Développer une app Android en 2015

Retour d'expérience chez BlaBlaCar - PAUG 3 mars 2015

Transcript

1. Développer une
   app Android en 2015


   View Slide

2. Saad Bouchehboun
   Tech Manager
   Francois-Xavier Oxeda
   Android developer
   @BlaBlaCarTech
   Alexandra Tritz
   Android developer


   View Slide

3. Mobile First
   Jan. 2013 → 2015


   View Slide

4. View Slide

5. View Slide

6. Librairies utilisées


   View Slide

7. ButterKnife
   public class ForgotPasswordActivity extends Activity {
   @InjectView(R.id.new_password_header) TextView newPasswordHeader;
   @InjectView(R.id.new_password_editText) EditText newPasswordEditText;
   @InjectView(R.id.confirm_password_editText) EditText confirmPasswordEditText;
   @Override
   protected void onCreate(Bundle savedInstanceState) {
   super.onCreate(savedInstanceState);
   setContentView(R.layout.activity_forgot_password);
   ButterKnife.inject(this);
   // Instead of
   // newPasswordHeader = (TextView) findViewById(R.id.new_password_header);
   // …


   View Slide

8. ButterKnife
   @Optional @OnClick(R.id.drawer_logout_textView)
   public void logout() {
   // ...
   }
   @Optional @OnClick(R.id.drawer_login_textView)
   public void login() {
   // ...
   }
   @OnItemSelected(R.id.listView)
   public void onItemSelected(int position){
   // ...
   }


   View Slide

9. Universal Image Loader
   public void displayUser(User user) {
   ImageLoader.getInstance().displayImage(
   user.getPictureUrl(),
   userImageView
   );
   // ...
   }
   public void displayUser(User user) {
   ImageLoader.getInstance().displayImage(
   user.getPictureUrl(),
   userImageView,
   options,
   listener
   );
   // ...
   }


   View Slide

10. Merge Adapter
    public class UpcomingRidesAdapter extends MergeAdapter {
    private TripOfferAdapter driverAdapter;
    private SeatBookedAdapter seatsBookedAdapter;
    private TripListAdapter visitedAdapter;
    public UpcomingRidesAdapter(Context context) {
    // driver trip offers sub-adapter
    driverAdapter = new TripOfferAdapter(context);
    addAdapter(driverAdapter);
    //booked seats
    seatsBookedAdapter = new SeatBookedAdapter(context);
    addAdapter(seatsBookedAdapter);
    // visited trips sub-adapter
    visitedAdapter = new TripListAdapter(context);
    addAdapter(visitedAdapter);
    }
    }


    View Slide

11. Retrofit
    A type-safe REST client
    for Android and Java


    View Slide

12. Otto
    public class BusManager {
    private static BusManager instance;
    public Bus bus;
    private BusManager() {
    bus = new Bus();
    }
    public static BusManager getInstance() {
    if (instance == null) {
    instance = new BusManager();
    }
    return instance;
    }
    }


    View Slide

13. Otto
    // Publishing
    BusManager.getInstance().bus.post(
    new NotificationCountEvent(result)
    );


    View Slide

14. Otto
    // Subscribing
    @Override
    public void onResume() {
    super.onResume();
    BusManager.getInstance().bus.register(this);
    }
    @Override
    public void onPause() {
    super.onPause();
    BusManager.getInstance().bus.unregister(this);
    }
    @Subscribe
    public void onNotificationCountEvent(NotificationCountEvent event) {
    // Update UI
    }


    View Slide

15. Autres...
    Crouton
    ViewPagerIndicator


    View Slide

16. Traductions
    Over The Air


    View Slide

17. OpenLocalization


    View Slide

18. openl10n.io


    View Slide

19. Déploiement des traductions
    Les traductions sont
    synchronisés sur openl10n
    Une fois éditées elles
    sont directement
    déployées en prod (S3)


    View Slide

20. Les traductions sont mises
    à jour dynamiquement à l’
    ouverture de l’application


    View Slide

21. strings-en.json
    {
    "contact.item.text.call_phone": "Call",
    "contact.item.text.text_phone": "Send a SMS",
    ...
    }
    strings-fr.json
    {
    "contact.item.text.call_phone": "Appeler",
    "contact.item.text.text_phone": "Envoyer un SMS",
    ...
    }


