Hitchhiker’s Guide to Compose: Snapshots, Compiler Plugins and Appliers

If you are an Android Developer, chances are you are pretty excited about Jetpack Compose! But how does it work? In this talk, we will take you along the journey of a Composable function, from being written, going through the unknown lands of the Kotlin and Compose compilers to being executed and displaying UI!

From Composables all the way down into the compiler plugins, we expose the metaprogramming responsible for all the "magic". Whether your interest is Jetpack Compose, compilers, or code transformations, this talk takes an otherwise complicated topic and makes it digestible for everybody by diving into specific features offered by Compose.

By examining Compose's snapshot system, you'll follow the compiler phases down to intercepting code transformations with IR. By recognizing the patterns that make it hard for Compose to generate efficient code, and this can help us to recognize patterns to use for performance.

Transcript

1. Hitchhiker’s Guide to Compose Snapshots, Compiler Plugins and Appliers @mvndy_hd @jossiwolf #hg2compose
2. #hg2compose TextView(text = "") FrameLayout FrameLayout @mvndy_hd @jossiwolf
3. #hg2compose setText("Bob") TextView(text = "") FrameLayout FrameLayout @mvndy_hd @jossiwolf
4. #hg2compose FrameLayout setText("Bob") FrameLayout TextView(text = "Bob") @mvndy_hd @jossiwolf
5. #hg2compose FrameLayout FrameLayout TextView(text = "Bob") getDisplayList() draw() @mvndy_hd @jossiwolf
6. #hg2compose FrameLayout FrameLayout TextView(text = "Bob") getDisplayList() getDisplayList() @mvndy_hd @jossiwolf
7. #hg2compose FrameLayout FrameLayout TextView(text = "Bob") getDisplayList() getDisplayList() getDisplayList() @mvndy_hd @jossiwolf
8. #hg2compose FrameLayout FrameLayout TextView(text = "Bob") draw() Bob @mvndy_hd @jossiwolf
9. #hg2compose Text(text = name) Layout Layout name by remember { mutableStateOf("") } @mvndy_hd @jossiwolf
10. #hg2compose Text(text = name) Layout Layout name by remember { mutableStateOf("Bob") } @mvndy_hd @jossiwolf
11. #hg2compose Text(text = name) Layout Layout name by remember { mutableStateOf("Bob") } @mvndy_hd @jossiwolf
12. #hg2compose Text(text = name) Layout Layout name by remember { mutableStateOf("Bob") } Bob @mvndy_hd @jossiwolf
13. "Jetpack Compose is Android's modern toolkit for building native UI." #hg2compose - developer.android.com @mvndy_hd @jossiwolf
14. Compiler Runtime UI #hg2compose != @mvndy_hd @jossiwolf
15. A Composable is a restartable function that emits nodes into a tree. #hg2compose Glossary @mvndy_hd @jossiwolf
16. Recomposition is the process of re-executing a Composable function to produce an updated slot table #hg2compose Glossary @mvndy_hd @jossiwolf
17. The Composition holds the Slot Table, invalidations and a Composer. #hg2compose Glossary @mvndy_hd @jossiwolf
18. The Slot Table is used to store the current state of the Composition. #hg2compose Glossary @mvndy_hd @jossiwolf
19. A Composer connects Composables to Runtime, keeps track of groups that are used to build the Slot Table and positions it. #hg2compose Glossary @mvndy_hd @jossiwolf
20. Recomposers manage the Snapshot and Compositions #hg2compose Glossary @mvndy_hd @jossiwolf
21. @Composable fun HitchhikerApp() { var name by remember { mutableStateOf("Bob") } HelloWorld(greeting = name) name = "Chet" } @Composable fun HelloWorld(greeting: String) { Text("Hello, $greeting!") } #hg2compose @mvndy_hd @jossiwolf
22. Snapshots 📸 #hg2compose @mvndy_hd @jossiwolf
23. "A Snapshot is a lot like a save point in a video game: it represents the state of your entire program at a single point in history." #hg2compose https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn - "Introduction to the Compose Snapshot System" by Zach Klippenstein Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
24. #hg2compose https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn class Dog { var name: MutableState<String> = mutableStateOf(“”) } fun main() { val dog = Dog() dog.name.value = "Spot" val snapshot = Snapshot.takeSnapshot() dog.name.value = "Fido" println(dog.name.value) } Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
