Performance Tools on Android

The Android ecosystem has a lot of tools to help us out when it comes to development. We all use Android Studio, gradle and adb, for instance. We need to, as these are essential tools for building our products. But what about the tools that help us diagnose problems in our apps? This session is all about asking 2 very common questions:

Why is my app stuttering or dropping below 60fps?

Why are my users telling me that my app drains their batteries?

Most of the times solving a problem means asking the right questions in order to find the right answers. So starting from these 2 questions, with concrete problem-code examples we will be using tools from Google to find our answers.

I don't want it to be a secret, so I'm telling you that the tools we will be using the most will be Traceview and Battery Historian. We will also be looking at Profiling GPU Rendering and Debugging Overdraw.

I know that these tools might look a bit scary or dull but I promise to keep it simple so that you walk away with information you can use at work the next day.

Presented at:
- Droidcon Romania 2016
- Codecamp Cluj Spring 2016

Transcript

1. Performance Tools
   Andrei Diaconu


   View Slide

2. Andrei Diaconu


   View Slide

3. Andrei Diaconu


   View Slide

4. Andrei Diaconu


   View Slide

5. Andrei Diaconu
   • Cofounder of Android Iași


   View Slide

6. Andrei Diaconu
   • Cofounder of Android Iași
   • 5 years of Android


   View Slide

7. Andrei Diaconu
   • Cofounder of Android Iași
   • 5 years of Android
   • Trainer & Speaker


   View Slide

8. View Slide

9. Why is my app dropping below 60fps?


   View Slide

10. Why is my app dropping below 60fps?
    Why is my app draining the battery?


    View Slide

11. Why is my app dropping below 60fps?


    View Slide

12. Why is my app dropping below 60fps?


    View Slide

13. Why is my app dropping below 60fps?
    • Simple list


    View Slide

14. Why is my app dropping below 60fps?
    • Simple list
    • Items have some text


    View Slide

15. Why is my app dropping below 60fps?
    • Simple list
    • Items have some text


    View Slide

16. Why is my app dropping below 60fps?
    • Simple list
    • Items have some text
    • Scroll is not smooth


    View Slide

17. • Scroll is not smooth


    View Slide

18. • Scroll is not smooth
    Why?


    View Slide

19. • Scroll is not smooth
    Why?
    Can we make sure?


    View Slide

20. • Scroll is not smooth
    Why?
    Can we make sure?


    View Slide

21. Can we make sure?


    View Slide

22. Can we make sure?


    View Slide

23. Can we make sure?


    View Slide

24. Can we make sure?


    View Slide

25. View Slide

26. Frames


    View Slide

27. Frames
    Time


    View Slide

28. Frames
    16ms line
    Time


    View Slide

29. Frames
    16ms line
    Time
    Choreographer: Skipped 34 frames! The application
    may be doing too much work on its main thread.


    View Slide

30. View Slide

31. Traceview


    View Slide

32. Traceview
    • Measure how long each method takes to execute


    View Slide

33. Traceview
    • Measure how long each method takes to execute
    • Analyse measurements using Traceview


    View Slide

34. Traceview
    • Measure how long each method takes to execute


    View Slide

35. Traceview
    //Start in OnResume

    Debug.startMethodTracing("bad_list");
    • Measure how long each method takes to execute


    View Slide

36. Traceview
    //Start in OnResume

    Debug.startMethodTracing("bad_list");
    //Stop in OnPause

    Debug.stopMethodTracing();
    • Measure how long each method takes to execute


    View Slide

37. Traceview
    //Start in OnResume

    Debug.startMethodTracing("bad_list");
    //Stop in OnPause

    Debug.stopMethodTracing();
    //Grab using adb

    adb pull
    • Measure how long each method takes to execute


    View Slide

38. Traceview
    //Start in OnResume

    Debug.startMethodTracing("bad_list");
    //Stop in OnPause

    Debug.stopMethodTracing();
    //Grab using adb

    adb pull
    • Measure how long each method takes to execute
    //Grab using adb

