Kernel Exploitation

Kernel Exploitation
yuawn
yuawn
_yuawn

View Slide

About
• yuawn

• Current Leader of Balsn / DoubleSigma

• NTU nslab

View Slide

Outline
• Linux kernel Concepts & Debug

• Kenrel Protection

• smep, smap, kaslr, kpti

• Leak & useful structures

• tty_struct, shm_
f
i
le_data, msg_msg ...

• Kernel Common Vulnerability

• double fetch

• race condition

• Exploitation & Tricks

• ret2usr - bypass smep, smap, kpti

• signal handler

• modprobe_path

• userfaultfd, setxattr, msgsnd & msgrcv, ...
ROOT

View Slide

Lab - kernel exploits demo
• https://github.com/yuawn/kernel-exploitation

• kernel module

• exploits

View Slide

Linux Kernel

View Slide

Kernel
• Software

• implemented syscalls

• Communicate with hardware

• Intel CPU ring model:

• ring 0, ring 1, ring 2, ring 3

• ring 0: kernel space

• ring 3: user space
kernel
OS
Applications
hardware: CPU, Memory, Disk, Devices

View Slide

Kernel - LKM
• Loadable kernel module

• Programs running in kernel space

• drivers

• kernel extensions
kernel
OS
Applications
hardware: CPU, Memory, Disk, Devices
kernel module

View Slide

Kernel - functions
•

•

•

•

•
copy_from_user(void *to, const void __user *from, unsigned long n)

copy_to_user(void __user *to, const void *from, unsigned long n)

printk()

kmalloc()

kfree()

View Slide

Kernel Pwn
• kernel exploitation

• Privilege Escalation - 提權

• linux root account

• user space to kernel space

• ring 3 -> ring 0

View Slide

Kernel Pwn
• Modi
f
i
ed kernel

• Mobile: Android, ARM TrustZone

• IoT

• Kernel Module

• Original Linux Kernel

• CVE
Hypervisor
ARM Trusted Firmware
APPs Trusted APPs
OS (kernel)
Trusted OS

View Slide

CTF

kernel pwn

View Slide

CTF Prepare -
f
i
les
• bzImage - kernel

• initramfs.cpio.gz -
f
i
le system

• run.sh - shell script for running qemu

View Slide

CTF Prepare - running script
• run.sh

• How to run with qemu

• check kernel protections:

• smep, smap, kaslr

•
#!/bin/bash

qemu-system-x86_64 \

-kernel ./bzImage \

-initrd ./initramfs.cpio.gz \

-nographic \

-monitor none \

-cpu qemu64,+smep,+smap \

-append "console=ttyS0 kaslr panic=1" \

-no-reboot \

-m 256M

https://github.com/torvalds/linux/blob/master/Documentation/admin-guide/kernel-parameters.txt

View Slide

CTF Prepare - kernel
• bzImage

• https://github.com/torvalds/linux/blob/master/scripts/extract-vmlinux

• $ ./extract-vmlinux.sh bzImage > vmlinux

• vmlinux: ELF 64-bit LSB executable, x86-64

• static analysis

• Find kernel ROP gadgets:

• $ ropper --nocolor --
f
i
le ./vmlinux > rop

View Slide

CTF Prepare -
f
i
le system
• initramfs.cpio.gz

• $ gunzip initramfs.cpio.gz && cpio -idv < initramfs.cpio

• Gain
f
i
le system

• /challenge.ko - kernel module

• /init

• /
f
l
ag

• -r-------- 1 root 0 /
f
l
ag

View Slide

CTF Prepare - init
f
i
le
• /init

• 觀察題⽬初始化設置

• insmod challenge.ko

• echo 1 > /proc/sys/kernel/kptr_restrict

• 0 -> no restrictions

• 1 -> User 要有 CAP_SYSLOG 權限 (root)

• 2 -> 不管權限如何 %pK 通通換成 0

• echo 1 > /proc/sys/kernel/dmesg_restrict

• 0 -> no restrictions

• 1 -> User 要有 CAP_SYSLOG 權限 (root)

