State Machine Saga Design Pattern

State Machine Saga Design Pattern

Building Cloud-Native App Series - Part 7 of 15
Microservices Architecture Series
FSM, Spring State Machine
States, Transitions, Events
Actions, Guards
Saga Design Pattern,
Enterprise Integration Patterns

Araf Karsh Hamid

August 30, 2023
Tweet

More Decks by Araf Karsh Hamid

Other Decks in Technology

Transcript

  1. @arafkarsh arafkarsh
    8 Years
    Network &
    Security
    6+ Years
    Microservices
    Blockchain
    8 Years
    Cloud
    Computing
    8 Years
    Distributed
    Computing
    Architecting
    & Building Apps
    a tech presentorial
    Combination of
    presentation & tutorial
    ARAF KARSH HAMID
    Co-Founder / CTO
    MetaMagic Global Inc., NJ, USA
    @arafkarsh
    arafkarsh
    1
    Finite State Machine
    Saga, EIP
    Building Cloud Native Apps
    FSM, Spring State Machine
    States, Transitions, Events
    Actions, Guards
    Saga Design Pattern,
    Enterprise Integration Patterns
    Part 7 of 15

    View Slide

  2. @arafkarsh arafkarsh 2
    Slides are color coded based on the topic colors.
    Finite State Machine
    Spring State
    Machine
    1
    State Machine Demo
    States, Transitions,
    Events, Actions, Guards
    2
    Distributed Tx
    Saga Design Pattern
    Orchestrator /
    Choreography
    3
    Enterprise Integration
    Patterns
    Spring Integration
    4

    View Slide

  3. @arafkarsh arafkarsh
    0
    Code Setup
    o SpringBoot 2.7.2 (MVC) / SpringBoot 3.1.0 (WebFlux)
    o Java 8 for Compile and Java 17 to run
    o H2 DB or PostgreSQL database
    3

    View Slide

  4. @arafkarsh arafkarsh
    Package Structure
    4
    Source: https://github.com/arafkarsh
    Threads / Rx Java 2: https://github.com/arafkarsh/fusion-sky-threads-rx-java
    Spring WebFlux Reactive Programming: https://github.com/arafkarsh/ms-springboot-310-webflux-r2dbc
    Spring MVC & Security: https://github.com/arafkarsh/ms-springboot-272-vanilla

    View Slide

  5. @arafkarsh arafkarsh
    Codebase
    5
    Source: https://github.com/arafkarsh/ms-quickstart

    View Slide

  6. @arafkarsh arafkarsh
    1
    Finite State Machines
    o States
    o Transitions
    6

    View Slide

  7. @arafkarsh arafkarsh
    Finite State Machine – States / Transitions
    7
    1. States: A state represents a condition or status of the system at a
    point in time. For instance, in a traffic light system, the states could
    be 'Green,' 'Orange,’ or 'Red.’ In a software system, the state might
    represent whether the system is in 'start-up,' 'operation,’ or
    'shutdown' mode. Each finite state machine must have at least one
    state and one of those states is designated as the starting state or
    initial state.
    2. Transitions: Transitions are the paths from one state to another.
    Events or conditions trigger them. For example, a timer reaching zero
    might trigger a transition from 'Green' to 'Orange' in a traffic light
    system. Each transition is associated with a specific condition that
    must be fulfilled to move from one state to another.

    View Slide

  8. @arafkarsh arafkarsh
    Understanding Finite State Machine
    8
    S1 S2 S3
    T1 T2
    T3
    T4
    States
    Transitions
    Transitions

    View Slide

  9. @arafkarsh arafkarsh
    Deterministic / Non-Deterministic State Machines
    9
    DFA (Deterministic Finite Automata):
    • A real-world example of a DFA could be a turnstile at a train station or
    amusement park. The turnstile has two states: Locked and Unlocked. When you
    insert a ticket or token (input), the state changes from Locked to Unlocked. After
    you pass through (another input), it changes back to the Locked state. At any
    point, the turnstile has a deterministic next state for a given input.
    NFA (Non-deterministic Finite Automata):
    • A real-world example of an NFA is less common because NFAs allow a system to
    be in multiple states at once or make transitions without specific inputs, which
    only sometimes occurs in everyday physical systems. However, in computer
    science, we often use NFAs while designing algorithms or systems, such as
    pattern-matching algorithms used in text editors, compilers, and the design of
    certain types of computer hardware (Network Routers, FPGAs).

    View Slide

  10. @arafkarsh arafkarsh
    Spring State Machine
    o States
    o Transitions: Triggers (Events, Timers, Choices)
    o Guards / Actions
    o Extended State
    o Choice
    o Entry / Exit States
    10

    View Slide

  11. @arafkarsh arafkarsh
    Spring State Machine
    11
    State Machine: The main entity that drives a collection of states,
    together with regions, transitions, and events.
    State: A state models a situation during which some invariant
    condition holds. The state is the main entity of a state machine
    where events drive state changes.
    Event: An entity sent to a state machine drives various state
    changes.
    Initial State: A unique state in which the state machine starts.
    The initial state is always bound to a particular state machine or
    region. A state machine with multiple regions may have multiple
    initial states

    View Slide

  12. @arafkarsh arafkarsh
    Spring State Machine
    12
    Extended State: An extended state is a special set of variables kept
    in a state machine to reduce the number of needed states.
    Transition: A transition is a relationship between a source and target
    states. It may be part of a compound transition, which takes the
    state machine from one state configuration to another, representing
    the state machine’s complete response to an event of a particular
    type.
    End State: (Also called a final state.) A special kind of state signifying
    that the enclosing region is completed. If the enclosing region is
    directly contained in a state machine and all other regions in the
    state machine are also completed, the entire state machine is
    completed.

