Reimagining text fields in Compose (dcNYC 23)

The Compose Text team is completely rethinking the text field APIs from scratch. Come learn why, how we're approaching the process, and get a sneak peak at what the future might look like.

Transcript

1. Reimagining
   text fields
   in Compose
   Zach Klippenstein (he/him), Google
   droidcon NYC 2023


   View Slide

2. refresher:
   TextField
   var text by remember { mutableStateOf("") }
   TextField(
   text,
   onValueChange = { text = it }
   )


   View Slide

3. refresher:
   BasicTextField
   var text by remember { mutableStateOf("") }
   BasicTextField(
   text,
   onValueChange = { text = it }
   )


   View Slide

4. refresher:
   BasicTextField
   BasicTextField(
   text,
   onValueChange = { text = it }
   )


   View Slide

5. refresher:
   BasicTextField
   var text by remember { mutableStateOf("") }


   View Slide

6. It’s got some
   bugs…


   View Slide

7. Tech debt


   View Slide

8. State management
   class ViewModel {
   val text = MutableStateFlow("")
   fun onTextUpdated(text: String) {
   // suspending call
   if (validate(text)) {
   text.value = text
   }
   }
   }


   View Slide

9. State mismanagement


   View Slide

10. State (mis)management
    VisualTransformation
    Single/min/max lines
    Detecting individual edits
    …


    View Slide

11. Back to first principles…


    View Slide

12. Plan to
    plan
    scoping & estimates


    View Slide

13. Project
    kick-off
    brainstorming


    View Slide

14. User study
    early validation
    –
    diverse backgrounds
    –
    interviews + take-home
    project
    –
    more info in previous
    talk:
    –
    bit.ly/3LnNqrI
    sign up:
    –
    goo.gle/AndroidDevUX


    View Slide

15. New APIs
    feedback requested!


    View Slide

16. caveat:
    Under construction!
    BasicTextField v2
    State
    Filtering
    Visual transformations
    Passwords
    Line limits
    Scrolling


    View Slide

17. BasicTextField v2
    var text by remember { mutableStateOf("") }
    BasicTextField(
    text,
    onValueChanged = { text = it }
    )
    becomes
    var text by remember { mutableStateOf("") }
    BasicTextField(
    text,
    onValueChanged = { text = it }
    )


    View Slide

18. BasicTextField v2
    var text by remember { mutableStateOf("") }
    BasicTextField(
    text,
    onValueChanged = { text = it }
    )
    becomes
    val state: TextFieldState = rememberTextFieldState("")
    BasicTextField(state)


    View Slide

19. BasicTextField v2
    val text = rememberTextFieldState("hello")
    is essentially
    val text = remember(TextFieldState.Saver) {
    TextFieldState("hello")
    }


    View Slide

20. Reading text
    var text by remember { mutableStateOf("") }
    …
    Text("Hello $text!")
    becomes
    val state = rememberTextFieldState("")
    …
    Text("Hello ${state.text}!")


    View Slide

21. State hoisting
    currently
    class ViewModel {
    var textState by mutableStateOf("")
    }


    View Slide

22. State hoisting
    …becomes
    class ViewModel {
    val textState = TextFieldState("")
    }
    @Composable fun Screen(viewModel: ViewModel) {
    TextField(viewModel.textState)
    }


    View Slide

23. Observing changes
    currently
    class ViewModel {
    private var textState by mutableStateOf("")
    suspend fun run() {
    snapshotFlow { textState }
    .collectLatest { processText(it) }
    }
    }


    View Slide

24. Observing changes
    becomes
    class ViewModel {
    val textState = TextFieldState("")
    suspend fun run() {
    textState.textAsFlow()
    .collectLatest { processText(it) }
    // or
    textState.forEachTextValue { processText(it) }
    }
    }


    View Slide

25. Observing changes
    example: debouncing
    textState.textAsFlow()
    .debounce(500)
    .collectLatest { runSearch(it) }
    // or
    textState.forEachTextValue {
    delay(500)
    runSearch(it)
    }


    View Slide

26. Setting text
    class ViewModel {
    private var textState by mutableStateOf("")
    fun prefill(text: String) {
    textState = prefill
    }
    }
    becomes
    class ViewModel {
    val textState = TextFieldState("")
    fun prefill(text: String) {
    textState.setTextAndPlaceCursorAtEnd(text)
    }
    }


    View Slide

27. Inserting/deleting text
    text = buildString {
    append(text)
    deleteRange(2, 6)
    insert(10, "foo")
    }
    becomes
    textState.edit {
    delete(2, 6)
    insert(10, "foo")
    }


    View Slide

28. TextFieldState
    @Stable
    class TextFieldState(
    initialText: String = "",
    initialSelection: TextRange = …
    ) {
    val text: CharSequence
    val selection: TextRange
    fun edit(block: TextFieldBuffer.() -> Unit)
    }


    View Slide

29. TextFieldBuffer
    aka “StringBuilder with selection”
    class TextFieldBuffer: Appendable {
    val length: Int
    val selection: TextRange
    fun append(text: CharSequence?)
    fun replace(start: Int, end: Int, text: CharSequence)
    fun insert(index: Int, text: CharSequence)
    fun delete(start: Int, end: Int)
    fun replace(regex: Regex, text: CharSequence)
    fun setSelection(range: TextRange)
    fun placeCursorBeforeCharAt(offset: Int)
    // lots more to come…
    }