25. #hg2compose https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn fun main() { val dog = Dog() dog.name.value = "Spot" val snapshot = Snapshot.takeSnapshot() dog.name.value = "Fido" println(dog.name.value) // Fido snapshot.enter { println(dog.name.value) / / Spot } println(dog.name.value) // Fido } Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
26. #hg2compose Snapshot.takeSnapshot() Dog(name = "Spot") 📸 Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
27. #hg2compose Snapshot.takeSnapshot() 📸 Dog(name = "Spot") Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
28. #hg2compose Snapshot.takeSnapshot() 1 2 📸 Dog(name = "Spot") Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
29. #hg2compose Snapshot.takeSnapshot() dog.name.value = "Fido" 📸 1 2 Dog(name = "Spot") Dog(name = "Fido") Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
30. #hg2compose Snapshot.takeSnapshot() dog.name.value = "Fido" 📸 1 2 Dog(name = "Spot") Dog(name = "Fido") snapshot.enter { . . . } Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
31. #hg2compose Snapshot.takeSnapshot() dog.name.value = "Fido" 📸 1 2 Dog(name = "Spot") Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } ❌ Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
32. #hg2compose Snapshot.takeSnapshot() dog.name.value = "Fido" 📸 1 2 Dog(name = "Spot") Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } ❌ Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
33. #hg2compose Snapshot.takeMutableSnapshot() dog.name.value = "Fido" 📸 1 2 Dog(name = "Spot") Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } ❌ Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
34. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) Snapshot.takeMutableSnapshot() 📸 1 2 dog.name.value = "Fido" Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot")
35. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) Snapshot.takeMutableSnapshot() 📸 1 2 dog.name.value = "Fido" Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot")
36. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) Snapshot.takeMutableSnapshot() 📸 1 2 dog.name.value = "Fido" Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot") Dog(name = "Taco") ✔
37. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) snapshot.apply() Snapshot.takeMutableSnapshot() dog.name.value = "Fido" 📸 1 2 snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot") Dog(name = "Taco") Dog(name = "Fido") Dog(name = "Taco")
38. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) snapshot.apply() Snapshot.takeMutableSnapshot() dog.name.value = "Fido" 📸 1 2 snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot") Dog(name = "Taco") Dog(name = "Fido") Dog(name = "Taco")
39. #hg2compose @mvndy @jossiwolf https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn fun main() { val dog = Dog() dog.name.value = "Spot" val snapshot = Snapshot.takeSnapshot( readObserver = { value -> ... } ) dog.name.value = "Fido" println(dog.name.value) // Fido snapshot.enter { println(dog.name.value) // Spot } } Snapshots 📸 (and dogs🐕)
40. #hg2compose @mvndy @jossiwolf fun main() { val dog = Dog() dog.name.value = "Spot" val snapshot = Snapshot.takeSnapshot( readObserver = { value -> println(value) // MutableState(value=Spot)@ ... } ) dog.name.value = "Fido" println(dog.name.value) // Fido snapshot.enter { println(dog.name.value) // Spot } } Snapshots 📸 (and dogs🐕)
41. #hg2compose @mvndy @jossiwolf fun main() { val dog = Dog() dog.name.value = "Spot" val snapshot = Snapshot.takeSnapshot( readObserver = { value -> println(value) // MutableState(value=Spot)@ ... } ) dog.name.value = "Fido" println(dog.name.value) // Fido snapshot.enter { println(dog.name.value) // Spot } } Snapshots 📸 (and dogs🐕)
42. #hg2compose @mvndy @jossiwolf fun main() { val dog = Dog() dog.name.value = "Spot" val snapshot = Snapshot.takeMutableSnapshot( readObserver = { value -> println(value) // MutableState(value=Spot)@ ... }, writeObserver = { value -> ... } ) dog.name.value = "Fido" snapshot.enter { dog.name.value = "Taco" } } Snapshots 📸 (and dogs🐕)
43. (Snapshot) State #hg2compose @mvndy_hd @jossiwolf
44. #hg2compose interface State<out T> { val value: T } package androidx.compose.runtime @mvndy_hd @jossiwolf