View Slide

CTF Prepare - .ko
• /challenge.ko

• 題⽬ binary 主體

• 通常會實作成⼀隻 miscdeivce 或 driver，可以透過 open 來使⽤ ioctl 或是
f
i
le operations 和 kernel module 溝通與使⽤操作。

• /dev/challenge

• /proc/challenge

View Slide

CTF Prepare - exploit
• 使⽤ C (或其他語⾔) 撰寫，編譯出 exploit binary

• 上傳到 remote server 的 qemu vm 中

• printf "" >> exp

• echo "" | base64 -d >> exp

• $ musl-gcc -static exp.c -o exp

• 輕量 libc，縮⼩ exp binary ⼤⼩，減少上傳時間

• $ sudo apt install musl-tools

• shell 執⾏ exploit

View Slide

Kernel Debug

View Slide

Debug
• $ dmesg

• printk()

• $ cat /proc/kallsyms

• function symbol

•
f
i
nd kernel base:

• $ cat /proc/kallsyms | grep _text | head -n 1

• $ cat /proc/modules

•
f
i
nd kernel module base:

• $ cat /proc/modules | grep

• $ cat /proc/slabinfo

View Slide

Debug
• 修改 init 檔案，獲得 root 權限，⽅便 debug

• setsid cttyhack setuidgid 1000 sh

• setsid cttyhack setuidgid 0 sh

• 打包回去給 qemu 跑：

• $
f
i
nd . -print0 | cpio --null -ov --format=newc > rootfs.cpio 2>/dev/null

View Slide

Debug
• run.sh qemu-system-x86_64

• -s 開 gdb debug port 在預設 port 1234

• -S 停在整個 CPU 執⾏的⼀開始

• -append "nokaslr" 關掉 kaslr

• gdb 連上去

• target remote localhost:1234

• add-symbol-
f
i
le challenge.ko baseaddr

• add-symbol-
f
i
le vmlinux baseaddr

View Slide

Kernel Protection

View Slide

kernel protections
• smep

• smap

• kaslr - kernel ASLR

• kpti

View Slide

smep
• Supervisor Mode Execution Protection

• 在 ring 0 kernel mode 底下，不能執⾏ user space 的 code

• 記錄在 cr4 register 中

View Slide

smap
• Supervisor Mode Access Protection

• 和 smep 類似，在 ring 0 kernel mode 底下，不能存取 user space memory

• 記錄在 cr4 register 中

View Slide

kpti
• kernel page-table isolation

• cr3 register

• page-table entry

• 效果類似 smep + smap

• Meltdown, Spectre

• $ dmesg | grep "Kernel/User page tables isolation: enabled"

View Slide

Information leak in kernel

View Slide

Leak
• CVE

• 1 day

• 0 day

• Vulnerable implementation in kernel module

• 概念和⼀般情形相同

• uninitialize

• oob or arbitrary read write

• race condition

• ...

View Slide

Leak
• 如果有未清空未初始化等漏洞，則可以透過 copy_to_user() 將 address 寫回 user
space，leak 出殘留內容。

• 如未對於請求的 kernel heap 清空或初始化，會希望在 user space (exploit binary) 中，
做⼀些會在 kernel 中請求記憶體 (kernel heap) 的操作使得 kernel heap 上殘留 kernel,
kernel stack, kernel heap 等 address，使得後續 kernel module 拿到的 heap chunk 上
有這些資訊。

• 概念類似 heap exploitation，free 出 unsorted bin，使 heap 上出現 libc address。

• ⽬標找出類似這樣概念好⽤的 kernel structure 來分配。

View Slide

useful structure for leak
• ⽅便從 user space 中控制分配與釋放

• size 合適，⽅便後續⾼機率拿到同⼀塊。

• heap spray

• 視情況是否可以控制 kmalloc() 的 size

• structure 中滿滿的 pointers

• kernel text, heap, stack

• vtable: function pointers

View Slide

useful structure for leak
• tty_struct (0x2e0, 02c0) base, heap

• shm_
f
i
le_data (0x20) base, heap

• seq_operations (0x20) base

• msg_msg (0x30〜0x1000) heap

• subprocess_info (0x60) base, heap

• ...

