheidi
56
14k
Facilitating Awesome Meetings
lara
56
6.6k
Fantastic passwords and where to find them - at NoRuKo
philnash
52
3.4k
Build your cross-platform service in a week with App Engine
jlugia
232
18k
Visualizing Your Data: Incorporating Mongo into Loggly Infrastructure
mongodb
48
9.7k
Understanding Cognitive Biases in Performance Measurement
bluesmoon
31
2.7k
Why Our Code Smells
bkeepers
PRO
340
57k
Exploring the Power of Turbo Streams & Action Cable | RailsConf2023
kevinliebholz
35
6.1k
Designing for Performance
lara
610
69k
Build The Right Thing And Hit Your Dates
maggiecrowley
37
2.9k
Transcript
DIAGRAMIZE IT TARAS KALAPUN
BLOCK DIAGRAMS
YUML.ME [Customer]<>-orders*>[Order]! [Order]++-0..*>[LineItem]! [Order]-[note:Aggregate root.]
BLOCKDIAG blockdiag {! A -> B -> C -> D;!
A -> E -> F -> G;! }
BLOCKDIAG blockdiag {! WeatherApi [shape = ellipse];! AdMob [shape =
ellipse];! Cloud [shape = cloud];! User [shape = actor];! ! WeatherApi -> Cloud! AdMob -> Cloud! Cloud -> App! App -> User! }
GRAPHVIZ
digraph G {! ranksep = 1! rankdir = TD! node
[! shape = "record"! height = 0.50! fontsize = 10! margin = 0.20,0.05! ]! A2 [! label = "Customer]"! style = "filled"! fillcolor = ""! ]! node [! shape = "record"! height = 0.50! GRAPHVIZ
USE CASE DIAGRAMS
YUML.ME [Customer]-(Make Cup of Tea)! (Make Cup of Tea)<(Add Milk)!
(Make Cup of Tea)>(Add Tea Bag)
GRAPHVIZ digraph G {! rankdir=LR;! ! subgraph clusterUser {label="User"; labelloc="b";
peripheries=0; user};! user [shapefile="stick.png", peripheries=0, style=invis];! login [label="Log In", shape=ellipse];! ! user->login [arrowhead=none];! }
GRAPHVIZ http://martin.elwin.com/blog/2008/05/uml-use-case-diagrams-graphviz/
ACTIVITY DIAGRAMS
YUML.ME (start)->|a|! |a|->(Make Coffee)->|b|! |a|->(Make Breakfast)->|b|! |b|-><c>[want more coffee]->(Make Coffee)!
<c>[satisfied]->(end)
GNU PIC .PS! ellipse "document";! arrow;! box "\fIgpic\fP(1)"! arrow;! box
width 1.2 "\fIgtbl\/\fP(1) or \fIgeqn\/\fP(1)" "(optional)" dashed;! arrow;! box "\fIgtroff\/\fP(1)";! arrow;! ellipse "PostScript"! .PE http://floppsie.comp.glam.ac.uk/Glamorgan/gaius/web/pic.html
GRAPHVIZ
digraph untitled {! rankdir=TD! size="4,4"! edge[fontsize="11" arrowhead=open]! start[shape=circle, label="", style=filled]!
end[shape=doublecircle, label="", style=filled]! action1[shape=box,style=rounded, label="action"]! action2[shape=box,style=rounded, label="action"]! action3[shape=box,style=rounded, label="action"]! if1[shape=diamond, label="decision"]! if2[shape=diamond, label="decision"]! ! start -> action1! action1 -> if1[headport=n]! if1 -> action2[label="condition" tailport=w]! if1 -> action3[taillabel="condition" labeldistance=2.5 tailport=e]! action2 -> if2[headport=w]
ACTDIAG actdiag {! write -> convert -> image! ! lane
user {! label = "User"! write [label = "Writing reST"];! image [label = "Get diagram IMAGE"];! }! lane actdiag {! convert [label = "Convert reST to Image"];! }! }
SEQUENCE DIAGRAMS
WEBSEQUENCEDIAGRAMS A->+B: text! B-->-A: text! A->B: text2
SEQDIAG seqdiag {! browser -> webserver [label = "GET /index.html"];!
browser <-- webserver;! browser -> webserver [label = "POST /blog/comment"];! webserver -> database [label = "INSERT comment"];! webserver <-- database;! browser <-- webserver;! }
PIC2PLOT brew install plotutils! https://github.com/dspinellis/UMLGraph/blob/master/sequence.pic! ! http://projetos.edugraf.ufsc.br/2011/1/convidado/jgzeni/ ProjetoFinal/JogoDeCartas/002/bin/src/UMLGraph-5.4/doc/uml- appa.html!
.PS! ! copy "sequence.pic";! ! boxwid = 1.1;! movewid =
0.5;! ! # Define the objects! object(C,"c:Client");! pobject(T);! object(P,"p:ODBCProxy");! ! # Message sequences! step();! active(C);! cmessage(C,T,":Transaction");! oconstraint("{Transient}");
OTHER COOL DIAGRAMS
NWDIAG
nwdiag {! network dmz {! address = "210.x.x.x/24"! ! //
set multiple addresses (using comma)! web01 [address = "210.x.x.1, 210.x.x.20"];! web02 [address = "210.x.x.2"];! }! network internal {! address = "172.x.x.x/24";! ! web01 [address = "172.x.x.1"];! web02 [address = "172.x.x.2"];! db01;! db02;! }! }
RACKDIAG rackdiag {! // define height of rack! 16U;! !
// define rack items! 1: UPS [2U];! 3: DB Server! 4: Web Server 1 // put 2 units to r 4: Web Server 2! 5: Web Server 3! 5: Web Server 4! 7: Load Balancer! 8: L3 Switch! }
ASCII DITAA +--------+ +-------+ +-------+! | | --+ ditaa +-->
| |! | Text | +-------+ |diagram|! |Document| |!magic!| | |! | {d}| | | | |! +---+----+ +-------+ +-------+! : ^! | Lots of work |! +-------------------------+ http://ditaa.sourceforge.net
GRAPHVIZ IC
digraph G {! graph [rankdir = LR];! ! node[shape=record];! Bar[label="{
\"Bar\"|{<p1>pin 1|<p2> 2|<p3> 3|<p4> 4| <p5> 5} }"];! Foo[label="{ {<data0>data0|<data1>data1|<data2>data2|<data3>data3| <data4>data4}|\"Foo\" |{<out0>out0|<out1>out1|<out2>out2|<GND>gnd| <ex0>ex0|<hi>hi|<lo>lo} }"];! ! Bew[label="{ {<clk>clk|<syn>syn|<mux0>mux0|<mux1>mux1| <signal>signal}|\"Bew\" |{<out0>out0|<out1>out1|<out2>out2} }"];! Bar:p1 -> Foo:data0;! Bar:p2 -> Foo:data1;! Bar:p3 -> Foo:data2;! Bar:p4 -> Foo:data3;! Bar:p5 -> Foo:data4;
THX! Q?
