  1. CDI Best Practices with
    Real-Life Examples
    Ahmad Gohar
    Software Architect & Technical Team Lead
    IBM Experienced IT-Specialist
    Client Innovation Center (CIC), IBM
    TUT3287

    View Slide

  2. View Slide

  3. Gohar , Ahmad Nabil
    • Software Architect & Technical Team Lead (9Y.) | CIC, IBM.
    • IBM/Open Group Certified Experienced IT Specialist.
    • M.Sc. in Information System, FCI, Egypt.
    • MIBA in Global Management, ESLSCA, France.
    • OCEJPA | OCPWCD | OCPJP | OCP PL/SQL | MCP(s).
    • JAVA Community Process (JCP) Member.
    • Blogger Author and Academic Researcher.

    View Slide

  4. View Slide

  5. View Slide

  6. Introduction to CDI
    JSR 299: Contexts and Dependency Injection for the Java EE platform

    View Slide

  7. Q : What is the old name of the CDI ?

    View Slide

  8. What is CDI (JSR 299)?
    • Java Specification Requests
    • JSR is a document of a proposed specification used in the Java Community
    Process (JCP).
    • Classes specify what their dependencies
    • NOT how to obtain them (container responsibility)

    View Slide

  9. What is CDI (JSR 299)?
    • Provides a unifying Dependency Injection and contextual life-cycle
    model for Java EE
    • Unified existing Dependency Injection schemes – Spring, Guice, Seam
    • A completely new, richer dependency management model
    • Type-safe dependency injection
    • Designed for use with stateful objects (scoped objects)

    View Slide

  10. What is CDI (JSR 299)?
    • Makes it much easier to build applications using JSF and EJB
    together
    • Let you use EJBs directly as JSF managed beans

    View Slide

  11. Q : What is Weld ?

    View Slide

  12. What is Weld?
    • The CDI Reference Implementation (RI)
    • Service Provider Interfaces (SPI)
    • Weld provides a complete SPI allowing Java EE containers to use
    CDI implementation
    • Weld also runs in servlet engines, or even in a plain Java SE
    environment

    View Slide

  13. Common Dependency Injection Frameworks
    • Spring
    • Guice
    • Seam
    • EJB 3.X
    • CDI

    View Slide

  14. CDI is more than a framework
    • It’s a whole, rich programming model
    • The theme of CDI is loosecoupling with strong typing.
    • A bean specifies only the type and semantics of other beans it depends upon
    • It need not be aware of the actual lifecycle, concrete implementation,
    threading model or other clients of any bean it interacts with
    • Even better, the concrete implementation, lifecycle and threading model of
    a bean may vary according to the deployment scenario, without affecting
    any client
    • This loose-coupling makes your code easier to maintain

    View Slide

  15. CDI theme – Loose coupling with Strong typing
    • Events, interceptors and decorators enhance the loose-coupling
    inherent in this model:
    • Event notifications
    • Decouple event producers from event consumers
    • Interceptors
    • Decouple technical concerns from business logic
    • Decorators
    • Allow business concerns to be compartmentalized

    View Slide

  16. CDI theme – Loose coupling
    • Decouple Server (dependency) and client (dependency user)
    • Using well-defiend types and qualifiers
    • Allows server implementations to vary
    • Decouple lifecycle of collaboration components (dependencies) from
    application (dependency user)
    • Automatic contextual life-cycle management by the CDI runtime
    • Decouple orthogonal concerns (AOP) from business logic
    • Interceptors & Decorators
    • Decouple message producer from consumer
    • Events

    View Slide

  17. CDI theme – Strong typing
    • Type-based injection has advantages of
    • No more reliance on string-based names
    • Compiler can detect type errors at compile time
    • Casting mostly eliminated
    • Strong tooling possible
    • Semantic code errors (errors that can't be detected by the compiler) can
    be detected at application start-upon
    • Tools can detect ambiguous dependencies
    • Leverages Java type system
    • @Annotation

    View Slide

  18. Getting our feet wet
    CDI First Example

    View Slide

  19. • http://ansgohar.blogspot.com/2016/09/create-first-cdi-application.html

    View Slide

  20. • http://ansgohar.blogspot.com/2016/09/create-first-cdi-application.html

    View Slide

  21. Automatic Bean Discovery
    • • How can container scan bean?
    • By detecting the presence of “beans.xml” in application archive
    • For WAR file, the “beans.xml” is under WEB-INF directory
    • For JAR file, the “beans.xml” is under META-INF directory
    • • “beans.xml”
    • It is not for declaring beans (like in Spring)
    • It can be empty
    • Used for some other purposes (like declaring an alternative)

