Zach Klippenstein (he/him) The Workflow Pattern, Composed droidconSF 2022 @zachklipp

@zachklipp Who’s this guy? • Android for 7+ years •
Square: POS, mobile infrastructure, design systems • Google: Compose

@zachklipp Workflow Workflow + Compose Lessons learned Current status

@zachklipp The What-flow pattern?

@zachklipp The Workflow pattern

@zachklipp The Workflow pattern 2018 2022

@zachklipp The Workflow pattern

@zachklipp The Workflow pattern 1/2

@zachklipp Work fl ow StateT RenderingT events PropsT

@zachklipp Overview Detail Work fl ow props Overview Work fl
ow Detail Work fl ow props renderings

@zachklipp Advantages • Injectability class MyWorkflow(val fooService, val barService) {
/ / . . . }

@zachklipp Advantages • Injectability • Reusability class MyWorkflow(val fooService, val
barService) { / / . . . }

@zachklipp Advantages • Injectability • Reusability • Testability class MyWorkflow(val
fooService, val barService) { / / . . . }

@zachklipp Advantages • Injectability • Reusability • Testability • Modularizability
FooModule MyWorkflow(val fooService, val barService) MyOtherWorkflow() BarModule OtherWorkflow(val bazService)

@zachklipp Advantages • Injectability • Reusability • Testability • Modularizability
• View customizability class MyWorkflow(val fooService, val barService) { / / . . . }

@zachklipp The Workflow pattern 2/2

@zachklipp 2,837.95USD Tech Company Class A View data class StockRendering(
val price: String, val currency: String, val name: String ) Rendering ScreenViewFactory

@zachklipp Overview Detail ViewFactory rendering Overview ViewFactory Detail ViewFactory rendering

@zachklipp interface ViewFactory<in RenderingT : Any>

@zachklipp interface ViewFactory<in RenderingT : Any> { fun buildView() :
View }

@zachklipp interface ViewFactory<in RenderingT : Any> { fun buildView( initialRendering:
RenderingT ) : View }

RenderingT, initialViewEnvironment: ViewEnvironment ) : View }

RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context ) : View }

RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? = null ) : View }

RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? = null ) : View } interface AndroidScreen<S : AndroidScreen<S > > { public val viewFactory: ViewFactory<S> }

@zachklipp ComposeViewFactory

@zachklipp abstract class ComposeViewFactory<RenderingT : Any> : ViewFactory<RenderingT>

@zachklipp abstract class ComposeViewFactory<RenderingT : Any> : ViewFactory<RenderingT> { f
i nal override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View }

i nal override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View = ComposeView(contextForNewView) }

i nal override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View = ComposeView(contextForNewView).also { composeView - > composeView.setContent {} } }

i nal override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View = ComposeView(contextForNewView).also { composeView - > composeView.setContent {} } @Composable abstract fun Content( rendering: RenderingT, viewEnvironment: ViewEnvironment ) }

i nal override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View = ComposeView(contextForNewView).also { composeView - > composeView.setContent { Content(initialRendering, initialViewEnvironment) } } @Composable abstract fun Content( rendering: RenderingT, viewEnvironment: ViewEnvironment ) }

i nal override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View = ComposeView(contextForNewView).also { composeView - > composeView.bindShowRendering( initialRendering, initialViewEnvironment ) { rendering, environment - > composeView.setContent { Content(initialRendering, initialViewEnvironment) } } } @Composable abstract fun Content( rendering: RenderingT, viewEnvironment: ViewEnvironment ) }

i nal override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View = ComposeView(contextForNewView).also { composeView - > composeView.bindShowRendering( initialRendering, initialViewEnvironment ) { rendering, environment - > composeView.setContent { Content(rendering, environment) } } } @Composable abstract fun Content( rendering: RenderingT, viewEnvironment: ViewEnvironment ) }

@zachklipp interface ViewFactory<in RenderingT : Any> interface AndroidScreen<S : AndroidScreen<S
> > { public val viewFactory: ViewFactory<S> }

@zachklipp interface ComposeScreen : AndroidScreen<ComposeScreen> { override val viewFactory: ViewFactory<ComposeScreen>
}

@Composable fun Content(viewEnvironment: ViewEnvironment) }

get() = object : ComposeViewFactory<ComposeScreen>() {} @Composable fun Content(viewEnvironment: ViewEnvironment) }

get() = object : ComposeViewFactory<ComposeScreen>() { @Composable override fun Content( rendering: ComposeScreen, viewEnvironment: ViewEnvironment ) {} } @Composable fun Content(viewEnvironment: ViewEnvironment) }

get() = object : ComposeViewFactory<ComposeScreen>() { @Composable override fun Content( rendering: ComposeScreen, viewEnvironment: ViewEnvironment ) { rendering.Content(viewEnvironment) } } @Composable fun Content(viewEnvironment: ViewEnvironment) }