45. #hg2compose interface State<out T> { val value: T } interface MutableState<T> : State<T> { override var value: T operator fun component1(): T operator fun component2(): (T) -> Unit } package androidx.compose.runtime @mvndy_hd @jossiwolf
46. #hg2compose /** * Return the current readable state record for the [snapshot]. * It is assumed that [this] is the first record of [state] */ fun <T : StateRecord> T.readable(state: StateObject, snapshot: Snapshot): T { // invoke the observer associated with the current snapshot. snapshot.readObserver ?. invoke(state) return readable(this, snapshot.id, snapshot.invalid) ?: readError() } package androidx.compose.runtime @mvndy_hd @jossiwolf
47. #hg2compose /** * Return the current readable state record for the [snapshot]. * It is assumed that [this] is the first record of [state] */ fun <T : StateRecord> T.readable(state: StateObject, snapshot: Snapshot): T { // invoke the observer associated with the current snapshot. snapshot.readObserver ?. invoke(state) return readable(this, snapshot.id, snapshot.invalid) ?: readError() } package androidx.compose.runtime @mvndy_hd @jossiwolf
48. @Composable fun HitchhikerApp() { var name = remember { mutableStateOf("Bob") } HelloWorld(greeting = name.value) } @Composable fun HelloWorld(greeting: String) { println("Hello, $greeting!") } #hg2compose @mvndy_hd @jossiwolf
49. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted() launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } @mvndy_hd @jossiwolf
50. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted() launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } medium.com/@takahirom/inside-jetpack-compose-2e971675e55e @mvndy_hd @jossiwolf
51. Recomposers manage the Snapshot and Compositions, i.e. composing initially and recomposing. #hg2compose Glossary @mvndy_hd @jossiwolf
52. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted() launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } medium.com/@takahirom/inside-jetpack-compose-2e971675e55e @mvndy_hd @jossiwolf
53. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted() launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } medium.com/@takahirom/inside-jetpack-compose-2e971675e55e @mvndy_hd @jossiwolf
54. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted() launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } medium.com/@takahirom/inside-jetpack-compose-2e971675e55e @mvndy_hd @jossiwolf
55. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted() launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } medium.com/@takahirom/inside-jetpack-compose-2e971675e55e @mvndy_hd @jossiwolf
56. #hg2compose private inline fun <T> composing( composition: ControlledComposition, modifiedValues: IdentityArraySet<Any>?, block: () -> T ): T { val snapshot = Snapshot.takeMutableSnapshot( readObserverOf(composition), writeObserverOf(composition, modifiedValues) ) try { return snapshot.enter(block) } finally { applyAndCheck(snapshot) } } Recomposer @mvndy_hd @jossiwolf
57. #hg2compose private inline fun <T> composing( composition: ControlledComposition, modifiedValues: IdentityArraySet<Any>?, block: () -> T ): T { val snapshot = Snapshot.takeMutableSnapshot( readObserverOf(composition), writeObserverOf(composition, modifiedValues) ) try { return snapshot.enter(block) } finally { applyAndCheck(snapshot) } } Recomposer @mvndy_hd @jossiwolf
58. #hg2compose private inline fun <T> composing( composition: ControlledComposition, modifiedValues: IdentityArraySet<Any>?, block: () -> T ): T { val snapshot = Snapshot.takeMutableSnapshot( readObserverOf(composition), writeObserverOf(composition, modifiedValues) ) try { return snapshot.enter(block) } finally { applyAndCheck(snapshot) } } Recomposer @mvndy_hd @jossiwolf
59. #hg2compose private fun readObserverOf( composition: ControlledComposition ): (Any) -> Unit { return { value -> composition.recordReadOf(value) } } Recomposer @mvndy_hd @jossiwolf
60. #hg2compose // Invalidate any recompose scopes that read this value. observations.forEachScopeOf(value) { scope -> if (scope.invalidateForResult(value) == InvalidationResult.IMMINENT) { observationsProcessed.add(value, scope) } } Composition @mvndy_hd @jossiwolf