    View Slide

  13. @arafkarsh arafkarsh
    Spring State Machine
    13
    Guard: A boolean expression evaluated dynamically based on the value of
    extended state variables and event parameters. Guard conditions affect the
    behavior of a state machine by enabling actions or transitions only when they
    evaluate to TRUE and disabling them when they evaluate to FALSE.
    Action: A action is a behavior run during the triggering of the transition.
    Choice State: A pseudo state that allows for making a transition choice based on
    (for example) event headers or extended state variables.
    Region: A region is an orthogonal part of either a composite state or a state
    machine. It contains states and transitions.
    Junction State: A pseudo state that is relatively similar to choice state but allows
    multiple incoming transitions, while choice allows only one incoming transition.

    View Slide

  14. @arafkarsh arafkarsh
    Spring State Machine
    14
    Fork State: A pseudo state that gives controlled entry into a region.
    Join State: A pseudo state that gives controlled exit from a region.
    Entry Point: A pseudo state that allows controlled entry into a
    submachine.
    Exit Point: A pseudo state that allows controlled exit from a
    submachine.
    History State: A pseudo state that lets a state machine remember its
    last active state. Two types of history state exists: shallow (which
    remembers only top level state) and deep (which remembers active
    states in sub-machines).

    View Slide

  15. @arafkarsh arafkarsh
    2
    State Machine Demo
    o Order Processing State Machine Configuration
    o Order Processing using State Machine
    o Order Entities and States, Events, Results
    15

    View Slide

  16. @arafkarsh arafkarsh
    Order State Machine Config
    16
    Order State Machine
    Config
    Order State Machine
    Listener Adapter
    Order State Change
    Interceptor
    Order State Details
    Order History Service
    Define States and
    Transitions
    Handles State
    Changes
    Handles Post State
    Transitions
    Keeps Order States in
    Request Scope
    Service to Persist
    Order State
    Transition History
    Setting up the State Machine Factory

    View Slide

  17. @arafkarsh arafkarsh
    Order Processing
    17
    Order State Machine
    Manager
    Order State Machine
    Actions
    Order State Machine
    Error Handler
    Order State Machine
    Guards
    Restores State Machine
    and Send Messages to
    State Machine
    Globally
    Handling Error
    Actions for
    Every State
    Guards to Validate
    the States and
    Control the Flow
    Order Service
    Implementation
    Handles Messages to
    State Machine
    Manager
    Order Process
    Controller
    Handles all the
    REST Endpoints
    State Machine is handled in stateless Architecture. State Machine is Restored using OSM Manager.

    View Slide

  18. @arafkarsh arafkarsh
    Order Entity
    18
    Order Entity
    Order Items
    Entity
    1
    *
    Shipping Address
    (VO)
    Order State
    History Entity
    1 1
    1
    *
    Order Entities / Repository
    Order State
    Order Event
    Order Result Order Notes
    Order Constants
    Enumerations

    View Slide

  19. @arafkarsh arafkarsh
    State Machine
    19

    View Slide

  20. @arafkarsh arafkarsh
    State Machine

    In Progress
    Details
    20

    View Slide

  21. @arafkarsh arafkarsh
    State Machine Code base
    o States and Transitions
    o Actions / Guards
    o Restore State Machine
    o Error Handling
    21
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  22. @arafkarsh arafkarsh
    State Machine – States 1/2
    22

    View Slide

  23. @arafkarsh arafkarsh
    State Machine – States 2/2
    23
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  24. @arafkarsh arafkarsh
    State Machine – Transitions 1/4
    24
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  25. @arafkarsh arafkarsh
    State Machine – Transitions 2/4
    25
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  26. @arafkarsh arafkarsh
    State Machine – Transitions 3/4
    26
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  27. @arafkarsh arafkarsh
    State Machine – Transitions 4/4
    27
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  28. @arafkarsh arafkarsh
    Actions
    28
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  29. @arafkarsh arafkarsh
    Guards
    29
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  30. @arafkarsh arafkarsh
    Error Handling
    30
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  31. @arafkarsh arafkarsh
    State Auto Transitioning
    31
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  32. @arafkarsh arafkarsh
    State Machine Restore
    32
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  33. @arafkarsh arafkarsh
    Communicating with State Machine
    33
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  34. @arafkarsh arafkarsh
    Communicating with State Machine
    34
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  35. @arafkarsh arafkarsh
    State Change
    through
    Interceptor
    35

    View Slide

  36. @arafkarsh arafkarsh
    State Change through Listener
    36
    Source: https://github.com/arafkarsh/ms-springboot-272-java-8

    View Slide

  37. @arafkarsh arafkarsh
    3
    Distributed
    Transactions
    37
    • Saga Design Pattern
    • Features
    • Handling Invariants
    • Forward recovery
    • Local Saga Feature
    • Distributed Saga
    • Use Case: Distributed Saga

    View Slide

  38. @arafkarsh arafkarsh
    Distributed Transactions: 2 Phase Commit
    2 PC or not 2 PC, Wherefore Art Thou XA?
    38
    How does 2PC impact scalability?
    • Transactions are committed in 2 phases.
    • This involves communicating with every database (XA:
    eXtended Architecture Resources) involved to determine if the
    transaction will commit (Prepare) in the 1st phase.
    • During the 2nd phase, each database is asked to complete the
    Commit.
    • While all of this coordination is going on, locks in all of the data
    sources are being held.
    • The longer duration locks create the risk of higher contention.
    • Additionally, the two phases require more database
    processing time than a single-phase commit.
    • The result is lower overall TPS in the
    system.
    Transaction
    Manager
    XA Resources
    Request to Prepare
    Commit
    Prepared
    Prepare
    Phase
    Commit
    Phase
    Done
    Source : Pat Helland (Amazon) : Life Beyond Distributed Transactions Distributed Computing : http://dancres.github.io/Pages/
    Solution : Resilient System
    • Event Based
    • Design for failure
    • Asynchronous Recovery
    • Make all operations idempotent.
    • Each DB operation is a 1 PC
    1
    2

