1. MICROSERVICES: BETTER FOR DEVS OR QA'S? Aliona Tudan, senior QA at N-iX
2. ABOUT MYSELF  7-8 years in QA  Leading teams  BI testing  WS testing  Back-end auto-tests writing & maintaining  Java, Groovy
5. Client Server
6. WTF?
7. WTF? REST
8. Hello dear Mr.Blah, sorry for disturbing, could you please... Kind regards, ...
9. Hello dear Mr.Blah, sorry for disturbing, could you please... Kind regards, ... SOAP
10. ARCHITECTURE OF COMMUNICATION
11. ONE LAYER
12. MORE
16. Microservice applications are composed of small, independently versioned, and scalable customer-focused services that communicate with each other over standard protocols with well- defined interfaces. MICROSERVICE
18. In short, the microservice architectural style is an approach to developing a single application as a suite of small services, each running in its own process and communicating with lightweight mechanisms, often an HTTP resource API. These services are built around business capabilities and independently deployable by fully automated deployment machinery. There is a bare minimum of centralized management of these services, which may be written in different programming languages and use different data storage technologies. -- James Lewis and Martin Fowler
19. https://docs.microsoft.com/en-us/azure/service-fabric/service-fabric-overview-microservices
20. https://martinfowler.com/articles/microservice-trade-offs.html
21. DIFFERENCES  A monolithic app contains domain-specific functionality and is normally divided by functional layers, such as web, business, and data.  You scale a monolithic app by cloning it on multiple servers/virtual machines/containers.  A microservice application separates functionality into separate smaller services.  The microservices approach scales out by deploying each service independently, creating instances of these services across servers/virtual machines/containers. https://docs.microsoft.com/en-us/azure/service-fabric/service-fabric-overview-microservices
22. REAL LIFE
23. REAL LIFE
24. REAL LIFE
25. private static class EventDetails { private static final String eventHubName = "Hub"; private static final String sasKeyName = "KeyName"; private static final String sasKey = "Key"; public static EventDetailsDto getEventDetails() { final URI endpoint; try { endpoint = new URI("http://url.com"); } catch (URISyntaxException e) { throw new RuntimeException("URI is not correct. Cause: " + e.getLocalizedMessage(), e); } EventDetailsDto eventDetailsDto = new EventDetailsDto(); eventDetailsDto.setEndpoint(endpoint); eventDetailsDto.setEventHubName(eventHubName); eventDetailsDto.setSasKeyName(sasKeyName); eventDetailsDto.setSasKey(sasKey); return eventDetailsDto; } } JAVA CODE
26. public class EventDetailsDto{ private URI endpoint; private String eventHubName; private String sasKeyName; private String sasKey; public EventDetailsDto() {} public URI getEndpoint() { return endpoint; } public void setEndpoint(URI endpoint) { this.endpoint = endpoint; } public String getEventHubName() { return eventHubName; } public void setEventHubName(String eventHubName) { this.eventHubName = eventHubName; } JAVA CODE
27. JAVA CODE public String getSasKeyName() { return sasKeyName; } public void setSasKeyName(String sasKeyName) { this.sasKeyName = sasKeyName; } public String getSasKey() { return sasKey; } public void setSasKey(String sasKey) { this.sasKey = sasKey; } @Override public String toString() { return "EventDetailsDto{" + "endpoint=" + endpoint + ", eventHubName='" + eventHubName + '\'' + ", sasKeyName='" + sasKeyName + '\'' + ", sasKey='" + sasKey + '\'' + '}'; } }
28. public static void sendEvent(final EventDetailsDto detailsDto, String partitionKey, byte[] payloadBytes, String streamNamespace) { EventHubClient ehClient = null; EventDetailsDto eventDetailsDto = detailsDto; try { if (eventDetailsDto == null) { eventDetailsDto = EventDetails.getEventDetails(); } ConnectionStringBuilder connStr = new ConnectionStringBuilder(eventDetailsDto.getEndpoint(), eventDetailsDto.getEventHubName(), eventDetailsDto.getSasKeyName(), eventDetailsDto.getSasKey()); EventData eventData = new EventData(payloadBytes); eventData.getProperties().put("StreamNamespace", streamNamespace); ehClient = EventHubClient.createFromConnectionStringSync(connStr.toString()); ehClient.sendSync(eventData, partitionKey); } catch (Throwable throwable) { throw new RuntimeException("There was a trouble building connection to Azure: " + throwable.getLocalizedMessage(), throwable); } finally { try { ehClient.closeSync(); } catch (ServiceBusException e) { throw new RuntimeException("Event to Azure Event Hub was not sent. Cause: " + e.getLocalizedMessage(), e); } } } JAVA CODE
29. HOW TO APPLY IN TESTS? Simply add scripts step into SOAP UI
30. SOAP UI SCRIPT import lib.PushEvent; def eventHubName = context.getTestCase().getTestSuite().project.getPropertyValue("eventHubName"); def sasKeyName = "Key"; def sasKey = "Blahblahblah"; endpoint = new URI("http://blah.net"); EventDetailsDto eventDetailsDto = new EventDetailsDto(); eventDetailsDto.setEndpoint(endpoint); eventDetailsDto.setEventHubName(eventHubName); eventDetailsDto.setSasKeyName(sasKeyName); eventDetailsDto.setSasKey(sasKey); String partitionKey = "uuid"; byte[] payloadBytes = "[{\"EmailAddress\":\"test@test.com\",\"TemplateId\":\"WelcomeEmail\",\"TimeStamp\":\" 2017-04-20T13:26:25\",\"Parameters\":{\"SenderName\":\“John Doe\"},\"Random\":\"Random\"}]".getBytes("UTF-8"); String streamNamespace = "Email"; PushEvent.sendEvent(eventDetailsDto, partitionKey,payloadBytes, streamNamespace);
31. CONCLUSIONS  Microservices are more expensive  More difficult for development  More time for settings  Easier to test when having OOP knowledge or desire to know OOP  More difficult to test manually because of configurations  More progress
32. QUESTIONS
33. LINKS  Microsoft docs  Martin Fowler: microservices  Microservices and Rules Engines – a blast from the past - Udi Dahan
34. CONTACTS Skype: ymkocv Facebook: ymkocv Email: ymkocv@gmail.com