@zachklipp • ComposeViewFactory • ComposeScreen

@zachklipp data class NameRendering( val name: String )

@zachklipp data class NameRendering( val name: String ) : ComposeScreen

{ @Composable override fun Content(viewEnvironment: ViewEnvironment) { } }

{ @Composable override fun Content(viewEnvironment: ViewEnvironment) { Text(name) } }

@zachklipp Showing another rendering Overview Detail ViewFactory rendering Overview ViewFactory
Detail ViewFactory rendering

@zachklipp data class PersonRendering( val name: String, val details: Any
) : ComposeScreen

) : ComposeScreen { @Composable override fun Content(viewEnvironment: ViewEnvironment) { Text(name) } }

) : ComposeScreen { @Composable override fun Content(viewEnvironment: ViewEnvironment) { Column { Text(name) ???(details) } } }

) : ComposeScreen { @Composable override fun Content(viewEnvironment: ViewEnvironment) { Column { Text(name) WorkflowRendering( details, viewEnvironment, Modif i er.weight(1f) ) } } }

@zachklipp @Composable fun WorkflowRendering( rendering: Any, viewEnvironment: ViewEnvironment, modif i
er: Modif i er = Modif i er ) {}

er: Modif i er = Modif i er ) { val viewFactory: ComposeViewFactory<Any> = ??? }

er: Modif i er = Modif i er ) { val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) } }

er: Modif i er = Modif i er ) { val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } }

er: Modif i er = Modif i er ) { val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } viewFactory.Content(rendering, viewEnvironment) }

er: Modif i er = Modif i er ) { val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } Box(modif i er, propagateMinConstraints = true) { viewFactory.Content(rendering, viewEnvironment) } }

@zachklipp Overview Detail ViewFactory rendering Overview ViewFactory Detail ViewFactory rendering

@zachklipp

er: Modif i er = Modif i er ) { val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } Box(modif i er, propagateMinConstraints = true) { viewFactory.Content(rendering, viewEnvironment) } }

er: Modif i er = Modif i er ) { val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } val lifecycleOwner = rememberChildLifecycleOwner() CompositionLocalProvider(LocalLifecycleOwner provides lifecycleOwner) { Box(modif i er, propagateMinConstraints = true) { viewFactory.Content(rendering, viewEnvironment) } } }

er: Modif i er = Modif i er ) { val renderingCompatibilityKey = rendering : : class val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } val lifecycleOwner = rememberChildLifecycleOwner() CompositionLocalProvider(LocalLifecycleOwner provides lifecycleOwner) { Box(modif i er, propagateMinConstraints = true) { viewFactory.Content(rendering, viewEnvironment) } } }

er: Modif i er = Modif i er ) { val renderingCompatibilityKey = rendering : : class val viewFactory: ComposeViewFactory<Any> = remember(renderingCompatibilityKey) { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } val lifecycleOwner = rememberChildLifecycleOwner() CompositionLocalProvider(LocalLifecycleOwner provides lifecycleOwner) { Box(modif i er, propagateMinConstraints = true) { viewFactory.Content(rendering, viewEnvironment) } } }

er: Modif i er = Modif i er ) { val renderingCompatibilityKey = rendering : : class key(renderingCompatibilityKey) { val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } val lifecycleOwner = rememberChildLifecycleOwner() CompositionLocalProvider(LocalLifecycleOwner provides lifecycleOwner) { Box(modif i er, propagateMinConstraints = true) { viewFactory.Content(rendering, viewEnvironment) } } } }