    View Slide

  39. @arafkarsh arafkarsh
    Distributed Tx: SAGA Design Pattern instead of 2PC
    39
    Long Lived Transactions (LLTs) hold on to DB resources for relatively long periods of time, significantly delaying
    the termination of shorter and more common transactions.
    Source: SAGAS (1987) Hector Garcia Molina / Kenneth Salem,
    Dept. of Computer Science, Princeton University, NJ, USA
    T1 T2 Tn
    Local Transactions
    C1 C2 Cn-1
    Compensating Transaction
    Divide long–lived, distributed transactions into quick local ones with compensating actions for
    recovery.
    Travel : Flight Ticket & Hotel Booking Example
    BASE (Basic Availability, Soft
    State, Eventual Consistency)
    Room Reserved
    T1
    Room Payment
    T2
    Seat Reserved
    T3
    Ticket Payment
    T4
    Cancelled Room Reservation
    C1
    Cancelled Room Payment
    C2
    Cancelled Ticket Reservation
    C3
    Error
    Error
    Error

    View Slide

  40. @arafkarsh arafkarsh
    SAGA Design Pattern Features
    40
    1. Backward Recovery (Rollback)
    T1
    T2
    T3
    T4
    C3
    C2
    C1
    Order Processing, Banking
    Transactions, Ticket Booking
    Examples
    Updating individual scores in
    a Team Game.
    2. Forward Recovery with Save Points
    T1
    (sp) T2
    (sp) T3
    (sp)
    • To recover from Hardware Failures, SAGA needs to be persistent.
    • Save Points are available for both Forward and Backward Recovery.
    Type
    Source: SAGAS (1987) Hector Garcia Molina / Kenneth Salem, Dept. of Computer Science, Princeton University, NJ, USA

    View Slide

  41. @arafkarsh arafkarsh
    Handling Invariants – Monolithic to Micro Services
    41
    In a typical Monolithic App
    Customer Credit Limit info and
    the order processing is part of
    the same App. Following is a
    typical pseudo code.
    Order Created
    T1
    Order
    Microservice
    Credit Reserved
    T2
    Customer
    Microservice
    In Micro Services world with Event Sourcing, it’s a
    distributed environment. The order is cancelled if
    the Credit is NOT available. If the Payment
    Processing is failed then the Credit Reserved is
    cancelled.
    Payment
    Microservice
    Payment Processed
    T3
    Order Cancelled
    C1
    Error
    Credit Cancelled due to
    payment failure
    C2
    Error
    Begin Transaction
    If Order Value <= Available
    Credit
    Process Order
    Process Payments
    End Transaction
    Monolithic 2 Phase Commit
    https://en.wikipedia.org/wiki/Invariant_(computer_science)

    View Slide

  42. @arafkarsh arafkarsh 42
    Use Case : Restaurant – Forward Recovery
    Domain
    The example focus on a
    concept of a Restaurant
    which tracks the visit of
    an individual or group
    to the Restaurant. When
    people arrive at the
    Restaurant and take a
    table, a table is opened.
    They may then order
    drinks and food. Drinks
    are served immediately
    by the table staff,
    however food must be
    cooked by a chef. Once
    the chef prepared the
    food it can then be
    served.
    Payment
    Billing
    Dining
    Source: http://cqrs.nu/tutorial/cs/01-design
    Soda Cancelled
    Table Opened
    Juice Ordered
    Soda Ordered
    Appetizer Ordered
    Soup Ordered
    Food Ordered
    Juice Served
    Food Prepared
    Food Served
    Appetizer Served
    Table Closed
    Aggregate Root : Dinning Order
    Billed Order
    T1
    Payment CC
    T2
    Payment Cash
    T3
    T1
    (sp) T2
    (sp) T3
    (sp)
    Event Stream
    Aggregate Root : Food Bill
    Transaction doesn't rollback if one payment
    method is failed. It moves forward to the
    NEXT one.
    sp
    Network
    Error
    C1 sp

    View Slide

  43. @arafkarsh arafkarsh
    Choreography Vs. Orchestration
    43
    1. Choreography: In this model, each local transaction
    publishes domain events that trigger local transactions in
    other services. There is no central coordination. The logic
    is distributed among the participants, which means that
    it must be a collaborative process.
    2. Orchestration: In this model, an orchestrator (object)
    tells the participants what local transactions to execute.
    The logic for the distributed transaction is centralized in
    the orchestrator.
    Comparison of Event Choreography and Orchestration Techniques in Microservices Architecture
    Chaitanya K Rudrabhatla, Executive Director, Solution Architect, Media & Entertainment Domain, LA USA

    View Slide

  44. @arafkarsh arafkarsh
    Choreography: Local SAGA Features
    44
    1. Part of the Microservices
    2. Local Transactions and Compensation
    Transactions
    3. SAGA State is persisted
    4. All the Local transactions are based on
    Single Phase Commit (1 PC)
    5. Developers need to ensure that
    appropriate compensating transactions
    are Raised in the event of a failure.
    API Examples
    @StartSaga(name=“HotelBooking”)
    public void reserveRoom(…) {
    }
    @EndSaga(name=“HotelBooking”)
    public void payForTickets(…) {
    }
    @AbortSaga(name=“HotelBooking”)
    public void cancelBooking(…) {
    }
    @CompensationTx()
    public void cancelReservation(…) {
    }

