1. Apache Kafka
2. Agenda Overview Topic Producer Consumer Getting Started Kafka and CPP
3. Overview (Project Info) • Distributed Publisher-Subscribe messaging system • Created by LinkedIn • Open sourced in 2011 (donated to apache) • Written in scala • Multi language support
4. Overview (highlights) • Functionality of a messaging system • Communication - high performance, language agnostic, TCP protocol • Run as a cluster of 1 or more servers (brokers) • Uses ZooKeeper for broker coordination • Maintains feeds of messages (topics) • Consumer - process subscribed to a topic • Producer - process publishing messages
5. Overview (Zookeeper) • Open source, high performance coordination service for distributed applications • Centralized service for: configuration management, naming, distributed sync.
6. Overview
7. Overview
8. Topic • Partition log for each topic • Each partition is ordered • Offset - sequence id • Configurable message retention • Partitions distributed in cluster • Each partition replicated • Leader/followers partitions
9. Producer • Publish data to topics of their choice • Before publishing, queries the leader broker for each partition • Responsible for assigning partition to each message • Can use round robin or custom semantics • Partitioner is informed about number of partitions
10. Producer Configuration Several interesting properties: • metadata.broker.list • serializer.class • partitioner.class • request.required.acks • message.send.max.retries
11. Producer Partitioner • Each producer configures a partitioner • Sample implementation of partitioner public class SimplePartitioner implements Partitioner<String> { public SimplePartitioner (VerifiableProperties props) { } public int partition(String key, int numberOfPartitions) { return Math.abs(key.hashCode()) % numberOfPartitions; } }
12. Producer
13. Consumer • Traditionally 2 models: queue vs broadcast • Consumer group abstraction - generalize both models. • Strong ordering guarantee • Each partition consumed by one consumer in group • Keep track of progress (store in zookeeper)
14. Consumer • Consumer stream per thread • Each thread receive message from a partition • Total threads <= number of partitions
15. Consumer Configuration Several interesting properties: • zookeeper.connect • group.id • auto.commit.enable • auto.commit.interval.ms • auto.offset.reset (smallest, largest)
16. Consumer API • Two types: High Level & Simple Consumer • High Level - easier and straightforward (no offset management) • Simple Consumer - not so simple ◦ read a message multiple times ◦ consume a subset of partitions in a process ◦ manage transactions to ensure message processed only once ◦ Require following several steps: ▪ find active broker & leader for a topic and a partition ▪ determine replica ▪ build request & fetch data ▪ recover from leader changes.
17. Getting Started (1) • Start Zookeper ./bin/zookeeper-server-start.sh config/zookeeper.properties • Start brokers ./bin/kafka-server-start.sh config/server.properties • Create topic ./bin/kafka-topics.sh --create --zookeeper localhost:2181 --replication-factor 2 --partitions 4 --topic test • List topics ./bin/kafka-topics.sh --list --zookeeper localhost:2181
18. Getting Started (2) • Describe topic ./bin/kafka-topics.sh --zookeeper localhost:2181 --describe test • Change number of partitions ./bin/kafka-topics.sh --alter --zookeeper localhost:2181 --partitions 5 --topic test • Start producer ./bin/kafka-console-producer.sh --broker-list localhost:9092 --topic test • Start consumer ./bin/kafka-console-consumer.sh --zookeeper localhost:2181 --topic test --from-beginning
19. Kafka and CPP • Messages in JSON format • High Level Consumer • No security on messaging layer (not supported by kafka) • Producer can sending duplicate messages (identified by transactionId). • Consumer, responsible for not processing duplicate messaging by managing message transactionId (store a limited set in a document). • Number of partitions - 12. • 3 Zookeeper servers & 3 Kafka servers • Messages persisted 1-2 days • Partitioning to be decided later • Monitoring needs to be addressed
20. References • http://kafka.apache.org/ • http://kafka.apache.org/documentation.html#quickstart • Introduction to Kafka • Error codes • Ops guide • Why we didn’t use Kafka • Apache Kafka and zookeeper (slides)
