Writing Music with Ruby

As given at MtnWest Ruby Conference, on 3/10/2015

Transcript

1. WRITING MUSIC WITH RUBY A SUBTLE INTRODUCTION TO MUSIC THEORY
2. BEN EGGETT @BENEGGETT
3. THANK YOU
4. THANK YOU
9. HOBBIES SKIING LONGBOARDING GUITAR MUSIC TRAVEL
10. UTAH VIRGINIA TOKYO WASHINGTON DC SAO PAULO
11. ACCESS DEVELOPMENT For 30 years, Access Development has helped companies connect with their customers through America’s largest merchant discount and rewards network. Our programs help organizations acquire new customers, increase retention and generate more revenue. Access brings new customers to over 300,000 merchants, serving 99.6% of the U.S. population. Interested in what we do? Talk to me after
13. UTRUBY.ORG
14. MUSICIANS IN THE HOUSE?
15. DO YOU KNOW ANY MUSIC THEORY?
16. MY STORY
17. RETROSPECTIVE
18. THE DOCUMENTATION IS BAD!
21. WAT?
24. THE API IS WORSE!
28. THE DOCUMENTATION DOESN'T FOSTER LEARNING
30. ! WARNING, TANGENT
32. If you can't build it, you don't understand it. — Richard Feynman
33. TO THOSE OF YOU WHO DON'T KNOW ANY MUSIC THEORY...
34. ARE YOU CERTAIN?
35. WHAT IS MUSIC? ▸ Vibrations (sound) ▸ Vibrations as a specific frequency (notes) ▸ Specific notes (scales) ▸ Specific notes played together (chords) ▸ Specific chords in order (songs)
36. ̇ NOTES
37. 440HZ
38. 440HZ ▸ 440 cycles per second ▸ ISO Standard ISO 16:1975
40. { code } MusicTheory::Note.new(frequency: 440).play
41. Lets build an API!
42. GITHUB.COM/BENEGGETT/MUSIC_THEORY gem install music_theory # https://rubygems.org/gems/music_theory
44. LET'S BUILD A NOTE
45. SINE WAVE
46. LET'S BUILD A NOTE TERMS frequency - number of cycles per second sample rate - number of frames per second duration - how long we want the note to be
47. LET'S BUILD A NOTE MATH total frames = duration x sample rate cycles per frame = frequency ÷ sample rate increment = 2π radians
48. module MusicTheory class Note include MusicTheory::Output attr_accessor :frequency, :duration, :output_file_name def initialize(options = {}) @frequency = options[:frequency] || 440.0 # Note frequency in Hz @duration = options[:duration] || 1.0 # Number of seconds per note @output_file_name = options[:output_file_name] || 'note' # File name to write (without extension) end def total_frames # We want 1 second of the note, so we need 1 second's worth of frames (duration * sample_rate).to_i end def cycles_per_frame # each frame, we want this fraction of a cycle: frequency / sample_rate end def sine_wave_cycle # A cycle is a full sine wave, which is 2π radians: 2 * Math::PI * cycles_per_frame end def samples # So to create a note that's one second long, we need to write out all the samples in the sine waves phase = 0 total_frames.times.map do sample = (Math.sin phase).to_f phase += sine_wave_cycle sample end end end end
49. { DEMO }
50. WRITING A FILE Wav format is quite simple Easily writable in Ruby standard library. This is the only point where I'll be using a gem: wavefile Because writing wav files is not really the focus of this talk
51. module MusicTheory module Output def sample_rate 22050 end def format WaveFile::Format.new :mono, :pcm_16, sample_rate end def buffer_format WaveFile::Format.new :mono, :float, sample_rate end def output_track WaveFile::Writer.new "#{output_file_name || 'music'}.wav", format do |writer| buffer = WaveFile::Buffer.new samples, buffer_format writer.write buffer end end def play output_track # unless File.file?("#{output_file_name}.wav") `afplay #{output_file_name}.wav` nil end end end
52. require 'music_theory/output' module MusicTheory class Note include MusicTheory::Output attr_accessor :frequency, :duration, :output_file_name # ... end end
53. { DEMO }
54. OUR FIRST ABSTRACTION
55. Abstraction is one of the greatest visionary tools ever invented by human beings to imagine, decipher, and depict the world. — Jerry Saltz
56. OCTAVES DOUBLE THE FREQUENCY NEXT A WOULD BE 880HZ OR PREVIOUS WOULD BE 220HZ
57. { DEMO }
58. require 'music_theory/output' module MusicTheory class Octave include MusicTheory::Output attr_accessor :starting_note, :amount, :direction, :output_file_name, :all_notes def initialize(options = {}) @starting_note = options[:starting_note] || MusicTheory::Note.new # Note to start on @amount = options[:amount] || 2 # Number of octaves to repeat @direction = options[:direction] || 'asc' # Number of seconds per note @output_file_name = options[:output_file_name] || 'octave' # File name to write (without extension) build_octave end def build_octave @all_notes = [ starting_note ] amount.to_i.times do new_note = all_notes.last.clone if direction == 'asc' new_note.frequency = all_notes.last.frequency * 2 elsif direction == 'desc' new_note.frequency = all_notes.last.frequency / 2 end all_notes << new_note unless new_note.frequency > 20500 end end def samples all_notes.map(&:samples).flatten end end end
59. { DEMO }
60. TONES & SEMITONES Semitones are the smallest interval common in western music One fret on a guitar, adjacent note on piano Tone is two semitones
61. MOVING SEMITONES There are 12 semitones in an octave (Western Music Theory) To move up one semitone, you multiply the pitch by a ratio r This ratio is constant as we move up Moving up 12 semitones doubles the pitch, so r^12 = 2 therefore r = 12th root of two = 1.059....