61. #hg2compose RecomposeScope /** * Invalidate the group which will cause [composition] to request * this scope be recomposed */ fun invalidateForResult(value: Any?): InvalidationResult = composition ?. invalidate(this, value) ?: InvalidationResult.IGNORED @mvndy_hd @jossiwolf
62. @Composable fun HitchhikerApp() { var name = remember { mutableStateOf("Bob") } HelloWorld(greeting = name.value) } @Composable fun HelloWorld(greeting: String) { println("Hello, $greeting!") } #hg2compose S
 N
 A
 P
 S
 H
 O
 T @mvndy_hd @jossiwolf
63. @Composable fun HelloWorld(greeting: String) { Text("Hello, $greeting!") } #hg2compose @mvndy_hd @jossiwolf
64. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer = %composer.startRestartGroup( <> ) val %dirty = %changed if (%changed and 0b1110 === 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 !== 0 || !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ?. updateScope { %composer: Composer?, %force: Int -> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
65. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer = %composer.startRestartGroup( <> ) val %dirty = %changed if (%changed and 0b1110 === 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 !== 0 || !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ?. updateScope { %composer: Composer?, %force: Int -> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
66. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer = %composer.startRestartGroup( <> ) val %dirty = %changed if (%changed and 0b1110 === 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 !== 0 || !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ?. updateScope { %composer: Composer?, %force: Int -> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
67. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer = %composer.startRestartGroup( <> ) val %dirty = %changed if (%changed and 0b1110 === 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 !== 0 || !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ?. updateScope { %composer: Composer?, %force: Int -> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
68. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer = %composer.startRestartGroup( <> ) val %dirty = %changed if (%changed and 0b1110 === 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 !== 0 || !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ?. updateScope { %composer: Composer?, %force: Int -> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
69. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer = %composer.startRestartGroup( <> ) val %dirty = %changed if (%changed and 0b1110 === 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 !== 0 || !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ?. updateScope { %composer: Composer?, %force: Int -> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
70. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer = %composer.startRestartGroup( <> ) val %dirty = %changed if (%changed and 0b1110 === 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 !== 0 || !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ?. updateScope { %composer: Composer?, %force: Int -> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
71. Restartable Groups @Composable fun HelloWorld(greeting: String) { Text("Hello, $greeting!") } @mvndy_hd @jossiwolf
72. @Composable fun HelloWorld(names: List<String>) { names.forEach { name -> key(name) { Text(name) } } } Moveable Groups @mvndy_hd @jossiwolf
73. @Composable fun HelloWorld(name: String) { if (name == "Amanda") { Text("Hello!") else if (name == "Jossi") { Text("Hallo!") } else { Text("Uhm .. hi?") } } Replaceable Groups @mvndy_hd @jossiwolf
74. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Resolution performed on AST tree - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Frontend Backend - Takes optimized IR and performs more analysis, transformations + optimisations speci fi c to target CPU architecture - Multithreading Machine-Dependent Optimisations IR Transform Compiler Analysis Middle End “Lower” - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control- fl ow graph < > Bytecode Target Program FUN BLOCK_BODY CALL VAR IR Unoptimized IR Codegen IR to Bytecode
