The Pregel Programming Model with Spark GraphX

GraphX is the API for distributed graph processing of Apache Spark. In this talk we'll introduce the Pregel programming model and we'll focus on how to write graph algorithms with this paradigm.

Transcript

1. The Pregel Programming Model with Spark GraphX
2. Agenda - GraphX Introduction - Pregel programming model - Code examples The main focus will be on the programming model
3. GraphX is a graph processing system built on top of Apache Spark - property graph representation - based on RDDs - user defined partitioning on RDDs
4. GraphX / Spark software stack
5. Pregel Programming Model https://kowshik.github.io/JPregel/pregel_paper.pdf - based on vertices - messages from/to neighbours - bounded in supersteps - status (active / inactive)
6. Pregel Sample: finding the maximum value
7. GraphX implementation of Pregel Uses three functions: - vprog computes the new vertex value - sendMsg decides to whom send the new value - mergeMsg merges incoming values
8. GraphX communication diagram
9. graph.pregel( initialMsg = Int.MinValue, maxIterations = Int.MaxValue, activeDirection = EdgeDirection.Out )( // vprog (vertexId: Long, currentVertexAttr: Int, newVertexAttr: Int) => if (newVertexAttr > currentVertexAttr) newVertexAttr else currentVertexAttr, // sendMsg (edgeTriplet: EdgeTriplet[Int, Int]) => { if (edgeTriplet.srcAttr > edgeTriplet.dstAttr) Iterator( (edgeTriplet.dstId, edgeTriplet.srcAttr) ) else Iterator.empty }, // mergeMsg (attribute1: Int, attribute2: Int) => if (attribute1 > attribute2) attribute1 else attribute2 ) Max Value implementation
10. Graph initial state Node [1]: 3 Node [2]: 6 Node [3]: 2 Node [4]: 1 Graph final state Node [1]: 6 Node [2]: 6 Node [3]: 6 Node [4]: 6 Max value of the graph is 6. Max Value implementation Results:
11. Dijkstra's algorithm Unvisited nodes: - Baltimore - Detroit - Chicago - NewYork - Philadelphia
12. Dijkstra's algorithm Unvisited nodes: - Baltimore - Detroit - Chicago - NewYork - Philadelphia
13. Dijkstra's algorithm Unvisited nodes: - Baltimore - Detroit - Chicago - NewYork - Philadelphia
14. Dijkstra's algorithm Unvisited nodes: - Baltimore - Detroit - Chicago - NewYork - Philadelphia
15. Dijkstra's algorithm Unvisited nodes: - Detroit - Chicago - NewYork - Philadelphia
16. Dijkstra's algorithm Unvisited nodes: - Detroit - Chicago - NewYork - Philadelphia
17. Dijkstra's algorithm Unvisited nodes: - Detroit - Chicago - NewYork - Philadelphia
18. Dijkstra's algorithm Unvisited nodes: - Chicago - NewYork - Philadelphia
19. Dijkstra's algorithm Unvisited nodes: - Chicago - NewYork - Philadelphia
20. Dijkstra's algorithm Unvisited nodes: - Chicago - Philadelphia
21. Dijkstra's algorithm Unvisited nodes: - Chicago - Philadelphia
22. Dijkstra's algorithm Unvisited nodes: - Chicago
23. Dijkstra's algorithm Unvisited nodes:
24. type VertexId = scala.Long case class City( name: String, id: VertexId ) case class VertexAttribute( cityName: String, distance: Double, path: List[City] ) Dijkstra's algorithm implementation Types definitions:
25. val shortestPathGraph = initialGraph.pregel( initialMsg = VertexAttribute( "", Double.PositiveInfinity, List[City]() ), maxIterations = Int.MaxValue, activeDirection = EdgeDirection.Out )( vprog, sendMsg, mergeMsg ) Dijkstra's algorithm implementation
26. val vprog = ( vertexId: VertexId, currentVertexAttr: VertexAttribute, newVertexAttr: VertexAttribute ) => if (currentVertexAttr.distance <= newVertexAttr.distance) { currentVertexAttr else newVertexAttr } val mergeMsg = ( attribute1: VertexAttribute, attribute2: VertexAttribute ) => if (attribute1.distance < attribute2.distance) { attribute1 else attribute2 } Dijkstra's algorithm implementation
27. val sendMsg = (edgeTriplet: EdgeTriplet[VertexAttribute, Double]) => { if (edgeTriplet.srcAttr.distance < (edgeTriplet.dstAttr.distance - edgeTriplet.attr)) { Iterator( ( edgeTriplet.dstId, new VertexAttribute( edgeTriplet.dstAttr.cityName, edgeTriplet.srcAttr.distance + edgeTriplet.attr, edgeTriplet.srcAttr.path :+ new City( edgeTriplet.dstAttr.cityName, edgeTriplet.dstId ) ) ) ) } else Iterator.empty } Dijkstra's algorithm implementation
28. Going from Washington to Chicago has a distance of 105.0 km. Path is: Washington [1] => Baltimore [2] => Detroit [3] => NewYork [5] => Chicago [4] Going from Washington to Washington has a distance of 0.0 km. Path is: Washington [1] Going from Washington to Philadelphia has a distance of 91.0 km. Path is: Washington [1] => Baltimore[2] => Detroit[3] => NewYork[5] => Philadelphia[6] Going from Washington to Detroit has a distance of 62.0 km. Path is: Washington [1] => Baltimore [2] => Detroit [3] Going from Washington to NewYork has a distance of 76.0 km. Path is: Washington [1] => Baltimore [2] => Detroit [3] => NewYork [5] Going from Washington to Baltimore has a distance of 27.0 km. Path is: Washington [1] => Baltimore [2] Dijkstra's algorithm implementation Results:
29. Questions & Answers
30. Thanks! The code is available at https://github.com/andreaiacono/TalkGraphX