    View Slide

  45. @arafkarsh arafkarsh
    Choreography: Use Case: Travel Booking
    45
    Travel : Hotel Booking / Car Booking / Flight Booking Example
    Room Reserved
    T1
    Room Payment
    T2
    Car Reserved
    T3
    Car Payment
    T4
    Cancelled Room Reservation
    C1
    Cancelled Room Payment
    C2
    Cancelled Car Reservation
    C3
    Error
    Error
    Error
    Seat Reserved
    T5
    Ticket Payment
    T6
    Cancelled Seat Reservation
    C4
    Error
    Cancelled Ticket Payment
    C5
    Error
    Distributed Tx Done
    Hotel
    Microservice
    Rental
    Microservice
    Travel
    Microservice

    View Slide

  46. @arafkarsh arafkarsh
    Orchestration: SAGA Execution Container (SEC)
    46
    1. SEC is a separate Process
    2. Stateless in nature and Saga state is stored in a
    messaging system (Kafka is a Good choice).
    3. SEC process failure MUST not affect Saga Execution as
    the restart of the SEC must start from where the Saga
    left.
    4. SEC – No Single Point of Failure (Master Slave Model).
    5. Distributed SAGA Rules are defined using a DSL.

    View Slide

  47. @arafkarsh arafkarsh
    Orchestrator: Use Case: Travel Booking – Distributed Saga (SEC)
    47
    Hotel Booking
    Car Booking
    Flight Booking
    Saga
    Execution
    Container
    Start Saga
    {Booking Request}
    Payment
    End
    Saga
    Start
    Saga
    Start Hotel
    End Hotel
    Start Car
    End Car
    Start Flight
    End Flight
    Start Payment
    End Payment
    Saga Log
    End Saga
    {Booking Confirmed}
    SEC knows the structure of the
    distributed Saga and for each
    of the Request Which Service
    needs to be called and what
    kind of Recovery mechanism it
    needs to be followed.
    SEC can parallelize the calls
    to multiple services to
    improve the performance.
    The Rollback or Roll forward
    will be dependent on the
    business case.
    Source: Distributed Sagas By Catitie McCaffrey, June 6, 2017

    View Slide

  48. @arafkarsh arafkarsh
    Orchestrator: Use Case : Travel Booking – Rollback
    48
    Hotel Booking
    Car Booking
    Flight Booking
    Saga
    Execution
    Container
    Start Saga
    {Booking Request}
    Payment
    Start
    Comp
    Saga
    End
    Comp
    Saga
    Start Hotel
    End Hotel
    Start Car
    Abort Car
    Cancel Hotel
    Cancel Flight
    Saga Log
    End Saga
    {Booking Cancelled}
    Kafka is a good choice to
    implement the SEC log.
    SEC is completely STATELESS in
    nature. Master Slave model
    can be implemented to avoid
    the Single Point of Failure.
    Source: Distributed Sagas By Catitie McCaffrey, June 6, 2017

    View Slide

  49. @arafkarsh arafkarsh
    Performance: Choreography Vs. Orchestration
    49
    175 ms : Choreography 8500 ms : Orchestration
    Comparison of Event Choreography and Orchestration Techniques in Microservices Architecture
    Chaitanya K Rudrabhatla, Executive Director, Solution Architect, Media & Entertainment Domain, LA USA

    View Slide

  50. @arafkarsh arafkarsh
    Choreography Service: Use Case: Travel Booking
    50
    Travel : Hotel Booking / Car Booking / Flight Booking Example
    Room
    Reserved
    T2
    Room
    Payment
    T3
    Car
    Reserved
    T4
    Car
    Payment
    T5
    Cancelled Room
    Reservation
    C1
    Cancelled Room
    Payment
    C2
    Cancelled Car
    Reservation
    C3
    Error
    Error
    Error
    Seat
    Reserved
    T6
    Ticket
    Payment
    T7
    Cancelled Seat
    Reservation
    C4
    Error
    Cancelled Ticket
    Payment
    C5
    Error
    Distributed Tx Done
    Hotel
    Microservice
    Rental
    Microservice
    Travel
    Microservice
    Reservation
    Microservice
    Reservation
    Completed
    T8
    Reservation
    Incomplete
    T8
    Reservation
    Request
    T1
    S

    View Slide

  51. @arafkarsh arafkarsh
    Scalability Requirement in Cloud
    51
    1. Availability and Partition Tolerance is more important
    than immediate Consistency.
    2. Eventual Consistency is more suitable in a highly
    scalable Cloud Environment
    3. Two Phase Commit has its limitations from Scalability
    perspective and it’s a Single Point of Failure.
    4. Scalability examples from eBay, Amazon, Netflix, Uber,
    Airbnb etc.

    View Slide

  52. @arafkarsh arafkarsh
    Libraries to Support Saga Design Pattern
    52
    1. Eventuate Tram and Eventuate Local (Both): Eventuate Tram and Eventuate Local are Java libraries that help handle
    distributed transactions using both choreography and orchestration. Eventuate Tram supports traditional JDBC/JPA-
    based persistence, while Eventuate Local supports event sourcing.
    2. Axon Framework (Both): Axon is a Java-based framework that can handle both the orchestration and choreography
    of Saga design patterns. This framework is designed for building scalable and extensible microservices.
    3. Spring State Machine (Orchestration): While not explicitly a Saga pattern library, the Spring State Machine can be
    adapted to orchestrate sagas. It's designed to manage stateful entities in Spring-based Java applications, which can
    be used to coordinate transactions across multiple services.
    4. Camunda (Orchestration): Camunda is an open-source platform for workflow and decision automation. While not a
    dedicated Saga pattern library, it can handle the orchestration of sagas using BPMN workflows. It supports Java, but it
    also has REST APIs, so it's accessible from other languages.
    5. Netflix Conductor (Orchestration): Conductor is a microservices orchestration engine developed by Netflix. It's
    primarily used for orchestrating complex distributed systems and can be used to manage sagas. It supports Java.
    6. Zeebe (Orchestration): Zeebe is a workflow engine designed to meet the scalability requirements of high-
    performance applications running on cloud-native and event-driven architectures. It can handle the orchestration of
    sagas and supports Java, among other languages.
    7. Cadence Workflow (Both): Cadence is a distributed, scalable, durable, and highly available orchestration engine
    developed by Uber. It supports long-running, durable workflows, and it can manage sagas. The Cadence Java client
    provides a framework for orchestrating sagas.