    View Slide

22. ids_ext_strings.xml

    MainActivity.java
    BlablacarApplication.getExtString(
    this.getContext(),
    R.id.str_contact.item.text.call_phone);
    activity_main.xml
    typeandroid:text="@id/str_contact.item.text.call_phone"/>


    View Slide

23. Configuration localisée


    View Slide

24. View Slide

25. View Slide

26. GET api.blablacar.com/trips/1234
    Accept-Language: fr-FR
    X-Currency: EUR
    HTTP vs Localization


    View Slide

27. Values-fr/context.xml


    fr_FR
    EUR
    false
    true
    true
    GTM-XXXXXX
    false

    getResources().getString(R.string.locale);


    View Slide

28. Now


    View Slide

29. Deeplink


    View Slide

30. View Slide

31. blablacar://pwd


    View Slide

32. mobiledeeplinking.org


    View Slide

33. Schéma
    AndroidManifest.xml



    ...


    View Slide

34. Routes
    MobileDeepLinkingConfig.json
    {
    "defaultRoute": {
    "class": "com.comuto.v3.activity.MainActivity"
    },
    "routes": {
    "search": {
    "class": "com.comuto.v3.activity.SearchActivity"
    "...":


    View Slide

35. Deeplink


    View Slide

36. Librairies


    View Slide

37. Exécute des requêtes asynchrones
    Respecte le cycle de vie des activités
    Cache les réponses


    View Slide

38. RoboSpice
    private SpiceManager spiceManager = new SpiceManager(SpiceService.class);
    @Override
    protected void onStart() {
    super.onStart();
    spiceManager.start(this);
    }
    @Override
    protected void onStop() {
    spiceManager.shouldStop();
    super.onStop();
    }
    spiceManager.execute(spiceRequest, requestListener);


    View Slide

39. RoboSpice
    // Request
    public class MySpiceRequest extends SpiceRequest {
    public MySpiceRequest(Class clazz) {
    super(clazz);
    }
    @Override
    public T loadDataFromNetwork() throws Exception {
    // Background process
    }
    }


    View Slide

40. RoboSpice
    // Listener
    public class MyRequestListener implements RequestListener {
    @Override
    public void onRequestFailure(SpiceException spiceException) {
    }
    @Override
    public void onRequestSuccess(T t) {
    }
    }


    View Slide

41. +
    Retrofit


    View Slide

42. RoboSpice + Retrofit
    // Interface
    public interface RetrofitInterface {
    @GET("/public_session")
    Session getPublicSession();
    }


    View Slide

43. RoboSpice + Retrofit
    // RetrofitGsonSpiceService
    public class MyRetrofitSpiceService extends RetrofitGsonSpiceService {
    @Override
    public void onCreate() {
    super.onCreate();
    addRetrofitInterface(RetrofitInterface.class);
    }
    @Override
    protected String getServerUrl() {
    return "http://www.base-url.com/";
    }
    }


    View Slide

44. RoboSpice + Retrofit
    // Interface:
    public class GetPublicSessionRequest
    extends RetrofitSpiceRequest {
    public GetPublicSessionRequest(Class clazz,
    Class interfaceClass) {
    super(clazz, interfaceClass);
    }
    @Override
    public Session loadDataFromNetwork() throws Exception {
    return getService().getPublicSession();
    }
    }


    View Slide

45. RoboSpice + Retrofit
    // Callback Interfaces
    public interface ManagerErrorCallback {
    public void onFailed(BlablacarError error);
    public void onFailed(List error);
    public void onNoNetworkError();
    }
    public interface ManagerCallback extends ManagerErrorCallback {
    public void onSuccess(T result);
    }


    View Slide

46. RoboSpice + Retrofit
    public class BaseActivity extends Activity implements ManagerErrorCallback
    {
    // ...
    }
    public class SomeActivity extends BaseActivity implements ManagerCallback
    {
    // ...
    }


    View Slide

47. RoboSpice + Retrofit
    public class BaseManager implements RequestListener {
    protected ManagerCallback callback;
    protected SpiceManager spiceManager;
    protected BaseManager(SpiceManager spiceManager, ManagerCallback callback) {
    this.spiceManager = spiceManager;
    this.callback = callback;
    }
    @Override
    public void onRequestFailure(SpiceException spiceException) {
    // Read exception and call the right callback accordingly
    // callback.onFailed(BlablacarError error);
    // callback.onFailed(List error);
    // callback.onNoNetworkError();
    }
    @Override
    public void onRequestSuccess(T result) { callback.onSuccess(result); }
    protected void execute(RetrofitSpiceRequest request) {
    spiceManager.execute(request, this);
    }
    }
    BaseManager
    UserManager
    TripManager
    PaymentManager


