Java Debugging Internals - JPrime 2023

Learn how to build a debugger in Java using built-in Java concepts and APIs!

Transcript

1. Java Debugging Internals @yardenlaif
2. 2 Who Am I? • Software Engineer at Rookout • Java, Go, Ruby • C#, Python, JavaScript, C++ • Amateur sewist
3. The Objective: Dynamic Snapshots • Dynamically add/remove snapshots on lines of code • Capture local variables • Capture stack trace 3
4. The Objective: Dynamic Snapshots • Dynamically add/remove snapshots on lines of code • Capture local variables • Capture stack trace 4 Breakpoints?
5. The Objective: Dynamic Snapshots • Dynamically add/remove snapshots • Capture local variables • Capture stack trace 5 Breakpoints? breakpoints on lines of code
6. Production Grade Breakpoints • Minimum performance impact • Debug more than one instance at a time • Multiple people debugging the same instance 6
7. jdb -attach 8000 java -agentlib:jdwp= transport=dt_socket,server=y, suspend=n,address=*:8000 myApp JDB - The Java Debugger 7 JVM MyApp Debugger CLI
8. JPDA - Java Platform Debugging Architecture The Java Platform Debugger Architecture (JPDA) consists of three interfaces designed for use by debuggers in development environments for desktop systems. - Oracle Documentation 8
9. JPDA - Java Platform Debugging Architecture • JDI - Java Debug Interface • JDWP - Java Debug Wire Protocol • JVMTI - Java Virtual Machine Tool Interface 9
10. JDI - Java Debug Interface • High level Java API • Inspect & Control • Connect remotely 10
11. JDI - Simple Debugger Flow • Launch and connect ◦ Get VirtualMachine instance ◦ Request to get events (breakpoint, watchpoint, threadStop, threadStart…) • When class is prepared, add a breakpoint • When breakpoint is hit, print variables 11
12. Using JDI • No availability during collection • Zero control or visibility • Easy to make mistakes • Single instance debugging 12
13. JPDA - Java Platform Debugging Architecture • JDI - Java Debug Interface • JDWP - Java Debug Wire Protocol • JVMTI - Java Virtual Machine Tool Interface 13
14. JDWP - Java Debug Wire Protocol • A protocol • Used for communication between a debugger and the JVM which it debugs 14 JVM MyApp Debugger CLI JDWP
15. Using JDWP • No availability during collection • Zero control or visibility • Easy to make mistakes • Single instance debugging • Managing multiple clients and connecting to multiple servers 15
16. JVMTI - Java Virtual Machine Tool Interface • Native programming interface • Interacts directly with the JVM • Inspect & Control 16
17. JPDA - Java Platform Debugging Architecture • JDI - Java Debug Interface • JDWP - Java Debug Wire Protocol • JVMTI - Java Virtual Machine Tool Interface 17
18. JVMTI - Get Stack Trace /* Get Stack Trace */ err = (*jvmti)->GetStackTrace(jvmti, thr, 0, 5, &frames, &count); if (err != JVMTI_ERROR_NONE) { printf("(GetThreadInfo) Error expected: %d, got: %d\n", JVMTI_ERROR_NONE, err); describe(err); printf("\n"); } printf("Number of records filled: %d\n", count); if (err == JVMTI_ERROR_NONE && count >=1) { char *methodName; methodName = "yet_to_call()"; char *declaringClassName; jclass declaring_class; int i=0; printf("Exception Stack Trace\n"); printf("=====================\n"); printf("Stack Trace Depth: %d\n", count); for ( i=0; i < count; i++) { err = (*jvmti)->GetMethodName(jvmti, frames[i].method, &methodName, NULL, NULL); if (err == JVMTI_ERROR_NONE) { err = (*jvmti)->GetMethodDeclaringClass(jvmti, frames[i].method, &declaring_class); err = (*jvmti)->GetClassSignature(jvmti, declaring_class, &declaringClassName, NULL); if (err == JVMTI_ERROR_NONE) { printf("at method %s() in class %s\n", methodName, declaringClassName); } } } } 18 *A lot of code*
19. Java - Get Stack Trace Thread.currentThread().getStackTrace() 19
20. Using JVMTI • Incredibly Complex • Native vulnerabilities • Not portable • Bugs are catastrophic 20
21. 21 Newer? Simpler? Full control? In-process? Unbreakable?