    View Slide

  53. @arafkarsh arafkarsh
    Summary:
    53
    1. 2 Phase Commit
    Doesn’t scale well in cloud environment
    2. SAGA Design Pattern
    Raise compensating events when the local transaction fails.
    3. SAGA Supports Rollbacks & Roll
    Forwards
    Critical pattern to address distributed transactions.

    View Slide

  54. @arafkarsh arafkarsh
    4
    Enterprise Integration Pattern
    54

    View Slide

  55. @arafkarsh arafkarsh
    55
    Enterprise Integration Patterns – Messaging System
    Page Number from Enterprise
    Integration Patterns
    Pattern Description Page
    1
    Message
    Channel
    The Message Channel is an internal
    implementation detail of the Endpoint
    interface and all interactions with the
    Message Channel are via the Endpoint
    Interfaces.
    60
    2 Message
    To support various message exchange
    patterns like one-way Event Messages
    and Request Reply messages, Camel
    uses an Exchange interface that has a
    pattern property that can be set to In-
    Only for an Event Message which has
    a single inbound Message or In-Out
    for a Request-Reply where there is an
    inbound and outbound message.
    53
    3
    Message
    Endpoint
    Supports 4 endpoints
    • Web Services: REST & SOAP
    • Database : JDBC
    • File : Reads File
    95
    4 Message
    Translator
    We have 3 built-in Processors
    1. SQL Processor (Take DTO and pass
    value to query)
    2. SOAP Processor (Generate SOAP
    Message)
    3. REST Processor(Take DTO convert
    into respected format
    85

    View Slide

  56. @arafkarsh arafkarsh
    56
    Enterprise Integration Patterns – Messaging Systems
    Pattern Description Page
    5
    Pipes and Filters
    Supports the Pipes and Filters from the EIP patterns in various ways.
    You can split your processing across multiple independent Endpoint instances
    which can then be chained together.
    70
    6
    Message Router
    The Message Router from the EIP patterns allows you to consume from an input
    destination, evaluate some predicate then choose the right output destination.
    78
    Page Number from Enterprise
    Integration Patterns

    View Slide

  57. @arafkarsh arafkarsh
    57
    Enterprise Integration Patterns – Messaging Channels
    Pattern Description Page
    7
    Publish
    Subscribe
    System
    Supports the Publish Subscribe Channel from the EIP patterns using for example the
    following components:
    • JMS for working with JMS Topics for high performance, clustering and load
    balancing
    • XMPP when using rooms for group communication
    • SEDA for working with SEDA in the same Camel Context which can work in pub-
    sub, but allowing multiple consumers.
    • VM as SEDA but for intra-JVM.
    106
    Page Number from Enterprise
    Integration Patterns

    View Slide

  58. @arafkarsh arafkarsh
    58
    Enterprise Integration Patterns – Messaging Channels
    Pattern Description Page
    8
    Point to
    Point
    Channel
    Supports the Point to Point Channel from the EIP patterns using the following
    components
    1. SEDA for in-VM seda based messaging
    2. JMS for working with JMS Queues for high performance, clustering and load
    balancing
    3. JPA for using a database as a simple message queue
    4. XMPP for point-to-point communication over XMPP (Jabber)
    5. and others 103
    9
    Event
    Driven
    Consumer
    Supports the Event Driven Consumer from the EIP patterns. The default consumer
    model is event based (i.e. asynchronous) as this means that the Camel container can
    then manage pooling, threading and concurrency for you in a declarative manner.
    The Event Driven Consumer is implemented by consumers implementing the
    Processor interface which is invoked by the Message Endpoint when a Message is
    available for processing.
    498
    Page Number from Enterprise
    Integration Patterns

    View Slide

  59. @arafkarsh arafkarsh
    59
    Enterprise Integration Patterns – Message Routing
    Pattern Description Page
    10
    Aggregator
    The Aggregator from the EIP patterns allows you to combine a number of
    messages together into a single message.
    268
    11
    Content Based
    Router
    The Content Based Router from the EIP patterns allows you to route messages to
    the correct destination based on the contents of the message exchanges.
    230
    12 Message Filter The Message Filter from the EIP patterns allows you to filter messages.
    237
    Page Number from Enterprise
    Integration Patterns

    View Slide

  60. @arafkarsh arafkarsh
    60
    Enterprise Integration Patterns – Message Routing
    Pattern Description Page
    13 Routing Slip
    The Routing Slip from the EIP patterns allows you to route a message
    consecutively through a series of processing steps where the sequence of
    steps is not known at design time and can vary for each message.
    301
    14
    Load Balancer The Load Balancer Pattern allows you to delegate to one of a number of
    endpoints using a variety of different load balancing policies.
    15 Multicast
    The Multicast allows to route the same message to a number of endpoints
    and process them in a different way. The main difference between the
    Multicast and Splitter is that Splitter will split the message into several
    pieces but the Multicast will not modify the request message.
    Page Number from Enterprise
    Integration Patterns

    View Slide

  61. @arafkarsh arafkarsh
    61
    Enterprise Integration Patterns – Message Transformation
    Pattern Description Page
    16
    Content Enricher
    Supports the Content Enricher from the EIP patterns using a Message Translator,
    an arbitrary Processor in the routing logic, or using the enrich DSL element to
    enrich the message.
    336
    17 Content Filter Supports the Content Filter from the EIP patterns using one of the following
    mechanisms in the routing logic to transform content from the inbound message.
    • Message Translator
    • invoking a Java bean
    • Processor object
    342
    Page Number from Enterprise
    Integration Patterns