 Optimized IR FUN BLOCK_BODY CALL VAR IR Backend The Kotlin compiler @mvndy_hd @jossiwolf
75. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Resolution performed on AST tree - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Frontend Backend - Takes optimized IR and performs more analysis, transformations + optimisations speci fi c to target CPU architecture - Multithreading Machine-Dependent Optimisations IR Transformations Compiler Analysis Middle End “Lower” - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control- fl ow graph < > Bytecode Target Program FUN BLOCK_BODY CALL VAR IR Unoptimized IR Codegen IR to Bytecode
 Optimized IR FUN BLOCK_BODY CALL VAR IR Backend Compose compiler plugin Backend - Takes optimized IR and performs more analysis, transformations + optimisations speci fi c to target CPU architecture - Multithreading Machine-Dependent Optimisations IR Transform Compiler Analysis Middle End “Lower” - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control- fl ow graph < > Bytecode Target Program FUN BLOCK_BODY CALL VAR IR Unoptimized IR Codegen IR to Bytecode
 Optimized IR FUN BLOCK_BODY CALL VAR IR Backend @mvndy_hd @jossiwolf
76. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens - Generates tokens to create an AST - PSI lays over AST Semantic Analysis Codegen Semantic Analysis performed on AST - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Kotlin Compiler Frontend @mvndy_hd @jossiwolf
77. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Semantic Analysis performed on AST - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Kotlin Compiler Frontend @mvndy_hd @jossiwolf
78. Element.FUN Element.BLOCK Element.CALL_EXPRESSION Token.L_BRACE Token.R_BRACE Element.REFERENCE_EXPRESSION Element.VALUE_ARGUMENT_LIST Token.IDENTIFIER Token.LPAR Token.RPAR Element.STRING_TEMPLATE Element.LITERAL_STRING_TEMPLATE_ENTRY Token.OPEN_QUOTE Element.REGULAR_STRING_PART Token.OPEN_QUOTE #hg2compose @mvndy_hd @jossiwolf Text("Hello, World!") AST
79. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Semantic Analysis performed on AST - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Kotlin Compiler Frontend @mvndy_hd @jossiwolf
80. KtBlockExpression KtCallExpression KtReferenceExpression KtValueArgument Token.IDENTIFIER Element.REGULAR_STRING_PART #hg2compose @mvndy_hd @jossiwolf Text("Hello, World!") KtValueArgument KtStringTemplateExpression PSI
81. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Semantic Analysis performed on AST - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Kotlin Compiler Frontend @mvndy_hd @jossiwolf
82. #hg2compose func() IR Transform Compiler Analysis Middle End “Lower” - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control- fl ow graph Backend - Takes optimized IR and performs more analysis, transformations + optimisations speci fi c to target CPU architecture - Multithreading func() Optimized IR < > Bytecode Target Program @mvndy_hd @jossiwolf
83. #hg2compose func() IR Transform Compiler Analysis Middle End “Lower” - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control- fl ow graph Backend - Takes optimized IR and performs more analysis, transformations + optimisations speci fi c to target CPU architecture - Multithreading func() Optimized IR < > Bytecode Target Program @mvndy_hd @jossiwolf
84. FUN name:HelloWorld visibility:public modality:FINAL <> (greeting:kotlin.String, $composer:androidx.compose.runtime.Composer?, $changed:kotlin.Int) returnType:kotlin.Unit annotations: Composable VALUE_PARAMETER name:greeting index:0 type:kotlin.String VALUE_PARAMETER name:$composer index:1 type:androidx.compose.runtime.Composer? [assignable] VALUE_PARAMETER name:$changed index:2 type:kotlin.Int BLOCK_BODY BLOCK type=kotlin.Unit origin=null SET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in <root>.HelloWorld' type=kotlin.Unit origin=null CALL 'public abstract fun startRestartGroup (key: kotlin.Int): androidx.compose.runtime.Composer declared in androidx.compose.runtime.Composer' type=androidx.compose.runtime.Composer