12-Factor Rails App and Kubernetes

The Twelve-Factor App is a guideline for modern web app development. Kubernetes is an open-source project for container management that gives you great flexibility around application deployments. With containers and Kubernetes, you can deploy and rollback a version, scale out to hundreds of nodes, copy the same configuration to multiple prod, staging, and dev environments, manage deployments through API, and so on.

This talk will review each of the twelve factors using a simple Rails application as an example and see how Kubernetes helps you run your Rails application. Experience with containers is not required.

Transcript

1. 12-Factor Rails App and Kubernetes Emma Haruka Iwao (@Yuryu)
2. Who Am I? Emma Haruka Iwao / 岩尾 艾玛 (@Yuryu) Developer Advocate for Google Cloud Platform Live in Tokyo (30%) Love travels, games, delicious food
4. Containers Virtual machine Kernel Dependencies Application Code Hardware + hypervisor Dedicated server Kernel Dependencies Application Code Hardware Container Kernel + Container Runtime Dependencies Application Code Hardware Deployment ~mins (sec) Portable Very Efficient Deployment ~weeks Not portable Low utilization Deployment ~mins Hypervisor specific Low isolation, Tied to OS
5. Why Containers? Fast Simple and Fast compared to VMs. Can be started in just a few milliseconds. Portable Can be run in many environments. Efficiency Low overhead. Resources use by containers can be limited.
6. Containerizing an Rails App Pretty straightforward. Step by step installation.
7. Image by Connie Zhou
8. http://research.google.com/pubs/pub43438.html
9. Kubernetes κυβερνήτης: Greek for “pilot” or “helmsman of a ship” the open source cluster manager from Google
11. g.co/dev/gkecomic
12. Inside a Kubernetes deployment … Node Pod Manage Container
13. Node Pool of computation resources Logical machines to run containers Can be physical or virtual machines Can run one or more containers Can be added or removed while running Node
14. Container Container instance Set of actual processes Application processes, middleware, etc Docker is often used, other engines supported Container
15. Pod Basic manageable unit in Kubernetes Holds network addresses and storage Provides running context to containers Can contain one or more containers Pod
16. Inside a Kubernetes deployment … Node Pod Manage Container
17. Inside a deployment … Manage Load Balancer Pod Pod Pod User
18. Reviewing 12-factor App
19. What is the 12-factor App? The best practices of web applications, proposed by Heroku Proven and some common sense principles
20. The 12 factors 1. Codebase (基准代码) 2. Dependencies (依赖) 3. Config (配置) 4. Backing services (后端服务) 5. Build, release, run (构建，发布，运行) 6. Processes (进程) 7. Port binding (端口绑定) 8. Concurrency (并发) 9. Disposability (易处理) 10. Dev/prod parity (开发环境与线上环境等价) 11. Logs (日志) 12. Admin processes (管理进程)
21. 12 Factors - obvious ones 1. Codebase 基准代码 Use git or anything to manage revisions! 2. Dependencies 依赖 No implicit dependencies Use Gemfile to manage dependencies
22. 12 Factors - As a Rails app Some of the factors are satisfied by Rails itself 4. Backing Services 后端服务 6. Processes 进程 7. Port binding 端口绑定
23. 4. Backing Services 后端服务 Backend services are attachable and independent from the code. You can switch one DB to another without editing code. e.g. ActiveRecord and database.yml
24. 6. Processes 进程 "Twelve-factor processes are stateless and share-nothing. Any data that needs to persist must be stored in a stateful backing service, typically a database." This is exactly what a Rails app looks like. $ rails server
25. 7. Port binding 端口绑定 "The twelve-factor app is completely self-contained [… and] exports HTTP as a service by binding to a port" Yes! A Rails app offers a service via http.
26. The 12 factors 1. Codebase (基准代码) 2. Dependencies (依赖) 3. Config (配置) 4. Backing services (后端服务) 5. Build, release, run (构建，发布，运行) 6. Processes (进程) 7. Port binding (端口绑定) 8. Concurrency (并发) 9. Disposability (易处理) 10. Dev/prod parity (开发环境与线上环境等价) 11. Logs (日志) 12. Admin processes (管理进程)
27. 3. Config 配置 "The twelve-factor app stores config in environment variables [...]." Config should be separate from code and easily modifiable. Kubernetes supports cluster-wide config variables! Simply write in a YAML file. spec: containers: - env: - name: VARIABLE1 value: test1
28. 3. Config - Secrets Secrets should be clearly separately managed (Do not commit). Kubernetes supports secret management. API CLI secrets
29. 5. Build, release, run 构建，发布，运行 Code to release should be one way. No production code change Releases should be versioned Kubernetes supports rolling releases and rollback
30. 8. Concurrency 并发 Scale out! (Fully exploit the shared-nothing architecture) Use multiple machines. Scale out by spawning more processes. Scaling out with Kubernetes is easy, just specify number of processes Kubernetes handles the rest.
31. 8. Concurrency - Scaling replica=3 Load Balancer Pod Pod Pod User
32. 8. Concurrency - Scaling Load Balancer Pod Pod Pod User Pod replica=3
33. 9. Disposability 易处理 "Maximize robustness with fast startup and graceful shutdown" Containers are processes. Fast and lightweight. Kubernetes watches container lifecycle. Respawn when they die.
34. 10. Dev/prod parity 开发环境与线上环境等价 "Keep development, staging, and production as similar as possible" Kubernetes has multiple environments for different uses Use the same configuration for dev, staging, prod All of the configurations are in YAML files
35. Three environments to run Kubernetes • Minikube - Single node version • Independent cluster - DIY Kubernetes custer • Google Kubernetes Engine (and others) - Managed Kubernetes
36. Minikube Single node Kubernetes Best for development and local testing $ brew install cask minikube Runs on Linux, Windows and macOS
37. Independent cluster • DIY Kubernetes Cluster • Full features and control, using the latest version • Manual setup and maintenance
38. Google Kubernetes Engine, or GKE Managed version of Kubernetes in Cloud No additional cost Supports auto-update, failover, etc Works with other GCP components like load balancers
39. From Laptop to Datacenter Kubernetes runs on your laptop, servers, and in Cloud Build your apps locally, lift-and-shift into Cloud when you are ready Don’t get stuck with a platform that doesn’t work for you
40. 11. Logs 日志 "A twelve-factor app never concerns itself with routing or storage of its output stream. [...] Instead, each running process writes its event stream, unbuffered, to stdout." Rails supports logging to stdout stdout / stderr are handled by Docker
41. Logging Agent to Forward Logs Rails Node Pod Logging Agent Pod logfile (fluentd, stackdriver, etc) stdout
42. 12. Admin processes 管理进程 "Run admin/management tasks as one-off processes" in the same context as production applications. e.g. rails db:migrate You can run a process in a pod, or create a Job. Cron is also supported.
43. The 12 factors 1. Codebase (基准代码) 2. Dependencies (依赖) 3. Config (配置) 4. Backing services (后端服务) 5. Build, release, run (构建，发布，运行) 6. Processes (进程) 7. Port binding (端口绑定) 8. Concurrency (并发) 9. Disposability (易处理) 10. Dev/prod parity (开发环境与线上环境等价) 11. Logs (日志) 12. Admin processes (管理进程)
44. Kubernetes is a good friend of Rails Kubernetes runs Rails Applications! It respects the 12 factors The 12-factor App is not hard Try it today on your laptop The 12-factor App: Copyright (c) 2012 Adam Wiggins Ruby on Rails: Copyright (c) 2005-2018 David Heinemeier Hansson