    View Slide

  62. @arafkarsh arafkarsh
    62
    Enterprise Integration Patterns – Others
    Pattern Description Page
    18
    Request Reply
    Supports the Request Reply from the EIP patterns by supporting the Exchange
    Pattern on a Message which can be set to In Out to indicate a request/reply.
    Camel Components then implement this pattern using the underlying transport
    or protocols.
    154
    19 Wire tap Wire Tap (from the EIP patterns) allows you to route messages to a separate
    location while they are being forwarded to the ultimate destination.
    547
    Page Number from Enterprise
    Integration Patterns

    View Slide

  63. @arafkarsh arafkarsh
    63
    Design Patterns – Service Design Pattern
    Patterns Description Page
    1
    Request
    Mapper
    How can a service process data from requests
    that are structurally different yet semantically
    equivalent?
    109
    2
    Response
    Mapper
    How can the logic required to construct a
    response be re-used by multiple services?
    122
    3
    Data Source
    Adapter
    How can web service provide access to internal
    resources like database tables, domain objects,
    or files with a minimum amount of custom code?
    137
    4
    Asynchronous
    Response
    Handler
    How can a client avoid blocking when sending a
    request? 184
    5
    Service
    Connector
    How can clients avoid duplicating the code
    required to use a specific service and also be
    insulated from the intricacies of communication
    logic?
    168
    Page Number from service Design
    Patterns

    View Slide

  64. @arafkarsh arafkarsh 64
    Design Patterns are
    solutions to general
    problems that
    software developers
    faced during software
    development.
    Design Patterns

    View Slide

  65. @arafkarsh arafkarsh 65
    DREAM | AUTOMATE | EMPOWER
    Araf Karsh Hamid :
    India: +91.999.545.8627
    http://www.slideshare.net/arafkarsh
    https://www.linkedin.com/in/arafkarsh/
    https://www.youtube.com/user/arafkarsh/playlists
    http://www.arafkarsh.com/
    @arafkarsh
    arafkarsh

    View Slide

  66. @arafkarsh arafkarsh 66
    Source Code: https://github.com/MetaArivu Web Site: https://metarivu.com/ https://pyxida.cloud/

    View Slide

  67. @arafkarsh arafkarsh 67
    http://www.slideshare.net/arafkarsh

    View Slide

  68. @arafkarsh arafkarsh
    References
    68
    1. July 15, 2015 – Agile is Dead : GoTo 2015 By Dave Thomas
    2. Apr 7, 2016 - Agile Project Management with Kanban | Eric Brechner | Talks at Google
    3. Sep 27, 2017 - Scrum vs Kanban - Two Agile Teams Go Head-to-Head
    4. Feb 17, 2019 - Lean vs Agile vs Design Thinking
    5. Dec 17, 2020 - Scrum vs Kanban | Differences & Similarities Between Scrum & Kanban
    6. Feb 24, 2021 - Agile Methodology Tutorial for Beginners | Jira Tutorial | Agile Methodology Explained.
    Agile Methodologies

    View Slide

  69. @arafkarsh arafkarsh
    References
    69
    1. Vmware: What is Cloud Architecture?
    2. Redhat: What is Cloud Architecture?
    3. Cloud Computing Architecture
    4. Cloud Adoption Essentials:
    5. Google: Hybrid and Multi Cloud
    6. IBM: Hybrid Cloud Architecture Intro
    7. IBM: Hybrid Cloud Architecture: Part 1
    8. IBM: Hybrid Cloud Architecture: Part 2
    9. Cloud Computing Basics: IaaS, PaaS, SaaS
    1. IBM: IaaS Explained
    2. IBM: PaaS Explained
    3. IBM: SaaS Explained
    4. IBM: FaaS Explained
    5. IBM: What is Hypervisor?
    Cloud Architecture

    View Slide

  70. @arafkarsh arafkarsh
    References
    70
    Microservices
    1. Microservices Definition by Martin Fowler
    2. When to use Microservices By Martin Fowler
    3. GoTo: Sep 3, 2020: When to use Microservices By Martin Fowler
    4. GoTo: Feb 26, 2020: Monolith Decomposition Pattern
    5. Thought Works: Microservices in a Nutshell
    6. Microservices Prerequisites
    7. What do you mean by Event Driven?
    8. Understanding Event Driven Design Patterns for Microservices

    View Slide

  71. @arafkarsh arafkarsh
    References – Microservices – Videos
    71
    1. Martin Fowler – Micro Services : https://www.youtube.com/watch?v=2yko4TbC8cI&feature=youtu.be&t=15m53s
    2. GOTO 2016 – Microservices at NetFlix Scale: Principles, Tradeoffs & Lessons Learned. By R Meshenberg
    3. Mastering Chaos – A NetFlix Guide to Microservices. By Josh Evans
    4. GOTO 2015 – Challenges Implementing Micro Services By Fred George
    5. GOTO 2016 – From Monolith to Microservices at Zalando. By Rodrigue Scaefer
    6. GOTO 2015 – Microservices @ Spotify. By Kevin Goldsmith
    7. Modelling Microservices @ Spotify : https://www.youtube.com/watch?v=7XDA044tl8k
    8. GOTO 2015 – DDD & Microservices: At last, Some Boundaries By Eric Evans
    9. GOTO 2016 – What I wish I had known before Scaling Uber to 1000 Services. By Matt Ranney
    10. DDD Europe – Tackling Complexity in the Heart of Software By Eric Evans, April 11, 2016
    11. AWS re:Invent 2016 – From Monolithic to Microservices: Evolving Architecture Patterns. By Emerson L, Gilt D. Chiles
    12. AWS 2017 – An overview of designing Microservices based Applications on AWS. By Peter Dalbhanjan
    13. GOTO Jun, 2017 – Effective Microservices in a Data Centric World. By Randy Shoup.
    14. GOTO July, 2017 – The Seven (more) Deadly Sins of Microservices. By Daniel Bryant
    15. Sept, 2017 – Airbnb, From Monolith to Microservices: How to scale your Architecture. By Melanie Cubula
    16. GOTO Sept, 2017 – Rethinking Microservices with Stateful Streams. By Ben Stopford.
    17. GOTO 2017 – Microservices without Servers. By Glynn Bird.