    adb pull /sdcard/bad_list.trace bad_list.trace


    View Slide

39. Traceview
    //Start in OnResume

    Debug.startMethodTracing("bad_list");
    //Stop in OnPause

    Debug.stopMethodTracing();
    //Grab using adb

    adb pull
    • Measure how long each method takes to execute
    //Needs permission
    WRITE_EXTERNAL_STORAGE
    //Grab using adb

    adb pull /sdcard/bad_list.trace bad_list.trace


    View Slide

40. Traceview
    //Start in OnResume

    Debug.startMethodTracing("bad_list");
    //Stop in OnPause

    Debug.stopMethodTracing();
    //Grab using adb

    adb pull
    • Measure how long each method takes to execute
    //Needs permission
    WRITE_EXTERNAL_STORAGE
    //Grab using adb

    adb pull /sdcard/bad_list.trace bad_list.trace


    View Slide

41. Traceview
    • Measure how long each method takes to execute


    View Slide

42. Traceview
    • Measure how long each method takes to execute


    View Slide

43. Traceview
    • Measure how long each method takes to execute
    • Analyse measurements using Traceview
    • Analyse measurements using Traceview


    View Slide

44. Traceview
    • Measure how long each method takes to execute
    • Analyse measurements using Traceview
    • Analyse measurements using Traceview


    View Slide

45. Traceview
    • Measure how long each method takes to execute
    • Analyse measurements using Traceview
    • Analyse measurements using Traceview


    View Slide

46. Traceview
    • Measure how long each method takes to execute
    • Analyse measurements using Traceview
    • Analyse measurements using Traceview


    View Slide

47. View Slide

48. View Slide

49. View Slide

50. View Slide

51. View Slide

52. View Slide

53. ~ 2 seconds


    View Slide

54. ~ 200 ms


    View Slide

55. Adaptor -> getView()
    ~ 200 ms


    View Slide

56. View Slide

57. inflate()


    View Slide

58. inflate() 4 x Html.fromHtml()


    View Slide

59. @Override

    public View getView(int position, View convertView, ViewGroup parent) {


    View view = LayoutInflater.from(parent.getContext())
    .inflate(R.layout.item_jumpy_list, parent, false);



    TextView text1 = (TextView) view.findViewById(R.id.item_text1);

    TextView text2 = (TextView) view.findViewById(R.id.item_text2);

    TextView text3 = (TextView) view.findViewById(R.id.item_text3);

    TextView text4 = (TextView) view.findViewById(R.id.item_text4);



    String string1 = parent.getContext().getString(R.string.item_number_x, position);

    String string2 = parent.getContext().getString(R.string.item_description);

    String string3 = parent.getContext().getString(R.string.item_details);

    String string4 = parent.getContext().getString(R.string.item_related);



    text1.setText(Html.fromHtml(string1));

    text2.setText(Html.fromHtml(string2));

    text3.setText(Html.fromHtml(string3));

    text4.setText(Html.fromHtml(string4));


    return view;

    }


    View Slide

60. @Override

    public View getView(int position, View convertView, ViewGroup parent) {


    View view = LayoutInflater.from(parent.getContext())
    .inflate(R.layout.item_jumpy_list, parent, false);



    TextView text1 = (TextView) view.findViewById(R.id.item_text1);

    TextView text2 = (TextView) view.findViewById(R.id.item_text2);

    TextView text3 = (TextView) view.findViewById(R.id.item_text3);

    TextView text4 = (TextView) view.findViewById(R.id.item_text4);



    String string1 = parent.getContext().getString(R.string.item_number_x, position);

    String string2 = parent.getContext().getString(R.string.item_description);

    String string3 = parent.getContext().getString(R.string.item_details);

    String string4 = parent.getContext().getString(R.string.item_related);



    text1.setText(Html.fromHtml(string1));

    text2.setText(Html.fromHtml(string2));

    text3.setText(Html.fromHtml(string3));

    text4.setText(Html.fromHtml(string4));


    return view;

    }


    View Slide

61. @Override

    public View getView(int position, View convertView, ViewGroup parent) {


    View view = LayoutInflater.from(parent.getContext())
    .inflate(R.layout.item_jumpy_list, parent, false);