    View Slide

48. RoboSpice + Retrofit
    public class UserManager extends BaseManager {
    public UserManager(SpiceManager spiceManager,
    ManagerCallback callback) {
    super(spiceManager, callback);
    }
    public void getPublicSession(){
    execute(new GetPublicSessionRequest());
    }
    }
    BaseManager
    UserManager
    TripManager
    PaymentManager


    View Slide

49. RoboSpice + Retrofit
    public class SomeActivity extends BaseActivity implements ManagerCallback {
    private SpiceManager spiceManager = new SpiceManager(MyRetrofitGsonSpiceService.class);
    private void someMethod(){
    // ...
    UserManager userManager = new UserManager(spiceManager, this);
    userManager.getPublicSession();
    // ...
    }
    @Override
    public void onSuccess(Session result) {
    }
    }


    View Slide

50. Performances


    View Slide

51. OAuth2
    POST /oauth2/access_token?grant_type=password
    &scope=user_profile
    &login=username
    &password=userpwd
    {
    "access_token": "abcd1234567890",
    "expires_in": 3600,
    "token_type": "bearer"
    }
    Récupération d’un Access Token


    View Slide

52. OAuth2
    Utilisation de l’Access Token
    GET /api/trips?fn=Paris
    Authorization: Bearer abcd1234567890
    {
    "trips": [...]
    }


    View Slide

53. OAuth2
    Varnish


    View Slide

54. OAuth2


    View Slide

55. Latence ?


    View Slide

56. OAuth2


    View Slide

57. OAuth2
    JWT


    View Slide

58. http://jwt.io
    JSON Web Token


    View Slide

59. Monitoring


    View Slide

60. View Slide

61. public SpiceManager(Class extends SpiceService> spiceServiceClass, Boolean withMonitoring) {
    super(spiceServiceClass);
    this.isMonitored.set(withMonitoring); //AtomicBoolean
    }
    @Override
    public synchronized void start(Context context) {
    super.start(context);
    if (this.isMonitored.get()) {
    MonitoringService.getInstance().start();
    }
    }
    @Override
    public synchronized void shouldStop() {
    super.shouldStop();
    if (isMonitored.get()) {
    MonitoringService.getInstance().stop();
    }
    }
    Network monitoring


    View Slide

62. private static AtomicInteger monitoredServiceNumber ;
    private ConcurrentLinkedQueue inMemoryQueue ;
    public synchronized void start() {
    if ( monitoredServiceNumber.getAndIncrement() > 0) {
    return;
    }
    startMonitoring();
    }
    private void flush() {
    int size = inMemoryQueue.size();
    if (size == 0) {
    return;
    }
    MonitoringData[] monitoringDatas = new MonitoringData[size];
    for (int i = 0; i < size; i++) {
    monitoringDatas[i] = inMemoryQueue.poll();
    }
    MonitoringRequest monitoringRequest = new MonitoringRequest(monitoringDatas);
    spiceManager.execute(monitoringRequest, new MonitoringListener());
    }
    Network monitoring


    View Slide

63. protected RestAdapter.Builder createRestAdapterBuilder() {
    RestAdapter.Builder bbcRestAdapter = new RestAdapter.Builder()
    .setProfiler(new MonitoringProfiler());
    return bbcRestAdapter;
    }
    public class MonitoringProfiler implements Profiler {
    @Override
    public void afterCall(RequestInformation requestInfo, long elapsedTime,
    int statusCode, Object beforeCallData) {
    MonitoringService.getInstance().sendReq(requestInfo, elapsedTime, statusCode);
    }
    }
    Network monitoring


    View Slide

64. Source : SPDY Essentials by Will Chan Roberto Peon
    SPDY


    View Slide

65. Crashs


    View Slide

66. Compte-rendu quotidien sur


    View Slide

67. 30 jours
    avant déploiement total d’une nouvelle release


    View Slide

68. Google+ Group
    Plus de 150 membres dont une vingtaine de très actifs.
    Des retours chaque semaine sur le fonctionnement
    produit, des bugs ou des suggestions d’amélioration.
    Sélection de membres pour tester nos prochaines
    features.


    View Slide

69. View Slide

70. Material Design


    View Slide

71. Wear


    View Slide

72. Merci
    @BlaBlaCarTech


    View Slide
