Using Monoids for Large Scale Business Stats

Using Monoids for Large Scale Business Stats

Talk gave at HackersAvenue: October 2017 - Data Engineering.

References for the presentation can be found at https://github.com/ashwanthkumar/large-scale-business-stats-talk

D90acaa01cb59a2b8b7e986958953eee?s=128

Ashwanth Kumar

October 07, 2017
Tweet

Transcript

  1. ashwanth kumar @_ashwanthkumar principal engineer using monoids for large scale

    business stats
  2. overview - Stats for Batch Jobs - Stats for Streaming

    Workloads - Generalizing aggregations with Monoids - Abel - Some cool logos!
  3. None
  4. but stats for MR jobs?

  5. None
  6. Used Scalding (from Twitter) + Simple to express aggregations stats

    as map-reduce jobs
  7. Used Scalding (from Twitter) + Simple to express aggregations -

    Have to include intermediary data in the output just for stats stats as map-reduce jobs
  8. Used Scalding (from Twitter) + Simple to express aggregations -

    Have to include intermediary data in the output just for stats - Have to think about writing stats after writing production code Stats as Map-Reduce Jobs
  9. Used Scalding (from Twitter) + Simple to express aggregations -

    Have to include intermediary data in the output just for stats - Have to think about writing stats after writing production code - Not updated at-least till next run (Not “realtime”) stats as map-reduce jobs
  10. but what about services running forever?

  11. (riemann.io)

  12. Service A Service B Service C

  13. stats for streaming workloads Push computed rollups to InfluxDB +

    Realtime
  14. stats for streaming workloads Push computed rollups to InfluxDB +

    Realtime + Allows arbitrary functions as rollups - code as config
  15. stats for streaming workloads Push computed rollups to InfluxDB +

    Realtime + Allows arbitrary functions as rollups - code as config - Not distributable - since it allows arbitrary functions
  16. stats for streaming workloads Push computed rollups to InfluxDB +

    Realtime + Allows arbitrary functions as rollups - code as config - Not distributable - since it allows arbitrary functions - Stats emission and rollups are at separate places - making it difficult to test and keep them in sync
  17. lessons so far

  18. - Have to include intermediary data in the output just

    for stats - Have to think about writing stats after writing production code - Not updated at-least till next run (Not “realtime”) - Not distributable - since it allows arbitrary functions - Stats emission and rollups are at separate places - making it difficult to test and keep them in sync stats for map-reduce jobs stats for streaming workloads
  19. what do we really want in stats?

  20. aggregations distribution / parallelism real time

  21. aggregates as monoids

  22. aggregates as monoids

  23. An operation is considered a monoid if: (x . y)

    . z = x . (y . z) (associativity aka semigroup) identity . x = x . identity = x (identity) monoids trait Semigroup[T] { def plus(left: T, right: T): T } trait Monoid[T] extends Semigroup[T] { def zero: T }
  24. A monoid can also be commutative x . y =

    y . x monoids Commutative property of monoids are used for parallel processing on large datasets
  25. monoids - count / sum sum is associative sum(sum(2, 6),

    6) == sum(2, sum(6, 6)) sum(8, 6) == sum(2, 12) 14 == 14
  26. monoids - average Average of an average is not an

    average, aka, not associative avg(avg(2, 6), 6) != avg(2, avg(6, 6)) avg(4, 6) != avg(2, 6) 5 != 4
  27. monoids - average But Average can be associative, if we

    have total & count individually case class Average(total: Double, count: Long) { def toAvg: Double = total / count }
  28. monoids : themes

  29. monoids : parallelism

  30. parallel aggregations 3 4 ... 7 2 1 3 ...