    View Slide

  72. @arafkarsh arafkarsh
    References
    72
    Domain Driven Design
    1. Oct 27, 2012 What I have learned about DDD Since the book. By Eric Evans
    2. Mar 19, 2013 Domain Driven Design By Eric Evans
    3. Jun 02, 2015 Applied DDD in Java EE 7 and Open Source World
    4. Aug 23, 2016 Domain Driven Design the Good Parts By Jimmy Bogard
    5. Sep 22, 2016 GOTO 2015 – DDD & REST Domain Driven API’s for the Web. By Oliver Gierke
    6. Jan 24, 2017 Spring Developer – Developing Micro Services with Aggregates. By Chris Richardson
    7. May 17. 2017 DEVOXX – The Art of Discovering Bounded Contexts. By Nick Tune
    8. Dec 21, 2019 What is DDD - Eric Evans - DDD Europe 2019. By Eric Evans
    9. Oct 2, 2020 - Bounded Contexts - Eric Evans - DDD Europe 2020. By. Eric Evans
    10. Oct 2, 2020 - DDD By Example - Paul Rayner - DDD Europe 2020. By Paul Rayner

    View Slide

  73. @arafkarsh arafkarsh
    References
    73
    Event Sourcing and CQRS
    1. IBM: Event Driven Architecture – Mar 21, 2021
    2. Martin Fowler: Event Driven Architecture – GOTO 2017
    3. Greg Young: A Decade of DDD, Event Sourcing & CQRS – April 11, 2016
    4. Nov 13, 2014 GOTO 2014 – Event Sourcing. By Greg Young
    5. Mar 22, 2016 Building Micro Services with Event Sourcing and CQRS
    6. Apr 15, 2016 YOW! Nights – Event Sourcing. By Martin Fowler
    7. May 08, 2017 When Micro Services Meet Event Sourcing. By Vinicius Gomes

    View Slide

  74. @arafkarsh arafkarsh
    References
    74
    Kafka
    1. Understanding Kafka
    2. Understanding RabbitMQ
    3. IBM: Apache Kafka – Sept 18, 2020
    4. Confluent: Apache Kafka Fundamentals – April 25, 2020
    5. Confluent: How Kafka Works – Aug 25, 2020
    6. Confluent: How to integrate Kafka into your environment – Aug 25, 2020
    7. Kafka Streams – Sept 4, 2021
    8. Kafka: Processing Streaming Data with KSQL – Jul 16, 2018
    9. Kafka: Processing Streaming Data with KSQL – Nov 28, 2019

    View Slide

  75. @arafkarsh arafkarsh
    References
    75
    Databases: Big Data / Cloud Databases
    1. Google: How to Choose the right database?
    2. AWS: Choosing the right Database
    3. IBM: NoSQL Vs. SQL
    4. A Guide to NoSQL Databases
    5. How does NoSQL Databases Work?
    6. What is Better? SQL or NoSQL?
    7. What is DBaaS?
    8. NoSQL Concepts
    9. Key Value Databases
    10. Document Databases
    11. Jun 29, 2012 – Google I/O 2012 - SQL vs NoSQL: Battle of the Backends
    12. Feb 19, 2013 - Introduction to NoSQL • Martin Fowler • GOTO 2012
    13. Jul 25, 2018 - SQL vs NoSQL or MySQL vs MongoDB
    14. Oct 30, 2020 - Column vs Row Oriented Databases Explained
    15. Dec 9, 2020 - How do NoSQL databases work? Simply Explained!
    1. Graph Databases
    2. Column Databases
    3. Row Vs. Column Oriented Databases
    4. Database Indexing Explained
    5. MongoDB Indexing
    6. AWS: DynamoDB Global Indexing
    7. AWS: DynamoDB Local Indexing
    8. Google Cloud Spanner
    9. AWS: DynamoDB Design Patterns
    10. Cloud Provider Database Comparisons
    11. CockroachDB: When to use a Cloud DB?

    View Slide

  76. @arafkarsh arafkarsh
    References
    76
    Docker / Kubernetes / Istio
    1. IBM: Virtual Machines and Containers
    2. IBM: What is a Hypervisor?
    3. IBM: Docker Vs. Kubernetes
    4. IBM: Containerization Explained
    5. IBM: Kubernetes Explained
    6. IBM: Kubernetes Ingress in 5 Minutes
    7. Microsoft: How Service Mesh works in Kubernetes
    8. IBM: Istio Service Mesh Explained
    9. IBM: Kubernetes and OpenShift
    10. IBM: Kubernetes Operators
    11. 10 Consideration for Kubernetes Deployments
    Istio – Metrics
    1. Istio – Metrics
    2. Monitoring Istio Mesh with Grafana
    3. Visualize your Istio Service Mesh
    4. Security and Monitoring with Istio
    5. Observing Services using Prometheus, Grafana, Kiali
    6. Istio Cookbook: Kiali Recipe
    7. Kubernetes: Open Telemetry
    8. Open Telemetry
    9. How Prometheus works
    10. IBM: Observability vs. Monitoring

    View Slide

  77. @arafkarsh arafkarsh
    References
    77
    1. Feb 6, 2020 – An introduction to TDD
    2. Aug 14, 2019 – Component Software Testing
    3. May 30, 2020 – What is Component Testing?
    4. Apr 23, 2013 – Component Test By Martin Fowler
    5. Jan 12, 2011 – Contract Testing By Martin Fowler
    6. Jan 16, 2018 – Integration Testing By Martin Fowler
    7. Testing Strategies in Microservices Architecture
    8. Practical Test Pyramid By Ham Vocke
    Testing – TDD / BDD