    View Slide

  22. Getting our feet wet
    EJB Simple Example

    View Slide

  23. View Slide

  24. Getting our feet wet
    Injecting EJB using CDI

    View Slide

  25. View Slide

  26. CDI Beans & Injection Point
    CDI Beans

    View Slide

  27. What is a Bean anyway?
    • Many forms of a “bean” already exist. So which bean arewe talking
    about?
    • JSF bean
    • EJB bean
    • Spring bean
    • Seam bean
    • Guice bean
    • CDI bean
    • Java EE needs a unified bean definition
    • Managed Bean 1.0 specification in Java EE 6 provides it

    View Slide

  28. What about Managed, EJB, REST, CDI Bean?
    • Managed Beans are container-managed POJOs
    • Lightweight component model
    • Instances are managed by the container
    • You could see everything as a Managed Bean with extra services
    • • An EJB is a Managed Bean with
    • Transaction support
    • Security
    • Thread safety
    • Persistence
    • • A REST service is a Managed Bean with
    • HTTP support
    • • A CDI bean is a Managed Bean with
    • CDI services (explained in the next slide)

    View Slide

  29. CDI is more than a framework
    • Auto-discovered
    • by the container
    • Set of qualifiers
    • solves ambiguity
    • Scope
    • context of a bean
    • Bean EL name
    • support non-type based invocation
    • Set of interceptor bindings
    • Alternative
    • replace bean at deployment time

    View Slide

  30. CDI Beans & Injection Point
    Injection Point

    View Slide

  31. Managed Bean  CDI Bean

    View Slide

  32. Q : How to Inject CDI Beans (Injection Point) ?

    View Slide

  33. CDI Injection Point
    • Use @Inject for field injection
    • can be Java interface
    • Bean can be injected at “Injection points”
    • Field
    • Method parameter
    • Method can be
    • Constructor (useful for created immutable object)
    • Initializer
    • Setter method
    • Producer
    • Observer

    View Slide

  34. Injecting Interface

    View Slide

  35. CDI Injection Point

    View Slide

  36. CDI Injection Point

    View Slide

  37. Qualifiers, Alternatives, Programmatically Lookup
    Qualifiers

    View Slide

  38. Q : What is the result of injecting CDI beans that :-
    1- have single Implementation ?
    2- have no Implementation ?
    3- have multiple Implementation ?

    View Slide

  39. What is a Qualifier?
    • For a given bean type (class or interface), there may be multiple
    beans which implement the type (in the classpath)
    • For an interface, there could be multiple implementations
    • For a class, there could be multiple child types
    • Ambiguity error will result
    • A qualifier is an annotation that lets a client choose one between
    multiple candidates of a certain type
    • Make type more specific
    • Assigns semantic meaning
    • Injected type is identified by
    • Qualifier(s) + Java type

    View Slide

  40. View Slide

  41. View Slide

  42. View Slide

  43. Qualifier and Type Safety (Strong Typing)
    • Qualifier + Java type makes a composite type (extended type)
    • Again, think of a Qualifier as a type
    • Qualifiers make type safe injection possible
    • Qualifiers replace “look-up via string-based names”
    • Qualifier and Type Safety (Strong Typing)

    View Slide

  44. Qualifiers, Alternatives, Programmatically Lookup
    Alternatives

    View Slide

  45. What is Alternative Bean?
    • Any bean with @Alternative is not considered for injection
    • Lets you package multiple beans that match injection type without ambiguity errors
    • In order to be considered for injection, it has to be activated in “beans.xml”
    • Provide a replacement implementation during deployment
    • You can apply the @Alternative annotation to two or more beans, then, based on
    your deployment, specify the bean you want to use in the “beans.xml” configuration
    file
    • Useful for providing mock objects for testing – mock objects are annotated with
    @Alternative

    View Slide

  46. View Slide

  47. Qualifiers, Alternatives, Programmatically Lookup
    Programmatically Lookup

    View Slide

  48. View Slide

  49. Scope, & Context
    CDI Beans Scope

    View Slide

  50. Q : What the allowed scopes in CDI ?

    View Slide

  51. Request – @RequestScoped
    • This scope describes a user’s interaction with a web
    application in a single HTTP request.
    • The instance of the @RequestScoped annotated
    bean has an HTTP request lifecycle.

    View Slide

  52. Session – @SessionScoped
    • This scope describes a user’s interaction with a web
    application across multiple HTTP requests.