@zachklipp /** * Renders [rendering] into the composition using this
[ViewEnvironment]'s [ViewRegistry] to * generate the view. * * This function fulf i lls a similar role as [WorkflowViewStub], but is much more convenient to use * from Composable functions. Note, however, that just like [WorkflowViewStub], it doesn't matter * whether the factory registered for the rendering is using classic Android views or Compose. * * # # Example * * ` ` ` * data class FramedRendering<R : Any>( * val borderColor: Color, * val child: R * ) : ComposeRendering { * * @Composable override fun Content(viewEnvironment: ViewEnvironment) { * Surface(border = Border(borderColor, 8.dp)) { * WorkflowRendering(child, viewEnvironment) * } * } * } * ` ` ` * * @param rendering The workflow rendering to display. May be of any type for which a [ViewFactory] * has been registered in [viewEnvironment]'s [ViewRegistry]. * @param modif i er A [Modif i er] that will be applied to composable used to show [rendering]. * * @throws I l l egalArgumentException if no factory can be found for [rendering]'s type. * / @WorkflowUiExperimentalApi @Composable public fun WorkflowRendering( rendering: Any, viewEnvironment: ViewEnvironment, modif i er: Modif i er = Modif i er ) { / / This will fetch a new view factory any time the new rendering is incompatible with the previous / / one, as determined by Compatible. This corresponds to WorkflowViewStub's canShowRendering / / check. val renderingCompatibilityKey = Compatible.keyFor(rendering) / / By surrounding the below code with this key function, any time the new rendering is not / / compatible with the previous rendering we'll tear down the previous subtree of the composition, / / including its lifecycle, which destroys the lifecycle and any remembered state. If the view / / factory created an Android view, this will also remove the old one from the view hierarchy / / before replacing it with the new one. key(renderingCompatibilityKey) { val viewFactory = remember { / / The view registry may return a new factory instance for a rendering every time we ask it, for / / example if an AndroidViewRendering doesn't share its factory between rendering instances. We / / intentionally don't ask it for a new instance every time to match the behavior of / / WorkflowViewStub and other containers, which only ask for a new factory when the rendering is / / incompatible. viewEnvironment[ViewRegistry] / / Can't use ViewRegistry.buildView here since we need the factory to convert it to a / / compose one. .getFactoryForRendering(rendering) .asComposeViewFactory() } / / Just like WorkflowViewStub, we need to manage a Lifecycle for the child view. We just provide / / a local here – ViewFactoryAndroidView will handle setting the appropriate view tree owners / / on the child view when necessary. Because this function is surrounded by a key() call, when / / the rendering is incompatible, the lifecycle for the old view will be destroyed. val lifecycleOwner = rememberChildLifecycleOwner() CompositionLocalProvider(LocalLifecycleOwner provides lifecycleOwner) { / / We need to propagate min constraints because one of the likely uses for the modif i er passed / / into this function is to directly control the layout of the child view – which means / / minimum constraints are likely to be signif i cant. Box(modif i er, propagateMinConstraints = true) { viewFactory.Content(rendering, viewEnvironment) } } } }

@zachklipp • ComposeViewFactory • ComposeScreen • WorkflowRendering

er: Modif i er = Modif i er ) { val viewFactory: ComposeViewFactory<Any> = remember { viewEnvironment[ViewRegistry] .getFactoryForRendering(rendering) .asComposeViewFactory() } val lifecycleOwner = rememberChildLifecycleOwner() CompositionLocalProvider(LocalLifecycleOwner provides lifecycleOwner) { Box(modif i er, propagateMinConstraints = true) { viewFactory.Content(rendering, viewEnvironment) } } }

@zachklipp ComposeViewFactory

@zachklipp asComposeViewFactory

@zachklipp fun <R : Any> ViewFactory<R>.asComposeViewFactory() : ComposeViewFactory<R>

@zachklipp internal fun <R : Any> ViewFactory<R>.asComposeViewFactory() : ComposeViewFactory

@zachklipp fun <R : Any> ViewFactory<R>.asComposeViewFactory() : ComposeViewFactory<R> = (this
as? ComposeViewFactory)

@zachklipp val color = composeViewFactory<Color> { rendering, _ - >
Text(rendering.toString()) } val red = composeViewFactory<Unit> { _, viewEnvironment - > Row { Text("Red: ") color.Content(Color.Red, viewEnvironment) } }

@zachklipp val color = composeViewFactory<Color> { rendering, _ - >
Text(rendering.toString()) } val red = composeViewFactory<Unit> { _, viewEnvironment - > Row { Text("Red: ") key(Color.Red : : class) { val lifecycleOwner = rememberChildLifecycleOwner() CompositionLocalProvider(LocalLifecycleOwner provides lifecycleOwner) { Box(propagateMinConstraints = true) { color.Content(Color.Red, viewEnvironment) } } } } }

as? ComposeViewFactory)

as? ComposeViewFactory) ?: object : ComposeViewFactory<R>() {}

as? ComposeViewFactory) ?: object : ComposeViewFactory<R>() { private val originalFactory = this@asComposeViewFactory @Composable override fun Content( rendering: R, viewEnvironment: ViewEnvironment ) {} }

as? ComposeViewFactory) ?: object : ComposeViewFactory<R>() { private val originalFactory = this@asComposeViewFactory @Composable override fun Content( rendering: R, viewEnvironment: ViewEnvironment ) { AndroidView() } }

as? ComposeViewFactory) ?: object : ComposeViewFactory<R>() { private val originalFactory = this@asComposeViewFactory @Composable override fun Content( rendering: R, viewEnvironment: ViewEnvironment ) { AndroidView( factory = { context - > }, update = { view - > } ) } }

as? ComposeViewFactory) ?: object : ComposeViewFactory<R>() { private val originalFactory = this@asComposeViewFactory @Composable override fun Content( rendering: R, viewEnvironment: ViewEnvironment ) { AndroidView( factory = { context - > originalFactory.buildView(rendering, viewEnvironment, context) }, update = { view - > } ) } }