    TextView text1 = (TextView) view.findViewById(R.id.item_text1);

    TextView text2 = (TextView) view.findViewById(R.id.item_text2);

    TextView text3 = (TextView) view.findViewById(R.id.item_text3);

    TextView text4 = (TextView) view.findViewById(R.id.item_text4);



    String string1 = parent.getContext().getString(R.string.item_number_x, position);

    String string2 = parent.getContext().getString(R.string.item_description);

    String string3 = parent.getContext().getString(R.string.item_details);

    String string4 = parent.getContext().getString(R.string.item_related);



    text1.setText(Html.fromHtml(string1));

    text2.setText(Html.fromHtml(string2));

    text3.setText(Html.fromHtml(string3));

    text4.setText(Html.fromHtml(string4));


    return view;

    }


    View Slide

62. @Override

    public View getView(int position, View convertView, ViewGroup parent) {


    View view = LayoutInflater.from(parent.getContext())
    .inflate(R.layout.item_jumpy_list, parent, false);



    TextView text1 = (TextView) view.findViewById(R.id.item_text1);

    TextView text2 = (TextView) view.findViewById(R.id.item_text2);

    TextView text3 = (TextView) view.findViewById(R.id.item_text3);

    TextView text4 = (TextView) view.findViewById(R.id.item_text4);



    String string1 = parent.getContext().getString(R.string.item_number_x, position);

    String string2 = parent.getContext().getString(R.string.item_description);

    String string3 = parent.getContext().getString(R.string.item_details);

    String string4 = parent.getContext().getString(R.string.item_related);



    text1.setText(Html.fromHtml(string1));

    text2.setText(Html.fromHtml(string2));

    text3.setText(Html.fromHtml(string3));

    text4.setText(Html.fromHtml(string4));


    return view;

    }


    View Slide

63. @Override

    public View getView(int position, View convertView, ViewGroup parent) {


    No recycling



    No View Holder





    Html.fromHtml is slow


    return view;

    }


    View Slide

64. View Slide

65. But 200ms?
    Isn't this a bit much?


    View Slide

66. But 200ms?
    Isn't this a bit much?
    Method tracking has a big impact itself


    View Slide

67. View Slide

68. Systrace
    measure at kernel level


    View Slide

69. Systrace


    View Slide

70. Systrace


    View Slide

71. Systrace


    View Slide

72. Systrace


    View Slide

73. Systrace
    It will run for 5 seconds
    Hit Ok and scroll the list


    View Slide

74. View Slide

75. Alert: Inflation during ListView recycling
    Time spent: 103.545 ms
    ListView items inflated: 20


    View Slide

76. View Slide

77. View Slide

78. View Slide

79. View Slide

80. View Slide

81. @Override

    public View getView(int position, View convertView, ViewGroup parent) {



    View view = LayoutInflater.from(parent.getContext())
    .inflate(R.layout.item_jumpy_list, parent, false);







    TextView text1 = (TextView) view.findViewById(R.id.item_text1);

    TextView text2 = (TextView) view.findViewById(R.id.item_text2);

    TextView text3 = (TextView) view.findViewById(R.id.item_text3);

    TextView text4 = (TextView) view.findViewById(R.id.item_text4);





    String string1 = parent.getContext().getString(R.string.item_number_x, position);

    String string2 = parent.getContext().getString(R.string.item_description);

    String string3 = parent.getContext().getString(R.string.item_details);

    String string4 = parent.getContext().getString(R.string.item_related);





    text1.setText(Html.fromHtml(string1));

    text2.setText(Html.fromHtml(string2));

    text3.setText(Html.fromHtml(string3));

    text4.setText(Html.fromHtml(string4));





    return view;

    }


    View Slide

82. @Override

    public View getView(int position, View convertView, ViewGroup parent) {

    Trace.beginSection("inflating");

    View view = LayoutInflater.from(parent.getContext())
    .inflate(R.layout.item_jumpy_list, parent, false);

    Trace.endSection();



    Trace.beginSection("noViewHolder");

    TextView text1 = (TextView) view.findViewById(R.id.item_text1);

    TextView text2 = (TextView) view.findViewById(R.id.item_text2);