62. PLAY ALL THE NOTES
63. { DEMO }
64. SCALES Simplest is chromatic Most common scales have 7 notes
65. MAJOR Most common Take 7 specific notes in a pattern: T, T, S, T, T, T, S Happy
66. MINOR Take 7 specific notes in a pattern: T, S, T, T, S, T, T Sad
67. MODES
68. MODES Difficult concept, though quite easy to understand in ruby. There are 7 modes altogether 7 modes because there are 7 notes in the major scale Simply put, modes are just rotations of the major scale - Ionian Mode
69. Mode Tonic Interval sequence Example ------------------------------------------------------------- Ionian I T-T-s-T-T-T-s C-D-E-F-G-A-B-C Dorian II T-s-T-T-T-s-T D-E-F-G-A-B-C-D Phrygian III s-T-T-T-s-T-T E-F-G-A-B-C-D-E Lydian IV T-T-T-s-T-T-s F-G-A-B-C-D-E-F Mixolydian V T-T-s-T-T-s-T G-A-B-C-D-E-F-G Aeolian VI T-s-T-T-s-T-T A-B-C-D-E-F-G-A Locrian VII s-T-T-s-T-T-T B-C-D-E-F-G-A-B
70. Mode Tonic Interval sequence Example ------------------------------------------------------------- Ionian I T-T-s-T-T-T-s C-D-E-F-G-A-B-C Dorian II T-s-T-T-T-s-T D-E-F-G-A-B-C-D Phrygian III s-T-T-T-s-T-T E-F-G-A-B-C-D-E Lydian IV T-T-T-s-T-T-s F-G-A-B-C-D-E-F Mixolydian V T-T-s-T-T-s-T G-A-B-C-D-E-F-G Aeolian VI T-s-T-T-s-T-T A-B-C-D-E-F-G-A Locrian VII s-T-T-s-T-T-T B-C-D-E-F-G-A-B Now, you ruby developers don't need to know all this, you just need to call rotate on the interval sequence and they will all be generated
71. module MusicTheory class Modes S = 1 T = 2 I = [T, T, S, T, T, T, S] II = I.rotate III = I.rotate(2) IV = I.rotate(3) V = I.rotate(4) VI = I.rotate(5) VII = I.rotate(6) CHROMATIC = [S,S,S,S,S,S,S,S,S,S,S,S] # Map the music theory names as class methods def self.ionian; I; end self.singleton_class.send(:alias_method, :major, :ionian) self.singleton_class.send(:alias_method, :i, :ionian) def self.dorian; II; end self.singleton_class.send(:alias_method, :ii, :dorian) def self.phrygian; III; end self.singleton_class.send(:alias_method, :iii, :phrygian) def self.lydian; IV; end self.singleton_class.send(:alias_method, :iv, :lydian) def self.mixolydian; V; end self.singleton_class.send(:alias_method, :v, :mixolydian) def self.aeolian; VI; end self.singleton_class.send(:alias_method, :minor, :aeolian) self.singleton_class.send(:alias_method, :vi, :aeolian) def self.locrian; VII; end self.singleton_class.send(:alias_method, :vii, :locrian) def self.chromatic; CHROMATIC; end end end
72. { DEMO }
73. SCALES
74. require 'music_theory/output' module MusicTheory class Scale include MusicTheory::Output attr_accessor :starting_note, :output_file_name, :all_notes, :scale_type, :scale_notes, :duration, :frequency def initialize(scale_type = :major, options = {}) @scale_type = scale_type @duration = options[:duration] || 0.5 @frequency = options[:frequency] || 220.0 @starting_note = create_new_note(frequency) # Note to start on @output_file_name = options[:output_file_name] || 'scale' # File name to write (without extension) set_all_notes set_scale_notes end def twelfth_root_of_two 2 ** (1.0/12) end def mode MusicTheory::Modes.send(scale_type) end def set_scale_notes @scale_notes = [all_notes.first] note_index = 0 mode.each do |interval| note_index += interval scale_notes << all_notes[note_index] end end def create_new_note(note_frequency) MusicTheory::Note.new( frequency: note_frequency, duration: duration) end def set_all_notes @all_notes = [@starting_note] 12.times do new_note = create_new_note(all_notes.last.frequency * twelfth_root_of_two) all_notes << new_note end end def samples scale_notes.map(&:samples).flatten end end end