    View Slide

  53. Application – @ApplicationScoped
    • In this case the state is shared across all users’
    interactions with a web application.
    • The container provides the same instance of the
    @ApplicationScoped annotated bean to all client
    requests.

    View Slide

  54. Dependent – @Dependent pseudo-scope
    • This pseudo-scope means that an object exists to serve
    exactly one client (bean) and has the same lifecycle as
    that client (bean).
    • This is the default scope for a bean which does not
    explicitly declare a scope type.
    • An instance of a dependent bean is never shared
    between different clients or different injection points.
    • It is strictly a dependent object of some other object.
    • It is instantiated when the object it belongs to is
    created, and destroyed when the object it belongs to
    is destroyed.

    View Slide

  55. View Slide

  56. View Slide

  57. View – @ ViewScoped
    • @ViewScoped belongs to JSF specification
    • Retains the scope lifespan for current page view
    • If the controller navigates away to a different page
    view the bean is de-scoped
    • Therefore view-scope is great for form validation
    and rich AJAX request and response sequences!

    View Slide

  58. Conversation – @ConversationScoped
    • A lifespan sits between a Http Request scope and
    Http Session scope
    • Maintains state for the unique interaction
    • Works for individual tab in web browsers
    • Better than @ViewScoped bean controllers
    • Application defined lifespan

    View Slide

  59. View Slide

  60. Session & Conversation Scoped Bean
    • A thing to notice is that beans must be serializable.
    • This is because the container passivates the HTTP
    session from time to time, so when the session is
    activated again the beans’ state must be retrieved.

    View Slide

  61. Singleton – @Singleton pseudo-scope
    • This is a pseudo-scope.
    • It defines that a bean is once instantiated.
    • When a CDI managed bean is injected into another
    bean, the CDI container makes use of a proxy.
    • The proxy is the one to handle calls to the bean.
    • Though, @Singleton annotated beans don’t have a
    proxy object.
    • Clients hold a direct reference to the singleton
    instance.

    View Slide

  62. Singleton – @Singleton pseudo-scope
    • So, what happens when a client is serialized ?
    • We must ensure that the singleton bean remains a
    singleton.
    • To do so there are a fiew ways, such as, have the
    singleton bean implement writeResolve() and
    readReplace() (as defined by the Java serialization
    specification), make sure the client keeps only a
    transient reference to the singleton bean, or give
    the client a reference of type Instance where X
    is the bean type of the singleton bean.

    View Slide

  63. Contextual scope
    • All predefined scopes except @Dependent are contextual
    scopes.
    • CDI places beans of contextual scope in the context whose
    lifecycle is defined by the Java EE specifications.
    • For example, a session context and its beans exist during the
    lifetime of an HTTP session.
    • Injected references to the beans are contextually aware.
    • The references always apply to the bean that is associated
    with the context for the thread that is making the reference.
    The CDI container ensures that the objects are created and
    injected at the correct time as determined by the scope that
    is specified for these objects.

    View Slide

  64. View Slide

  65. Interceptors, & Decorators
    Interceptors

    View Slide

  66. Interceptors
    • Interceptor functionality is defined in the Java Interceptors
    specification.
    • The Interceptors specification defines three kinds of interception
    points:
    • Business method interception,
    • Lifecycle callback interception, and
    • Timeout method interception (EJB only).
    • A business method interceptor applies to invocations of methods
    of the bean by clients of the bean
    • By default, all interceptors are disabled

    View Slide

  67. Business Method Interceptor
    • A business method interceptor applies to invocations of methods
    of the bean by clients of the bean

    View Slide

  68. Lifecycle Callback Interceptor
    • A lifecycle callback interceptor applies to invocations of lifecycle
    callbacks by the container
    • An interceptor class may intercept both lifecycle callbacks and
    business methods

    View Slide

  69. Timeout Method Interceptor
    • A timeout method interceptor applies to invocations of EJB
    timeout methods by the container

    View Slide

  70. View Slide

  71. Interceptors, & Decorators
    Decorators

    View Slide

  72. Q : What is the deference between Interceptor and Decorators in CDI ?

    View Slide

  73. What is a Decorator?
    • Decorators implement the Decorator design pattern
    • Allows implementation of an additional business logic for a bean
    • A Decorator decorates interfaces they implement
    • @Delegate is used to inject the original object
    • Original object business logic can be be invoked within the decorator
    • Decorators must be activated through “beans.xml”

    View Slide

  74. View Slide

  75. View Slide

  76. Interceptors VS Decorators
    • Interceptors and Decorators both geared towards cross-cutting
    logic.
    • Bypass traditional complexity associated with AOP by avoiding
    point-cuts.
    • Interceptors are designed for system-level crosscutting concerns
    very decoupled from business logic.
    • Decorators intended for concerns that should be
    compartmentalized but are still very close to business logic.