origin=null $this: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in <root>.HelloWorld' type=androidx.compose.runtime.Composer? origin=null key: CONST Int type=kotlin.Int value=734305942 CALL 'public final fun sourceInformation (composer: androidx.compose.runtime.Composer, sourceInformation: kotlin.String): kotlin.Unit declared in androidx.compose.runtime.ComposerKt' type=kotlin.Unit origin=null composer: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in <root>.HelloWorld' type=androidx.compose.runtime.Composer? origin=null sourceInformation: CONST String type=kotlin.String value="C(HelloWorld):Test.kt" WHEN type=kotlin.Unit origin=IF BRANCH if: WHEN type=kotlin.Boolean origin=OROR BRANCH if: CALL 'public final fun not (): kotlin.Boolean [operator] declared in kotlin.Boolean' type=kotlin.Boolean origin=null $this: CALL 'public final fun EQEQEQ (arg0: kotlin.Any?, arg1: kotlin.Any?): kotlin.Boolean declared in kotlin.internal.ir' type=kotlin.Boolean origin=null arg0: CALL 'public final fun and (other: kotlin.Int): kotlin.Int [infix] declared in kotlin.Int' type=kotlin.Int origin=null $this: GET_VAR '$changed: kotlin.Int declared in <root>.HelloWorld' type=kotlin.Int origin=null other: CONST Int type=kotlin.Int value=1 arg1: CONST Int type=kotlin.Int value=0 then: CONST Boolean type=kotlin.Boolean value=true BRANCH if: CONST Boolean type=kotlin.Boolean value=true then: CALL 'public final fun not (): kotlin.Boolean [operator] declared in kotlin.Boolean' type=kotlin.Boolean origin=null $this: CALL 'public abstract fun <get-skipping> (): kotlin.Boolean declared in androidx.compose.runtime.Composer' type=kotlin.Boolean origin=null $this: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in <root>.HelloWorld' type=androidx.compose.runtime.Composer? origin=null then: BLOCK type=kotlin.Unit origin=null CALL 'public final fun println (message: kotlin.Any?): kotlin.Unit [inline] declared in kotlin.io.ConsoleKt' type=kotlin.Unit origin=null message: CONST String type=kotlin.String value="Hello" BRANCH if: CONST Boolean type=kotlin.Boolean value=true then: CALL 'public abstract fun skipToGroupEnd (): kotlin.Unit declared in androidx.compose.runtime.Composer' type=kotlin.Unit origin=null $this: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in <root>.HelloWorld' type=androidx.compose.runtime.Composer? origin=null BLOCK type=kotlin.Unit origin=null BLOCK type=kotlin.Unit origin=SAFE_CALL VAR IR_TEMPORARY_VARIABLE name:tmp0_safe_receiver type:androidx.compose.runtime.ScopeUpdateScope? [val] CALL 'public abstract fun endRestartGroup (): androidx.compose.runtime.ScopeUpdateScope? declared in androidx.compose.runtime.Composer' type=androidx.compose.runtime.ScopeUpdateScope? origin=null $this: GET_VAR '$composer: androidx.compose.runtime.Composer? [assignable] declared in <root>.HelloWorld' type=androidx.compose.runtime.Composer? origin=null WHEN type=kotlin.Unit origin=IF BRANCH if: CALL 'public final fun EQEQEQ (arg0: kotlin.Any?, arg1: kotlin.Any?): kotlin.Boolean declared in kotlin.internal.ir' type=kotlin.Boolean origin=null arg0: GET_VAR 'val tmp0_safe_receiver: androidx.compose.runtime.ScopeUpdateScope? [val] declared in <root>.HelloWorld' type=androidx.compose.runtime.ScopeUpdateScope? origin=null arg1: CONST Null type=kotlin.Any? value=null then: CONST Null type=kotlin.Any? value=null BRANCH if: CONST Boolean type=kotlin.Boolean value=true then: CALL 'public abstract fun updateScope (block: kotlin.Function2<androidx.compose.runtime.Composer, kotlin.Int, kotlin.Unit>): kotlin.Unit declared in androidx.compose.runtime.ScopeUpdateScope' type=kotlin.Unit origin=null $this: GET_VAR 'val tmp0_safe_receiver: androidx.compose.runtime.ScopeUpdateScope? [val] declared in <root>.HelloWorld' type=androidx.compose.runtime.ScopeUpdateScope? origin=null block: BLOCK type=kotlin.Function2<androidx.compose.runtime.Composer, kotlin.Int, kotlin.Unit> origin=LAMBDA FUN LOCAL_FUNCTION_FOR_LAMBDA name : < anonymous> visibility:local modality:FINAL < > ($composer:androidx.compose.runtime.Composer?, $force:kotlin.Int) returnType:kotlin.Unit VALUE_PARAMETER name:$composer index:0 type:androidx.compose.runtime.Composer? VALUE_PARAMETER name:$force index:1 type:kotlin.Int BLOCK_BODY RETURN type=kotlin.Nothing from='local final fun <anonymous> ($composer: androidx.compose.runtime.Composer?, $force: kotlin.Int): kotlin.Unit declared in <root>.HelloWorld' CALL 'public final fun HelloWorld (greeting: kotlin.String, $composer: androidx.compose.runtime.Composer?, $changed: kotlin.Int): kotlin.Unit declared in <root>' type=kotlin.Unit origin=null greeting: GET_VAR 'greeting: kotlin.String declared in <root>.HelloWorld' type=kotlin.String origin=null $composer: GET_VAR '$composer: androidx.compose.runtime.Composer? declared in <root>.HelloWorld.