22. Java Agents 22
23. Java Agents 23 JVM MyApp Java Agent java.lang.Instrument API
24. Sample Program 24 1| public class HelloWorld { 2| public static void main(String[] args) { 3| while(true) { 4| System.out.println("Hello, World!"); 5| } 6| } 7| }
25. Sample Program 25 • Build HelloWorld to JAR • Run: java -jar HelloWorld.jar • Output: Hello, World! Hello, World! ...
26. Java Agent - Premain 26 public class JavaAgent { public static void premain(String agentArgs, Instrumentation instrumentation) throws Exception { System.out.println("Hello, JavaSummit!"); } }
27. Java Agent - Premain 27 public class JavaAgent { public static void premain(String agentArgs, Instrumentation instrumentation) throws Exception { System.out.println("Hello, JavaSummit!"); } }
28. Java Agent - Premain 28 public class JavaAgent { public static void premain(String agentArgs, Instrumentation instrumentation) throws Exception { System.out.println("Hello, JavaSummit!"); } }
29. Java Agent - Premain 29 public class JavaAgent { public static void premain(String agentArgs, Instrumentation instrumentation) throws Exception { System.out.println("Hello, JavaSummit!"); } }
30. Java Agent - Premain 30 • Build JavaAgent to JAR • Run with java agent: java -javaagent:JavaAgent.jar -jar HelloWorld.jar • Output: Hello, JavaSummit! Hello, World! ...
31. Java Agent - ClassFileTransformer 31 JVM Compiler Code Bytecode
32. Java Agent - ClassFileTransformer 32 JVM 32 | … 33 | new Item() 34 | … Class Loader Get Item class bytecode Return Item class bytecode
33. Java Agent - ClassFileTransformer 33 JVM 32 | … 33 | new Item() 34 | … Class Loader Get Item class bytecode Return Item class bytecode Class File Transformer Return transformed Item class bytecode
34. Java Agent - ClassFileTransformer 34 public class JavaAgent { public static void premain(String agentArgs, Instrumentation instrumentation) throws Exception { System.out.println("Hello, JavaSummit!"); } } • void addTransformer(ClassFileTransformer transformer);
35. Java Agent - ClassFileTransformer 35 public class DebugTransformer implements ClassFileTransformer { @Override public byte[] transform(ClassLoader classLoader, String className, Class<?> classBeingRedefined, ProtectionDomain protectionDomain, byte[] classfileBuffer) {
36. Java Agent - ClassFileTransformer 36 public class DebugTransformer implements ClassFileTransformer { @Override public byte[] transform(ClassLoader classLoader, String className, Class<?> classBeingRedefined, ProtectionDomain protectionDomain, byte[] classfileBuffer) {
37. Java Agent - ClassFileTransformer 37 public class DebugTransformer implements ClassFileTransformer { @Override public byte[] transform(ClassLoader classLoader, String className, Class<?> classBeingRedefined, ProtectionDomain protectionDomain, byte[] classfileBuffer) {
38. Open Source Bytecode Manipulation Tools BCEL ASM 38
39. Bytecode Abstraction 39 • AbstractInsnNode ◦ JumpInsnNode ◦ MethodInsnNode ◦ VarInsnNode • InsnList instructions
40. Bytecode Manipulation 40 byte[] addPrintCall(byte[] classfileBuffer) { // Add call to System.out.println("Transformed!") // Return transformed bytecode }
41. Java Agent - ClassFileTransformer 41 public class DebugTransformer implements ClassFileTransformer { @Override public byte[] transform(ClassLoader classLoader, String className, Class<?> classBeingRedefined, ProtectionDomain protectionDomain, byte[] classfileBuffer) { if (className.contains("HelloWorld")) { return addPrintCall(classfileBuffer); } return classfileBuffer; } }
42. Java Agent - ClassFileTransformer 42 public class DebugTransformer implements ClassFileTransformer { @Override public byte[] transform(ClassLoader classLoader, String className, Class<?> classBeingRedefined, ProtectionDomain protectionDomain, byte[] classfileBuffer) { if (className.contains("HelloWorld")) { return addPrintCall(classfileBuffer); } return classfileBuffer; } }
43. Java Agent - Premain 43 public class JavaAgent { public static void premain(String agentArgs, Instrumentation instrumentation) throws Exception { DebugTransformer transformer = new DebugTransformer(); instrumentation.addTransformer(transformer); } }
44. Java Agent - Premain 44 public class JavaAgent { public static void premain(String agentArgs, Instrumentation instrumentation) throws Exception { DebugTransformer transformer = new DebugTransformer(); instrumentation.addTransformer(transformer); } }
45. Java Agent - Premain 45 • Build JavaAgent to JAR • Run with java agent: java -javaagent:JavaAgent.jar -jar HelloWorld.jar • Output: Transformed! Hello, World! Hello, World! ...