• 任何發覺可使⽤的 structure

• structure size 會因為 kernel version 變動

• https://ptr-yudai.hatenablog.com/entry/2020/03/16/165628

View Slide

tty_struct
• Leak: base, heap

• Size: 0x2c0

• size 少⽤，好拿取到同⼀塊

•

• ⽅便從 user land trigger

• tty_operations

• 類似 vtable，存了許多對於 tty 操作對應的 function pointer 如 open, write, close, ioctl ...

• 如果可以 UAF 等，可以透過 overwrite struct tty_operations 指向可控區域，如修改 write operation pointer，對 tty
做 write(pfd, ,) 時，則可以控制 kernel rip
int pfd = open("/dev/ptmx", O_RDWR|O_NOCTTY);

struct tty_struct {

int magic;

struct kref kref;

struct device *dev;

struct tty_driver *driver;

const struct tty_operations *ops;

int index;

/* Protects ldisc changes: Lock tty not pty */

struct ld_semaphore ldisc_sem;

struct tty_ldisc *ldisc;

...

View Slide

tty_operations
struct tty_operations {

struct tty_struct * (*lookup)(struct tty_driver *driver,

struct file *filp, int idx);

int (*install)(struct tty_driver *driver, struct tty_struct *tty);

void (*remove)(struct tty_driver *driver, struct tty_struct *tty);

int (*open)(struct tty_struct * tty, struct file * filp);

void (*close)(struct tty_struct * tty, struct file * filp);

void (*shutdown)(struct tty_struct *tty);

void (*cleanup)(struct tty_struct *tty);

int (*write)(struct tty_struct * tty,

const unsigned char *buf, int count);

int (*put_char)(struct tty_struct *tty, unsigned char ch);

void (*flush_chars)(struct tty_struct *tty);

int (*write_room)(struct tty_struct *tty);

int (*chars_in_buffer)(struct tty_struct *tty);

int (*ioctl)(struct tty_struct *tty,

unsigned int cmd, unsigned long arg);

....

• include/linux/tty_driver.h

View Slide

• heap spray
tty_struct
for( int i = 0 ; i < 0x100 ; ++i )

pfd[i] = open( "/dev/ptmx" , O_RDWR | O_NOCTTY ); // tty_struct

for( int i = 0 ; i < 0x100 ; ++i )

close(pfd[i]);

View Slide

Kernel Common Vulnerability

View Slide

double fetch
• kernel space 與 user space 間 race condition

• kernel 存取兩次來⾃ user space 的 data，產⽣ race condition 的空隙

View Slide

double fetch
User Space
Kernel Space
Program
kernel module

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
syscall/ioctl

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
syscall/ioctl

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
syscall/ioctl
memory

0x401000: 0x30
copy_from_user()

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
syscall/ioctl
memory

0x401000: 0x30
copy_from_user()
2nd fetch

(use)
check
 
0x30 < 0x100

True

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
memory

0x401000: 0x30
syscall/ioctl
copy_from_user()
check
 
0x30 < 0x100

True
memory

0x401000: 0x30
copy_from_user()
2nd fetch

(use)

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
syscall/ioctl
memory

0x401000: 0x30
copy_from_user()

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
syscall/ioctl
memory

0x401000: 0x30
copy_from_user()
2nd fetch

(use)
check
 
0x30 < 0x100

True

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
memory

0x401000: 0x1000
syscall/ioctl
copy_from_user()
check
 
0x30 < 0x100

True
memory

0x401000: 0x1000
modify user data
2nd fetch

(use)