    TextView text3 = (TextView) view.findViewById(R.id.item_text3);

    TextView text4 = (TextView) view.findViewById(R.id.item_text4);

    Trace.endSection();



    String string1 = parent.getContext().getString(R.string.item_number_x, position);

    String string2 = parent.getContext().getString(R.string.item_description);

    String string3 = parent.getContext().getString(R.string.item_details);

    String string4 = parent.getContext().getString(R.string.item_related);



    Trace.beginSection("fromHtml");

    text1.setText(Html.fromHtml(string1));

    text2.setText(Html.fromHtml(string2));

    text3.setText(Html.fromHtml(string3));

    text4.setText(Html.fromHtml(string4));

    Trace.endSection();



    return view;

    }


    View Slide

83. View Slide

84. View Slide

85. inflating


    View Slide

86. inflating noViewHolder


    View Slide

87. inflating noViewHolder
    fromHtml


    View Slide

88. View Slide

89. • obtainView = ~5ms


    View Slide

90. • obtainView = ~5ms
    • doFrame = ~20 * obtainView


    View Slide

91. • obtainView = ~5ms
    • doFrame = ~20 * obtainView
    • each frame = ~100ms


    View Slide

92. • obtainView = ~5ms
    • doFrame = ~20 * obtainView
    • each frame = ~100ms
    Alert: Inflation during ListView recycling
    Time spent: 103.545 ms
    ListView items inflated: 20


    View Slide

93. View Slide

94. Why is my app dropping below 60fps?


    View Slide

95. Why is my app dropping below 60fps?
    Why is my app draining the battery?


    View Slide

96. Why is my app draining the battery?


    View Slide

97. Why is my app draining the battery?
    What is a wake lock?


    View Slide

98. Why is my app draining the battery?


    View Slide

99. Why is my app draining the battery?
    Battery Historian 2.0


    View Slide

100. Why is my app draining the battery?
     Battery Historian 2.0


     View Slide

101. Why is my app draining the battery?
     Battery Historian 2.0
     adb bugreport > bugreport.txt


     View Slide

102. Why is my app draining the battery?
     Battery Historian 2.0
     adb bugreport > bugreport.txt
     go run battery-historian.go


     View Slide

103. Why is my app draining the battery?
     Battery Historian 2.0
     adb bugreport > bugreport.txt
     go run battery-historian.go
     open http://127.0.0.1:9999


     View Slide

104. View Slide

105. View Slide

106. View Slide

107. View Slide

108. View Slide

109. View Slide

110. View Slide

111. View Slide

112. View Slide

113. View Slide

114. View Slide

115. View Slide

116. View Slide

117. View Slide

118. View Slide

119. View Slide

120. public static class UselessWorker {

     Runnable uselessWorker = new Runnable() {

     @Override

     public void run() {

     PowerManager pm = (PowerManager) BadApplication.instance

     .getSystemService(Context.POWER_SERVICE);

     PowerManager.WakeLock wakeLock =

     pm.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK, "cool wakelock tag");

     wakeLock.acquire();



     //Some useless, but hard work



     wakeLock.release();

     try {

     Thread.sleep(45 * 1000);

     } catch (InterruptedException e) {

     e.printStackTrace();

     } finally {

     work();

     }

     }

     };



     private void work() {

     new Thread(uselessWorker, "cool thread name").start();

     }

     }
     public static class UselessWorker {

     Runnable uselessWorker = new Runnable() {

     @Override

     public void run() {

     PowerManager pm = (PowerManager) BadApplication.instance

     .getSystemService(Context.POWER_SERVICE);

     PowerManager.WakeLock wakeLock =

     pm.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK, "cool wakelock tag");

     wakeLock.acquire();



     //Some useless, but hard work



     wakeLock.release();

     try {

     Thread.sleep(45 * 1000);

     } catch (InterruptedException e) {

     e.printStackTrace();

     } finally {

     work();

     }

     }

     };



     private void work() {

     new Thread(uselessWorker, "cool thread name").start();