    8 7 5 ... 1 3 4 ... 7 Σ A 2 1 3 ... 8 7 5 ... 1 Σ C Σ B Σ = Σ A +Σ B +Σ C
  31. monoids : approximates

  32. - While sum is accurate, distinct counts in constant memory

    are not monoids - approximates
  33. - While sum is accurate, distinct counts in constant memory

    are not - Approximate structures like HyperLogLog can find unique counts in constant memory (and a known error bound) monoids - approximates
  34. - While sum is accurate, distinct counts in constant memory

    are not - Approximate structures like HyperLogLog can find unique counts in constant memory (and a known error bound) - 2 more HLL can be merged and their merge is both associative and commutative - can be expressed as a monoid monoids - approximates
  35. approximate stats now is better than accurate stats tomorrow

  36. - Stats naturally can be expressed as Monoids learnings so

    far
  37. - Stats naturally can be expressed as Monoids - Monoids

    given they are associative (and some are also commutative), we can exploit them for massive parallel processing learnings so far
  38. - Stats naturally can be expressed as Monoids - Monoids

    given they are associative (and some are also commutative), we can exploit them for massive parallel processing - We need our stats to be real time even if they’re approximate for some metrics as long as the error bounds are known learnings so far
  39. abel

  40. Written in Scala Backed by RocksDB Uses twitter/algebird for HLL

    Uses Kafka for stats delivery abel Consumes stats in (near) Realtime Expose aggregations over HTTP Crunches 1M events in less than 15 seconds on 1 machine
  41. stats.service.ix abel data flow Count(“a”, 1L) Unique(“a”, 1L) Count(“c”, 1L)

    Unique(“a”, 1L) Count(“b”, 1L)
  42. abel: internals

  43. case class Metric[T <: Aggregate[T]] (key: Key, value: T with

    Aggregate[T]) abel internals Metric = Key * Aggregate (Semigroup)
  44. trait Aggregate[T <: Aggregate[_]] { self: T => def plus(another:

    T): T def show: JsValue } abel internals
  45. case class Time(time: Long, granularity: Long) case class Key(name:String, tags:SortedSet[String],

    time:Time = Time.Forever) abel internals Key = Name * Tags * Granularity * Timestamp
  46. client.send(Metric(Key( name = “unique-ups-per-hour”, tags = SortedSet(“site:www.amazon.com”), time = Time.ThisHour

    ), UniqueCount(“825633348769”)) abel internals
  47. Let’s find Unique count of a UPC occurring per site

    and across all sites at the granularities of every hour, every day and overall. That would need 6 metrics per record. abel internals
  48. abel internals client.send(Metrics( “unique-upcs”, (tag(“site:www.amazon.com”) | `#`) * (perhour |

    perday | forever) * now, UniqueCount(“825633348769”) ))
  49. abel: distributed (experimental) made possible with suuchi (github.com/ashwanthkumar/suuchi)

  50. - Peer-to-Peer system built using Suuchi - Kafka consumer auto

    rebalances the partitions across instances - Uses scatter-gather primitive in Suuchi to perform query time reductions of the metrics before serving it to the users distributed abel
  51. 1.1.1.1 1.1.1.2 1.1.1.3 A stats.service.ix 1.1.1.1 1.1.1.2 1.1.1.3 DNS based

    Load Balancing distributed abel architecture Count(“a”, 1L) Unique(“a”, 1L) Count(“c”, 1L) Unique(“a”, 1L) Count(“b”, 1L) monoid.plus monoid.plus monoid.plus
  52. twitter/algebird ashwanthkumar/suuchi

  53. questions? https://github.com/ashwanthkumar/large-scale-business-stats-talk

  54. -- . - .-

  55. suuchi toolkit for building distributed function shipping applications github.com/ashwanthkumar/suuchi

  56. rocksdb

  57. Open source by facebook Fast persistent KV store Server Workloads

    Embeddable Optimized for SSDs rocksdb Fork of LevelDB Modelled after BigTable LSM Tree based SST files Written in C++
  58. Simple C++ API Has bindings in C Java Go Python

    rocksdb
  59. rocksdb @indix

  60. - Serving our API in production for 3+ years -

    Search on hierarchical documents - Dynamic fields didn’t scale well on Solr - Brand / Store / Category Counts for a filter - Price History Service - More than a billion prices and serve online to REST queries rocksdb @indix
  61. - Stats (as Monoids) Storage System - All we want

    was approximate aggregates real-time - HTML Archive System - Stores ~120TB of url and timestamp indexed HTML pages - Real-time scheduler for our crawlers - Finds out which of the 20 urls to crawl now out of 3+ billion urls - Helps crawler crawl 20+ million urls everyday rocksdb @indix
  62. recursive reduction

  63. - sum / multiplication - (sorted) top-K elements - operations

    on a graph - eg. link reach on twitter graph - function should be associative and optionally commutative recursive reduction
  64. EOF