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
2nd fetch

(use)
syscall/ioctl
copy_from_user()
check
 
0x30 < 0x100

True
memory

0x401000: 0x1000
modify user data
copy_from_user()
0x1000 < 0x100

memory

0x401000: 0x1000

View Slide

double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
2nd fetch

(use)
syscall/ioctl
copy_from_user()
check
 
0x30 < 0x100

True
memory

0x401000: 0x1000
modify user data
copy_from_user()
0x1000 < 0x100

False
memory

0x401000: 0x1000

View Slide

memory

0x401000: 0x1000
double fetch
User Space
Kernel Space
Program
kernel module
1st fetch

(check)
2nd fetch

(use)
syscall/ioctl
copy_from_user()
check
 
0x30 < 0x100

True
memory

0x401000: 0x1000
modify user data
copy_from_user()
0x1000 < 0x100

False
Pwned ☠

View Slide

double fetch
• 正確姿勢

• ⼀次性 copy_from_user()

• 先 copy 到 kernel 裡，再做後續使⽤

View Slide

Kernel Exploitation

View Slide

ret2user

View Slide

ret2user
• user mode 不能 access kernel space，kernel mode 可以 access user space

• 在 kernel mode 執⾏時 return 到 user space，帶著 ring 0 特權執⾏ user code

• control kernel rip

• Status Switch

• user space to kernel space

• kernel space to user space

• arch/x86/entry/entry_64.S

View Slide

ret2user
• Status Switch


• Restore GS value by swapgs instruction

• iret instruction

• iretq

• Stored register value at stack
user cs
iretq
user space rip
user r
f
l
ags
user sp
user ss
kernel rsp
swapgs ; ret

View Slide

ret2user
• Status Switch


• Save status
size_t user_cs, user_ss, user_rflags, user_sp;

void save_status()

{

__asm__("mov user_cs, cs;"

"mov user_ss, ss;"

"mov user_sp, rsp;"

"pushf;"

"pop user_rflags;"

);

puts("[*]status has been saved.");

}

View Slide

ret2user
• Constraints

• smep

• smap

• kpti

View Slide

Bypass smep
• ROP

• 類似 bypass NX 的概念

• 將 kernel stack rsp 搬到 user space 上做 ROP

• 直接在 kernel 中 ROP

View Slide

Bypass smap
• ROP dead

• Disallows explicit supervisor-mode data accesses to user-mode pages

• how do copy_from_user() and copy_to_user() work?

View Slide

Bypass smap
• arch/x86/lib/copy_user_64.S

• instruction

• stac

• clac
SYM_FUNC_START(copy_user_generic_unrolled)

ASM_STAC

cmpl $8,%edx

jb 20f /* less then 8 bytes, go to byte copy loop */

ALIGN_DESTINATION

movl %edx,%ecx

andl $63,%edx

shrl $6,%ecx

jz .L_copy_short_string

...

movl %edx,%ecx

21: movb (%rsi),%al

22: movb %al,(%rdi)

incq %rsi

incq %rdi

decl %ecx

jnz 21b

23: xor %eax,%eax

ASM_CLAC

ret

View Slide

Bypass smap
• arch/x86/lib/copy_user_64.S

• instruction

• stac - allow

• clac - disallow
SYM_FUNC_START(copy_user_generic_unrolled)

ASM_STAC

cmpl $8,%edx

jb 20f /* less then 8 bytes, go to byte copy loop */

ALIGN_DESTINATION

movl %edx,%ecx

andl $63,%edx

shrl $6,%ecx

jz .L_copy_short_string

...

movl %edx,%ecx

21: movb (%rsi),%al

22: movb %al,(%rdi)

incq %rsi

incq %rdi

decl %ecx

jnz 21b

23: xor %eax,%eax

ASM_CLAC

ret

View Slide

Bypass smap
• instruction

• stac - allow

• clac - disallow

• Only allowed in kernel mode, they fault in user-space.