    View Slide

  78. @arafkarsh arafkarsh 78
    1. Simoorg : LinkedIn’s own failure inducer framework. It was designed to be easy to extend and
    most of the important components are plug- gable.
    2. Pumba : A chaos testing and network emulation tool for Docker.
    3. Chaos Lemur : Self-hostable application to randomly destroy virtual machines in a BOSH-
    managed environment, as an aid to resilience testing of high-availability systems.
    4. Chaos Lambda : Randomly terminate AWS ASG instances during business hours.
    5. Blockade : Docker-based utility for testing network failures and partitions in distributed
    applications.
    6. Chaos-http-proxy : Introduces failures into HTTP requests via a proxy server.
    7. Monkey-ops : Monkey-Ops is a simple service implemented in Go, which is deployed into an
    OpenShift V3.X and generates some chaos within it. Monkey-Ops seeks some OpenShift
    components like Pods or Deployment Configs and randomly terminates them.
    8. Chaos Dingo : Chaos Dingo currently supports performing operations on Azure VMs and VMSS
    deployed to an Azure Resource Manager-based resource group.
    9. Tugbot : Testing in Production (TiP) framework for Docker.
    Testing tools

    View Slide

  79. @arafkarsh arafkarsh
    References
    79
    CI / CD
    1. What is Continuous Integration?
    2. What is Continuous Delivery?
    3. CI / CD Pipeline
    4. What is CI / CD Pipeline?
    5. CI / CD Explained
    6. CI / CD Pipeline using Java Example Part 1
    7. CI / CD Pipeline using Ansible Part 2
    8. Declarative Pipeline vs Scripted Pipeline
    9. Complete Jenkins Pipeline Tutorial
    10. Common Pipeline Mistakes
    11. CI / CD for a Docker Application

    View Slide

  80. @arafkarsh arafkarsh
    References
    80
    DevOps
    1. IBM: What is DevOps?
    2. IBM: Cloud Native DevOps Explained
    3. IBM: Application Transformation
    4. IBM: Virtualization Explained
    5. What is DevOps? Easy Way
    6. DevOps?! How to become a DevOps Engineer???
    7. Amazon: https://www.youtube.com/watch?v=mBU3AJ3j1rg
    8. NetFlix: https://www.youtube.com/watch?v=UTKIT6STSVM
    9. DevOps and SRE: https://www.youtube.com/watch?v=uTEL8Ff1Zvk
    10. SLI, SLO, SLA : https://www.youtube.com/watch?v=tEylFyxbDLE
    11. DevOps and SRE : Risks and Budgets : https://www.youtube.com/watch?v=y2ILKr8kCJU
    12. SRE @ Google: https://www.youtube.com/watch?v=d2wn_E1jxn4

    View Slide

  81. @arafkarsh arafkarsh
    References
    81
    1. Lewis, James, and Martin Fowler. “Microservices: A Definition of This New Architectural Term”, March 25, 2014.
    2. Miller, Matt. “Innovate or Die: The Rise of Microservices”. e Wall Street Journal, October 5, 2015.
    3. Newman, Sam. Building Microservices. O’Reilly Media, 2015.
    4. Alagarasan, Vijay. “Seven Microservices Anti-patterns”, August 24, 2015.
    5. Cockcroft, Adrian. “State of the Art in Microservices”, December 4, 2014.
    6. Fowler, Martin. “Microservice Prerequisites”, August 28, 2014.
    7. Fowler, Martin. “Microservice Tradeoffs”, July 1, 2015.
    8. Humble, Jez. “Four Principles of Low-Risk Software Release”, February 16, 2012.
    9. Zuul Edge Server, Ketan Gote, May 22, 2017
    10. Ribbon, Hysterix using Spring Feign, Ketan Gote, May 22, 2017
    11. Eureka Server with Spring Cloud, Ketan Gote, May 22, 2017
    12. Apache Kafka, A Distributed Streaming Platform, Ketan Gote, May 20, 2017
    13. Functional Reactive Programming, Araf Karsh Hamid, August 7, 2016
    14. Enterprise Software Architectures, Araf Karsh Hamid, July 30, 2016
    15. Docker and Linux Containers, Araf Karsh Hamid, April 28, 2015

    View Slide

  82. @arafkarsh arafkarsh
    References
    82
    16. MSDN – Microsoft https://msdn.microsoft.com/en-us/library/dn568103.aspx
    17. Martin Fowler : CQRS – http://martinfowler.com/bliki/CQRS.html
    18. Udi Dahan : CQRS – http://www.udidahan.com/2009/12/09/clarified-cqrs/
    19. Greg Young : CQRS - https://www.youtube.com/watch?v=JHGkaShoyNs
    20. Bertrand Meyer – CQS - http://en.wikipedia.org/wiki/Bertrand_Meyer
    21. CQS : http://en.wikipedia.org/wiki/Command–query_separation
    22. CAP Theorem : http://en.wikipedia.org/wiki/CAP_theorem
    23. CAP Theorem : http://www.julianbrowne.com/article/viewer/brewers-cap-theorem
    24. CAP 12 years how the rules have changed
    25. EBay Scalability Best Practices : http://www.infoq.com/articles/ebay-scalability-best-practices
    26. Pat Helland (Amazon) : Life beyond distributed transactions
    27. Stanford University: Rx https://www.youtube.com/watch?v=y9xudo3C1Cw
    28. Princeton University: SAGAS (1987) Hector Garcia Molina / Kenneth Salem
    29. Rx Observable : https://dzone.com/articles/using-rx-java-observable

    View Slide