    View Slide

  77. Events
    Events

    View Slide

  78. Q : What is Events ?

    View Slide

  79. CDI Event Observer Pattern
    • Completely decouple action (event producer) and reactions
    • (event consumers)
    • Qualifiers tune which event notifications are received
    • Define Event Class
    • Event producer fires an event
    • Event consumer observes event through @Observes

    View Slide

  80. Event
    • Event Producers
    • An event is fired by an injected javax.enterprise.event.Event object
    • Event Consumer (Event Observer)
    • The only thing event consumer has to do is to use @Observes
    annotation

    View Slide

  81. View Slide

  82. CDI and EJB
    When you still need EJB?

    View Slide

  83. Q : When you still need EJB ?

    View Slide

  84. When you still need EJB ? … not yet aligned!
    • Security
    • @RolesAllowed
    • @PermitAll
    • @DenyAll
    • Usable by
    • @Stateless
    • @Stateful
    • @Singleton

    View Slide

  85. When you still need EJB ? … not yet aligned!
    • Startup
    • @Startup
    • Eagerly creates the instance upon startup
    • Usable by
    • @Singleton

    View Slide

  86. When you still need EJB ? … not yet aligned!
    • Asynchronous
    • @Asynchronsous
    • Allows method calls to be asynchronous and return Future objects
    • Usable by
    • @Stateless
    • @Stateful
    • @Singleton

    View Slide

  87. When you still need EJB ? … not yet aligned!
    • Schedule
    • @Schedule
    • Effectively Cron -- schedule invocations by minute or date, etc.
    • Usable by
    • @Stateless
    • @Singleton
    • Not @Stateful

    View Slide

  88. When you still need EJB ? … not yet aligned!
    • Locking
    • @Lock(READ
    • @Lock(WRITE)
    • @AccessTimeout
    • Allows for synchronization of methods without complex code
    • Usable by
    • @Singleton
    • Not @Stateless
    • Not @Stateful

    View Slide

  89. When you still need EJB ? … not yet aligned!
    • MDBs
    • @MessageDriven
    • Connector-Driven Beans
    • Usable by
    • Not @Singleton
    • Not @Stateless
    • Not @Stateful

    View Slide

  90. CDI Takeover
    • EJB adopts CDI (Java EE 6)
    • JSF adopts CDI (Java EE 7)
    • MVC adopts CDI (Java EE 8)
    • JAX-RS considers CDI (Java EE 8)
    • CDI moves to SE (Java EE 8)

    View Slide

  91. Common Mistakes you will make
    • Not putting a beans.xml in your app (Java EE 6)
    • No CDI for you!
    • Not understanding @Typed
    • Think @Local from EJB
    • Bites you when using @Produces
    • Not understanding what Dependent and NormalScope
    • Dependent == plain object
    • NormalScoped == proxied object
    • Bites you when creating custom scopes

    View Slide

  92. Result for EJB after CDI ?
    • Java EE 7
    • Focus on realignment: @Transactional
    • • Java EE 8
    • First spec round with no new EJB JSR
    • Realignment stalled
    • Awkward relationship

    View Slide

  93. CDI Wrap-up
    Who did this now ! ! !

    View Slide

  94. CDI Wrap-up
    • Basic dependency injection
    • @Inject, @Qualifier, @Stereotype, @Alternative,
    • Instance, @All, @Any
    • Component naming
    • @Named
    • Context management
    • @Dependent, @RequestScoped, @SessionScoped,
    • @ConversationScoped, @ApplicationScoped,
    • @Scope

    View Slide

  95. CDI Wrapup
    • Custom Object Factories
    • @Produces, @Disposes, InjectionPoint
    • Lightweight Events
    • Event, @Observes
    • Interceptors/Decorators
    • @Interceptor, @InterceptorBinding, @AroundInvoke,
    • InvocationContext
    • @Decorator, @Delegate

    View Slide

  96. Biggest benefits of CDI
    • Very active and open expert group
    • Fully extendable
    • Beans can be added at runtime
    • Fully Open Source
    • Spec is open source
    • All implementations are open source
    • Compliance test (TCK) suite is open source

    View Slide

  97. Q & A
    •https://about.me/ansgohar
    •http://ansgohar.blogspot.co.uk
    •https://twitter.com/ansgohar

    View Slide

  98. View Slide