View Slide

Bypass smap
• Overwrite cr4 register

• 在 kernel 中先做些事 (ROP, ...)，把 cr4 register 寫掉 -> 0x6f0

• 關掉 smep, smap 再 return 回 user space 執⾏或 ROP

View Slide

ret2user
• Constraints

• bypass smep

• 將 kernel stack rsp 搬到 user space 上做 ROP直接在 kernel 中 ROP

• bypass smap

• 在 kernel 中先做些事 (ROP, ...)，把 cr4 register 寫掉 -> 0x6f0

• 關掉 smep, smap 再 return 回 user space 執⾏或 ROP

• kpti

•
f
i
x cr3 register - page table

• swapgs_restore_regs_and_return_to_usermode()

View Slide

privilege escalation
• ROP

•

• ret2user -> system("/bin/sh")

• spawn a root shell!
commit_creds(prepare_kernel_cred(0))

View Slide

privilege escalation
• ROP

•

• ret2user -> system("/bin/sh")

• spawn a root shell!
commit_creds(prepare_kernel_cred(0))

ROOT ☠

View Slide

Kernel Exploitation 萬解

View Slide

modprobe_path

View Slide

modprobe_path
• kernel global variable

• default path: /sbin/modprobe

• $ cat /proc/sys/kernel/modprobe

• 執⾏⼀個 kernel 認不得的執⾏檔格式時，kernel 會帶 root 權限執⾏這個
path 所定義的檔案。

View Slide

modprobe_path
• sys_execve

• do_execve()

• do_execveat_common()

• bprm_execve()

• exec_binprm()

• search_binary_handler()

• request_module()

• call_modprobe()

• call_usermodehelper_exec()
static int search_binary_handler(struct linux_binprm *bprm)

{

...

if (need_retry) {

if (printable(bprm->buf[0]) && printable(bprm->buf[1]) &&

printable(bprm->buf[2]) && printable(bprm->buf[3]))

return retval;

if (request_module("binfmt-%04x", *(ushort *)(bprm->buf + 2)) < 0)

return retval;

need_retry = false;

goto retry;

}

...

View Slide

modprobe_path
• exploitation

• overwrite modprobe_path 成⾃⼰寫得 shell script，/tmp/x

• $ echo -ne '#!/bin/sh\n/bin/chmod 777 /flag' > /tmp/x

• 執⾏格式壞掉的執⾏檔

• $ echo -ne '\\xff\\xff\\xff\\xff' > /tmp/fake

• $ chmod +x /tmp/fake && /tmp/fake

• kernel 以 root 權限執⾏ /tmp/x

• cat /
f
l
ag

View Slide

modprobe_path
• exploitation

• overwrite modprobe_path 成⾃⼰寫得 shell script，/tmp/x

• $ echo -ne '#!/bin/sh\n/bin/chmod 777 /flag' > /tmp/x

• 執⾏格式壞掉的執⾏檔

• $ echo -ne '\\xff\\xff\\xff\\xff' > /tmp/fake

• $ chmod +x /tmp/fake && /tmp/fake

• kernel 以 root 權限執⾏ /tmp/x

• cat /
f
l
ag
ROOT ☠

View Slide

View Slide

modprobe_path
• android root

• http://powerofcommunity.net/poc2016/x82.pdf

• powero
f
f
_cmd

View Slide

setxattr & userfaultfd

View Slide

userfaultfd
• syscall - 323

• 註冊 userfault 記憶體區域，並⾃⾏實作 page fault handler

• ⾃⾏控制 page fault 處理⾏為

• 當 kernel 中進⾏ copy_from_user() 或 copy_to_user() 時，access user
memory 會觸發 page fault，此時可以在 page fault handler 中處理⾏為。

View Slide

userfaultfd
• 應⽤在 exploitation 上的效果

• race condition friendly

• 如在 page fault handler 中 sleep，即可卡住 kernel 中的執⾏流程

• 先執⾏其他操作才完成對 fault 處理，控制執⾏流程先後順序

• 使其穩定發⽣能觸發 race condition 的 scenario，不需撞機率

View Slide

setxattr

View Slide

setxattr
• syscall - 188

• 可以在 user space 直接使⽤ setxattr 來接 kvmalloc() 請求 1 ~ 65536
(0x10000)範圍的⼤⼩，並且將 user land data copy 上去。