46. Dynamic Snapshots!
47. The Method: Inject a Hook • Inject a hook that will execute a specific function on the line of the snapshot 47 11: System.out.println(“Hello world!”); 12: return; Breakpoint()
48. Profiling Interpreter C2 C1 Profiling Profiling Interpreter C2 C1 Profiling JVM Execution Engine 48
49. The Method: Inject a Hook • Pass all local variables to function 49 11: System.out.println(“Hello world!”); 12: return; Breakpoint(locals)
50. Add Breakpoint 50 public void Breakpoint(Object[] locals) { System.out.println("Breakpoint hit!"); for (Object local : locals) { System.out.println(local); } }
51. Add Breakpoint 51 byte[] addBreakpoint(byte[] classfileBuffer, int lineno) { // Find where to insert Breakpoint call // Push local variables onto stack // Insert call to Breakpoint // Return transformed bytecode }
52. Add Breakpoint 52 byte[] addBreakpoint(byte[] classfileBuffer, int lineno) { // Find where to insert Breakpoint call // Push local variables onto stack // Insert call to Breakpoint // Return transformed bytecode }
53. Add Breakpoint 53 byte[] addBreakpoint(byte[] classfileBuffer, int lineno) { // Find where to insert Breakpoint call // Push local variables onto stack // Insert call to Breakpoint // Return transformed bytecode }
54. Add Breakpoint 54 byte[] addBreakpoint(byte[] classfileBuffer, int lineno) { // Find where to insert Breakpoint call // Push local variables onto stack // Insert call to Breakpoint // Return transformed bytecode }
55. Add Breakpoint 55 byte[] addBreakpoint(byte[] classfileBuffer, int lineno) { // Find where to insert Breakpoint call // Push local variables onto stack // Insert call to Breakpoint // Return transformed bytecode }
56. Sample Program 56 1| public class HelloWorld { 2| public static void main(String[] args) { 3| while(true) { 4| System.out.println("Hello, World!"); 5| } 6| } 7| }
57. Java Agent - ClassFileTransformer 57 public class DebugTransformer implements ClassFileTransformer { @Override public byte[] transform(ClassLoader classLoader, String className, Class<?> classBeingRedefined, ProtectionDomain protectionDomain, byte[] classfileBuffer) { if (className.contains("HelloWorld")) { return addBreakpoint(classfileBuffer, 4); } return classfileBuffer; } }
58. Java Agent - Premain 58 • Build JavaAgent to JAR • Run with java agent: java -javaagent:JavaAgent.jar -jar HelloWorld.jar • Output: Breakpoint hit! [Ljava.lang.Object;@3d075dc0 Hello, World! ...
59. 59 What if the class has already been loaded?
60. Magic Instrumentation 60 void redefineClasses(ClassDefinition... definitions) void retransformClasses(Class<?>... classes)
61. Putting it all together 61 • Transform on demand • Add call to breakpoint function • Access locals as objects
62. 62 Putting it all together
63. Thank You @yardenlaif rookout.com