<anonymous>' type=androidx.compose.runtime.Composer? origin=null $changed: CALL 'public final fun or (other: kotlin.Int): kotlin.Int [infix] declared in kotlin.Int' type=kotlin.Int origin=null $this: GET_VAR '$changed: kotlin.Int declared in <root>.HelloWorld' type=kotlin.Int origin=null other: CONST Int type=kotlin.Int value=1 @mvndy_hd @jossiwolf
85. @Composable fun HelloWorld() { Text("Hello World!") } #hg2compose @mvndy_hd @jossiwolf
86. @Composable fun HelloWorld(%composer: Composer?, %changed: Int) { %composer = %composer.startRestartGroup( <> ) if (%changed !== 0 || !%composer.skipping) { Text("Hello World”) } else { %composer.skipToGroupEnd() } %composer.endRestartGroup()? .updateScope { %composer: Composer?, %force: Int -> HelloWorld(%composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
87. A Composer connects Composables to Runtime, keeps track of groups that are used to build the Slot Table and positions it. #hg2compose @mvndy_hd @jossiwolf
88. #hg2compose var name by remember { mutableStateOf("Bob") } @Composable fun Greeting(greeting: String) { Text("Hello, $greeting!") } Greeting(name) name = "Jossi" // Hello, Bob! // Hello, Jossi! Slot Table by Example @mvndy_hd @jossiwolf
89. #hg2compose EMPTY EMPTY Group(4) State(“Bob”) var name by remember { mutableStateOf("Bob") } Slot Table by Example EMPTY EMPTY EMPTY EMPTY EMPTY @mvndy_hd @jossiwolf
90. #hg2compose Group(4) State(“Bob”) Group(5) var name by remember { mutableStateOf("Bob") } Slot Table by Example EMPTY EMPTY EMPTY EMPTY EMPTY EMPTY @Composable fun Greeting(greeting: String) { } Greeting(name) @mvndy_hd @jossiwolf
91. #hg2compose EMPTY EMPTY Group(4) State(“Bob”) Group(5) Group(6) Group(7) Group(8) “Hello, Bob!” var name by remember { mutableStateOf("Bob") } Slot Table by Example @Composable fun Greeting(greeting: String) { Text("Hello, $greeting!”) } Greeting(name) @mvndy_hd @jossiwolf
92. #hg2compose EMPTY EMPTY Group(4) State(“Bob”) Group(5) Group(6) Group(7) Group(8) “Hello, Jossi!” var name by remember { mutableStateOf("Bob") } @Composable fun Greeting(greeting: String) { Text("Hello, $greeting!”) } Greeting(name) name = "Jossi" Slot Table by Example @mvndy_hd @jossiwolf
93. UI #hg2compose @mvndy_hd @jossiwolf
94. #hg2compose Text(text = name) Layout Layout name by remember { mutableStateOf("Bob") } Bob @mvndy_hd @jossiwolf
95. #hg2compose @mvndy_hd @jossiwolf interface Applier<N> { val current: N fun onBeginChanges() {} fun onEndChanges() {} fun down(node: N) fun up() fun insertTopDown(index: Int, instance: N) fun insertBottomUp(index: Int, instance: N) fun remove(index: Int, count: Int) fun move(from: Int, to: Int, count: Int) fun clear() }
96. #hg2compose Text(text = name) Layout Layout @mvndy_hd @jossiwolf LayoutNode LayoutNode LayoutNode
97. 🏃Efficient Codegen Tips🏃 #hg2compose The point of Compose transformations is to reduce as many groups + group executions as possible - but you can help too! @mvndy_hd @jossiwolf
98. #hg2compose Use key to make recomposition of lists cheaper! This helps Compose generate moveable groups, avoiding recomposition i.e. when the position of a list item changes. @mvndy_hd @jossiwolf
99. #hg2compose Make sure to read state values at the lowest node of the tree possible You only want to recompose where you actually need the state :) @mvndy_hd @jossiwolf
100. • Jorge Castillo for writing "Compose Internals" • Leland Richardson for sitting down with us and patiently answering our questions! #hg2compose Thank you!!! @mvndy_hd @jossiwolf
101. #hg2compose linktr.ee/hg2compose @mvndy_hd @jossiwolf
