[35] RFID NFC TOOLS - NFC TOOLS

Kali Linux Tools

Transcript

1. Digital Forensics
   Penetration Testing
   @Aleks_Cudars
   Last updated: 25.04.2013


   View Slide

2. NB!
   • This reference guide describes every tool one by one and is aimed at anyone who wants to get familiar with digital forensics and penetration
   testing or refresh their knowledge in these areas with tools available in Kali Linux
   • Note! I’ve tried to gather as much information as possible, however, even despite that, some entries don’t have information, which I might update
   if I get more information. Also, mistakes are inevitable
   • The purpose was to create the most detailed source of every tool in Kali Linux for quick reference and better understanding
   • Some tools fall under several categories, which means that duplicate entries exist in the full ~670 pages long source
   • The information about every tool usually consists of: DESCRIPTION, USAGE, EXAMPLE and sometimes OPTIONS and TIPs
   • Kali Linux tools are not limited to Kali Linux / Backtrack (most can be installed on other Linux distributions taking into consideration all the
   necessary dependencies. Additionally, some tools are also available on other types of operating systems such as Windows and Mac OS)
   • Kali Linux is a new and developing OS – some tools may be added, some - updated, some – removed over time
   • It is assumed that all tools are run as root (or as administrator) (in Kali Linux you are root by default)
   • All the information gathered about each tool has been found freely on the Internet and is publicly available
   • Sources of information are referenced at the end
   • Most command line tools include options, however, due to space considerations, only some tools have options listed (search the internet for
   options, read documentation/manual, use –h or --help)
   • For more information on each tool - search the internet, click on links or check the references at the end
   • PLEASE DO NOT USE KALI LINUX AND THE TOOLS LISTED HERE FOR ANY ILLEGAL OPERATION!
   • Tools which are specifically aimed at DOS, DDOS or anonymity are rarely used in legitimate engagements, and are
   therefore not installed by default in Kali Linux
   List of Tools for Kali Linux 2013 2


   View Slide

3. [35] RFID/NFC TOOLS: NFC TOOLS
   • mfcuk
   • mfoc
   • mifare-classic-format
   • nfc-list
   • nfc-mfclassic
   3
   List of Tools for Kali Linux 2013


   View Slide

4. mfcuk
   4
   List of Tools for Kali Linux 2013
   DESCRIPTION MFCUK - MiFare Classic Universal toolKit.
   Toolkit containing samples and various tools based on and around libnfc and crapto1, with emphasis on Mifare
   Classic NXP/Philips RFID cards.
   Special emphasis of the toolkit is on the following:
   • mifare classic weakness demonstration/exploitation
   • demonstrate use of libnfc (and ACR122 readers)
   • demonstrate use of Crapto1 implementation to confirm internal workings and to verify theoretical/practical
   weaknesses/attacks
   USAGE ./mfcuk [OPTIONS]
   EXAMPLE ./mfcuk_keyrecovery_darkside -C -R 0:A -v 2 (Recovering a key)


   View Slide

5. mfoc
   5
   List of Tools for Kali Linux 2013
   DESCRIPTION MFOC is an open source implementation of "offline nested" attack by Nethemba. MFOC uses LIBNFC
   and CRAPTO1 library to recover the keys, provided at least one valid Key-A/Key-B of any sector is known, or if the
   card uses a default key. If a card uses at least one block encrypted with a default key, all the other keys can be
   extracted in minutes. If the card does not use default keys, one key for a sector can be retrieved using the MFCUK
   library, after which this library can be used.
   This program allows to recover authentication keys from MIFARE Classic card.
   Please note MFOC is able to recover keys from target only if it have a known key: default one (hardcoded in MFOC) or
   custom one (user provided using command line).
   USAGE mfoc [-h] [-k key]... [-P probnum] [-T tolerance] [-O output]
   EXAMPLE mfoc –h
   EXAMPLE mfoc -O mycard.mfd
   EXAMPLE mfoc -k ffffeeeedddd -O mycard.mfd
   EXAMPLE mfoc -P 50 -T 30 -O mycard.mfd


   View Slide

6. mifare-classic-format
   6
   List of Tools for Kali Linux 2013
   DESCRIPTION MifareClassicTool - An Android NFC-App for reading/writing/analysing/etc Mifare Classic RFID-Tags.
   USAGE mifare-classic-format [option]
   OPTIONS -h Help
   -f Fast format (only erase MAD)
   -y Do not ask for confirmation (dangerous)
   EXAMPLE mifare-classic-format -h


   View Slide

7. nfc-list
   7
   List of Tools for Kali Linux 2013
   DESCRIPTION libnfc is a library which allows userspace application access to NFC devices.
   nfc-list is part of libnfc .
   nfc-list is a utility for listing any available tags like ISO14443-A, FeliCa, Jewel or ISO14443-B (according to the
   device capabilities). It may detect several tags at once thanks to a mechanism called anti-collision but all types of
   tags don't support anti-collision and there is some physical limitation of the number of tags the reader can
   discover.
   This tool displays all available information at selection time.
   More info: http://nfc-tools.org/index.php?title=Main_Page
   USAGE nfc-list
   EXAMPLE nfc-list


   View Slide

8. nfc-mfclassic
   8
   List of Tools for Kali Linux 2013
   DESCRIPTION libnfc is a library which allows userspace application access to NFC devices.
   nfc-mfclassic is part of libnfc .
   With this tool a complete MIFARE card can be dumped to / restored from a MIFARE dump file (*.mfd).
   More info: http://nfc-tools.org/index.php?title=Libnfc:nfc-mfclassic and http://nfc-
   tools.org/index.php?title=Main_Page
   USAGE nfc-mfclassic [Options]
   OPTIONS https://code.google.com/p/libnfc/source/browse/utils/nfc-
   mfclassic.1?r=03a6f5e29c9a177788c20470b71128938d90120c
   EXAMPLE nfc-mfclassic r X ~/Desktop/dump.mfd


   View Slide