75. { DEMO }
76. THIRDS Thirds are intervals on a scale Can be major or minor: Major is 3 semitones, Minor is 4 Taken in groups of two: If you add T + T == 4 ; T + S == 3 Played sequentially, this is called arpeggio
77. require 'music_theory/output' module MusicTheory class Third include MusicTheory::Output attr_accessor :scale, :all_notes def initialize(scale) @scale = scale @all_notes = [scale.scale_notes.first] current = 0 double_scale_notes = scale.scale_notes * 2 scale.mode.in_groups_of(2, false) do |group| current += group.sum all_notes << double_scale_notes[current] end all_notes.uniq! {|note| note.frequency} all_notes.sort_by! {|note| note.frequency} end def samples all_notes.map(&:samples).flatten end end end
78. { DEMO }
79. CHORDS Single Notes are easy To make a chord, we need to melt it all down. Clamp the values so they fit in a wav format
80. require 'music_theory/output' module MusicTheory class Chord include MusicTheory::Output attr_accessor :third, :duration, :all_notes, :output_file_name def initialize(third, options = {}) @duration = options[:duration] || 2.0 @third = third @output_file_name = options[:output_file_name] || 'chord' # File name to write (without extension) end def flatten_third third.all_notes.each {|note| note.duration = duration} new_samples = [] sample_count = third.all_notes.first.samples.count third.samples.in_groups_of(sample_count).each do |group| group.each_with_index do |value, i| new_samples[i] ||= 0 new_samples[i] += value end end normalize_samples(new_samples) end def normalize_samples(new_samples) max = new_samples.map {|s| s.abs }.max multiplier = 1.0 / max new_samples.map!{ |s| multiplier * s } end def samples flatten_third end end end
81. { DEMO }
82. CHORD SCALES You can make different chords from a scale They will automatically be minor/major based on what will 'fit' into the scale pattern (mode) Each mode has a chord that you can make from it by moving up in thirds
83. module MusicTheory module ScaleSteps # Concern for Scale def i self end def ii set_scale_step(1) end def iii set_scale_step(2) end def iv set_scale_step(3) end def v set_scale_step(4) end def vi set_scale_step(5) end def vii set_scale_step(6) end def viii set_scale_step(7) end private def set_scale_step(jump) MusicTheory::Scale.new scale_type, frequency: scale_notes[jump].frequency, duration: duration end end end
84. CHORD PROGRESSIONS Now that you've built up all the chords you can use, you just play them in a specific order A common progression is I V VI IV One or more chord progressions is a song ^ NOW WE HAVE THE FUNDAMENTALS OF WRITING MUSIC
85. Journey - Don't Stop Believing James Blunt - You're Beautiful Black Eyed Peas - Where Is The Love Alphaville - Forever Young Jason Mraz - I'm Yours Train - Hey Soul Sister The Caling - Wherever You Will Go Elton John - Can You Feel The Love Tonight Akon - Don't Matter John Denver - Take Me Home, Country Home
86. Lady Gaga - Paparazzi U2- With Or Without You Maroon Five - She Will Be Loved The Beatles - Let It Be Bob Marley - No Woman No Cry Men At Work - Land Down Under Spice Girls - Two Become One AHa - Take On Me Green Day - When I Come Around Eagle Eye Cherry - Save Tonight
87. Tomo - Africa Beyonce - If I Were A Boy The Smashing Pumpkins - Bullet Iwth Butterfly Wings The Offspring - Self Esteem Aqua - Barbie Girl Eminem & Rihanna - Love The Way You Lie Lady Gaga - Pokerface MGMT - Kids Bon Jovi - It's My Life The Gregory Brothers - Double Rainbow
88. FINAL ABSTRACTION
89. REFLECTION
90. THANK YOU #creativecode
