Django and this thing called Channels
Andrew Godwin
March 09, 2016
Programming
1
480
Django and this thing called Channels
A talk I gave at Python SF Meetup, March 2016.
Andrew Godwin
March 09, 2016
Tweet
Share
More Decks by Andrew Godwin
See All by Andrew Godwin
Writing Maintainable Software At Scale
andrewgodwin
0
190
A Newcomer's Guide To Airflow's Architecture
andrewgodwin
0
150
Async, Python, and the Future
andrewgodwin
2
440
How To Break Django: With Async
andrewgodwin
1
420
Taking Django's ORM Async
andrewgodwin
0
400
The Long Road To Asynchrony
andrewgodwin
0
420
The Scientist & The Engineer
andrewgodwin
1
440
Pioneering Real-Time
andrewgodwin
0
190
Just Add Await: Retrofitting Async Into Django
andrewgodwin
2
1.2k
Other Decks in Programming
See All in Programming
コンピュータビジョンセミナー2 / computer_vision_seminar_libSGM
fixstars
0
310
花き業界のサプライチェーンを繋げるプロダクト開発の進め方
userlike1
0
150
OSC大阪 パスワード認証は人類には早すぎる ~ IDaaSを使ったソーシャルログインのすすめ ~
authyasan
6
1.2k
Azure Functionsをサクッと開発、サクッとデプロイ/vscodeconf2023-baba
nina01
1
330
爆速の日経電子版開発の今
shinyaigeek
1
530
23年のJavaトレンドは?Quarkusで理解するコンテナネイティブJava
tatsuya1bm
1
120
Git Rebase
bkuhlmann
10
1.2k
Gradle build: The time is now
nonews
1
440
ポケモンで学ぶiOS 16弾丸ツアー 🚅
giginet
PRO
1
610
Showkase、Paparazziを用いたビジュアルリグレッションテストの導入にチャレンジした話 / MoT TechTalk #15
mot_techtalk
0
100
(新米)エンジニアリングマネージャーのしごと #RSGT2023
murabayashi
9
5.6k
T3 Stack and TypeScript ecosystem
quramy
3
720
Featured
See All Featured
Understanding Cognitive Biases in Performance Measurement
bluesmoon
2
390
Navigating Team Friction
lara
176
12k
Designing Dashboards & Data Visualisations in Web Apps
destraynor
224
50k
Helping Users Find Their Own Way: Creating Modern Search Experiences
danielanewman
10
1.3k
The Art of Programming - Codeland 2020
erikaheidi
35
11k
A Modern Web Designer's Workflow
chriscoyier
689
180k
ReactJS: Keep Simple. Everything can be a component!
pedronauck
657
120k
Building Adaptive Systems
keathley
27
1.3k
Learning to Love Humans: Emotional Interface Design
aarron
263
38k
From Idea to $5000 a Month in 5 Months
shpigford
374
44k
Teambox: Starting and Learning
jrom
124
7.9k
XXLCSS - How to scale CSS and keep your sanity
sugarenia
236
1.1M
Transcript
Andrew Godwin @andrewgodwin DJANGO and this thing called CHANNELS
Andrew Godwin Hi, I'm Django core developer Senior Software Engineer
at Likes complaining about networking
The Problem First: The Solution Then: The Future Finally:
The Problem WSGI ain't so bad
Browser HTTP Webserver Django WSGI View Handler
Browser WebSocket Webserver Django ???? ??? ????
Very hard to deadlock/cause errors Seems "Django-ish" DESIGN GOALS Scales
decently All works inside runserver
Browser WebSocket Webserver Django Channels Consumers Routing
Browser HTTP Webserver Django Channels Consumer Ch. Routing View URL
dispatch
The Solution A Series Of Channels
An ordered, first-in-first-out, at-most once queue with expiry and delivery
to only one listening consumer. Identified by a unique unicode name. WHAT IS A CHANNEL?
Producers Consumers Channel
There are standard channel names: STANDARDS Clients have unique response
channels: http.request websocket.connect websocket.receive !http.response.jaS4kSDj !websocket.send.Qwek120d
There are standard message formats: STANDARDS - HTTP request -
WebSocket close - HTTP response chunk But you can make your own channel names and formats too.
But how do we do this without making Django asynchronous?
Channels are network-transparent, and protocol termination is separate from business
logic process 1 process 2 protocol server worker server channels client socket
Async/cooperative code, but none of yours process 1 process 2
protocol server worker server channels client socket Your logic running synchronously worker server
For runserver, we run them as threads thread 1 thread
2 protocol server worker server channels client socket worker server thread 3 process 1
A view receives a request and sends a single response.
WHAT IS A CONSUMER? A consumer receives a message and sends zero or more messages.
EXAMPLE This echoes messages back: def ws_message(message): text = message.content['text']
reply = "You said: %s" % text message.reply_channel.send({ 'text': reply, })
EXAMPLE This notifies clients of new blog posts: def newpost(message):
for client in client_list: Channel(client).send({ 'text': message.content['id'], })
EXAMPLE But Channels has a better solution for that: #
Channel "websocket.connect" def connect(message): Group('liveblog').add( message.reply_channel) # Channel "new-liveblog" def newpost(message): Group('liveblog').send({ 'text': message.content['id'], })
EXAMPLE And you can send to channels from anywhere: class
LiveblogPost(models.Model): ... def save(self): ... Channel('new-liveblog').send({ 'id': str(self.id), })
EXAMPLE You can offload processing from views: def upload_image(request): ...
Channel('thumbnail').send({ 'id': str(image.id), }) return render(...)
EXAMPLE All the routing is set up like URLs: from
.consumers import ws_connect routing = { 'websocket.connect': ws_connect, 'websocket.receive': 'a.b.receive', 'thumbnail': 'images.consumers.thumb', }
EXAMPLE The HTTP channel just goes to the view system
by default. routing = { # This is actually the default 'http.request': 'channels.asgi.ViewConsumer', }
The Future What does it all mean?
WSGI
WSGI 2?
ASGI channels.readthedocs.org/en/latest/asgi.html
channel_layer.send(channel, message) channel_layer.receive_many(channels) + message standards + extensions (groups, stats)
Daphne HTTP/WebSocket ASGI server asgiref Memory layer, conformance suite, WSGI
adapters asgi_redis Redis-based channel layer
Raw ASGI app example: while True: channel, message = layer.receive_many(
["http.request"], block = True, ) if channel is None: continue layer.send( message['reply_channel'], { 'content': 'Hello World!', 'status': 200, } )
Django 1.10
Django 1.10 And 1.8, 1.9 as a third-party app
It's all optional. No need to change anything if you
don't want to use channels.
pip install channels channels.readthedocs.org
Thanks. Andrew Godwin @andrewgodwin