@zachklipp fun <R : Any> ViewFactory<R>.asComposeViewFactory() i nal override fun
buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View = ComposeView(contextForNewView).also { composeView - > composeView.bindShowRendering( initialRendering, initialViewEnvironment ) { rendering, environment - > composeView.setContent { Content(rendering, environment) } } }

as? ComposeViewFactory) ?: object : ComposeViewFactory<R>() { private val originalFactory = this@asComposeViewFactory @Composable override fun Content( rendering: R, viewEnvironment: ViewEnvironment ) { AndroidView( factory = { context - > originalFactory.buildView(rendering, viewEnvironment, context) }, update = { view - > } ) } }

as? ComposeViewFactory) ?: object : ComposeViewFactory<R>() { private val originalFactory = this@asComposeViewFactory @Composable override fun Content( rendering: R, viewEnvironment: ViewEnvironment ) { AndroidView( factory = { context - > originalFactory.buildView(rendering, viewEnvironment, context) }, update = { view - > view.showRendering(rendering, viewEnvironment) } ) } }

@zachklipp • ComposeViewFactory • ComposeScreen • WorkflowRendering • asComposeViewFactory

@zachklipp View-based Rendering View-based Rendering Compose-based Rendering Compose-based Rendering View-based
Rendering

@zachklipp

@zachklipp Compose / View intro • Complicated implementation, simple API
• Back in early 2020, very buggy – much be tt er now

@zachklipp class ComposeViewFactory<RenderingT : Any>( override val type: KClass<RenderingT>, private
val content: @Composable() (RenderingT, ViewEnvironment) - > Unit ) : ViewFactory<RenderingT> { override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View { val composeContainer = FrameLayout(contextForNewView) val renderState = mutableStateOf<Pair<RenderingT, ViewEnvironment>?>( / / This will be updated immediately by bindShowRendering below. value = null, areEquivalent = StructurallyEqual ) FrameManager.ensureStarted() composeContainer.bindShowRendering( initialRendering, initialViewEnvironment ) { rendering, environment - > renderState.value = Pair(rendering, environment) } composeContainer.setOrContinueContent(initialViewEnvironment) { val (rendering, environment) = renderState.value ! ! showRenderingWrappedWithRoot(rendering, environment) } return composeContainer } @Composable internal fun showRenderingWrappedWithRoot( rendering: RenderingT, viewEnvironment: ViewEnvironment ) { wrapWithRootIfNecessary(viewEnvironment) { content(rendering, viewEnvironment) } } }

@zachklipp abstract class ComposeViewFactory<RenderingT : Any> : ViewFactory<RenderingT> { @Composable
abstract fun Content( rendering: RenderingT, viewEnvironment: ViewEnvironment ) f i nal override fun buildView( initialRendering: RenderingT, initialViewEnvironment: ViewEnvironment, contextForNewView: Context, container: ViewGroup? ) : View = ComposeView(contextForNewView).also { composeView - > composeView.bindShowRendering( initialRendering, initialViewEnvironment ) { rendering, environment - > composeView.setContent { Content(rendering, environment) } } } }

@zachklipp ViewTree*Owners… 😐 • More fl exible than previous hooks
• Gotcha: root views (e.g. modals) • Only a pa tt ern

@zachklipp Implementing view state restoration is hard • Multiple mechanisms
• View onSaveInstanceState/onRestoreInstanceState • AndroidX SavedStateRegistry • Compose SaveableStateRegistry • IDs • Lifecycle-sensitive

@zachklipp CompositionLocals • For ViewEnvironment? • Strongly discouraged o ffi
cially • Cleaner demos ≠ more maintainable code

@zachklipp Writing a navigation library is hard • But there
are bene fi ts if you’re willing to invest.

@zachklipp Writing a navigation library for Views is hard •
But there are bene fi ts if you’re willing to invest. • It’s a lot easier in Compose! • Bidirectional interop is one of Compose’s best features.

@zachklipp Current status Adoption • Integration with internal app sca
ff olding. • New internal design system is primarily Compose-based. • All new UIs are built with Compose. • ~120 renderings already using it. • Lots of samples on public GitHub.

@zachklipp Current status Work fl ow pe rf ormance •
Immutable tree of immutable renderings • Eager rendering • Molecule?

@zachklipp Final thoughts…

@zachklipp Thanks: • Ray Ryan + Square Foundation team: Code
reviews, talk feedback, the entire Work fl ow project • Leland Richardson: Troubleshooting early interop bugs

@zachklipp …and thank you! Questions? Zach Klippenstein (he/him) @zachklipp [email protected]
kotlinlang.slack.com #squarelibraries #compose square.github.io/work fl ow bit.ly/work fl ow-compose-blog developer.android.com/jetpack/compose