     }

     }


     View Slide

121. public static class UselessWorker {

     Runnable uselessWorker = new Runnable() {

     @Override

     public void run() {

     PowerManager pm = (PowerManager) BadApplication.instance

     .getSystemService(Context.POWER_SERVICE);

     PowerManager.WakeLock wakeLock =

     pm.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK, "cool wakelock tag");

     wakeLock.acquire();



     //Some useless, but hard work



     wakeLock.release();

     try {

     Thread.sleep(45 * 1000);

     } catch (InterruptedException e) {

     e.printStackTrace();

     } finally {

     work();

     }

     }

     };



     private void work() {

     new Thread(uselessWorker, "cool thread name").start();

     }

     }
     public static class UselessWorker {

     Runnable uselessWorker = new Runnable() {

     @Override

     public void run() {

     PowerManager pm = (PowerManager) BadApplication.instance

     .getSystemService(Context.POWER_SERVICE);

     PowerManager.WakeLock wakeLock =

     pm.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK, "cool wakelock tag");

     wakeLock.acquire();



     //Some useless, but hard work



     wakeLock.release();

     try {

     Thread.sleep(45 * 1000);

     } catch (InterruptedException e) {

     e.printStackTrace();

     } finally {

     work();

     }

     }

     };



     private void work() {

     new Thread(uselessWorker, "cool thread name").start();

     }

     }


     View Slide

122. public static class UselessWorker {

     Runnable uselessWorker = new Runnable() {

     @Override

     public void run() {

     PowerManager pm = (PowerManager) BadApplication.instance

     .getSystemService(Context.POWER_SERVICE);

     PowerManager.WakeLock wakeLock =

     pm.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK, "cool wakelock tag");

     wakeLock.acquire();



     //Some useless, but hard work



     wakeLock.release();

     try {

     Thread.sleep(45 * 1000);

     } catch (InterruptedException e) {

     e.printStackTrace();

     } finally {

     work();

     }

     }

     };



     private void work() {

     new Thread(uselessWorker, "cool thread name").start();

     }

     }
     public static class UselessWorker {

     Runnable uselessWorker = new Runnable() {

     @Override

     public void run() {

     PowerManager pm = (PowerManager) BadApplication.instance

     .getSystemService(Context.POWER_SERVICE);

     PowerManager.WakeLock wakeLock =

     pm.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK, "cool wakelock tag");

     wakeLock.acquire();



     //Some useless, but hard work



     wakeLock.release();

     try {

     Thread.sleep(45 * 1000);

     } catch (InterruptedException e) {

     e.printStackTrace();

     } finally {

     work();

     }

     }

     };



     private void work() {

     new Thread(uselessWorker, "cool thread name").start();

     }

     }


     View Slide

123. public static class UselessWorker {

     Runnable uselessWorker = new Runnable() {

     @Override

     public void run() {

     PowerManager pm = (PowerManager) BadApplication.instance

     .getSystemService(Context.POWER_SERVICE);

     PowerManager.WakeLock wakeLock =

     pm.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK, "cool wakelock tag");

     wakeLock.acquire();



     //Some useless, but hard work



     wakeLock.release();

     try {

     Thread.sleep(45 * 1000);

     } catch (InterruptedException e) {

     e.printStackTrace();

     } finally {

     work();

     }

     }

     };



     private void work() {

     new Thread(uselessWorker, "cool thread name").start();

     }

     }
     public static class UselessWorker {

     Runnable uselessWorker = new Runnable() {

     @Override

     public void run() {

     PowerManager pm = (PowerManager) BadApplication.instance

     .getSystemService(Context.POWER_SERVICE);

     PowerManager.WakeLock wakeLock =

     pm.newWakeLock(PowerManager.PARTIAL_WAKE_LOCK, "cool wakelock tag");

     wakeLock.acquire();



     //Some useless, but hard work



     wakeLock.release();

     try {

     Thread.sleep(45 * 1000);

     } catch (InterruptedException e) {

     e.printStackTrace();

     } finally {

     work();

     }

     }

     };



     private void work() {

     new Thread(uselessWorker, "cool thread name").start();

     }

     }


     View Slide

124. ?
     ?
     Questions


     View Slide