    View Slide

30. State
    Snapshot-backed (@Stable)
    Observe via snapshots or flows
    Edit via mutable buffer
    Hoistable


    View Slide

31. Filtering
    currently
    BasicTextField(
    text,
    onValueChange = {
    if (it.isDigitsOnly()) {
    text = it
    }
    }
    )


    View Slide

32. Filtering
    …becomes
    BasicTextField(
    text,
    inputTransformation = {
    replace("""\D""".toRegex(), "")
    }
    )


    View Slide

33. Filtering
    …or factored out
    object DigitsOnly : InputTransformation {
    override fun TextFieldBuffer.transformInput() {
    replace("""\D""".toRegex(), "")
    }
    }


    View Slide

34. Filtering
    built-in
    BasicTextField(
    state,
    inputTransformation = InputTransformation.digitsOnly()
    )


    View Slide

35. Filtering
    chaining
    BasicTextField(
    state,
    inputTransformation = digitsOnly() then maxChars(10)
    )


    View Slide

36. Filtering
    keyboard
    BasicTextField(
    state,
    inputTransformation = digitsOnly(),
    keyboardOptions = KeyboardOptions(
    keyboardType = Number
    )
    )


    View Slide

37. Filtering
    keyboard
    object DigitsOnly : InputTransformation {
    override val keyboardOptions = KeyboardOptions(
    keyboardType = Number
    )
    override fun TextFieldBuffer.transformInput() {
    …
    }
    }


    View Slide

38. InputTransformation
    definition
    fun interface InputTransformation {
    val keyboardOptions: KeyboardOptions? get() = null
    fun TextFieldBuffer.transformInput()
    }


    View Slide

39. example
    Formatting a phone number


    View Slide

40. Visual transformations
    currently
    fun interface VisualTransformation {
    fun filter(text: AnnotatedString): TransformedText
    }
    class TransformedText(
    val text: AnnotatedString,
    val offsetMapping: OffsetMapping
    )
    interface OffsetMapping {
    fun originalToTransformed(offset: Int): Int
    fun transformedToOriginal(offset: Int): Int
    }


    View Slide

41. View Slide

42. View Slide

43. View Slide

44. OutputTransformation
    example
    BasicTextField2(
    state,
    outputTransformation = {
    if (length > 0) insert(0, "(")
    if (length > 4) insert(4, ") ")
    if (length > 9) insert(9, "-")
    }
    )


    View Slide

45. OutputTransformation
    with InputTransformation
    BasicTextField2(
    state,
    outputTransformation = {
    if (length > 0) insert(0, "(")
    if (length > 4) insert(4, ") ")
    if (length > 9) insert(9, "-")
    },
    inputTransformation = digitsOnly() then maxChars(10)
    )


    View Slide

46. OutputTransformation
    fun interface OutputTransformation {
    fun TextFieldBuffer.transformOutput()
    }


    View Slide

47. Passwords
    currently
    BasicTextField(
    password,
    onValueChange = { password = it },
    visualTransformation = PasswordVisualTransformation(),
    )


    View Slide

48. Passwords
    currently
    BasicTextField(
    password,
    onValueChange = { password = it },
    visualTransformation = PasswordVisualTransformation(),
    modifier = Modifier.semantics { password() },
    keyboardOptions = KeyboardOptions(
    keyboardType = Password
    )
    )


    View Slide

49. Passwords
    …becomes
    BasicSecureTextField(state)
    Obfuscated text (customizable)
    –
    No cut/copy/drag (paste allowed)
    –
    IME password mode
    –
    Autofill support (planned)
    –


    View Slide

50. Line limits
    no more nonsense
    BasicTextField(
    …,
    singleLine = true,
    minLines = 5,
    maxLines = 10
    )


    View Slide

51. Line limits
    BasicTextField(
    …,
    singleLine = true
    )
    becomes
    BasicTextField(
    …,
    lineLimits = SingleLine
    )


    View Slide

52. Line limits
    BasicTextField(
    …,
    singleLine = false, maxLines = 10
    )
    becomes
    BasicTextField(
    …,
    lineLimits = MultiLine(maxHeightInLines = 10)
    )


    View Slide

53. Line limits
    SingleLine
    MultiLine(min, max)
    Never wraps
    –
    No newlines
    –
    Fixed height
    –
    Horizontal scrolling
    –
    Wraps long lines
    –
    Newlines allowed
    –
    Height shrinks and grows
    –
    Vertical scrolling
    –


    View Slide

54. ScrollState
    val state = rememberTextFieldState("")
    val scrollState = rememberScrollState()
    BasicTextField(
    state,
    scrollState = scrollState
    )
    LaunchedEffect(scrollState) {
    scrollState.scrollTo(…)
    }
    Horizontal in SingleLine mode
    –
    Vertical in MultiLine mode
    –


    View Slide

55. Recap
    BasicTextField2
    –
    TextFieldState +
    TextFieldBuffer
    –
    InputTransformation
    –
    OutputTransformation
    –
    BasicSecureTextField
    –
    LineLimits
    –
    ScrollState
    –
    also…
    User studies are great!
    Sign up:
    Available in 1.6.x alphas
    goo.gle/AndroidDevUX


    View Slide

56. Contact
    Kotlin Slack: #
    Socials:
    compose
    issuetracker.google.com
    – androiddev.social/@zachklipp
    – twitter.com/@halilozercan
    Slides
    bit.ly/3PboGEk


    View Slide