• setxattr + userfualtfd 連技

• 常搭配 userfaultfd 串招，來卡住中間執⾏ copy_from_user()，⽤可以
⾃⾏決定處理好 page fault 的時機來使 setxattr 繼續執⾏，間接控制
kfree() 時機，可以⽤來⽅便串 UAF。

View Slide

• linux-5.9.12/fs/xattr.c#510
setxattr
static long

setxattr(struct dentry *d, const char __user *name, const void __user *value,

size_t size, int flags)

{

int error;

void *kvalue = NULL;

char kname[XATTR_NAME_MAX + 1];

if (flags & ~(XATTR_CREATE|XATTR_REPLACE))

return -EINVAL;

error = strncpy_from_user(kname, name, sizeof(kname));

if (error == 0 || error == sizeof(kname))

error = -ERANGE;

if (error < 0)

return error;

if (size) {

if (size > XATTR_SIZE_MAX)

return -E2BIG;

kvalue = kvmalloc(size, GFP_KERNEL);

if (!kvalue)

return -ENOMEM;

if (copy_from_user(kvalue, value, size)) {

error = -EFAULT;

goto out;

}

if ((strcmp(kname, XATTR_NAME_POSIX_ACL_ACCESS) == 0) ||

(strcmp(kname, XATTR_NAME_POSIX_ACL_DEFAULT) == 0))

posix_acl_fix_xattr_from_user(kvalue, size);

else if (strcmp(kname, XATTR_NAME_CAPS) == 0) {

error = cap_convert_nscap(d, &kvalue, size);

if (error < 0)

goto out;

size = error;

}

}

error = vfs_setxattr(d, kname, kvalue, size, flags);

out:

kvfree(kvalue);

return error;

}

View Slide

setxattr + userfaultfd
• 將 userfaultfd 結合⽤來卡住 setxattr 內的 copy_from_user()，使其不會
直接⾺上 kfree()

• 當需要 kfree() chunk 時，於⾃⾏實作的 userfaultfd page felt handler 中
copy mmap 出來準備好的 page 完成 page fault 處理，即可使 setxattr 繼
續執⾏完成 kfree()

• 解決 setxattr 可以任意控制 kmalloc() 時機與 size, content，卻無法控制
kfree() 時機的缺點。

View Slide

• 串招後，從 user land 可以直接：

• 任意時機調⽤ kmalloc()

• 滿⾜絕⼤多數需求的 size range: 1 ~ 65536(0x10000)

• 完全從 user land 控制 chunk 內容

• 搭配 userfaultfd，任意時機選擇 kfree()

View Slide

• SECCON 2020 - Kstack

• https://github.com/Brie
f
l
yX/ctf-pwns/tree/master/kernel/kstack

View Slide

msg_msg
• msgget()

• msgsnd()

• msgrcv()

• https://duasynt.com/blog/linux-kernel-heap-spray

View Slide

msg_msg
•

•

• kmalloc(size+0x30)

• 將 msgbuf 內容 copy ⾄ chunk + 0x30 處，前 0x30 為其 header

•

• kfree
int qid = msgget(IPC_PRIVATE, 0644 | IPC_CREAT)

msgsnd(qid, &msgbuf, real_size - 0x30, 0)

msgrcv(qid, &msgbuf, real_size - 0x30, 1, 0)

View Slide

msg_msg
• Pros

• ⽅便從 user land 控制 kmalloc() kfree()

• code 好寫

• 比 setxattr + userfaultfd 更好控制 kfree() 時機，即使⽤ msgrcv() 即可

• Cons

• kmalloc 出來的 chunk 前 0x30，不好控

View Slide

Thanks! yuawn
_yuawn

View Slide

Kernel Exploitation

Kernel Exploitation

yuawn

More Decks by yuawn

Other Decks in Research

Featured

Transcript
